Floquet product mode and eigenphase order

Felix Möckel1, Harald Schmid1,2,3, and Felix von Oppen4

PDF

Phys. Rev. B 114, 165138 – Published 24 September, 2026

DOI: https://doi.org/10.1103/64fp-6gy7

Abstract

We study the robustness of the Floquet quantum Ising model against integrability-breaking perturbations, focusing on the phase hosting both Majorana zero and π modes. A recent work [H.-C. Yeh, A. Rosch, and A. Mitra, Phys. Rev. B 110, 075117 (2024)] observed that the Floquet product mode, a composite edge mode constructed from both Majorana operators, is considerably more robust than the individual Majorana edge modes. We analyze these strong modes from the point of view of the eigenphase order present in finite chains with open boundary conditions. As a result of the Majorana modes, all Floquet eigenstates come in quadruplets in the integrable limit. We show that the robustness of the various modes as well as the behavior of the boundary spin correlation functions can be understood in terms of the spectral statistics of these quadruplets in the presence of integrability-breaking perturbations.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (58)

  1. P. Fendley, Parafermionic edge zero modes in Zn-invariant spin chains, J. Stat. Mech. (2012) P11020.
  2. P. Fendley, Free parafermions, J. Phys. A: Math. Theor. 47, 075001 (2014).
  3. P. Fendley, Strong zero modes and eigenstate phase transitions in the XYZ/interacting Majorana chain, J. Phys. A: Math. Theor. 49, 30LT01 (2016).
  4. L. M. Vasiloiu, F. Carollo, and J. P. Garrahan, Enhancing correlation times for edge spins through dissipation, Phys. Rev. B 98, 094308 (2018).
  5. L. M. Vasiloiu, F. Carollo, M. Marcuzzi, and J. P. Garrahan, Strong zero modes in a class of generalized Ising spin ladders with plaquette interactions, Phys. Rev. B 100, 024309 (2019).
  6. J. Kemp, N. Y. Yao, and C. R. Laumann, Symmetry-enhanced boundary qubits at infinite temperature, Phys. Rev. Lett. 125, 200506 (2020).
  7. J. Kemp, N. Y. Yao, C. R. Laumann, and P. Fendley, Long coherence times for edge spins, J. Stat. Mech. (2017) 063105.
  8. N. Chepiga and N. Laflorencie, Topological and quantum critical properties of the interacting Majorana chain model, SciPost Phys. 14, 152 (2023).
  9. N. Laflorencie, Universal signatures of Majorana zero modes in critical Kitaev chains, arXiv:2311.07571.
  10. F. H. L. Essler, P. Fendley, and E. Vernier, Strong zero modes in integrable spin-S chains, SciPost Phys. 20, 164 (2026).
  11. G. J. Sreejith, A. Lazarides, and R. Moessner, Parafermion chain with 2π/k Floquet edge modes, Phys. Rev. B 94, 045127 (2016).
  12. C. W. von Keyserlingk and S. L. Sondhi, Phase structure of one-dimensional interacting Floquet systems. I. Abelian symmetry-protected topological phases, Phys. Rev. B 93, 245145 (2016).
  13. D. J. Yates, A. G. Abanov, and A. Mitra, Lifetime of almost strong edge-mode operators in one-dimensional, interacting, symmetry protected topological phases, Phys. Rev. Lett. 124, 206803 (2020).
  14. D. J. Yates, F. H. L. Essler, and A. Mitra, Almost strong (0,π) edge modes in clean interacting one-dimensional Floquet systems, Phys. Rev. B 99, 205419 (2019).
  15. D. E. Parker, R. Vasseur, and T. Scaffidi, Topologically protected long edge coherence times in symmetry-broken phases, Phys. Rev. Lett. 122, 240605 (2019).
