  • Open Access

Multiplicative Chern insulator: Generalized bulk-boundary correspondences, 4π Aharonov-Bohm effect, and adiabatic evolution to topological skyrmion phase with symmetry breaking

Archi Banerjee1,2,3 and Ashley M. Cook1,2

PDF

Phys. Rev. B 113, 085105 – Published 4 February, 2026

DOI: https://doi.org/10.1103/9f5b-y98z

Abstract

We study multiplicative Chern insulators (MCIs) as canonical examples of multiplicative topological phases of matter. Constructing the MCI Bloch Hamiltonian as a symmetry-protected tensor product of two topologically nontrivial parent Chern insulators (CIs), we study two-dimensional (2D) MCIs and introduce three-dimensional mixed MCIs, constructed by requiring the two 2D parent Hamiltonians share only one momentum component. We study the 2D MCI response to time-reversal symmetric flux insertion, observing a 4π Aharonov-Bohm effect, relating these topological states to fractional quantum Hall states via the microscopic field theories of the quantum skyrmion Hall effect. As part of this response, we observe evidence of quantization of a proposed topological invariant for compactified many-body states to a rational number, suggesting higher-dimensional topology may also be relevant. Finally, we study effects of bulk perturbations breaking the symmetry-protected tensor-product structure of the child Hamiltonian, finding the MCI evolves adiabatically into a topological skyrmion phase.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (69)

