Nonlocal origin and correlations in the Johnson noise at nonuniform temperature

Jorge Berger*

Guy Katriel

  • *Contact author: jorge.berger@braude.ac.il
PDF

Phys. Rev. B 112, 224311 – Published 10 December, 2025

DOI: https://doi.org/10.1103/ywtp-sqt3

Abstract

The conventional description of thermal noise in conductors (the Nyquist scenario) assumes that this noise has local origin and, therefore, the noise in the emf (electromotive force) in a conductor with nonuniform temperature can be described as a sum of contributions from uncorrelated regions, each in local thermal equilibrium. Here we propose an alternative scenario for the propagation of thermal noise in a conductor and suggest experiments that could distinguish between different scenarios. To explore the proposed scenario, we introduce a workable 1D model for a gas of particles that undergo stochastic collisions with the lattice and exert distance-dependent forces on each other. We define current, voltage, and emf in a manner appropriate to a wire with limited number of particles. For uniform temperature and within appropriate length and temperature ranges, we verify that our simulations comply with Nyquist's result. Our numerical simulations indicate that (1) thermal noise in a resistor at uniform local temperature is influenced not only by its own temperature but also by the temperatures of other resistors in the circuit; (2) for sufficiently long circuits, the deviation from the Nyquist prediction is inversely proportional to the distance between the centers of the resistors; and (3) if the resistors differ in temperature, their emf can be correlated, even if they are detached. Analytic results can be obtained in the limit of strong interparticle interaction. The long-range repulsion between charges in electrically connected resistors may have conceptual and technological impact on nanodevices.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (45)

