  • Letter
  • Open Access

Theory of planar ballistic SNS junctions at T=0

Edouard B. Sonin*

  • *Contact author: sonin@cc.huji.ac.il
PDF

Phys. Rev. B 113, L060502 – Published 2 February, 2026

DOI: https://doi.org/10.1103/2g8w-bbpd

Abstract

This Letter presents the theory of planar ballistic superconductor–normal metal–superconductor junctions at T=0 for any normal layer thickness L taking into account phase gradients in superconducting leads. The current-phase relation was derived in the model of the steplike pairing potential analytically and is exact in the limit of large ratio of the Fermi energy to the superconducting gap. At small L (short junction) the obtained current-phase relation is essentially different from that in the previous theory neglecting phase gradients. It was confirmed by recent numerical calculations and was observed in the experiment on short InAs nanowire Josephson junctions. The analysis resolves the problem with the charge conservation law in the steplike pairing potential model.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (19)

  1. I. O. Kulik, Macroscopic quantization and proximity effect in S–N–S junctions, Zh. Eksp. Teor. Fiz. 57, 1745 (1969) [Sov. Phys. JETP 30, 944 (1970)].
  2. C. Ishii, Josephson currents through junctions with normal metal barriers, Prog. Theor. Phys. 44, 1525 (1970).
  3. J. Bardeen and J. L. Johnson, Josephson current flow in pure superconducting-normal-superconducting junctions, Phys. Rev. B 5, 72 (1972).
  4. P. G. de Gennes, Superconductivity of Metals and Alloys (Benjamin, New York, 1966).
  5. A. F. Andreev, Electron spectrum of the intermediate state of superconductors, Zh. Eksp. Teor. Fiz. 49, 655 (1964) [Sov. Phys. JETP 22, 455 (1966)].
  6. S. V. Bakurskiy, A. A. Golubov, and M. Y. Kupriyanov, Basic properties of the Josephson effect, in Fundamentals and Frontiers of the Josephson Effect, edited by F. Tafuri (Springer, Cham, Switzerland, 2019), Chap. 3, pp. 81–116.
  7. E. Thuneberg, Square-well model for superconducting pair-potential, J. Low Temp. Phys. 217, 12 (2024).
  8. E. R. Mucciolo, J. Nieminen, X. Xiao, and W.-C. Chiu, Green's function methods for computing supercurrents in Josephson junctions, arXiv:2509.07165.
  9. E. B. Sonin, Ballistic SNS sandwich as a Josephson junction, Phys. Rev. B 104, 094517 (2021); 105, 219902(E) (2022); 110, 139902(E) (2024).
  10. E. Sonin, Andreev reflection, Andreev states, and long ballistic SNS junction, J. Low Temp. Phys. 217, 24 (2024).
  11. R. A. Riedel, L.-F. Chang, and P. F. Bagwell, Critical current and self-consistent order parameter of a superconductor–normal-metal–superconductor junction, Phys. Rev. B 54, 16082 (1996).
  12. S. Krekels, V. Levajac, K. Moors, G. Simion, and B. Sorée, Current conservation in the self-consistent Josephson junction, Phys. Rev. B 112, 144508 (2025).
  13. E. Thuneberg, Comment on “Ballistic SNS sandwich as a Josephson junction,” Phys. Rev. B 108, 176501 (2023).
  14. E. B. Sonin, Reply to comment on “Ballistic SNS sandwich as a Josephson junction,” Phys. Rev. B 108, 176502 (2023).
  15. I. O. Kulik and A. A. N. Omel'yanchouk, Josephson effect in superconducting bridges: Microscopic theory, Fiz. Nizk. Temp. 4, 296 (1978) [Sov. J. Low Temp. Phys. 4, 142 (1978)].
  16. E. B. Sonin, Comment on “Square-well model for superconducting pair-potential,” arXiv:2410.12580.
  17. Z. G. Ivanov, M. Y. Kupriyanov, K. K. Likharev, S. V. Meriakri, and O. V. Snigirev, Boundary conditions for the Eilenberger and Usadel equations and properties of “dirty” SNS sandwiches, Fiz. Nizk. Temp. 7, 560 (1981) [Sov. J. Low Temp. Phys. 7, 274 (1981)].
  18. A. A. Golubov, M. Y. Kupriyanov, and E. Il'ichev, The current-phase relation in Josephson junctions, Rev. Mod. Phys. 76, 411 (2004).
  19. E. M. Spanton, M. Deng, S. Vaitiekėnas, P. Krogstrup, J. Nygård, C. M. Marcus, and K. A. Moler, Current–phase relations of few-mode InAs nanowire Josephson junctions, Nat. Phys. 13, 1177 (2017).

Outline

Information

Phys. Rev. B 113, L060502– Published 2 February, 2026
  • Received 16 December 2024
  • Revised 18 December 2025
  • Accepted 7 January 2026
