Quadrature for the generalized hydrodynamics equation and absence of shocks in the Lieb-Liniger model

Friedrich Hübner and Benjamin Doyon

PDF

Phys. Rev. B 112, L241101 – Published 1 December, 2025

DOI: https://doi.org/10.1103/5w4p-bxnt

Abstract

In conventional fluids, it is well known that Euler-scale equations are plagued by ambiguiti es and instabilities. In one dimension smooth initial conditions may develop shocks, and weak solutions, such as for domain wall initial conditions (the paradigmatic Riemann problem of hydrodynamics), are not unique (and must be supplemented by physically motivated conditions such as non-negative entropy production). The absence of shock formation experimentally observed in quasi-one-dimensional cold-atomic gases, which are described by the Lieb-Liniger model, provides perhaps the strongest pointer to a modification of the hydrodynamic equation due to integrability. Generalized hydrodynamics (GHD) is the required hydrodynamic theory, taking into account the infinite number of conserved quantities afforded by integrability. We provide a new quadrature for the GHD equation—a solution in terms of a Banach fixed-point problem where time has been explicitly integrated. The quadrature is an efficient numerical solution tool; and it allows us, in the Lieb-Liniger model, to rigorously show that no shock may appear at all times, and, when combined with recent hydrodynamic fluctuation theories, to obtain new expressions for correlations in nonstationary states, establishing for the first time the presence of discontinuities that are fundamental to the nonequilibrium physics of integrable systems.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (54)

