High-speed x-ray reflectometry for characterization of thin film growth at high deposition rates

David Schumi-Mareček1, Andrew Nelson2, Erwin Pfeiler1, Maximilian Eder1, Florian Bertram3, and Stefan Kowarik1,*

  • *Contact author: stefan.kowarik@uni-graz.at
PDF

Phys. Rev. B 112, 235304 – Published 8 December, 2025

DOI: https://doi.org/10.1103/xxx9-8tk2

Abstract

We present a high-throughput, real-time study of PTCDI-C8 thin film growth using quick x-ray reflectivity (qXRR) with 12 ms time resolution, combined with machine learning-based analysis. In situ qXRR enables monitoring of vacuum deposition at growth rates from 1 to 30Å/s, accessing a previously unexplored regime in molecular beam deposition. To efficiently analyze the resulting ∼20000 reflectivity curves, we employ a convolutional neural network trained on a physics-informed multilayer model. This approach robustly extracts key structural parameters—including thickness, roughness, and crystalline versus amorphous content—from noisy data. We quantify interface roughness as a function of both film thickness and growth rate, identifying rapid roughening with a scaling exponent of β=0.62 with film thickness and a secondary scaling exponent of γ=0.21 with growth rate. Additionally, we observe a reduction in the coherently ordered film thickness and a rise in amorphous content at higher deposition rates. These results demonstrate that combining qXRR with machine learning provides quantitative access to fast kinetic growth processes, offering a powerful tool for in situ characterization and morphological control in organic thin film fabrication.

View figure in article
