Fabry-Pérot quasinormal modes for topological edge states
Phys. Rev. B 113, L140102 – Published 20 April, 2026
DOI: https://doi.org/10.1103/1hy4-j86q
Abstract
Topological waveguides supporting quantum valley Hall edge states confine waves to interfaces and, due to topological protection, are resistant to backscattering even in the presence of defects. These topological insulators are typically studied by means of an infinite spectral problem. However, practical implementations are necessarily finite. In this work, we propose an alternative framework for analyzing topologically nontrivial states in open, finite systems. Our approach is based on a quasinormal modal expansion method, which directly characterizes the existence and excitation of these modes within the open system. The resulting spectrum is complex and discrete and fully describes the topologically nontrivial states, revealing an analogy of topological mode steering as a dispersive Fabry-Pérot cavity, with a dispersion relation closely related to that of the corresponding infinite (Floquet-Bloch) ribbon problem. Our results illustrate how topologically protected waveguiding can be understood in terms of leaky cavity modes and offers a powerful framework for analyzing finite topological devices.
Physics Subject Headings (PhySH)
Article Text
Supplemental Material
References (38)
- A. B. Khanikaev, S. Hossein Mousavi, W.-K. Tse, M. Kargarian, A. H. MacDonald, and G. Shvets, Photonic topological insulators, Nat. Mater. 12, 233 (2013).
- L. Lu, J. D. Joannopoulos, and M. Soljačić, Topological photonics, Nat. Photon. 8, 821 (2014).
- X. Ni, S. Yves, A. Krasnok, and A. Alu, Topological metamaterials, Chem. Rev. 123, 7585 (2023).
- T. Ozawa, H. M. Price, A. Amo, N. Goldman, M. Hafezi, L. Lu, M. C. Rechtsman, D. Schuster, J. Simon, O. Zilberberg, et al., Topological photonics, Rev. Mod. Phys. 91, 015006 (2019).
- J. Noh, S. Huang, K. P. Chen, and M. C. Rechtsman, Observation of photonic topological valley Hall edge states, Phys. Rev. Lett. 120, 063902 (2018).
- S. Mittal, V. V. Orre, D. Leykam, Y. D. Chong, and M. Hafezi, Photonic anomalous quantum Hall effect, Phys. Rev. Lett. 123, 043201 (2019).
- M. P. Makwana and R. V. Craster, Designing multidirectional energy splitters and topological valley supernetworks, Phys. Rev. B 98, 235125 (2018).
- R. Wiltshaw, R. V. Craster, and M. P. Makwana, Asymptotic approximations for Bloch waves and topological mode steering in a planar array of Neumann scatterers, Wave Motion 99, 102662 (2020).
- R. Wiltshaw, J. M. De Ponti, and R. V. Craster, Analytical solutions for Bloch waves in resonant phononic crystals: deep-subwavelength energy splitting and mode steering between topologically protected interfacial and edge states, Q. J. Mech. Appl. Math. 76, 163 (2023).
- N. Laforge, R. Wiltshaw, R. V. Craster, V. Laude, J. A. Iglesias Martínez, G. Dupont, S. Guenneau, M. Kadic, and M. P. Makwana, Acoustic topological circuitry in square and rectangular phononic crystals, Phys. Rev. Appl. 15, 054056 (2021).
- Q. Yan, R. Ma, Q. Lyu, X. Hu, and Q. Gong, Transmissible topological edge states based on Su-Schrieffer-Heeger photonic crystals with defect cavities, Nanophotonics 13, 1397 (2024).
- X.-X. Li, B. Li, and P.-B. Li, Simulation of topological phases with color center arrays in phononic crystals, Phys. Rev. Res. 2, 013121 (2020).
- G. J. Chaplain, J. M. De Ponti, G. Aguzzi, A. Colombi, and R. V. Craster, Topological rainbow trapping for elastic energy harvesting in graded Su-Schrieffer-Heeger systems, Phys. Rev. Appl. 14, 054035 (2020).
- H. Okita, R. Wiltshaw, A. K. Gautam, O. B. Wright, and H. OGI, A mass-loaded topological switching mechanism for phononic biosensors, Jpn. J. Appl. Phys. 65, 03SP30 (2026).
- Z. Wang, Y. Chong, J. D. Joannopoulos, and M. Soljačić, Observation of unidirectional backscattering-immune topological electromagnetic states, Nature (London) 461, 772 (2009).
