Berry curvature of low-energy excitons in rhombohedral graphene

Henry Davenport1, Frank Schindler1, and Johannes Knolle1,2,3

PDF

Phys. Rev. B 113, 115102 – Published 2 March, 2026

DOI: https://doi.org/10.1103/shrm-4swg

Abstract

We investigate low-energy excitons in rhombohedral pentalayer graphene encapsulated by hexagonal boron nitride (hBN/R5G/hBN), focusing on the regime at the experimental twist angle θ=0.77∘ and with an applied electric field. We introduce a new low-energy two-band model of rhombohedral graphene that captures the band structure more accurately than previous models while keeping the number of parameters low. Using this model, we show that the centres of the exciton Wannier functions are displaced from the moiré unit cell origin by a quantized amount—they are instead localized at C3-symmetric points on the boundary. We also find that the exciton shift is electrically tunable: by varying the electric field strength, the exciton Wannier center can be exchanged between inequivalent corners of the moiré unit cell. Our results suggest the possibility of detecting excitonic corner or edge modes, as well as novel excitonic crystal defect responses in hBN/R5G/hBN. Lastly, we find that the excitons in hBN/R5G/hBN inherit excitonic Berry curvature from the underlying electronic bands, enriching their semiclassical transport properties. Our results position rhombohedral graphene as a compelling tunable platform for probing exciton topology in moiré materials.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (39)