  1. O. A. Castro-Alvaredo, B. Doyon, and T. Yoshimura, Emergent hydrodynamics in integrable quantum systems out of equilibrium, Phys. Rev. X 6, 041065 (2016).
  2. B. Bertini, M. Collura, J. De Nardis, and M. Fagotti, Transport in out-of-equilibrium XXZ chains: Exact profiles of charges and currents, Phys. Rev. Lett. 117, 207201 (2016).
  3. G. El, The thermodynamic limit of the Whitham equations, Phys. Lett. A 311, 374 (2003).
  4. M. Schemmer, I. Bouchoule, B. Doyon, and J. Dubail, Generalized hydrodynamics on an atom chip, Phys. Rev. Lett. 122, 090601 (2019).
  5. J.-S. Caux, B. Doyon, J. Dubail, R. Konik, and T. Yoshimura, Hydrodynamics of the interacting Bose gas in the Quantum Newton Cradle setup, SciPost Phys. 6, 070 (2019).
  6. F. Møller, C. Li, I. Mazets, H.-P. Stimming, T. Zhou, Z. Zhu, X. Chen, and J. Schmiedmayer, Extension of the generalized hydrodynamics to the dimensional crossover regime, Phys. Rev. Lett. 126, 090602 (2021).
  7. N. Malvania, Y. Zhang, Y. Le, J. Dubail, M. Rigol, and D. S. Weiss, Generalized hydrodynamics in strongly interacting 1D Bose gases, Science 373, 1129 (2021).
  8. E. Lieb and W. Liniger, Exact analysis of an interacting Bose gas. I. The general solution and the ground state, Phys. Rev. 130, 1605 (1963).
  9. I. Bouchoule and J. Dubail, Generalized hydrodynamics in the one-dimensional Bose gas: theory and experiments, J. Stat. Mech. (2022) 014003.
  10. P. Suret, S. Randoux, A. Gelash, D. Agafontsev, B. Doyon, and G. El, Soliton gas: Theory, numerics, and experiments, Phys. Rev. E 109, 061001 (2024).
  11. B. Doyon, Lecture notes on Generalised Hydrodynamics, SciPost Phys. Lect. Notes 18 (2020).
  12. A. Bastianello, B. Bertini, B. Doyon, and R. Vasseur, Introduction to the special issue on emergent hydrodynamics in integrable many-body systems, J. Stat. Mech. (2022) 014001.
  13. F. H. Essler, A short introduction to Generalized Hydrodynamics, Physica A 631, 127572 (2023), Lecture Notes of the 15th International Summer School of Fundamental Problems in Statistical Physics.
  14. H. Spohn, Hydrodynamic Scales of Integrable Many-Body Systems (World Scientific, Singapore, 2024).
  15. B. Doyon, G. Perfetto, T. Sasamoto, and T. Yoshimura, Emergence of hydrodynamic spatial long-range correlations in nonequilibrium many-body systems, Phys. Rev. Lett. 131, 027101 (2023).
  16. B. Doyon, G. Perfetto, T. Sasamoto, and T. Yoshimura, Ballistic macroscopic fluctuation theory, SciPost Phys. 15, 136 (2023).
  17. B. Doyon, J. Dubail, R. Konik, and T. Yoshimura, Large-scale description of interacting one-dimensional Bose gases: Generalized hydrodynamics supersedes conventional hydrodynamics, Phys. Rev. Lett. 119, 195301 (2017).
  18. G. El, A. Kamchatnov, M. V. Pavlov, and S. Zykov, Kinetic equation for a soliton gas and its hydrodynamic reductions, J. Nonlinear Sci. 21, 151 (2011).
  19. M. V. Pavlov, V. B. Taranov, and G. A. El, Generalized hydrodynamic reductions of the kinetic equation for a soliton gas, Theor. Math. Phys. 171, 675 (2012).
  20. E. Ferapontov, Integration of weakly nonlinear hydrodynamic systems in Riemann invariats, Phys. Lett. A 158, 112 (1991).
  21. B. L. Rozdestvenskii and A. D. Sidorenko, On the impossibility of ‘gradient catastrophe’ for weakly nonlinear systems, Comput. Math. & Math. Phys. 7, 1176 (1967).
  22. T. P. Liu, On the impossibility of ‘gradient catastrophe’ for weakly nonlinear systems, J. Diff. Equ. 33, 92 (1979).
  23. A. Bressan, Hyperbolic Systems of Conservation Laws: The One-Dimensional Cauchy Problem, Vol. 20 (Oxford University Press on Demand, Madrid, 2000).
  24. B. Doyon, H. Spohn, and T. Yoshimura, A geometric viewpoint on generalized hydrodynamics, Nucl. Phys. B 926, 570 (2018).
  25. V. B. Bulchandani, R. Vasseur, C. Karrasch, and J. E. Moore, Solvable hydrodynamics of quantum integrable systems, Phys. Rev. Lett. 119, 220604 (2017).
  26. F. Hübner and B. Doyon, Existence and uniqueness of solutions to the generalized hydrodynamics equation, arXiv:2411.04922 [math-ph].
  27. B. Doyon, Exact large-scale correlations in integrable systems out of equilibrium, SciPost Phys. 5, 054 (2018).