- R. K. Pal and M. Ruzzene, Edge waves in plates with resonators: An elastic analogue of the quantum valley Hall effect, New J. Phys. 19, 025001 (2017).
- M. I. Shalaev, W. Walasik, A. Tsukernik, Y. Xu, and N. M. Litchinitser, Robust topologically protected transport in photonic crystals at telecommunication wavelengths, Nat. Nanotechnol. 14, 31 (2019).
- E. Levy and E. Akkermans, Topological boundary states in 1D: An effective Fabry-Perot model, Eur. Phys. J.: Spec. Top. 226, 1563 (2017).
- F. Barra and P. Gaspard, Scattering in periodic systems: From resonances to band structure, J. Phys. A: Math. Gen. 32, 3357 (1999).
- P. Kalozoumis, G. Theocharis, V. Achilleos, S. Félix, O. Richoux, and V. Pagneux, Finite-size effects on topological interface states in one-dimensional scattering systems, Phys. Rev. A 98, 023838 (2018).
- D. Muis, Y. Li, R. Barczyk, S. Arora, L. Kuipers, G. Shvets, and E. Verhagen, Broadband localization of light at the termination of a topological photonic waveguide, Sci. Adv. 11, eadr9569 (2025).
- V. P. Shestopalov and Y. V. Shestopalov, Spectral Theory and Excitation of Open Structures, Electromagnetic Waves Vol. 42 (IET, The Institution of Engineering and Technology, London, UK, 1996).
- S. Dyatlov and M. Zworski, Mathematical Theory of Scattering Resonances, Graduate Studies in Mathematics Vol. 200 (American Mathematical Society, Providence, RI, 2019).
- P. T. Kristensen and S. Hughes, Modes and mode volumes of leaky optical cavities and plasmonic nanoresonators, ACS Photon. 1, 2 (2014).
- B. Vial, M. Martí Sabaté, R. Wiltshaw, S. Guenneau, and R. V. Craster, Quasinormal mode expansion in thin elastic plates, Phys. Rev. B 110, 174305 (2024).
- D. Torrent, D. Mayou, and J. Sánchez-Dehesa, Elastic analog of graphene: Dirac cones and edge states for flexural waves in thin plates, Phys. Rev. B 87, 115143 (2013).
- P. A. Martin, Multiple Scattering: Interaction of Time-Harmonic Waves with N Obstacles, Encyclopedia of Mathematics and Its Applications Vol. 107 (Cambridge University Press, Cambridge, England, 2006).
- See Supplemental Material at http://link.aps.org/supplemental/10.1103/1hy4-j86q for information about the multiple scattering model and the QNM expansion, which includes Refs. [29, 30, 31, 32, 33].
- S. Güttel and F. Tisseur, The nonlinear eigenvalue problem, Acta Numer. 26, 1 (2017).
- M. Van Barel and P. Kravanja, Nonlinear eigenvalue problems and contour integrals, J. Comput. Appl. Math. 292, 526 (2016).
- D. Evans and R. Porter, Penetration of flexural waves through a periodically constrained thin elastic plate in vacuo and floating on water, J. Eng. Math. 58, 317 (2007).
- M. Duy Truong, A. Nicolet, G. Demésy, and F. Zolla, Continuous family of exact dispersive quasi-normal modal (DQNM) expansions for dispersive photonic structures, Opt. Express 28, 29016 (2020).
- M. V. Keldysh, On the completeness of the eigenfunctions of some classes of non-selfadjoint linear operators, Russ. Math. Surv. 26, 15 (1971).
- K. Sakoda, Optical Properties of Photonic Crystals, Springer Series in Optical Sciences Vol. 80 (Springer, Berlin, 2004).
- M. P. Makwana and G. Chaplain, Tunable three-way topological energy-splitter, Sci. Rep. 9, 18939 (2019).
- E. A. Muljarov, W. Langbein, and R. Zimmermann, Brillouin-Wigner perturbation theory in open electromagnetic systems, Europhys. Lett. 92, 50010 (2010).
- J. M. Llorens, J. Buencuerpo, and P. A. Postigo, Absorption features of the zero frequency mode in an ultra-thin slab, Appl. Phys. Lett. 105, 231115 (2014).
- P. Jakobsen, M. Mansuripur, and M. Kolesik, Leaky-mode expansion of the electromagnetic field inside dispersive spherical cavity, J. Math. Phys. 59, 033501 (2018).
