Normalized Andreev conductance peak in metal-superconductor point contacts can be enhanced above its ballistic maximum by disorder in the superconductor

Martin Moško1,2,*, Maroš Gregor1, Richard Hlubina1, Antónia Mošková2, Tomáš Roch1, Serhii Volkov1, and Tomáš Plecenik1

  • *Contact author: martin.mosko@savba.sk
PDF

Phys. Rev. B 114, 094505 – Published 10 August, 2026

DOI: https://doi.org/10.1103/kx1t-gwcp

Abstract

The metal-superconductor point contact (PC) is ballistic, if the coherence length ξ0 in the superconductor, the electron mean free path l0 in the metal, and the electron mean free path l in the superconductor are much larger than the PC radius a. The differential conductance G(V) of the ballistic PC at low temperatures and at voltages |V|≤Δ/e, where Δ is the superconducting gap, exhibits the Andreev peak caused by Andreev reflection. In the ballistic PC involving an isotropic superconductor, the Andreev peak at |V|≤Δ/e normalized by the background conductance G(V) at |V|≫Δ/e, is equal to two. It is believed that in a disordered PC, where conditions l0,l≫a fail, the normalized Andreev peak is smaller than two. Here we study the PC between a clean metal (l0≫a) and a weakly disordered (l≳a) isotropic superconductor in the limit l≪ξ0. We show theoretically and experimentally that, surprisingly, disorder on the superconducting side, however weak, raises the normalized Andreev peak above the ballistic value of two. Such disorder does not affect the Andreev reflection and G(V) at |V|<Δ/e. However, it scatters the quasiparticles injected into the superconductor above the gap and reflects a part of them back to the PC before they join the condensate. As a result, G(V) at |V|>Δ/e is lowered and the Andreev peak-to-background ratio becomes larger than two. In the normal state, the backscattering modifies the Sharvin-Maxwell PC resistance by adding a coherent resistance term ∝(a/l)2.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (50)