  1. K. v. Klitzing, G. Dorda, and M. Pepper, New method for high-accuracy determination of the fine-structure constant based on quantized Hall resistance, Phys. Rev. Lett. 45, 494 (1980).
  2. D. C. Tsui, H. L. Stormer, and A. C. Gossard, Two-dimensional magnetotransport in the extreme quantum limit, Phys. Rev. Lett. 48, 1559 (1982).
  3. R. B. Laughlin, Quantized Hall conductivity in two dimensions, Phys. Rev. B 23, 5632 (1981).
  4. B. I. Halperin, Quantized Hall conductance, current-carrying edge states, and the existence of extended states in a two-dimensional disordered potential, Phys. Rev. B 25, 2185 (1982).
  5. F. D. M. Haldane, Fractional quantization of the Hall effect: A hierarchy of incompressible quantum fluid states, Phys. Rev. Lett. 51, 605 (1983).
  6. Q. Niu, D. J. Thouless, and Y.-S. Wu, Quantized Hall conductance as a topological invariant, Phys. Rev. B 31, 3372 (1985).
  7. R. B. Laughlin, Anomalous quantum Hall effect: An incompressible quantum fluid with fractionally charged excitations, Phys. Rev. Lett. 50, 1395 (1983).
  8. S. C. Zhang, T. H. Hansson, and S. Kivelson, Effective-field-theory model for the fractional quantum Hall effect, Phys. Rev. Lett. 62, 82 (1989).
  9. J. K. Jain, Composite-fermion approach for the fractional quantum Hall effect, Phys. Rev. Lett. 63, 199 (1989).
  10. D.-H. Lee and C. L. Kane, Boson-vortex-skyrmion duality, spin-singlet fractional quantum Hall effect, and spin-1/2 anyon superconductivity, Phys. Rev. Lett. 64, 1313 (1990).
  11. F. D. M. Haldane, Model for a quantum Hall effect without Landau levels: Condensed-matter realization of the “parity anomaly,” Phys. Rev. Lett. 61, 2015 (1988).
  12. C. L. Kane and E. J. Mele, Z2 topological order and the quantum spin Hall effect, Phys. Rev. Lett. 95, 146802 (2005).
  13. L. Fu, C. L. Kane, and E. J. Mele, Topological insulators in three dimensions, Phys. Rev. Lett. 98, 106803 (2007).
  14. J. E. Moore and L. Balents, Topological invariants of time-reversal-invariant band structures, Phys. Rev. B 75, 121306(R) (2007).
  15. B. A. Bernevig, T. L. Hughes, and S.-C. Zhang, Quantum spin Hall effect and topological phase transition in HgTe quantum wells, Science 314, 1757 (2006).
  16. C.-Z. Chang, J. Zhang, X. Feng, J. Shen, Z. Zhang, M. Guo, K. Li, Y. Ou, P. Wei, L.-L. Wang, Z.-Q. Ji, Y. Feng, S. Ji, X. Chen, J. Jia, X. Dai, Z. Fang, S.-C. Zhang, K. He, Y. Wang, et al., Experimental observation of the quantum anomalous Hall effect in a magnetic topological insulator, Science 340, 167 (2013).
  17. M. König, S. Wiedmann, C. Brüne, A. Roth, H. Buhmann, L. W. Molenkamp, X.-L. Qi, and S.-C. Zhang, Quantum spin Hall insulator state in HgTe quantum wells, Science 318, 766 (2007).
  18. D. Hsieh, D. Qian, L. Wray, Y. Xia, Y. S. Hor, R. J. Cava, and M. Z. Hasan, A topological Dirac insulator in a quantum spin Hall phase, Nature (London) 452, 970 (2008).
  19. Y. L. Chen, J. G. Analytis, J.-H. Chu, Z. K. Liu, S.-K. Mo, X. L. Qi, H. J. Zhang, D. H. Lu, X. Dai, Z. Fang, S. C. Zhang, I. R. Fisher, Z. Hussain, and Z.-X. Shen, Experimental realization of a three-dimensional topological insulator, Bi2Te3, Science 325, 178 (2009).
  20. Y. L. Chen, J.-H. Chu, J. G. Analytis, Z. K. Liu, K. Igarashi, H.-H. Kuo, X. L. Qi, S. K. Mo, R. G. Moore, D. H. Lu, M. Hashimoto, T. Sasagawa, S. C. Zhang, I. R. Fisher, Z. Hussain, and Z. X. Shen, Massive Dirac fermion on the surface of a magnetically doped topological insulator, Science 329, 659 (2010).
  21. H. Peng, K. Lai, D. Kong, S. Meister, Y. Chen, X.-L. Qi, S.-C. Zhang, Z.-X. Shen, and Y. Cui, Aharonov–Bohm interference in topological insulator nanoribbons, Nat. Mater. 9, 225 (2010).
