Incommensurate twisted bilayer graphene: Emerging quasiperiodicity and stability

Ian Jauslin*

Vieri Mastropietro†

  • *Contact author: ian.jauslin@rutgers.edu
  • †Contact author: vieri.mastropietro@uniroma1.it
PDF

Phys. Rev. B 113, 115142 – Published 19 March, 2026

DOI: https://doi.org/10.1103/t4j9-3c26

Abstract

We consider a lattice model of twisted bilayer graphene (TBG) for incommensurate twist angles, focusing on the role of large-momentum-transfer umklapp terms. These terms, which nearly connect the Fermi points of different layers, are typically neglected in effective continuum descriptions but could, in principle, destroy the Dirac cones; they are indeed closely analogous to those appearing in fermions within quasiperiodic potentials, where they play a crucial role. We prove that, for small but finite interlayer coupling, the semimetallic phase is stable provided the angles belong to a fractal set of large measure (which decreases with the hopping strength) characterized by a number-theoretic Diophantine condition. In particular, this set excludes the (zero measure) commensurate angles. Our method combines a renormalization group (RG) analysis of the imaginary-time, zero-temperature Green's functions, with number theoretic properties, and it is similar to the technique used in the Lindstedt series approach to Kolmogorov-Arnold-Moser (KAM) theory. The convergence of the resulting series allows us to rule out nonperturbative effects. The result provides a partial justification of the effective continuum description of TBG in which such large-momentum interlayer hopping processes are neglected.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (32)