  16. D. J. Yates and A. Mitra, Strong and almost strong modes of Floquet spin chains in Krylov subspaces, Phys. Rev. B 104, 195121 (2021).
  17. X. Mi et al., Noise-resilient edge modes on a chain of superconducting qubits, Science 378, 785 (2022).
  18. H.-C. Yeh, A. Rosch, and A. Mitra, Decay rates of almost strong modes in Floquet spin chains beyond Fermi's golden rule, Phys. Rev. B 108, 075112 (2023).
  19. H.-C. Yeh, A. Rosch, and A. Mitra, Floquet product mode, Phys. Rev. B 110, 075117 (2024).
  20. E. Vernier, H.-C. Yeh, L. Piroli, and A. Mitra, Strong zero modes in integrable quantum circuits, Phys. Rev. Lett. 133, 050606 (2024).
  21. H. Schmid, A.-G. Penner, K. Yang, L. Glazman, and F. von Oppen, Robust spectral π pairing in the random-field Floquet quantum Ising model, Phys. Rev. Lett. 132, 210401 (2024).
  22. F. Jin et al., Topological prethermal strong zero modes on superconducting processors, Nature (London) 645, 626 (2025).
  23. A. J. Friedman, B. Ware, R. Vasseur, and A. C. Potter, Topological edge modes without symmetry in quasiperiodically driven spin chains, Phys. Rev. B 105, 115117 (2022).
  24. H. Schmid, Y. Peng, G. Refael, and F. von Oppen, Self-similar phase diagram of the Fibonacci-driven quantum Ising model, Phys. Rev. Lett. 134, 240404 (2025).
  25. K. Klobas, P. Fendley, and J. P. Garrahan, Stochastic strong zero modes and their dynamical manifestations, Phys. Rev. E 107, L042104 (2023).
  26. A. Y. Kitaev, Unpaired Majorana fermions in quantum wires, Phys. Usp. 44, 131 (2001).
  27. L. Jiang, T. Kitagawa, J. Alicea, A. R. Akhmerov, D. Pekker, G. Refael, J. I. Cirac, E. Demler, M. D. Lukin, and P. Zoller, Majorana fermions in equilibrium and in driven cold-atom quantum wires, Phys. Rev. Lett. 106, 220402 (2011).
  28. M. Thakurathi, A. A. Patel, D. Sen, and A. Dutta, Floquet generation of Majorana end modes and topological invariants, Phys. Rev. B 88, 155133 (2013).
  29. B. Bauer, T. Pereg-Barnea, T. Karzig, M.-T. Rieder, G. Refael, E. Berg, and Y. Oreg, Topologically protected braiding in a single wire using Floquet Majorana modes, Phys. Rev. B 100, 041102(R) (2019).
  30. D. A. Huse, R. Nandkishore, V. Oganesyan, A. Pal, and S. L. Sondhi, Localization-protected quantum order, Phys. Rev. B 88, 014206 (2013).
  31. D. Pekker, G. Refael, E. Altman, E. Demler, and V. Oganesyan, Hilbert-glass transition: New universality of temperature-tuned many-body dynamical quantum criticality, Phys. Rev. X 4, 011052 (2014).
  32. V. Khemani, A. Lazarides, R. Moessner, and S. L. Sondhi, Phase structure of driven quantum systems, Phys. Rev. Lett. 116, 250401 (2016).
  33. X. Mi, M. Ippoliti, C. Quintana, et al., Time-crystalline eigenstate order on a quantum processor, Nature (London) 601, 531 (2022).
  34. A. Lerose, M. Sonner, and D. A. Abanin, Scaling of temporal entanglement in proximity to integrability, Phys. Rev. B 104, 035137 (2021).
  35. A.-G. Penner, H. Schmid, L. I. Glazman, and F. von Oppen, Subharmonic spin correlations and spectral pairing in Floquet time crystals, Phys. Rev. B 111, 184308 (2025).
  36. The corresponding many-body states differ only by a finite number of quasiparticles, so that the many-body eigenphase differences can be expressed as finite sums of quasiparticle eigenphases. While the many-body level spacing is exponentially small, the level spacing of few-particle excitations scales polynomially as ∼1/N2 (for two-particle excitations corresponding to states, which differ by two quasiparticles) or as ∼1/N4 (for four-particle excitations corresponding to states, which differ by four quasiparticles).