  1. D. Xiao, M.-C. Chang, and Q. Niu, Berry phase effects on electronic properties, Rev. Mod. Phys. 82, 1959 (2010).
  2. M. O. Soldini, N. Astrakhantsev, M. Iraola, A. Tiwari, M. H. Fischer, R. Valentí, M. G. Vergniory, G. Wagner, and T. Neupert, Interacting topological quantum chemistry of Mott atomic limits, Phys. Rev. B 107, 245145 (2023).
  3. K. Shiozaki, C. Z. Xiong, and K. Gomi, Generalized homology and Atiyah–Hirzebruch spectral sequence in crystalline symmetry protected topological phenomena, Prog. Theor. Exp. Phys. 2023, 083I01 (2023).
  4. N. Manjunath, V. Calvera, and M. Barkeshli, Characterization and classification of interacting (2+1)-dimensional topological crystalline insulators with orientation-preserving wallpaper groups, Phys. Rev. B 109, 035168 (2024).
  5. J. Herzog-Arbeitman, B. A. Bernevig, and Z.-D. Song, Interacting topological quantum chemistry in 2D with many-body real space invariants, Nat. Commun. 15, 1171 (2024).
  6. H. Davenport, J. Knolle, and F. Schindler, Interaction-induced crystalline topology of excitons, Phys. Rev. Lett. 133, 176601 (2024).
  7. Y. H. Kwan, Y. Hu, S. H. Simon, and S. A. Parameswaran, Exciton band topology in spontaneous quantum anomalous Hall insulators: Applications to twisted bilayer graphene, Phys. Rev. Lett. 126, 137601 (2021).
  8. P. Froese, T. Neupert, and G. Wagner, Topological excitons in moiré MoTe2/WSe2 heterobilayers, Phys. Rev. Res. 7, 023047 (2025).
  9. W. Yao and Q. Niu, Berry phase effect on the exciton transport and on the exciton Bose-Einstein condensate, Phys. Rev. Lett. 101, 106401 (2008).
  10. W. J. Jankowski, J. J. P. Thompson, B. Monserrat, and R.-J. Slager, Excitonic topology and quantum geometry in organic semiconductors, Nat. Commun. 16, 4661 (2025).
  11. H.-Y. Xie, P. Ghaemi, M. Mitrano, and B. Uchoa, Theory of topological exciton insulators and condensates in flat Chern bands, Proc. Natl. Acad. Sci. USA 121, e2401644121 (2024),.
  12. Z. Lu, T. Han, Y. Yao, A. P. Reddy, J. Yang, J. Seo, K. Watanabe, T. Taniguchi, L. Fu, and L. Ju, Fractional quantum anomalous Hall effect in a graphene moire superlattice, arXiv:2309.17436.
  13. J. Herzog-Arbeitman, Y. Wang, J. Liu, P. M. Tam, Z. Qi, Y. Jia, D. K. Efetov, O. Vafek, N. Regnault, H. Weng, Q. Wu, B. A. Bernevig, and J. Yu, Moiré fractional Chern insulators. II. First-principles calculations and continuum models of rhombohedral graphene superlattices, Phys. Rev. B 109, 205122 (2024).
  14. J. Dong, T. Wang, T. Wang, T. Soejima, M. P. Zaletel, A. Vishwanath, and D. E. Parker, Anomalous Hall crystals in rhombohedral multilayer graphene. I. Interaction-driven Chern bands and fractional quantum Hall states at zero magnetic field, Phys. Rev. Lett. 133, 206503 (2024).
  15. T. Soejima, J. Dong, T. Wang, T. Wang, M. P. Zaletel, A. Vishwanath, and D. E. Parker, Anomalous Hall crystals in rhombohedral multilayer graphene. II. General mechanism and a minimal model, Phys. Rev. B 110, 205124 (2024).
  16. B. A. Bernevig and Y. H. Kwan, ”Berry trashcan” model of interacting electrons in rhombohedral graphene, arXiv:2503.09692.
  17. J. Yu, J. Herzog-Arbeitman, Y. H. Kwan, N. Regnault, and B. A. Bernevig, Moiré fractional Chern insulators IV: Fluctuation-driven collapse of FCIs in multi-band exact diagonalization calculations on rhombohedral graphene Phys. Rev. B 112, 075110 (2025).
  18. Z. Dong, A. S. Patri, and T. Senthil, Stability of anomalous Hall crystals in multilayer rhombohedral graphene, Phys. Rev. B 110, 205130 (2024).
  19. Z. Dong, A. S. Patri, and T. Senthil, Theory of quantum anomalous Hall phases in pentalayer rhombohedral graphene moiré structures, Phys. Rev. Lett. 133, 206502 (2024).
  20. B. Zhou, H. Yang, and Y.-H. Zhang, Fractional quantum anomalous Hall effect in rhombohedral multilayer graphene in the moiréless limit, Phys. Rev. Lett. 133, 206504 (2024).
  21. B. Bradlyn, L. Elcoro, J. Cano, M. G. Vergniory, Z. Wang, C. Felser, M. I. Aroyo, and B. A. Bernevig, Topological quantum chemistry, Nature (London) 547, 298 (2017).
  22. J. B. Haber, D. Y. Qiu, F. H. da Jornada, and J. B. Neaton, Maximally localized exciton Wannier functions for solids, Phys. Rev. B 108, 125118 (2023).
  23. H. Davenport, J. Knolle, and F. Schindler, Exciton Berryology Phys. Rev. B 113, 045125 (2026).
  24. A. Fischer, L. Klebl, D. M. Kennes, and T. O. Wehling, Supercell Wannier functions and a faithful low-energy model for Bernal bilayer graphene, Phys. Rev. B 110, L201113 (2024).
  25. X.-T. Zhang, Y. H. Gao, and G. Chen, Thermal Hall effects in quantum magnets, Phys. Rep. 1070, 1 (2024).
  26. H. C. Nerl, K. T. Winther, F. S. Hage, K. S. Thygesen, L. Houben, C. Backes, J. N. Coleman, Q. M. Ramasse, and V. Nicolosi, Probing the local nature of excitons and plasmons in few-layer MoS2, npj 2D Mater. Appl. 1, 2 (2017).
  27. S. Susarla, M. H. Naik, D. D. Blach, J. Zipfel, T. Taniguchi, K. Watanabe, L. Huang, R. Ramesh, F. H. da Jornada, S. G. Louie, P. Ercius, and A. Raja, Hyperspectral imaging of exciton confinement within a moiré unit cell with a subnanometer electron probe, Science 378, 1235 (2022).
  28. P. Moon and M. Koshino, Electronic properties of graphene/hexagonal-boron-nitride moiré superlattice, Phys. Rev. B 90, 155406 (2014).
  29. X. Sun, S. Zhang, Z. Liu, H. Zhu, J. Huang, K. Yuan, Z. Wang, K. Watanabe, T. Taniguchi, X. Li, M. Zhu, J. Mao, T. Yang, J. Kang, J. Liu, Y. Ye, Z. V. Han, and Z. Zhang, Correlated states in doubly-aligned hBN/graphene/hBN heterostructures, Nat. Commun. 12, 7196 (2021).
  30. C. Fang, M. J. Gilbert, and B. A. Bernevig, Bulk topological invariants in noninteracting point group symmetric insulators, Phys. Rev. B 86, 115112 (2012).
  31. F. Schindler, O. Vafek, and B. A. Bernevig, Trions in twisted bilayer graphene, Phys. Rev. B 105, 155135 (2022).
  32. E. Khalaf and A. Vishwanath, Baby skyrmions in Chern ferromagnets and topological mechanism for spin-polaron formation in twisted bilayer graphene, Nat. Commun. 13, 6245 (2022).
  33. T. Fukui, Y. Hatsugai, and H. Suzuki, Chern numbers in discretized Brillouin zone: Efficient method of computing (spin) Hall conductances, J. Phys. Soc. Jpn. 74, 1674 (2005).
  34. P. Nguyen, L. Ma, R. Chaturvedi, K. Watanabe, T. Taniguchi, J. Shan, and K. Mak, Perfect Coulomb drag in a dipolar excitonic insulator, Science 388, 274 (2025).
  35. R. Qi, A. Y. Joe, Z. Zhang, J. Xie, Q. Feng, Z. Lu, Z. Wang, T. Taniguchi, K. Watanabe, S. Tongay, et al., Perfect Coulomb drag and exciton transport in an excitonic insulator, Science 388, 278 (2025).
  36. P. Czajka, T. Gao, M. Hirschberger, P. Lampen-Kelley, A. Banerjee, N. Quirk, D. G. Mandrus, S. E. Nagler, and N. P. Ong, Planar thermal Hall effect of topological bosons in the Kitaev magnet α−RuCl3, Nat. Mater. 22, 36 (2023).
  37. F. Schindler, S. S. Tsirkin, T. Neupert, B. Andrei Bernevig, and B. J. Wieder, Topological zero-dimensional defect and flux states in three-dimensional insulators, Nat. Commun. 13, 5791 (2022).
  38. H. Davenport, J. Knolle, and F. Schindler, Berry curvature of low-energy excitons in rhombohedral graphene, (Data) [Data set], Zenodo (2025), https://doi.org/10.5281/zenodo.16902666.
  39. F. Zhang, B. Sahu, H. Min, and A. H. MacDonald, Band structure of abc-stacked graphene trilayers, Phys. Rev. B 82, 035409 (2010).
