Limits on the axion-photon coupling from Chandrayaan-2 observations

Tanmoy Kumar1,*, N. P. S. Mithun2,†, Subhendra Mohanty3,4,‡, Sourov Roy1,§, B. S. Bharath Saiguhan2,∥, and Santosh Vadawale2,¶

  • *Contact author: kumartanmoy1998@gmail.com
  • †Contact author: mithun@prl.res.in
  • ‡Contact author: subhendram@iiserb.ac.in
  • §Contact author: tpsr@iacs.res.in
  • ∥Contact author: bsg@prl.res.in
  • Contact author: santoshv@prl.res.in
PDF

Phys. Rev. D 113, L061303 – Published 16 March, 2026

DOI: https://doi.org/10.1103/3t6n-8xpj

Abstract

Axions and axionlike particles have gained immense attention in searches for beyond Standard Model physics. Experiments searching for axions leverage their predicted couplings to Standard Model particles to look for observable signals. Though weak, these couplings allow axions to be produced abundantly in the interiors of stars such as the Sun. Once created, axions can escape the Sun and, while passing through the solar atmosphere, oscillate into photons in the magnetic field, producing x-rays. For the first time, to the best of our knowledge, we use data from the observation of soft x-rays from the quiet Sun during the 2019–2020 solar minimum by the Solar X-ray Monitor, on board India’s Chandrayaan-2 lunar exploration mission, to constrain the coupling of axions to photons (gaγγ). Using the latest models of the solar atmosphere to calculate the magnetic field and plasma frequency, we constrain gaγγ≲(0.50–2.26)×10−10  GeV−1 at 95% confidence level for axion masses ma≲5×10−4  eV.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (54)

