Hybrid bound states in the continuum beyond the diffraction limit

Ji Tong Wang1,*,† and Nicolae C. Panoiu1,2,‡

  • 1Department of Electronic and Electrical Engineering, University College London, Torrington Place, London WC1E 7JE, United Kingdom
  • 2Wuzhen Laboratory, Jiaxing 314500, People's Republic of China

  • *Contact author: jitong.wang@alumni.ucl.ac.uk
  • †Present address: Emergent Photonics Research Centre, Department of Physics, Loughborough University, Loughborough LE11 3TU, United Kingdom.
  • ‡Contact author: n.panoiu@ucl.ac.uk
PDF

Phys. Rev. B 114, L111414 – Published 27 August, 2026

DOI: https://doi.org/10.1103/3ym7-s255

Abstract

Bound states in the continuum (BICs) have greatly impacted our ability to manipulate light-matter interactions at the nanoscale. However, in periodic structures, BICs are typically realized below the diffraction limit, thus leaving a broad spectral domain largely unexplored. Here, we introduce another type of at-Γ BICs of photonic crystal (PhC) slabs supporting higher-diffraction orders, which we call hybrid BICs (h-BICs), whereby symmetry protection and parameter tuning are utilized to suppress light emission in the zeroth- and higher-diffraction orders, respectively. By tuning certain structural parameters of the PhC slab, we fully characterize the dynamics of the topological structure of these h-BICs, including the generation, merging, splitting, and annihilation of circularly polarized states. We further show that the relative amount of light radiated in the first-order diffraction channels can be effectively controlled by simply breaking the C4v symmetry of the PhC slab. Our findings reveal a versatile approach to realize different types of BICs above the diffraction limit, and could potentially inspire efforts toward the development of photonic nanodevices, such as multivortex-beam generators, frequency converters, and lasers.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (37)

