Hexagonal Ge/Si0.25Ge0.75 quantum wells: Prediction of quantization and light-emission strength

Abderrezak Belabbes1,2,*, Martin Keller2, Jürgen Furthmüller2, Silvana Botti3,2, and Friedhelm Bechstedt2

  • 1Department of Physics, Sultan Qaboos University, P.O. Box 36, PC 123, Muscat, Oman
  • 2Institut für Festkörpertheorie und -optik, Friedrich-Schiller-Universität Jena, Max-Wien-Platz 1, 07743 Jena, Germany
  • 3Research Center Future Energy Materials and Systems, Interdisciplinary Centre for Advanced Materials Simulation, Faculty of Physics and Astronomy, Ruhr University Bochum, Universitätsstrasse 150, 44801 Bochum, Germany

  • *Contact author: abderrezak.belabbes@uni-jena.de
PDF

Phys. Rev. B 112, 205304 – Published 24 November, 2025

DOI: https://doi.org/10.1103/3l5b-b8ry

Abstract

We investigate heterostructures composed of hexagonal Ge quantum wells embedded within hexagonal Si0.25Ge0.75 alloy layers, systematically considering variations in crystallographic orientation, well thickness, and external biaxial strain. This study employs density functional theory together with accurate functionals for calculations of the quasiparticle electronic structure. Overall, the heterostructures exhibit type-I band alignment, with the localization of electron and hole wave functions predominantly within the hexagonal Ge regions. The quantum confinement of both charge carrier types is determined by the orientation and thickness of the Ge layer for three different external strains. The results obtained can be interpreted within a rectangular potential-well model, with characteristic parameters derived from ab initio band structures of hexagonal Ge and Si0.25Ge0.75, as well as their strained multiquantum well structures, properly aligned via the branch point energies. Besides confinement energies and subbands, optical transition strengths are also discussed.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (40)

