JLab and J-PARC measurements for $J / ψ$ production at threshold

Igor I. Strakovsky ^* and William J. Briscoe ^†

Jung Keun Ahn ^‡

Misha G. Ryskin ^§

Axel Schmidt ^∥

Institute for Nuclear Studies, Department of Physics, The George Washington University, Washington, District of Columbia 20052, USA

Department of Physics, Korea University, 145 Anam-ro, Seongbuk-gu, Seoul 02841, Republic of Korea

NRC “Kurchatov Institute,” Petersburg Nuclear Physics Institute, Gatchina, 188300, Russia

Institute for Nuclear Studies, Department of Physics, The George Washington University, Washington, District of Columbia 20052, USA

^*Contact author: igor@gwu.edu
^†Contact author: briscoe@gwu.edu
^‡Contact author: ahnjk@korea.ac.kr
^§Contact author: ryskinmg@airnet.ru
^∥Contact author: axelschmidt@gwu.edu

PDF

Phys. Rev. D 113, 114023 – Published 12 June, 2026

DOI: https://doi.org/10.1103/3g18-qv5t

Abstract

New threshold measurements for $γ p \to p J / ψ \to p (μ^{+} μ^{-})$ by 007 and $γ^{*} p \to p J / ψ \to p (e^{+} e^{-})$ by CLAS12 allow us to extend the previous phenomenological determination of the $J / ψ$ -proton scattering length, $α_{J / ψ p}$ , using GlueX threshold data for $γ p \to p J / ψ \to p (e^{+} e^{-})$ . The agreement between all three $J / ψ$ datasets shows no indication of systematic differences between methodologies. Furthermore, perturbative QCD predictions support the phenomenological determination of heavy vector meson-nucleon scattering lengths. The role of the nucleon form factor, $F_{N}$ , is discussed, and a possible correction to the phenomenological scattering length for heavy vector meson photoproduction is calculated using the pole form of $F_{N}$ . Upcoming J-PARC threshold measurements of the reaction $π^{-} p \to n J / ψ \to n (l^{+} l^{-})$ will help to evaluate the possible role of heavy pentaquark, $P_{c}$ , states in low-energy $J / ψ$ production and the effects caused by the nucleon form factors.

Physics Subject Headings (PhySH)

Article Text

References (52)