  1. C. W. Hsu, B. Zhen, A. D. Stone, J. D. Joannopoulos, and M. Soljacic, Bound states in the continuum, Nat. Rev. Mater. 1, 16048 (2016).
  2. M. Kang, T. Liu, C. T. Chan, and M. Xiao, Applications of bound states in the continuum in photonics, Nat. Rev. Phys. 5, 659 (2023).
  3. L. Huang, L. Xu, D. A. Powell, W. J. Padilla, and A. E. Miroshnichenko, Resonant leaky modes in all-dielectric metasystems: Fundamentals and applications, Phys. Rep. 1008, 1 (2023).
  4. H. M. Doeleman, F. Monticone, W. den Hollander, A. Alu, and A. F. Koenderink, Experimental observation of a polarization vortex at an optical bound state in the continuum, Nat. Photonics 12, 397 (2018).
  5. Y. Zhang, A. Chen, W. Liu, C. W. Hsu, B. Wang, F. Guan, X. Liu, L. Shi, L. Lu, and J. Zi, Observation of polarization vortices in momentum space, Phys. Rev. Lett. 120, 186103 (2018).
  6. J. Wang, P. Li, X. Zhao, Z. Qian, X. Wang, F. Wang, X. Zhou, D. Han, C. Peng, L. Shi, and J. Zi, Optical bound states in the continuum in periodic structures: Mechanisms, effects, and applications, Photonics Insights 3, R01 (2024).
  7. A. Tittl, A. Leitis, M. Liu, F. Yesilkoy, D.-Y. Choi, D. N. Neshev, Y. S. Kivshar, and H. Altug, Imaging-based molecular barcoding with pixelated dielectric metasurfaces, Science 360, 1105 (2018).
  8. F. Yesilkoy, E. R. Arvelo, Y. Jahani, M. Liu, A. Tittl, V. Cevher, Y. Kivshar, and H. Altug, Ultrasensitive hyperspectral imaging and biodetection enabled by dielectric metasurfaces, Nat. Photon. 13, 390 (2019).
  9. A. Aigner, T. Weber, A. Wester, S. A. Maier, and A. Tittl, Continuous spectral and coupling-strength encoding with dual-gradient metasurfaces, Nat. Nanotechnol. 19, 1804 (2024).
  10. A. Kodigala, T. Lepetit, Q. Gu, B. Bahari, Y. Fainman, and B. Kante, Lasing action from photonic bound states in continuum, Nature (London) 541, 196 (2017).
  11. G. Salerno, R. Heilmann, K. Arjas, K. Aronen, J. P. Martikainen, and P. Torma, Loss-driven topological transitions in lasing, Phys. Rev. Lett. 129, 173901 (2022).
  12. R. Contractor, W. Noh, W. Redjem, W. Qarony, E. Martin, S. Dhuey, A. Schwartzberg, and B. Kante, Scalable single-mode surface-emitting laser via open-Dirac singularities, Nature (London) 608, 692 (2022).
  13. J. Cui, S. Han, B. Zhu, C. Wang, Y. Chua, Q. Wang, L. Li, A. G. Davies, E. H. Linfield, and Q. J. Wang, Ultracompact multibound-state-assisted flat-band lasers, Nat. Photon. 19, 643 (2025).
  14. M. V. Gorkunov, A. A. Antonov, and Y. S. Kivshar, Metasurfaces with maximum chirality empowered by bound states in the continuum, Phys. Rev. Lett. 125, 093903 (2020).
  15. A. Overvig, N. Yu, and A. Alu, Chiral quasi-bound states in the continuum, Phys. Rev. Lett. 126, 073001 (2021).
  16. Y. Chen, H. Deng, X. Sha, W. Chen, R. Wang, Y. H. Chen, D. Wu, J. Chu, Y. S. Kivshar, S. Xiao, and C. W. Qiu, Observation of intrinsic chiral bound states in the continuum, Nature (London) 613, 474 (2023).
  17. K. Koshelev, Y. Tang, K. Li, D.-Y. Choi, G. Li, and Y. Kivshar, Nonlinear metasurfaces governed by bound states in the continuum, ACS Photonics 6, 1639 (2019).
  18. Z. Liu, Y. Xu, Y. Lin, J. Xiang, T. Feng, Q. Cao, J. Li, S. Lan, and J. Liu, High-Q quasibound states in the continuum for nonlinear metasurfaces, Phys. Rev. Lett. 123, 253901 (2019).
  19. D. Gromyko, J. S. Loh, J. Feng, C. W. Qiu, and L. Wu, Enabling all-to-circular polarization up-conversion by nonlinear chiral metasurfaces with rotational symmetry, Phys. Rev. Lett. 134, 023804 (2025).
  20. J. T. Wang and N. C. Panoiu, Nonlinear optical metasurfaces empowered by bound-states in the continuum, Rev. Phys. 13, 100117 (2025).
  21. C. W. Hsu, B. Zhen, J. Lee, S. L. Chua, S. G. Johnson, J. D. Joannopoulos, and M. Soljacic, Observation of trapped light within the radiation continuum, Nature (London) 499, 188 (2013).
  22. K. Koshelev, S. Lepeshov, M. Liu, A. Bogdanov, and Y. Kivshar, Asymmetric metasurfaces with high-Q resonances governed by bound states in the continuum, Phys. Rev. Lett. 121, 193903 (2018).
  23. M. Kang, S. Zhang, M. Xiao, and H. Xu, Merging bound states in the continuum at off-high symmetry points, Phys. Rev. Lett. 126, 117402 (2021).
  24. C. Schiattarella, S. Romano, L. Sirleto, V. Mocella, I. Rendina, V. Lanzio, F. Riminucci, A. Schwartzberg, S. Cabrini, J. Chen, L. Liang, X. Liu, and G. Zito, Directive giant upconversion by supercritical bound states in the continuum, Nature (London) 626, 765 (2024).
  25. W. Chen, Y. Chen, and W. Liu, Singularities and Poincaré indices of electromagnetic multipoles, Phys. Rev. Lett. 122, 153907 (2019).
  26. B. Zhen, C. W. Hsu, L. Lu, A. D. Stone, and M. Soljacic, Topological nature of optical bound states in the continuum, Phys. Rev. Lett. 113, 257401 (2014).
  27. J. Jin, X. Yin, L. Ni, M. Soljacic, B. Zhen, and C. Peng, Topologically enabled ultrahigh-Q guided resonances robust to out-of-plane scattering, Nature (London) 574, 501 (2019).
  28. M. Kang, M. Xiao, and C. T. Chan, Janus bound states in the continuum with asymmetric topological charges, Phys. Rev. Lett. 134, 013805 (2025).
  29. T. Yoda and M. Notomi, Generation and annihilation of topologically protected bound states in the continuum and circularly polarized states by symmetry breaking, Phys. Rev. Lett. 125, 053902 (2020).
  30. A. Cerjan, C. Jorg, S. Vaidya, S. Augustine, W. A. Benalcazar, C. W. Hsu, G. von Freymann, and M. C. Rechtsman, Observation of bound states in the continuum embedded in symmetry bandgaps, Sci. Adv. 7, eabk1117 (2021).
  31. W. Ye, Y. Gao, and J. Liu, Singular points of polarizations in the momentum space of photonic crystal slabs, Phys. Rev. Lett. 124, 153904 (2020).
  32. P. Hu, C. Xie, Q. Song, A. Chen, H. Xiang, D. Han, and J. Zi, Bound states in the continuum based on the total internal reflection of Bloch waves, Natl. Sci. Rev. 10, nwac043 (2023).
  33. Z. F. Sadrieva, I. S. Sinev, K. L. Koshelev, A. Samusev, I. V. Iorsh, O. Takayama, R. Malureanu, A. A. Bogdanov, and A. V. Lavrinenko, Transition from optical bound states in the continuum to leaky resonances: Role of substrate and roughness, ACS Photonics 4, 723 (2017).
  34. COMSOL Multiphysics®, www.comsol.com.
  35. Synopsys' RSoft Photonic Device Tools®, www.synopsys.com.
  36. See Supplemental Material at http://link.aps.org/supplemental/10.1103/3ym7-s255 for details of (S1) Numerical simulation methods; (S2) Bragg-diffraction orders and partition of band diagram; (S3) Definition of 2D polarization vector for topological charge calculation; (S4) Q factor in a radiative channel; (S5) Fourier analysis of radiative fields; (S6) Further characterization of hybrid BICs; (S7) Symmetry properties of polarization in first-order diffraction channels; (S8) Further analysis of polarization maps; (S9) Tuning of radiation intensity in first-order diffraction channels; (S10) Photonic band structure around the hybrid BIC and the corresponding linear optical response; (S11) Additional hybrid BICs with up to first-order diffraction channels; (S12) Hybrid BICs with up to second-order diffraction channels; and (S13) Example of hybrid BICs in PhC slabs with hexagonal lattice, which includes Ref.  [37].
  37. H. Qin, S. Chen, W. Zhang, H. Zhang, R. Pan, J. Li, L. Shi, J. Zi, and X. Zhang, Optical moiré bound states in the continuum, Nat. Commun. 15, 9080 (2024).