  1. J. E. Kim and G. Carosi, Axions and the strong CP problem, Rev. Mod. Phys. 82, 557 (2010); 91, 049902(E) (2019).
  2. L. Di Luzio et al., The landscape of QCD axion models, Phys. Rep. 870, 1 (2020).
  3. A. Arvanitaki et al., String axiverse, Phys. Rev. D 81, 123530 (2010).
  4. R. D. Peccei and H. R. Quinn, CP conservation in the presence of instantons, Phys. Rev. Lett. 38, 1440 (1977).
  5. R. D. Peccei and H. R. Quinn, Constraints imposed by CP conservation in the presence of instantons, Phys. Rev. D 16, 1791 (1977).
  6. S. Weinberg, A new light boson?, Phys. Rev. Lett. 40, 223 (1978).
  7. F. Wilczek, Problem of strong P and T invariance in the presence of instantons, Phys. Rev. Lett. 40, 279 (1978).
  8. R. D. Peccei, The strong CP problem and axions, Lect. Notes Phys. 741, 3 (2008).
  9. J. Preskill et al., Cosmology of the invisible axion, Phys. Lett. 120B, 127 (1983).
  10. L. F. Abbott and P. Sikivie, A cosmological bound on the invisible axion, Phys. Lett. 120B, 133 (1983).
  11. M. Dine and W. Fischler, The not so harmless axion, Phys. Lett. 120B, 137 (1983).
  12. M. Y. Khlopov et al., The nonlinear modulation of the density distribution in standard axionic CDM and its cosmological impact, Nucl. Phys. B, Proc. Suppl. 72, 105 (1999).
  13. J. L. Ouellet et al., First results from ABRACADABRA-10 cm: A search for sub-μeV axion dark matter, Phys. Rev. Lett. 122, 121802 (2019).
  14. J. L. Ouellet et al., Design and implementation of the ABRACADABRA-10 cm axion dark matter search, Phys. Rev. D 99, 052012 (2019).
  15. M. Silva-Feaver et al., Design overview of DM Radio pathfinder experiment, IEEE Trans. Appl. Supercond. 27, 1400204 (2017).
  16. L. Brouwer et al. (DMRadio Collaboration), Proposal for a definitive search for GUT-scale QCD axions, Phys. Rev. D 106, 112003 (2022).
  17. L. Brouwer et al. (DMRadio Collaboration), Projected sensitivity of DMRadio-m3: A search for the QCD axion below 1  μeV, Phys. Rev. D 106, 103008 (2022).
  18. S. J. Asztalos et al. (ADMX Collaboration), An improved RF cavity search for halo axions, Phys. Rev. D 69, 011101 (2004).
  19. N. Du et al. (ADMX Collaboration), A search for invisible axion dark matter with the Axion Dark Matter Experiment, Phys. Rev. Lett. 120, 151301 (2018).
  20. T. Braine et al. (ADMX Collaboration), Extended search for the invisible axion with the Axion Dark Matter Experiment, Phys. Rev. Lett. 124, 101303 (2020).
  21. L. Zhong et al. (HAYSTAC Collaboration), Results from phase 1 of the HAYSTAC microwave cavity axion experiment, Phys. Rev. D 97, 092001 (2018).
  22. A. Caldwell et al., Dielectric haloscopes: A new way to detect axion dark matter, Phys. Rev. Lett. 118, 091801 (2017).
  23. A. J. Millar et al., Dielectric haloscopes to search for axion dark matter: Theoretical foundations, J. Cosmol. Astropart. Phys. 01 (2017) 061.
  24. M. I. Vysotsky et al., Some astrophysical limitations on axion mass, Pis’ma Zh. Eksp. Teor. Fiz. 27, 533 (1978).
  25. G. G. Raffelt, Astrophysical axion bounds, Lect. Notes Phys. 741, 51 (2008).
  26. A. Lella et al., Protoneutron stars as cosmic factories for massive axionlike particles, Phys. Rev. D 107, 103017 (2023).
  27. A. Lella et al., Getting the most on supernova axions, Phys. Rev. D 109, 023001 (2024).
  28. P. Carenza et al., Axion astrophysics, Phys. Rep. 1117, 1 (2025).
  29. F. Lecce et al., Probing axionlike particles with multimessenger observations of neutron star mergers, Phys. Rev. D 112, 023001 (2025).
  30. D. F. G. Fiorillo et al., Axion-photon conversion in transient compact stars: Systematics, constraints, and opportunities, arXiv:2509.13322.
  31. K. Zioutas et al. (CAST Collaboration), First results from the CERN Axion Solar Telescope (CAST), Phys. Rev. Lett. 94, 121301 (2005).
  32. K. Barth et al., CAST constraints on the axion-electron coupling, J. Cosmol. Astropart. Phys. 05 (2013) 010.
  33. V. Anastassopoulos et al. (CAST Collaboration), New CAST limit on the axion-photon interaction, Nat. Phys. 13, 584 (2017).
  34. S. V. Vadawale et al., Observations of the quiet sun during the deepest solar minimum of the past century with Chandrayaan-2 XSM: Elemental abundances in the quiescent corona, Astrophys. J. Lett. 912, L12 (2021).
  35. S. V. Vadawale et al., Observations of the quiet sun during the deepest solar minimum of the past century with Chandrayaan-2 XSM: Sub-A-class microflares outside active regions, Astrophys. J. Lett. 912, L13 (2021).
  36. J. Ruz et al., NuSTAR as an axion helioscope, Phys. Rev. Lett. 135, 141001 (2025).
  37. G. G. Raffelt, Astrophysical axion bounds diminished by screening effects, Phys. Rev. D 33, 897 (1986).
  38. J. N. Bahcall et al., New solar opacities, abundances, helioseismology, and neutrino fluxes, Astrophys. J. Lett. 621, L85 (2005).
  39. G. Raffelt and L. Stodolsky, Mixing of the photon with low mass particles, Phys. Rev. D 37, 1237 (1988).
  40. K. van Bibber et al., A practical laboratory detector for solar axions, Phys. Rev. D 39, 2089 (1989).
  41. C. A. Manzari et al., Supernova axions convert to gamma rays in magnetic fields of progenitor stars, Phys. Rev. Lett. 133, 211002 (2024).
  42. R. P. Dufresne et al., chianti—An atomic database for emission lines—Paper. XVIII. Version 11, advanced ionization equilibrium models: Density and charge transfer effects, Astrophys. J. 974, 71 (2024).
  43. G. Del Zanna et al., chianti—An atomic database for emission lines. XVI. Version 10, further extensions, Astrophys. J. 909, 38 (2021).
  44. chiantipy, https://github.com/chianti-atomic/ChiantiPy/ (2022).
  45. M. J. Berger et al., XCOM: Photon Cross Section Database https://www.nist.gov/pml/xcom-photon-cross-sections-database (2010).
  46. M. Shanmugam et al., Solar X-ray monitor onboard Chandrayaan-2 Orbiter, Curr. Sci. 118, 45 (2020).
  47. N. P. S. Mithun et al., Solar X-ray monitor on board the Chandrayaan-2 Orbiter: In-flight performance and science prospects, Sol. Phys. 295, 139 (2020).
  48. N. P. S. Mithun et al., Data processing software for Chandrayaan-2 Solar X-ray monitor, Astron. Comput. 34, 100449 (2021).
  49. M. Türler et al., INTEGRAL hard X-ray spectra of the cosmic X-ray background and Galactic ridge emission, Astron. Astrophys. 512, A49 (2010).
  50. F. Feroz et al., multinest: An efficient and robust Bayesian inference tool for cosmology and particle physics, Mon. Not. R. Astron. Soc. 398, 1601 (2009).
  51. R. Bähre et al., Any light particle search II—Technical design report, J. Instrum. 8, T09001 (2013).
  52. E. Armengaud et al., Conceptual design of the International Axion Observatory (IAXO), J. Instrum. 9, T05002 (2014).
  53. E. Armengaud et al. (IAXO Collaboration), Physics potential of the International Axion Observatory (IAXO), J. Cosmol. Astropart. Phys. 06 (2019) 047.
  54. J. B. Dent et al., Inverse Primakoff scattering as a probe of solar axions at liquid xenon direct detection experiments, Phys. Rev. Lett. 125, 131805 (2020).

Outline

Information

Phys. Rev. D 113, L061303– Published 16 March, 2026
  • Received 19 November 2025
  • Accepted 11 February 2026
Crossmark - Check for updates button
Creative Commons Logo

Published by the American Physical Society under the terms of the Creative Commons Attribution 4.0 International license. Further distribution of this work must maintain attribution to the author(s) and the published article’s title, journal citation, and DOI. Funded by SCOAP3.