  1. G. E. Blonder, M. Tinkham, and T. M. Klapwijk, Transition from metallic to tunneling regimes in superconducting microconstrictions: Excess current, charge imbalance, and supercurrent conversion, Phys. Rev. B 25, 4515 (1982).
  2. A. V. Zaitsev, Quasiclassical equations of the theory of superconductivity for contiguous metals and the properties of constricted microcontacts, Zh Eksp. Teor. Fiz. 86, 1742 (1984) [Sov. Phys. JETP 59, 1015 (1984)].
  3. Yu G. Naidyuk and I. K. Yanson, Point-Contact Spectroscopy (Springer, New York, 2005).
  4. D. Daghero and R. S. Gonnelli, Probing multiband superconductivity by point-contact spectroscopy, Supercond. Sci. Technol. 23, 043001 (2010).
  5. Y. V. Sharvin, A possible method for studying Fermi surfaces, Zh Eksp. Teor. Fiz. 48, 984 (1965) [Sov. Phys. JETP 21, 655 (1965)].
  6. A. Andreev, The thermal conductivity of the intermediate state in superconductors, Zh Eksp. Teor. Fiz. 46, 1823 (1964) [Sov. Phys. JETP 19, 1228 (1974)].
  7. S.-K. Yip, Josephson current between d-wave superconductors through an interface with finite transmission, J. Low Temp. Phys. 109, 547 (1997).
  8. A. Pleceník, M. Grajcar, Š. Beňačka, P. Seidel, and A. Pfuch, Finite-quasiparticle-lifetime effects in the differential conductance of Bi2Sr2CaCu2Oy/Au junctions, Phys. Rev. B 49, 10016 (1994).
  9. G. E. Blonder and M. Tinkham, Metallic to tunneling transition in Cu-Nb point contacts, Phys. Rev. B 27, 112 (1983).
  10. Yu G. Naidyuk, H. v. Lohneysen, and I. K. Yanson, Temperature and magnetic-field dependence of the superconducting order parameter in Zn studied by point-contact spectroscopy, Phys. Rev. B 54, 16077 (1996).
  11. Yu G. Naidyuk and K. Gloos, Anatomy of point-contact Andreev reflection spectroscopy from the experimental point of view, Low Temp. Phys. 44, 257 (2018).
  12. Yan Huang, Jing Yan, Yonglei Wang, Lei Shan, Qiang Luo, Weihua Wang, and Hai-Hu Wen, Isotropic s-wave pairing symmetry in non-centrosymmetric Re3W revealed by point-contact spectroscopy, Supercond. Sci. Technol. 21, 075011 (2008).
  13. M. Moško, M. Koscelanská, A. Mošková, M. Vidiš, S. Volkov, M. Gregor, M. Poláčková, T. Roch, B. Grančič, L. Satrapinskyy, P. Kúš, A. Plecenik, and T. Plecenik, Observation and characterization of titanium-like nano-filament in TiO2 memristor using superconducting electrode(s) and Andreev spectroscopy, J. Appl. Phys. 136, 054303 (2024).
  14. C. W. J. Beenakker, Random-matrix theory of quantum transport, Rev. Mod. Phys. 69, 731 (1997).
  15. A. A. Golubov, Interface resistance in ferromagnet/superconductor junctions, Physica C 326, 46 (1999).
  16. I. Mazin, A. A. Golubov, and B. E. Nadgorny, Probing spin polarization with Andreev reflection: A theoretical basis, J. Appl. Phys. 89, 7576 (2001).
  17. G. T. Woods, R. J. Soulen Jr., I. Mazin, B. Nadgorny, M. S. Osofsky, J. Sanders, H. Srikanth, W. F. Egelhoff, and R. Datla, Analysis of point-contact Andreev reflection spectra in spin polarization measurements, Phys. Rev. B 70, 054416 (2004).
  18. S. N. Artemenko, A. F. Volkov, and A. V. Zaitsev, Theory of nonstationary Josephson effect in short superconducting contacts, Zh Eksp. Teor. Fiz. 76, 1816 (1979) [Sov. Phys. JETP 49, 924 (1979)].
  19. B. E. Nadgorny, Point contact Andreev reflection spectroscopy, in Spintronics Handbook: Spin Transport and Magnetism, 2nd ed., edited by E. Y. Tsymbal and I. Žutić (CRC Press, Boca Raton, FL, 2019), Vol. 3, pp. 35–97.
  20. M. Chand, G. Saraswat, A. Kamlapure, M. Mondal, S. Kumar, J. Jesudasan, V. Bagwe, L. Benfatto, V. Tripathi, and P. Raychaudhuri, Phase diagram of the strongly disordered s-wave super-conductor NbN close to the metal-insulator transition, Phys. Rev. B 85, 014508 (2012).
  21. A. Geresdi, M. Csontos, A. Gubicza, A. Halbritter, and G. Mihály, A fast operation of nanometer-scale metallic memristors: Highly transparent conductance channels in Ag2S devices, Nanoscale 6, 2613 (2014).
  22. See Supplemental Material at http://link.aps.org/supplemental/10.1103/kx1t-gwcp for the growth and characterisation of the used multilayers, for the device fabrication, and for the complete set of transport data for devices 3, 4, 5, and 6, which includes Refs. [23, 24].
  23. T. Roch, M. Gregor, S. Volkov, M. Čaplovičová, L. Satrapinskyy, and A. Plecenik, Substrate dependent epitaxy of superconducting niobium nitride thin films grown by pulsed laser deposition, Appl. Surf. Sci. 551, 149333 (2021).
  24. S. Volkov, M. Gregor, T. Roch, L. Satrapinskyy, B. Grančič, T. Fiantok, and A. Plecenik, Superconducting properties of very high quality NbN thin films grown by pulsed laser deposition, J. Electr. Eng. 70, 89 (2019).