  1. D. J. Paul, Si/SiGe heterostructures: from material and physics to devices and circuits, Semicond. Sci. Technol. 19, R75 (2004).
  2. C. G. Van de Walle and R. M. Martin, Theoretical calculations of heterojunction discontinuities in the Si/Ge system, Phys. Rev. B 34, 5621 (1986).
  3. M. El Kurdi, S. Sauvage, G. Fishman, and P. Boucaud, Band-edge alignment of SiGeSi quantum wells and SiGeSi self-assembled islands, Phys. Rev. B 73, 195327 (2006).
  4. M. Friesen, P. Rugheimer, D. E. Savage, M. G. Lagally, D. W. van der Weide, R. Joynt, and M. A. Eriksson, Practical design and simulation of silicon-based quantum-dot qubits, Phys. Rev. B 67, 121301(R) (2003).
  5. L. R. Schreiber and H. Bluhm, Silicon comes back, Nat. Nanotechnol. 9, 966 (2014).
  6. B. Paquelet Wuetz, D. Degli Esposti, A.-M. J. Zwerver, S. V. Amitonov, M. Botifoll, J. Arbiol, A. Sammak, L. M. Vandersypen, M. Russ, and G. Scappucci, Reducing charge noise in quantum dots by using thin silicon quantum wells, Nat. Commun. 14, 1385 (2023).
  7. Y. Liu, K.-P. Gradwohl, C.-H. Lu, K. Dadzis, Y. Yamamoto, L. Becker, P. Storck, T. Remmele, T. Boeck, C. Richter, and M. Albrecht, Strain relaxation from annealing of SiGe heterostructures for qubits, J. Appl. Phys. 134, 035302 (2023).
  8. D. Jirovec, A. Hofmann, A. Ballabio, P. M. Mutter, G. Tavani, M. Botifoll, A. Crippa, J. Kukucka, O. Sagi, F. Martins, J. Saez-Mollejo, I. Prieto, M. Borovkov, J. Arbiol, D. Chrastina, G. Isella, and G. Katsaros, A singlet-triplet hole spin qubit in planar Ge, Nat. Mater. 20, 1106 (2021).
  9. Y. Liu, K.-P. Gradwohl, C.-H. Lu, T. Remmele, Y. Yamamoto, M. H. Zoellner, T. Schroeder, T. Boeck, H. Amari, C. Richter, and M. Albrecht, Role of critical thickness in SiGe/Si/SiGe heterostructure design for qubits, J. Appl. Phys. 132, 085302 (2022).
  10. S. S. Iyer and Y. H. Xie, Light emission from silicon, Science 260, 40 (1993).
  11. E. M. T. Fadaly, A. Dijkstra, J. R. Suckert, D. Ziss, M. A. J. van Tilburg, C. Mao, Y. Ren, V. T. van Lange, K. Korzun, S. Kölling, M. A. Verheijen, D. Busse, C. Rödl, J. Furthmüller, F. Bechstedt, J. Stangl, J. J. Finley, S. Botti, J. E. M. Haverkort, and E. P. A. M. Bakkers, Direct-bandgap emission from hexagonal Ge and SiGe alloys, Nature (London) 580, 205 (2020).
  12. P. Borlido, J. R. Suckert, J. Furthmüller, F. Bechstedt, S. Botti, and C. Rödl, From pseudo-direct hexagonal germanium to direct silicon-germanium alloys, Phys. Rev. Mater. 5, 114604 (2021).
  13. P. Borlido, F. Bechstedt, S. Botti, and C. Rödl, Ensemble averages of ab initio optical, transport, and thermoelectric properties of hexagonal SixGe1−x alloys, Phys. Rev. Mater. 7, 014602 (2023).
  14. A. Belabbes, F. Bechstedt, and S. Botti, Giant optical oscillator strengths in perturbed hexagonal germanium, Phys. Status Solidi - Rapid Res. Lett. 16, 2100555 (2022).
  15. J. R. Suckert, C. Rödl, J. Furthmüller, F. Bechstedt, and S. Botti, Efficient strain-induced light emission in lonsdaleite germanium, Phys. Rev. Mater. 5, 024602 (2021).
  16. H. Kroemer, A proposed class of hetero-junction injection lasers, Proc. IEEE 51, 1782 (1963).
  17. W. H. J. Peeters, V. T. van Lange, A. Belabbes, M. C. van Hemert, M. M. Jansen, R. Farina, M. A. J. van Tilburg, M. A. Verheijen, S. Botti, F. Bechstedt, J. E. M. Haverkort, and E. P. A. M. Bakkers, Direct bandgap quantum wells in hexagonal silicon germanium, Nat. Commun. 15, 5252 (2024).
  18. M. Virgilio and G. Grosso, Type-I alignment and direct fundamental gap in SiGe based heterostructures, J. Phys.: Condens. Matter. 18, 1021 (2006).
  19. L. Yang, J. R. Watling, R. C. Wilkins, M. Borici, J. R. Barker, A. Asenov, and S. Roy, Si/SiGe heterostructure parameters for device simulations, Semicond. Sci. Technol. 19, 1174 (2004).
  20. G. Di Liberto and G. Pacchioni, Band offset in semiconductor heterojunctions, J. Phys.: Condens. Matter. 33, 415002 (2021).