J. J. Sakurai, Theory of strong interactions, Ann. Phys. (N.Y.) 11, 1 (1960).
J. J. Aubert et al. (E598 Collaboration), Experimental observation of a heavy particle $J$ , Phys. Rev. Lett. 33, 1404 (1974).
J. E. Augustin et al. (SLAC-SP-017 Collaboration), Discovery of a narrow resonance in $e^{+} e^{-}$ annihilation, Phys. Rev. Lett. 33, 1406 (1974).
A. Ali et al. (GlueX Collaboration), First measurement of near-threshold $J / ψ$ exclusive photoproduction off the proton, Phys. Rev. Lett. 123, 072001 (2019).
S. Adhikari et al. (GlueX Collaboration), Measurement of the $J / ψ$ photoproduction cross section over the full near-threshold kinematic region, Phys. Rev. C 108, 025201 (2023).
B. Duran, Z. E. Meziani, S. Joosten, M. K. Jones, S. Prasad, C. Peng, W. Armstrong, H. Atac, E. Chudakov, H. Bhatt et al., Determining the gluonic gravitational form factors of the proton, Nature (London) 615, 813 (2023).
S. Joosten et al. (007 Collaboration), Near-threshold $J / ψ \to μ^{+} μ^{-}$ photoproduction and the gluonic gravitational form factors of the proton, arXiv:2602.14416.
P. Chatagnon, V. Kubarovsky, R. Paremuzyan, S. Stepanyan, M. Tenorio, R. Tyson, A. G. Acar, P. Achenbach, J. S. Alvarado, M. J. Amaryan et al., Measurement of the near-threshold $J / ψ$ photoproduction cross section with the CLAS12 experiment, arXiv:2602.22128.
I. I. Strakovsky, E. L. Isupov, V. Mokeev, and A. Schmidt, $ρ$ -meson nucleon scattering length from CLAS threshold photoproduction measurements, Phys. Rev. D 112, 114045 (2025).
X. Y. Wang, F. Zeng, Q. Wang, and L. Zhang, First extraction of the proton mass radius and scattering length $| α_{ρ^{0} p} |$ from $ρ^{0}$ photoproduction, Sci. China Phys. Mech. Astron. 66, 232012 (2023).
I. I. Strakovsky et al. (A2 Collaboration at MAMI), Photoproduction of the $ω$ meson on the proton near threshold, Phys. Rev. C 91, 045207 (2015).
T. Ishikawa, H. Fujimura, H. Fukasawa, R. Hashimoto, Q. He, Y. Honda, A. Hosaka, T. Iwata, S. Kaida, J. Kasagi et al., $ω N$ scattering length from $ω$ photoproduction on the proton near the threshold, Phys. Rev. C 101, 052201 (2020).
C. Han, W. Kou, R. Wang, and X. Chen, Extraction of $ω$ n, $ω$ p, and $ϕ N$ scattering lengths from $ω$ and $ϕ$ differential photoproduction cross sections on a deuterium target, Phys. Rev. C 107, 015204 (2023).
I. I. Strakovsky, L. Pentchev, and A. Titov, Comparative analysis of $ω$ p, $ϕ$ p, and $J / ψ$ p scattering lengths from A2, CLAS, and GlueX threshold measurements, Phys. Rev. C 101, 045201 (2020).
I. Strakovsky, D. Epifanov, and L. Pentchev, $J / ψ p$ scattering length from GlueX threshold measurements, Phys. Rev. C 101, 042201 (2020).
I. I. Strakovsky, W. J. Briscoe, P. Gubler, J. R. Pybus, A. Schmidt, and A. Somov, $J / ψ$ -meson nucleon scattering length from threshold photoproduction on light nuclei, arXiv:2512.08701.
I. I. Strakovsky, W. J. Briscoe, L. Pentchev, and A. Schmidt, Threshold $ϒ$ -meson photoproduction at the EIC and EicC, Phys. Rev. D 104, 074028 (2021).
S. Navas et al. (Particle Data Group), Review of particle physics, Phys. Rev. D 110, 030001 (2024).
E. Golovatch et al. (CLAS Collaboration), First results on nucleon resonance photocouplings from the $γ p \to π^{+} π^{-} p$ reaction, Phys. Lett. B 788, 371 (2019).
F. J. Klein et al. (SAPHIR Collaboration), Proceedings of the GW/TJNAF Workshop on N^* Physics (Washington, DC, 1997); F. J. Klein, Ph.D. thesis, University of Bonn, 1996.
F. Dietz et al. (CBELSA/TAPS Collaboration), Photoproduction of $ω$ mesons off protons and neutrons, Eur. Phys. J. A 51, 6 (2015).
B. Dey et al. (CLAS Collaboration), Data analysis techniques, differential cross sections, and spin density matrix elements for the reaction $γ p \to ϕ p$ , Phys. Rev. C 89, 055208 (2014).
W. C. Chang, K. Horie, S. Shimizu, M. Miyabe, D. S. Ahn, J. K. Ahn, H. Akimune, Y. Asano, S. Date, H. Ejiri et al., Forward coherent $ϕ$ -meson photoproduction from deuterons near threshold, Phys. Lett. B 658, 209 (2008); T. Mibe et al. (LEPS Collaboration), Diffractive $ϕ$ -meson photoproduction on proton near threshold, Phys. Rev. Lett. 95, 182001 (2005).
S. Adhikari et al. (GlueX Collaboration), Measurement of spin-density matrix elements in $ρ (770)$ production with a linearly polarized photon beam at $E γ = 8.2 - 8.8 GeV$ , Phys. Rev. C 108, 055204 (2023).
Y. Guo, X. Ji, and Y. Liu, QCD analysis of near-threshold photon-proton production of heavy quarkonium, Phys. Rev. D 103, 096010 (2021).