  25. W. L. McMillan, Tunneling model of the superconducting proximity effect, Phys. Rev. 175, 537 (1968).
  26. R. C. Dynes, V. Narayanamurti, and J. P. Garno, Direct measurement of quasiparticle-lifetime broadening in a strong-coupled superconductor, Phys. Rev. Lett. 41, 1509 (1978).
  27. F. Herman and R. Hlubina, Microscopic interpretation of the Dynes formula for the tunneling density of states, Phys. Rev. B 94, 144508 (2016)
  28. D. Daghero, E. Piatti, N. D. Zhigadlo, and R. S. Gonnelli, A model for critical current effects in point-contact Andreev-reflection spectroscopy, Low Temp. Phys. 49, 886 (2023).
  29. J.-C. Villegirr, N. Hadacek, S. Monso, B. Delaet, A. Roussy, P. Febvre, G. Lamura, and J.-Y. Laval, NbN multilayer technology on R-plane sapphire, IEEE Trans. Appl. Supercond. 11, 68 (2001).
  30. A. Kamlapure, M. Mondal, M. Chand, A. Mishra, J. Jesudasan, V. Bagwe, L. Benfatto, V. Tripathi, and P. Raychaudhuri, Measurement of magnetic penetration depth and superconducting energy gap in very thin epitaxial NbN films, Appl. Phys. Lett. 96, 072509 (2010).
  31. G. Wexler, The size effect and the non-local Boltzmann transport equation in orifice and disk geometry, Proc. Phys. Soc. 89, 927 (1966).
  32. S. Kashiwaya, Y. Tanaka, M. Koyanagi, and K. Kajimura, Theory for tunneling spectroscopy of anisotropic superconductors, Phys. Rev. B 53, 2667 (1996).
  33. C. Honerkamp and M. Sigrist, Andreev reflection in unitary and non-unitary triplet states, J. Low Temp. Phys. 111, 895 (1998).
  34. X.-X. Gong, H.-X. Zhou, P.-C. Xu, D. Yue, K. Zhu, X.-F. Jin, H. Tian, G.-J. Zhao, and T.-Y. Chen, Possible p-wave superconductivity in epitaxial Bi/Ni bilayers, Chinese. Phys. Lett. 32, 067402 (2015).
  35. S. Sasaki, M. Kriener, K. Segawa, K. Yada, Y. Tanaka, M. Sato, and Y. Ando, Topological superconductivity in CuxBi2Se3, Phys. Rev. Lett. 107, 217001 (2011)
  36. O. Millo and G. Koren, What can Andreev bound states tell us about superconductors? Phil. Trans. R. Soc. A 376, 20140143 (2018).
  37. P. Parab, D. Singh, S. Haram, R. P. Singh, and S. Bose, Point contact Andreev reflection studies of a non-centro symmetric superconductor, Sci. Rep. 9, 2498 (2019).
  38. J.-C. He and Y. Chen, Evidence of triplet superconductivity in Bi/Ni bilayers: Theoretical analysis of point contact Andreev reflection spectroscopy results, Phys. Rev. B 106, 224508 (2022).
  39. F. Romeo, F. Giubileo, R. Citro, A. Di Bartolomeo, C. Attanasio, C. Cirillo, A. Polcari, and P. Romano, Resonant Andreev spectroscopy in normal-metal/thin-ferromagnet/superconductor device: Theory and application, Sci. Rep. 5, 17544 (2015).
  40. A. A. Clerk, V. Ambegaokar, and S. Hershfield, Andreev scattering and the Kondo effect, Phys. Rev. B 61, 3555 (2000).
  41. J. A. Gifford, G. J. Zhao, B. C. Li, J. Zhang, D. R. Kim, and T. Y. Chen, Zero bias anomaly in Andreev reflection spectroscopy, J. Appl. Phys. 120, 163901 (2016).
  42. M. Moško, M. Gregor, A. Mošková, T. Roch, S. Volkov, and T. Plecenik, Disorder in metal-superconductor point contacts: Does it lower the Andreev conductance peak? [Data set], Zenodo, 2026, https://doi.org/10.5281/zenodo.17307564.
  43. B. L. Altshuler and A. G. Aronov, Modern Problems in Condensed Matter Sciences, Vol. 10, (Elsevier, Amsterdam, 1985).
  44. Y. Imry, Introduction to Mesoscopic Physics (Oxford University Press, 2002), Vol. 2.
  45. D. L. Maslov, B. Barnes, and G. Kirczenow, Ballistic transport in a disordered environment: Why is conductance quantization observable? Phys. Rev. Lett 70, 1984 (1993).
  46. V. I. Kozub, J. Caro, and P. A. M. Holweg, Local-interference theory of conductance fluctuations in ballistic metallic point contacts: Combination of near and remote backscattered trajectories, Phys. Rev. B 50, 15126 (1994).
  47. V. Baltz, A. D. Naylor, K. M. Seemann, W. Elder, S. Sheen, K. Westerholt, H. Zabel, G. Burnell, C. H. Marrows, and B. J. Hickey, Conductance features in point contact Andreev reflection spectra, J. Phys.: Condens. Matter 21, 095701 (2009).
  48. J. B. Ketterson, L. R. Windmiller, S. Hörnfeldt, and F. Mueller, Fermi velocity and Fermi radius in platinum, Solid State Commun. 6, 851 (1968).
  49. S. Dutta, K. Sankaran, K. Moors, G. Pourtois, S. V. Elshocht, J. Bömmels, W. Vandervorst, Z. Tőkei, and C. Adelmann, Thickness dependence of the resistivity of platinum-group metal thin films, J. Appl. Phys. 122, 025107 (2017).
  50. C. Kittel, Introduction to Solid State Physics, 8th ed. (John Wiley & Sons, Inc., Hoboken, NJ, 2005).