  21. A. Belabbes, S. Botti, and F. Bechstedt, Band lineup at hexagonal SixGe1−x/SiyGe1−y alloy interfaces, Phys. Rev. B 106, 085303 (2022).
  22. A. Belabbes, S. Botti, and F. Bechstedt, Erratum: Band lineup at hexagonal SixGe1−x/SiyGe1−y alloy interfaces [Phys. Rev. B 106, 085303 (2022)], Phys. Rev. B 107, 039903(E) (2023).
  23. A. D. Becke and E. R. Johnson, A simple effective potential for exchange, J. Chem. Phys. 124, 221101 (2006).
  24. F. Tran, P. Blaha, and K. Schwarz, Band gap calculations with Becke-Johnson exchange potential, J. Phys.: Condens. Matter 19, 196208 (2007).
  25. F. Tran and P. Blaha, Accurate band gaps of semiconductors and insulators with a semilocal exchange-correlation potential, Phys. Rev. Lett. 102, 226401 (2009).
  26. M. Laubscher, S. Küfner, P. Kroll, and F. Bechstedt, Amorphous Ge quantum dots embedded in crystalline Si: ab initio results, J. Phys.: Condens. Matter 27, 405302 (2015).
  27. C. Rödl, J. Furthmüller, J. R. Suckert, V. Armuzza, F. Bechstedt, and S. Botti, Accurate electronic and optical properties of hexagonal germanium for optoelectronic applications, Phys. Rev. Mater. 3, 034602 (2019).
  28. Y.-S. Kim, K. Hummer, and G. Kresse, Accurate band structures and effective masses for InP, InAs, and InSb using hybrid functionals, Phys. Rev. B 80, 035203 (2009).
  29. P. Borlido, T. Aull, A. W. Huran, F. Tran, M. A. L. Marques, and S. Botti, Large-scale benchmark of exchange-correlation functionals for the determination of electronic band gaps of solids, J. Chem. Theory Comput. 15, 5069 (2019).
  30. G. Kresse and J. Furthmüller, Efficient iterative schemes for ab initio total-energy calculations using a plane-wave basis set, Phys. Rev. B 54, 11169 (1996).
  31. G. Kresse and J. Furthmüller, Efficiency of ab-initio total energy calculations for metals and semiconductors using a plane-wave basis set, Comput. Mater. Sci. 6, 15 (1996).
  32. G. Kresse and D. Joubert, From ultrasoft pseudopotentials to the projector augmented-wave method, Phys. Rev. B 59, 1758 (1999).
  33. J. P. Perdew, A. Ruzsinszky, G. I. Csonka, O. A. Vydrov, G. E. Scuseria, L. A. Constantin, X. Zhou, and K. Burke, Restoring the density-gradient expansion for exchange in solids and surfaces, Phys. Rev. Lett. 100, 136406 (2008).
  34. W. Kohn and L. J. Sham, Self-consistent equations including exchange and correlation effects, Phys. Rev. 140, A1133 (1965).
  35. See Supplemental Material at http://link.aps.org/supplemental/10.1103/3l5b-b8ry for details regarding the supporting data for Ge/Si0.25Ge0.75 quantum wells; the relevant bulk band structures and projected DOS of 2H-Ge and 2H-Si0.25Ge0.75; a depiction of the bulk hexagonal BZ and its projections onto the two-dimensional BZs of the m-, a-, and c-plane interfaces; a full set of calculated effective masses for various subbands and external strains; and a list of optical intersubband transition energies and their dipole matrix elements.
  36. A. Schleife, F. Fuchs, C. Rödl, J. Furthmüller, and F. Bechstedt, Branch-point energies and band discontinuities of III-nitrides and III-/II-oxides from quasiparticle band-structure calculations, Appl. Phys. Lett. 94, 012104 (2009).
  37. C. Kittel, Introduction to Solid State Physics, 8th ed. (John Wiley and Sons Inc., New York, Chichester, 2005).
  38. H. Haug and S. Koch, Quantum Theory of the Optical and Electronic Properties of Semiconductors (World Scientific, Singapore, 2009).
  39. V. Wang, N. Xu, J.-C. Liu, G. Tang, and W.-T. Geng, VASPKIT: A user-friendly interface facilitating high-throughput computing and analysis using VASP code, Comput. Phys. Commun. 267, 108033 (2021).
  40. F. Bechstedt, Many-Body Approach to Electronic Excitations, Springer Series in Solid-State Sciences, Vol. 181 (Springer, Berlin, 2015).