E. L. Feinberg, Hadron clusters and half-dressed particles in quantum field theory, Usp. Fiz. Nauk 132, 225 (1980) [Sov. Phys. Usp. 23, 629 (1980)].
L. Tang, H. Y. Xing, M. Ding, and C. D. Roberts, Exclusive photoproduction of light and heavy vector mesons: Thresholds to very high energies, Eur. Phys. J. C 86, 284 (2026).
M. L. Du, V. Baru, F. K. Guo, C. Hanhart, U. G. Meißner, A. Nefediev, and I. Strakovsky, Deciphering the mechanism of near-threshold $J / ψ$ photoproduction, Eur. Phys. J. C 80, 1053 (2020).
B. Wu, X. K. Dong, M. L. Du, F. K. Guo, and B. S. Zou, Deciphering the mechanism of $J / ψ$ -nucleon scattering, Fund. Res. 5, 2530 (2025).
Y. Lyu, T. Doi, T. Hatsuda, and T. Sugiura, Nucleon-charmonium interactions from lattice QCD, Phys. Lett. B 860, 139178 (2025).
T. Appelquist and W. Fischler, Some remarks on van der Waals forces in QCD, Phys. Lett. B 77, 405 (1978).
M. E. Peskin, Short distance analysis for heavy quark systems. 1. Diagrammatics, Nucl. Phys. B156, 365 (1979).
L. Liu, H. W. Lin, and K. Orginos, Charmed hadron interactions, Proc. Sci. LATTICE2008 (2008) 112.
S. Aoki, T. Hatsuda, and N. Ishii, Theoretical foundation of the nuclear force in QCD and its applications to central and tensor forces in quenched Lattice QCD simulations, Prog. Theor. Phys. 123, 89 (2010).
B. Assi, A. V. Grebe, and M. L. Wagman, Baryon-baryon, meson-meson, and meson-baryon interactions in nonrelativistic QCD, Phys. Rev. D 113, 016013 (2026).
Yu. L. Dokshitzer (private communication).
S. Y. Ryu et al. (J-PARC P111 Collaboration), $J / ψ$ production in $π^{-} p$ reaction near threshold, Proposal for Nuclear and Particle Physics Experiments at J-PARC (2024), https://j-parc.jp/researcher/Hadron/en/pac_2507/pdf/P111_2025-15.pdf.
S. Adhikari et al. (GlueX Collaboration), The GlueX beamline and detector, Nucl. Instrum. Methods Phys. Res., Sect. A 987, 164807 (2021).
S. Ali, A. Ahmidouch, G. R. Ambrose, A. Asaturyan, C. Ayerbe Gayoso, J. Benesch, V. Berdnikov, H. Bhatt, D. Bhetuwal, D. Biswas et al., The SHMS $11 GeV / c$ spectrometer in Hall C at Jefferson Lab, Nucl. Instrum. Methods Phys. Res., Sect. A 1083, 171070 (2026).
V. D. Burkert, L. Elouadrhiri, K. P. Adhikari, S. Adhikari, M. J. Amaryan, D. Anderson, G. Angelini, M. Antonioli, H. Atac, S. Aune et al., The CLAS12 spectrometer at Jefferson laboratory, Nucl. Instrum. Methods Phys. Res., Sect. A 959, 163419 (2020).
Y. Z. Xu, S. Chen, Z. Q. Yao, D. Binosi, Z. F. Cui, and C. D. Roberts, Vector-meson production and vector meson dominance, Eur. Phys. J. C 81, 895 (2021).
B. Z. Kopeliovich, I. Schmidt, and M. Siddikov, Suppression versus enhancement of heavy quarkonia in pA collisions, Phys. Rev. C 95, 065203 (2017).
K. G. Boreskov and B. L. Ioffe, $J / ψ$ meson photoproduction in the peripheral model, Yad. Fiz. 25, 806 (1977) [Sov. J. Nucl. Phys. 25, 331 (1977)].
R. Aaij et al. (LHCb Collaboration), Observation of a narrow pentaquark state, $P_{c} (4312)^{+}$ , and of two-peak structure of the $P_{c} (4450)^{+}$ , Phys. Rev. Lett. 122, 222001 (2019).
I. Strakovsky, W. J. Briscoe, E. Chudakov, I. Larin, L. Pentchev, A. Schmidt, and R. L. Workman, Plausibility of the LHCb $P_{c} (4312)^{+}$ in the GlueX $γ p \to J / ψ p$ total cross sections, Phys. Rev. C 108, 015202 (2023).
A. I. Titov, T. Nakano, S. Date, and Y. Ohashi, Comments on differential cross-section of $ϕ$ -meson photoproduction at threshold, Phys. Rev. C 76, 048202 (2007).
A. Sibirtsev and K. Tsushima, $J / ϕ$ production in $π N$ collisions, arXiv:nucl-th/9810029.
J. J. Wu and T. S. H. Lee, Production of $J / ϕ$ on the nucleon and on deuteron targets, Phys. Rev. C 88, 015205 (2013).
Q. F. Lü, X. Y. Wang, J. J. Xie, X. R. Chen, and Y. B. Dong, Neutral hidden charm pentaquark states $P_{c}^{0} (4380)$ and $P_{c}^{0} (4450)$ in $π^{-} p \to J / ψ n$ reaction, Phys. Rev. D 93, 034009 (2016).
S. H. Kim, H. C. Kim, and A. Hosaka, Heavy pentaquark states $P_{c} (4380)$ and $P_{c} (4450)$ in the $J / ψ$ production induced by pion beams off the nucleon, Phys. Lett. B 763, 358 (2016).
C. N. Brown et al. (NuSea Collaboration), Observation of polarization in bottomonium production at $\sqrt{s} = 38.8 GeV$ , Phys. Rev. Lett. 86, 2529 (2001).
T. H. Chang et al. (NuSea Collaboration), $J / ψ$ polarization in 800 GeV pCu interactions, Phys. Rev. Lett. 91, 211801 (2003).