  1. A. Einstein, On the theory of Brownian motion, Ann. Phys. (NY) 324, 371 (1906).
  2. J. B. Johnson, Thermal agitation of electricity in conductors, Phys. Rev. 32, 97 (1928).
  3. H. Nyquist, Thermal agitation of electric charge in conductors, Phys. Rev. 32, 110 (1928).
  4. J. F. Qu, S. P. Benz, H. Rogalla, W. L. Tew, D. R. White, and K. L. Zhou, Johnson noise thermometry, Meas. Sci. Technol. 30, 112001 (2019).
  5. J. Qu, S. P. Benz, K. Coakley, H. Rogalla, W. L. Tew, R. White, K. Zhou, and Z. Zhou, An improved electronic determination of the Boltzmann constant by Johnson noise thermometry, Metrologia 54, 549 (2017).
  6. S. P. Benz, K. J. Coakley, N. E. Flowers-Jacobs, H. Rogalla, W. L. Tew, J. Qu, D. R. White, C. Gaiser, A. Pollarolo, and C. Urano, Practical realisation of the Kelvin by Johnson noise thermometry, Metrologia 61, 022001 (2024).
  7. R. de-Picciotto, M. Reznikov, M. Heiblum, V. Umansky, G. Bunin, and D. Mahalu, Direct observation of a fractional charge, Phys. B: Condens. Matter, 249-251, 395 (1998).
  8. Shot noise was required for this purpose.
  9. K. C. Fong and K. C. Schwab, Ultrasensitive and wide-bandwidth thermal measurements of graphene at low temperatures, Phys. Rev. X 2, 031006 (2012).
  10. B. S. Karasik, C. B. McKitterick, and D. E. Prober, Prospective performance of graphene HEB for ultrasensitive detection of sub-mm radiation, J. Low Temp. Phys. 176, 249 (2014).
  11. D. K. Efetov, R.-J. Shiue, Y. Gao, B. Skinner, E. D. Walsh, H. Choi, J. Zheng, C. Tan, G. Grosso, C. Peng, J. Hone, K. C. Fong, and D. Englund, Fast thermal relaxation in cavity-coupled graphene bolometers with a Johnson noise read-out, Nat. Nanotechnol. 13, 797 (2018).
  12. W. Miao, H. Gao, Z. Wang, W. Zhang, Y. Ren, K. M. Zhou, S. C. Shi, C. Yu, Z. Z. He, Q. B. Liu, and Z. H. Feng, A graphene-based terahertz hot electron bolometer with Johnson noise readout, J. Low Temp. Phys. 193, 387 (2018).
  13. C. Liu, L. Du, W. Tang, D. Wei, J. Li, L. Wang, G. Chen, X. Chen, and W. Lu, Towards sensitive terahertz detection via thermoelectric manipulation using graphene transistors, NPG Asia Mater. 10, 318 (2018).
  14. J. Waissman, L. E. Anderson, A. V. Talanov, Z. Yan, Y. J. Shin, D. H. Najafabadi, M. Rezaee, X. Feng, D. G. Nocera, T. Taniguchi, K. Watanabe, B. Skinner, K. A. Matveev, and P. Kim, Electronic thermal transport measurement in low-dimensional materials with graphene non-local noise thermometry, Nat. Nanotechnol. 17, 166 (2022).
  15. C. J. Bakker and G. Heller, On the brownian motion in electric resistances, Physica 6, 262 (1939).
  16. Z. Kapetanovic, M. Morales, and J. R. Smith, Communication by means of modulated johnson noise, Proc. Natl. Acad. Sci. USA 119, e2201337119 (2022).
  17. B. Huard, H. Pothier, D. Esteve, and K. E. Nagaev, Electron heating in metallic resistors at sub-Kelvin temperature, Phys. Rev. B 76, 165426 (2007).
  18. A. C. Betz, F. Vialla, D. Brunel, C. Voisin, M. Picher, A. Cavanna, A. Madouri, G. Fève, J.-M. Berroir, B. Plaçais, and E. Pallecchi, Hot electron cooling by acoustic phonons in graphene, Phys. Rev. Lett. 109, 056805 (2012).
  19. B. Monnet, S. Ciliberto, and L. Bellon, Extended nyquist formula for a resistance subject to a heat flow, J. Stat. Mech. (2019) 104011.
  20. S. Ciliberto, A. Imparato, A. Naert, and M. Tanase, Heat flux and entropy produced by thermal fluctuations, Phys. Rev. Lett. 110, 180601 (2013).
  21. A. Bérut, A. Imparato, A. Petrosyan, and S. Ciliberto, The role of coupling on the statistical properties of the energy fluxes between stochastic systems at different temperatures, J. Stat. Mech. (2016) 054002.
  22. E. V. Sukhorukov and D. Loss, Noise in multiterminal diffusive conductors: Universality, nonlocality and exchange effects, Phys. Rev. B 59, 13054 (1999).
  23. O. S. Lumbroso, L. Simine, A. Nitzan, D. Segal, and O. Tal, Electronic noise due to temperature difference demonstrated in molecular junctions: Beyond standard thermal and shot noises, Nature (London) 562, 240 (2018).
  24. E. Zhitlukhina, M. Belogolovskii, and P. Seidel, Electronic noise generated by a temperature gradient across a hybrid normal metal–superconductor nanojunction, Appl. Nanosci. 10, 5121 (2020).
  25. G. Zhang, I. V. Gornyi, and C. Spånslätt, Delta-T noise for weak tunneling in one-dimensional systems: Interactions versus quantum, Phys. Rev. B 105, 195423 (2022).
  26. C. Pozderac and B. Skinner, Relation between johnson noise and heating power in a two-terminal conductor, Phys. Rev. B 104, L161403 (2021).
  27. J. Crossno et al., Observation of the Dirac fluid and the breakdown of the Wiedemann-Franz law in graphene, Science 351, 1058 (2016).
  28. A. Hui and B. Skinner, Current noise of hydrodynamic electrons, Phys. Rev. Lett. 130, 256301 (2023).
  29. A. Talanov, J. Waissman, A. Hui, B. Skinner, K. Watanabe, T. Taniguchi, and P. Kim, Observation of electronic viscous dissipation in graphene magneto-thermal transport, arXiv:2406.13799.
  30. A. Hui, Resolving the corbino shockley-ramo paradox for hydrodynamic current noise, Phys. Rev. Res. 6, 043248 (2024).
  31. For example, a crucial reason for choosing graphene in [14] was its negligible electron-phonon coupling, so that the temperature of the bath is felt only at the terminals. Energy loss to the phonons is regarded as a parasitic phenomenon that requires correction, as addressed in section 6 of the supplementary information for [14], In contrast, in our case, recurrent collisions with phonons characterized by the local temperature of the bath occur everywhere in the resistor.
  32. P. Drude, Zur elektronentheorie der metalle, Ann. Phys. (NY) 306, 566 (1900).
  33. P. Dutta and P. M. Horn, Low-frequency fluctuations in solids: 1/f noise, Rev. Mod. Phys. 53, 497 (1981).
  34. A. A. Balandin, Low-Frequency 1/f noise in graphene devices, Nat. Nanotechnol. 8, 549 (2013).
  35. H. Lee, Thermoelectrics: Design and Materials (Wiley, Hoboken, 2025).
  36. R. Chabay, B. Sherwood, and A. Titus, A unified, contemporary approach to teaching energy in introductory physics, Am. J. Phys. 87, 504 (2019).
  37. F. D. M. Haldane, ‘ Luttinger liquid theory’ of one-dimensional quantum fluids. I. Properties of the luttinger model and their extension to the general 1D interacting spinless fermi gas, J. Phys. C: Solid State Phys. 14, 2585 (1981).
  38. D. Cavazos-Cavazos, R. Senaratne, A. Kafle, and R. G. Hulet, Thermal disruption of a luttinger liquid, Nat. Commun. 14, 3154 (2023).
  39. T. Giamarchi, Quantum Physics in One Dimension (Clarendon, Oxford, 2003).
  40. D. Pines and D. Bohm, A collective description of electron interactions: II. Collective vs individual particle aspects of the interactions, Phys. Rev. 85, 338 (1952).
  41. A. Lucas and S. D. Sarma, Electronic sound modes and plasmons in hydrodynamic two-dimensional metals, Phys. Rev. B 97, 115449 (2018).
  42. D. Bohm and D. Pines, A collective description of electron interactions: III. Coulomb interactions in a degenerate electron gas, Phys. Rev. 92, 609 (1953).
  43. C. Collignon,. X. Lin, C. W. Rischau, B. Fauqué, and K. Behnia, Metallicity and superconductivity in doped strontium titanate, Annu. Rev. Condens. Matter Phys. 10, 25 (2019).
  44. Zh Yang, D. Lee, J. Yue, J. Gabel, T.-L. Lee., R. D. James, S. A. Chambers, and B. Jalan, Epitaxial SrTiO3 films with dielectric constants exceeding 25000, Proc. Natl. Acad. Sci. USA 119, e2202189119 (2022).
  45. F. Reif, Fundamentals of Statistical and Thermal Physics (McGraw-Hill, Tokyo, 1965), Chap. 15.