  22. Z. K. Liu, B. Zhou, Y. Zhang, Z. J. Wang, H. M. Weng, D. Prabhakaran, S.-K. Mo, Z. X. Shen, Z. Fang, X. Dai, Z. Hussain, and Y. L. Chen, Discovery of a three-dimensional topological Dirac semimetal, Na3Bi, Science 343, 864 (2014).
  23. Z. K. Liu, J. Jiang, B. Zhou, Z. J. Wang, Y. Zhang, H. M. Weng, D. Prabhakaran, S.-K. Mo, H. Peng, P. Dudin, T. Kim, M. Hoesch, Z. Fang, X. Dai, Z. X. Shen, D. L. Feng, Z. Hussain, and Y. L. Chen, A stable three-dimensional topological Dirac semimetal Cd3As2, Nat. Mater. 13, 677 (2014).
  24. S.-Y. Xu, I. Belopolski, N. Alidoust, M. Neupane, G. Bian, C. Zhang, R. Sankar, G. Chang, Z. Yuan, C.-C. Lee, S.-M. Huang, H. Zheng, J. Ma, D. S. Sanchez, B. Wang, A. Bansil, F. Chou, P. P. Shibayev, H. Lin, S. Jia, et al., Discovery of a Weyl fermion semimetal and topological Fermi arcs, Science 349, 613 (2015).
  25. S. Tang, C. Zhang, D. Wong, Z. Pedramrazi, H.-Z. Tsai, C. Jia, B. Moritz, M. Claassen, H. Ryu, S. Kahn, J. Jiang, H. Yan, M. Hashimoto, D. Lu, R. G. Moore, C.-C. Hwang, C. Hwang, Z. Hussain, Y. Chen, M. M. Ugeda, et al., Quantum spin Hall state in monolayer 1T'-WTe2, Nat. Phys. 13, 683 (2017).
  26. S. Nadj-Perge, I. K. Drozdov, J. Li, H. Chen, S. Jeon, J. Seo, A. H. MacDonald, B. A. Bernevig, and A. Yazdani, Observation of Majorana fermions in ferromagnetic atomic chains on a superconductor, Science 346, 602 (2014).
  27. P. Roushan, J. Seo, C. V. Parker, Y. S. Hor, D. Hsieh, D. Qian, A. Richardella, M. Z. Hasan, R. J. Cava, and A. Yazdani, Topological surface states protected from backscattering by chiral spin texture, Nature (London) 460, 1106 (2009).
  28. Y. Xia, D. Qian, D. Hsieh, L. Wray, A. Pal, H. Lin, A. Bansil, D. Grauer, Y. S. Hor, R. J. Cava, and M. Z. Hasan, Observation of a large-gap topological-insulator class with a single Dirac cone on the surface, Nat. Phys. 5, 398 (2009).
  29. S.-M. Huang, S.-Y. Xu, I. Belopolski, C.-C. Lee, G. Chang, B. Wang, N. Alidoust, G. Bian, M. Neupane, C. Zhang, S. Jia, A. Bansil, H. Lin, and M. Z. Hasan, A Weyl fermion semimetal with surface Fermi arcs in the transition metal monopnictide TaAs class, Nat. Commun. 6, 7373 (2015).
  30. S. Ryu, A. P. Schnyder, A. Furusaki, and A. W. W. Ludwig, Topological insulators and superconductors: Tenfold way and dimensional hierarchy, New J. Phys. 12, 065010 (2010).
  31. A. P. Schnyder, S. Ryu, A. Furusaki, and A. W. W. Ludwig, Classification of topological insulators and superconductors in three spatial dimensions, Phys. Rev. B 78, 195125 (2008).
  32. A. Kitaev, Periodic table for topological insulators and superconductors, AIP Conf. Proc. 1134, 22 (2009).
  33. P. Anderson, Resonating valence bonds: A new kind of insulator? Mater. Res. Bull. 8, 153 (1973).
  34. P. W. Anderson, The resonating valence bond state in La2CuO4 and superconductivity, Science 235, 1196 (1987).
  35. G. Baskaran, Z. Zou, and P. Anderson, The resonating valence bond state and high-tc superconductivity—A mean field theory, Solid State Commun. 63, 973 (1987).
  36. V. Kalmeyer and R. B. Laughlin, Equivalence of the resonating-valence-bond and fractional quantum Hall states, Phys. Rev. Lett. 59, 2095 (1987).
  37. S. A. Kivelson, D. S. Rokhsar, and J. P. Sethna, Topology of the resonating valence-bond state: Solitons and high-Tc superconductivity, Phys. Rev. B 35, 8865 (1987).
  38. D. S. Rokhsar and S. A. Kivelson, Superconductivity and the quantum hard-core dimer gas, Phys. Rev. Lett. 61, 2376 (1988).
  39. I. Affleck and J. B. Marston, Large-n limit of the Heisenberg-Hubbard model: Implications for high-Tc superconductors, Phys. Rev. B 37, 3774 (1988).
  40. N. Read and S. Sachdev, Large-N expansion for frustrated quantum antiferromagnets, Phys. Rev. Lett. 66, 1773 (1991).