  28. F. S. Møller, G. Perfetto, B. Doyon, and J. Schmiedmayer, Euler-scale dynamical correlations in integrable systems with fluid motion, SciPost Phys. Core 3, 016 (2020).
  29. F. Hübner, L. Biagetti, J. De Nardis, and B. Doyon, Diffusive hydrodynamics from long-range correlations, Phys. Rev. Lett. 134, 187101 (2025).
  30. See Supplemental Material at http://link.aps.org/supplemental/10.1103/5w4p-bxnt for a discussion of (1) our results with other momentum parametrisations, (2) an application to partitioning protocols, (3) expressions for further Riemann-invariants, (4) equivalence of two fixed-point problems, and (5) a derivation of conservation of total charge and entropy, which includes Refs. [50, 51, 52, 53, 54].
  31. B. Doyon, T. Yoshimura, and J.-S. Caux, Soliton gases and generalized hydrodynamics, Phys. Rev. Lett. 120, 045301 (2018).
  32. B. Doyon, F. Hübner, and T. Yoshimura, New classical integrable systems from generalized TT¯-deformations, Phys. Rev. Lett. 132, 251602 (2024).
  33. F. S. Møller and J. Schmiedmayer, Introducing iFluid: a numerical framework for solving hydrodynamical equations in integrable models, SciPost Phys. 8, 041 (2020).
  34. H. Spohn, Large Scale Dynamics of Interacting Particles (Springer, Berlin, Heidelberg, 1991).
  35. B. Pozsgay, T. Gombor, A. Hutsalyuk, Y. Jiang, L. Pristyák, and E. Vernier, Integrable spin chain with Hilbert space fragmentation and solvable real-time dynamics, Phys. Rev. E 104, 044106 (2021).
  36. B. Pozsgay, T. Gombor, and A. Hutsalyuk, Integrable hardrod deformation of the Heisenberg spin chains, Phys. Rev. E 104, 064124 (2021).
  37. B. Doyon, F. Hübner, and T. Yoshimura, Generalised TT¯-deformations of classical free particles, arXiv:2312.14855 [cond-mat.stat-mech].
  38. D. A. Croydon and M. Sasada, Generalized hydrodynamic limit for the BoxBall system, Commun. Math. Phys. 383, 427 (2021).
  39. M. Takahashi, Thermodynamics of One-Dimensional Solvable Models (Cambridge University Press, Cambridge, 1999).
  40. F. Hübner, E. Vernier, and L. Piroli, Generalized hydrodynamics of integrable quantum circuits, SciPost Phys. 18, 135 (2025).
  41. B. Doyon and H. Spohn, Drude weight for the Lieb-Liniger Bose gas, SciPost Phys. 3, 039 (2017).
  42. This means the jump develops faster than the hydrodynamic time scale.
  43. B. Doyon and T. Yoshimura, A note on generalized hydrodynamics: inhomogeneous fields and other concepts, SciPost Phys. 2, 014 (2017).
  44. J. De Nardis, D. Bernard, and B. Doyon, Hydrodynamic diffusion in integrable systems, Phys. Rev. Lett. 121, 160603 (2018).
  45. J. De Nardis, D. Bernard, and B. Doyon, Diffusion in generalized hydrodynamics and quasiparticle scattering, SciPost Phys. 6, 049 (2019).
  46. J. De Nardis and B. Doyon, Hydrodynamic gauge fixing and higher order hydrodynamic expansion, J. Phys. A: Math. Theor. 56, 245001 (2023).
  47. J. Bezanson, A. Edelman, S. Karpinski, and V. B. Shah, Julia: A fresh approach to numerical computing, SIAM Rev. 59, 65 (2017).
  48. S. Olver and A. Townsend, A practical framework for infinitedimensional linear algebra, in Proceedings of the 1st Workshop for High Performance Technical Computing in Dynamic Languages – HPTCDL ‘14 (IEEE, New Orleans, 2014).
  49. King's College London. (2022). King's computational research, engineering and technology environment (CREATE). Retrieved June 30, 2023, from https://doi.Org/10.18742/rnvf-m076.
  50. T. Bonnemain, B. Doyon, and G. El, Generalized hydrodynamics of the KdV soliton gas, J. Phys. A: Math. Theor. 55, 374004 (2022).
  51. C. N. Yang and C. P. Yang, Thermodynamics of a one dimensional system of bosons with repulsive delta-function interaction, J. Stat. Phys. 10, 1115 (1969).
  52. A. Zamolodchikov, Thermodynamic Bethe ansatz in relativistic models: Scaling 3-state potts and Lee-Yang models, Nucl. Phys. B 342, 695 (1990).
  53. P. Fendley and H. Saleur, Nonequilibrium dc noise in a Luttinger liquid with an impurity, Phys. Rev. B 54, 10845 (1996).
  54. B. Doyon and H. Spohn, Dynamics of hard rods with initial domain wall state, J. Stat. Mech. (2017) 073210.
