Demagnetization in micromagnetics: Magnetostatic self-interactions of bulk chiral magnetic skyrmions

Paul Leask1,* and Martin Speight2,†

  • *Contact author: palea@kth.se
  • †Contact author: j.m.speight@leeds.ac.uk
PDF

Phys. Rev. B 113, 064406 – Published 4 February, 2026

DOI: https://doi.org/10.1103/zy2n-m4tn

Abstract

We develop a theoretical and numerical framework for three-dimensional bulk chiral magnets that includes the full magnetostatic dipole-dipole interaction and its back-reaction on the magnetization. Assuming translational invariance along one spatial direction, we analyze the effect of dipolar interactions on three Dzyaloshinskii-Moriya interaction (DMI) terms—Dresselhaus, Rashba, and Heusler—corresponding to Bloch, Néel, and antiskyrmion textures. In the absence of the dipolar interaction, these three DMI terms are gauge equivalent and yield degenerate skyrmion energies. Incorporating the nonlocal dipole-dipole interaction breaks this degeneracy: Bloch skyrmions remain unaffected, Néel skyrmions shrink slightly, and Heusler antiskyrmions lose axial symmetry and stabilize into square lattice crystals. The system is solved using a nonlocal numerical relaxation method that self-consistently computes the magnetostatic potential from Poisson's equation. Our results show that long-range dipolar interactions can stabilize bulk antiskyrmion crystals in translationally invariant three-dimensional chiral magnets.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (39)