  37. J.-P. Bouchaud and A. Georges, Anomalous diffusion in disordered media: Statistical mechanisms, models and physical applications, Phys. Rep. 195, 127 (1990).
  38. A.-G. Penner, F. von Oppen, G. Zaránd, and M. R. Zirnbauer, Hilbert space geometry of random matrix eigenstates, Phys. Rev. Lett. 126, 200604 (2021).
  39. A. S. Jermyn, R. S. K. Mong, J. Alicea, and P. Fendley, Stability of zero modes in parafermion chains, Phys. Rev. B 90, 165106 (2014).
  40. J. Alicea and P. Fendley, Topological phases with parafermions: Theory and blueprints, Annu. Rev. Condens. Matter Phys. 7, 119 (2016).
  41. F. M. Surace, A. Russomanno, M. Dalmonte, A. Silva, R. Fazio, and F. Iemini, Floquet time crystals in clock models, Phys. Rev. B 99, 104303 (2019).
  42. A. Verdeny, J. Puig, and F. Mintert, Quasi-periodically driven quantum systems, Z. Naturforsch. A 71, 897 (2016).
  43. P. T. Dumitrescu, R. Vasseur, and A. C. Potter, Logarithmically slow relaxation in quasiperiodically driven random spin chains, Phys. Rev. Lett. 120, 070602 (2018).
  44. Y. Peng and G. Refael, Time-quasiperiodic topological superconductors with Majorana multiplexing, Phys. Rev. B 98, 220509(R) (2018).
  45. P. J. D. Crowley, I. Martin, and A. Chandran, Topological classification of quasiperiodically driven quantum systems, Phys. Rev. B 99, 064306 (2019).
  46. S. Maity, U. Bhattacharya, A. Dutta, and D. Sen, Fibonacci steady states in a driven integrable quantum system, Phys. Rev. B 99, 020306(R) (2019).
  47. B. Lapierre, K. Choo, A. Tiwari, C. Tauber, T. Neupert, and R. Chitra, Fine structure of heating in a quasiperiodically driven critical quantum system, Phys. Rev. Res. 2, 033461 (2020).
  48. D. M. Long, P. J. D. Crowley, and A. Chandran, Nonadiabatic topological energy pumps with quasiperiodic driving, Phys. Rev. Lett. 126, 106805 (2021).
  49. S. Bhattacharjee, S. Bandyopadhyay, and A. Dutta, Quasilocalization dynamics in a Fibonacci quantum rotor, Phys. Rev. A 106, 022206 (2022).
  50. H. Zhao, F. Mintert, R. Moessner, and J. Knolle, Random multipolar driving: Tunably slow heating through spectral engineering, Phys. Rev. Lett. 126, 040601 (2021).
  51. H. Zhao, M. S. Rudner, R. Moessner, and J. Knolle, Anomalous random multipolar driven insulators, Phys. Rev. B 105, 245119 (2022).
  52. H. Zhao, J. Knolle, and R. Moessner, Temporal disorder in spatiotemporal order, Phys. Rev. B 108, L100203 (2023).
  53. Z.-H. Liu et al., Prethermalization by random multipolar driving on a 78-qubit processor, Nature (London) 650, 79 (2026).
  54. X. Wen, R. Fan, A. Vishwanath, and Y. Gu, Periodically, quasiperiodically, and randomly driven conformal field theories, Phys. Rev. Res. 3, 023044 (2021).
  55. B. Lapierre, L.-H. Mo, and S. Ryu, Entanglement transitions in structured and random nonunitary Gaussian circuits, arXiv:2507.03768.
  56. B. Lapierre, P. Pelliconi, S. Ryu, and J. Sonner, Driven nonunitary dynamics of quantum critical systems, Phys. Rev. B 112, 104322 (2025).
  57. L. Bennett, B. Melchers, and B. Proppe, Curta: A general-purpose high-performance computer at ZEDAT, Freie Universität Berlin, 2020.
  58. F. Möckel, H. Schmid, and F. von Oppen, Data and code for: “Floquet product mode and eigenphase order,” Zenodo, 2026, https://doi.org/10.5281/zenodo.19087203.