  1. G. Li, A. Luican, J. M. B. Lopes dos Santos, A. H. Castro Neto, A. Reina, J. Kong, and E. Y. Andrei, Observation of Van Hove singularities in twisted graphene layers, Nat. Phys. 6, 109 (2010).
  2. Y. Cao, V. Fatemi, A. Demir, S. Fang, S. L. Tomarken, J. Y. Luo, J. D. Sanchez-Yamagishi, K. Watanabe, T. Taniguchi, E. Kaxiras, R. C. Ashoori, and P. Jarillo-Herrero, Correlated insulator at half-filling in magic-angle graphene superlattices, Nature (London) 556, 80 (2018).
  3. E. Andrei and A. H. MacDonald, Graphene bilayers with a twist, Nat. Mater. 19, 1265 (2020).
  4. A. Nimbalkar and H. Kim, Opportunities and challenges in twisted bilayer graphene: A review, Nano Micro Lett. 12, 126 (2020).
  5. D. Aggarwal, R. Narula, and S. Ghosh, A primer on twistronics: A massless Dirac fermion's journey to moiré patterns and flat bands in twisted bilayer graphene, J. Phys.: Condens. Matter 35, 143001 (2023).
  6. S. Shallcross, S. Sharma, E. Kandelaki, and O. A. Pankratov, Electronic structure of turbostratic graphene, Phys. Rev. B 81, 165105 (2010).
  7. G. Trambly de Laissardière, D. Mayou, and L. Magaud, Localization of Dirac electrons in rotated graphene bilayers, Nano Lett. 10, 804 (2010).
  8. M. G. Scheer, K. Gu, and B. Lian, Magic angles in twisted bilayer graphene near commensuration: Towards a hypermagic regime, Phys. Rev. B 106, 115418 (2022).
  9. Y. Fu, E. J. König, J. H. Wilson, Y.-Z. Chou, and J. H. Pixley, Magic-angle semimetals, npj Quantum Mater. 5, 71 (2020).
  10. H. C. Po, L. Zou, A. Vishwanath, and T. Senthil, Origin of Mott insulating behavior and superconductivity in twisted bilayer graphene, Phys. Rev. X 8, 031089 (2018).
  11. L. Zou, H. C. Po, A. Vishwanath, and T. Senthil, Band structure of twisted bilayer graphene: Emergent symmetries, commensurate approximants, and Wannier obstructions, Phys. Rev. B 98, 085435 (2018).
  12. E. J. Mele, Commensuration and interlayer coherence in twisted bilayer graphene, Phys. Rev. B 81, 161405(R) (2010).
  13. J. M. B. Lopes dos Santos, N. M. R. Peres, and A. H. Castro Neto, Graphene bilayer with a twist: Electronic structure, Phys. Rev. Lett. 99, 256802 (2007).
  14. R. Bistritzer and A. H. MacDonald, Transport between twisted graphene layers, Phys. Rev. B 81, 245412 (2010).
  15. R. Bistritzer and A. H. MacDonald, Moiré bands in twisted double-layer graphene, Proc. Natl. Acad. Sci. USA 108, 12233 (2011).
  16. G. Tarnopolsky, A. J. Kruchkov, and A. Vishwanath, Origin of magic angles in twisted bilayer graphene, Phys. Rev. Lett. 122, 106405 (2019).
  17. A. B. Watson, T. Kong, A. H. MacDonald, and M. Luskin, Bistritzer–MacDonald dynamics in twisted bilayer graphene, J. Math. Phys. 64, 031502 (2023).
  18. S. Aubry and G. André, Analyticity breaking and Anderson localization in incommensurate lattices, Ann. Israel Phys. Soc. 3, 133 (1980).
  19. E. Dinaburg and Y. Sinai, Functional analysis methods in quasiperiodic systems, Funct. Anal. Its Appl. 9, 279 (1976).
  20. J. Fröhlich, T. Spencer, and P. Wittwer, Localization for a class of one-dimensional quasiperiodic Schrödinger operators, Commun. Math. Phys. 132, 5 (1990).
  21. A. Avila and S. Jitomirskaya, The Ten Martini problem, Ann. Math. 170, 303 (2009).
  22. C. R. Dean, L. Wang, P. Maher, C. Forsythe, F. Ghahari, Y. Gao, J. Katoch, M. Ishigami, P. Moon, M. Koshino, T. Taniguchi, K. Watanabe, K. L. Shepard, J. Hone, and P. Kim, Hofstadter's butterfly and the fractal quantum Hall effect in moiré superlattices, Nature (London) 497, 598 (2013).
  23. G. Gallavotti, Twistless KAM tori, twistless KAM tori, Commun. Math. Phys. 164, 145 (1994).
  24. G. Benfatto, G. Gentile, and V. Mastropietro, Electrons in a lattice with an incommensurate potential, J. Stat. Phys. 89, 655 (1997).
  25. V. Mastropietro, Small denominators and anomalous behaviour in the incommensurate Hubbard–Holstein model, Commun. Math. Phys. 201, 81 (1999).
  26. J. Vidal, D. Mouhanna, and T. Giamarchi, Interacting fermions in self-similar potentials, Phys. Rev. B 65, 014201 (2001).
  27. V. Oganesyan and D. A. Huse, Localization of interacting fermions at high temperature, Phys. Rev. B 75, 155111 (2007).
  28. V. Mastropietro, Localization of interacting fermions in the Aubry-André model, Phys. Rev. Lett. 115, 180401 (2015); Localization in interacting fermionic chains with quasirandom disorder, Commun. Math. Phys. 351, 283 (2017) .
  29. J. H. Pixley, J. H. Wilson, D. A. Huse, and S. Gopalakrishnan, Weyl semimetal to metal phase transitions driven by quasiperiodic potentials, Phys. Rev. Lett. 120, 207604 (2018).
  30. V. Mastropietro, Stability of Weyl semimetals with quasiperiodic disorder, Phys. Rev. B 102, 045101 (2020).
  31. B. Chirikov and B. Shepelyansky, Chirikov standard map, Scholarpedia 3, 3550 (2008).
  32. S. R. Hudson, Calculation of cantori for Hamiltonian flows, Phys. Rev. E 74, 056203 (2006).