  1. A. Bernand-Mantel, C. B. Muratov, and T. M. Simon, Unraveling the role of dipolar versus Dzyaloshinskii-Moriya interactions in stabilizing compact magnetic skyrmions, Phys. Rev. B 101, 045416 (2020).
  2. A. N. Bogdanov and D. A. Yablonskii, Thermodynamically stable “vortices” in magnetically ordered crystals. The mixed state of magnets, Zh. Eksp. Teor. Fiz. 95, 178 (1989).
  3. A. Bogdanov and A. Hubert, Thermodynamically stable magnetic vortex states in magnetic crystals, J. Magn. Magn. Mater. 138, 255 (1994).
  4. R. Saha, A. K. Srivastava, T. Ma, J. Jena, P. Werner, V. Kumar, C. Felser, and S. S. P. Parkin, Intrinsic stability of magnetic anti-skyrmions in the tetragonal inverse Heusler compound Mn1.4Pt0.9Pd0.1Sn, Nat. Commun. 10, 5305 (2019).
  5. C. Felser and S. Parkin, Topology, skyrmions, and Heusler compounds, MRS Bull. 47, 600 (2022).
  6. L. Peng, R. Takagi, W. Koshibae, K. Shibata, K. Nakajima, T. hisa Arima, N. Nagaosa, S. Seki, X. Yu, and Y. Tokura, Controlled transformation of skyrmions and antiskyrmions in a non-centrosymmetric magnet, Nat. Nanotechnol. 15, 181 (2020).
  7. Y. Amari and M. Nitta, Chiral magnets from string theory, J. High Energy Phys. 11 (2023) 212.
  8. B. Barton-Singer, C. Ross, and B. J. Schroers, Magnetic skyrmions at critical coupling, Commun. Math. Phys. 375, 2259 (2020).
  9. C. Back, V. Cros, H. Ebert, K. Everschor-Sitte, A. Fert, M. Garst, T. Ma, S. Mankovsky, T. L. Monchesky, M. Mostovoy, N. Nagaosa, S. S. P. Parkin, C. Pfleiderer, N. Reyren, A. Rosch, Y. Taguchi, Y. Tokura, K. von Bergmann, and J. Zang, The 2020 skyrmionics roadmap, J. Phys. D: Appl. Phys. 53, 363001 (2020).
  10. D. A. Garanin, D. Capic, S. Zhang, X. Zhang, and E. M. Chudnovsky, Writing skyrmions with a magnetic dipole, J. Appl. Phys. 124, 113901 (2018).
  11. B. Göbel, J. Henk, and I. Mertig, Forming individual magnetic biskyrmions by merging two skyrmions in a centrosymmetric nanodisk, Sci. Rep. 9, 9521 (2019).
  12. A. B. Kashuba and V. L. Pokrovsky, Stripe domain structures in a thin ferromagnetic film, Phys. Rev. B 48, 10335 (1993).
  13. M. Ezawa, Giant skyrmions stabilized by dipole-dipole interactions in thin ferromagnetic films, Phys. Rev. Lett. 105, 197202 (2010).
  14. H. Kwon, K. Bu, Y. Wu, and C. Won, Effect of anisotropy and dipole interaction on long-range order magnetic structures generated by Dzyaloshinskii–Moriya interaction, J. Magn. Magn. Mater. 324, 2171 (2012).
  15. M.-X. Sui and Y. Hu, Skyrmion-(non)crystal structure stabilized by dipolar interaction, Rare Met. 41, 3160 (2022).
  16. V. M. Kuchkin, B. Barton-Singer, F. N. Rybakov, S. Blügel, B. J. Schroers, and N. S. Kiselev, Magnetic skyrmions, chiral kinks, and holomorphic functions, Phys. Rev. B 102, 144422 (2020).
  17. A. Bogdanov and A. Hubert, The stability of vortex-like structures in uniaxial ferromagnets, J. Magn. Magn. Mater. 195, 182 (1999).
  18. X. Wang, H. Yuan, and X. Wang, A theory on skyrmion size, Commun. Phys. 1, 31 (2018).
  19. C. Adam, M. Haberichter, and A. Wereszczynski, The volume of a soliton, Phys. Lett. B 754, 18 (2016).
  20. A. O. Leonov, T. L. Monchesky, N. Romming, A. Kubetzka, A. N. Bogdanov, and R. Wiesendanger, The properties of isolated chiral skyrmions in thin magnetic films, New J. Phys. 18, 065003 (2016).
  21. A. K. Nayak, V. Kumar, T. Ma, P. Werner, E. Pippel, R. Sahoo, F. Damay, U. K. Rößler, C. Felser, and S. S. P. Parkin, Magnetic antiskyrmions above room temperature in tetragonal Heusler materials, Nature (London) 548, 561 (2017).
  22. P. Leask, Baby skyrmion crystals, Phys. Rev. D 105, 025010 (2022).
  23. S. B. Gudnason, B. Barsanti, and S. Bolognesi, Near-BPS baby skyrmions, J. High Energy Phys. 11 (2020) 062.
  24. F. N. Rybakov and N. S. Kiselev, Chiral magnetic skyrmions with arbitrary topological charge, Phys. Rev. B 99, 064437 (2019).
  25. R. Qin and Y. Wang, Magnetostatics of magnetic skyrmion crystals, New J. Phys. 20, 063029 (2018).
  26. G. D. Fratta, C. B. Muratov, F. N. Rybakov, and V. V. Slastikov, Variational principles of micromagnetics revisited, SIAM J. Math. Anal. 52, 3580 (2020).
  27. G. Mozurkewich, H. I. Ringermacher, and D. I. Bolef, Effect of demagnetization on magnetic resonance line shapes in bulk samples: Application to tungsten, Phys. Rev. B 20, 33 (1979).
  28. G. H. Derrick, Comments on nonlinear wave equations as models for elementary particles, J. Math. Phys. 5, 1252 (1964).
  29. D. Harland, P. Leask, and M. Speight, Skyrmion crystals stabilized by ω-mesons, J. High Energy Phys. 06 (2024) 116.
  30. P. Leask, Baby skyrmion crystals stabilized by vector mesons, Phys. Lett. B 855, 138842 (2024).
  31. M. Eto, Y. Hamada, and M. Nitta, Tying knots in particle physics, Phys. Rev. Lett. 135, 091603 (2025).
  32. S. B. Gudnason and J. M. Speight, Backreacted Coulomb energy in the Skyrme model, J. High Energy Phys. 01 (2025) 150..
  33. R. Tomasello, E. Martinez, R. Zivieri, L. Torres, M. Carpentieri, and G. Finocchio, A strategy for the design of skyrmion racetrack memories, Sci. Rep. 4, 6784 (2014).
  34. S. Lee, T. Fujimori, M. Nitta, and S. K. Kim, Domain wall networks as skyrmion crystals in chiral magnets, Phys. Rev. B 112, 064422 (2025).
  35. A. O. Leonov, I. E. Dragunov, U. K. Rößler, and A. N. Bogdanov, Theory of skyrmion states in liquid crystals, Phys. Rev. E 90, 042502 (2014).
  36. P. Leask, Topological transition from a hopfion to a toron via flexoelectric self-polarization in chiral liquid crystals, Phys. Rev. Res. 7, 043001 (2025).
  37. https://github.com/Paulnleask/cuDemag.
  38. M. Speight and T. Winyard, Vortex lattices and critical fields in anisotropic superconductors, J. Phys. A: Math. Theor. 58, 095203 (2025).
  39. J. M. Speight, Solitons on tori and soliton crystals, Commun. Math. Phys. 332, 355 (2014).