  41. X. G. Wen, Vacuum degeneracy of chiral spin states in compactified space, Phys. Rev. B 40, 7387 (1989).
  42. X. G. Wen, Mean-field theory of spin-liquid states with finite energy gap and topological orders, Phys. Rev. B 44, 2664 (1991).
  43. T. Senthil and M. P. A. Fisher, Z2 gauge theory of electron fractionalization in strongly correlated systems, Phys. Rev. B 62, 7850 (2000).
  44. T. Senthil and M. P. A. Fisher, Fractionalization in the cuprates: Detecting the topological order, Phys. Rev. Lett. 86, 292 (2001).
  45. F. J. Wegner, Duality in generalized Ising models and phase transitions without local order parameters, J. Math. Phys. 12, 2259 (1971).
  46. J. B. Kogut, An introduction to lattice gauge theory and spin systems, Rev. Mod. Phys. 51, 659 (1979).
  47. R. Moessner and S. L. Sondhi, Resonating valence bond phase in the triangular lattice quantum dimer model, Phys. Rev. Lett. 86, 1881 (2001).
  48. A. Kitaev, Fault-tolerant quantum computation by anyons, Ann. Phys. (NY) 303, 2 (2003).
  49. A. Kitaev, Anyons in an exactly solved model and beyond, Ann. Phys. (NY) 321, 2 (2006).
  50. A. M. Cook and J. E. Moore, Multiplicative topological phases, Commun. Phys. 5, 262 (2022).
  51. A. M. Cook, Topological skyrmion phases of matter, J. Phys.: Condens. Matter 35, 184001 (2023).
  52. A. M. Cook and A. E. B. Nielsen, Finite-size topology, Phys. Rev. B 108, 045144 (2023).
  53. A. M. Cook, Quantum skyrmion Hall effect, Phys. Rev. B 109, 155123 (2024).
  54. V. Patil, R. Flores-Calderon, and A. M. Cook, Effective field theory of the quantum skyrmion Hall effect, arXiv:2412.19565.
  55. V. Kalmeyer and R. B. Laughlin, Theory of the spin liquid state of the Heisenberg antiferromagnet, Phys. Rev. B 39, 11879 (1989).
  56. B. I. Halperin, P. A. Lee, and N. Read, Theory of the half-filled Landau level, Phys. Rev. B 47, 7312 (1993).
  57. Y. W. Suen, L. W. Engel, M. B. Santos, M. Shayegan, and D. C. Tsui, Observation of a ν=1/2 fractional quantum Hall state in a double-layer electron system, Phys. Rev. Lett. 68, 1379 (1992).
  58. R. Flores-Calderon and A. M. Cook, Time-reversal invariant topological skyrmion phases, Phys. Rev. B 108, 235102 (2023).
  59. J. H. Winter, R. Ay, B. Braunecker, and A. M. Cook, Observable-enriched entanglement, Phys. Rev. B 111, 165143 (2025).
  60. S.-W. Liu, L.-K. Shi, and A. M. Cook, Defect bulk-boundary correspondence of topological skyrmion phases of matter, Phys. Rev. B 107, 235109 (2023).
  61. X.-L. Qi, Y.-S. Wu, and S.-C. Zhang, Topological quantization of the spin Hall effect in two-dimensional paramagnetic semiconductors, Phys. Rev. B 74, 085308 (2006).
  62. A. Pal, J. H. Winter, and A. M. Cook, Majorana zero modes in multiplicative topological phases, Phys. Rev. B 109, 014516 (2024).
  63. R. Flores-Calderon, R. Moessner, and A. M. Cook, Time-reversal invariant finite-size topology, Phys. Rev. B 108, 125410 (2023).
  64. V. Patil, A. Banerjee, and A. M. Cook, Microscopic field theories of the quantum skyrmion Hall effect, arXiv:2508.16547.
  65. See Supplemental Material at http://link.aps.org/supplemental/10.1103/9f5b-y98z for details on computing the skyrmion number Q and further characterization of the topological invariant Tr[C], which includes Ref. [69].
  66. I. Peschel, Calculation of reduced density matrices from correlation functions, J. Phys. A: Math. Gen. 36, L205 (2003).
  67. A. P. Polychronakos, Noncommutative Chern-Simons terms and the noncommutative vacuum, J. High Energy Phys. 11 (2000) 008.
  68. R. Ay, A. Pal, and A. M. Cook, Signatures of the quantum skyrmion Hall effect in the Bernevig-Hughes-Zhang model, arXiv:2412.19568.
  69. A. Pal, J. H. Winter, and A. M. Cook, Multiplicative topological semimetals, Phys. Rev. B 109, 035147 (2024).
