Tuning spin currents in collinear antiferromagnets and altermagnets

Sajjan Sheoran1,2 and Pratibha Dev1,3,*

  • *Contact author: pdev@lps.umd.edu
PDF

Phys. Rev. B 113, 174426 – Published 19 May, 2026

DOI: https://doi.org/10.1103/159t-fq4k

Abstract

Spin-current generation through nonrelativistic spin splittings, found in uncompensated magnets and d-wave altermagnets (AMs), is desirable for low-power spintronics. Such spin currents, however, are symmetry forbidden in conventional collinear antiferromagnets and higher-order AMs. Using spin-point-group analysis, we demonstrate that finite spin currents can be induced in these materials via magnetoelectric-, piezomagnetic-, and piezomagnetoelectric-like couplings. We utilize electric fields, strain, and their combinations to drive symmetry-lowering phase transitions into uncompensated magnetic or d-wave AM states, thereby enabling finite spin conductivity in a broader class of magnetic materials. We further substantiate this framework using density functional theory and Boltzmann transport calculations on representative magnetic materials—KV2Se2O, RuF4, Cr2O3, FeS2, and MnPSe3—spanning these different cases. The charge-to-spin conversion and spin-splitter ratio reaches up to almost 100% via uncompensated magnetism and about 40% via d-wave AM under realistic conditions, highlighting the effectiveness of this approach for efficient spin-current generation.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (54)

  1. I. Žutić, J. Fabian, and S. D. Sarma, Spintronics: Fundamentals and applications, Rev. Mod. Phys. 76, 323 (2004).
  2. J. E. Hirsch, Spin Hall effect, Phys. Rev. Lett. 83, 1834 (1999).
  3. M. Dyakonov and V. Perel, Spin relaxation of conduction electrons in noncentrosymmetric semiconductors, Sov. Phys. Solid State Ussr 13, 3023 (1972).
  4. R. J. Elliott, Theory of the effect of spin-orbit coupling on magnetic resonance in some semiconductors, Phys. Rev. 96, 266 (1954).
  5. Y. Yafet, g factors and spin-lattice relaxation of conduction electrons, Solid State Phys. 14, 1 (1963).
  6. S. Hayami, Y. Yanagi, and H. Kusunose, Bottom-up design of spin-split and reshaped electronic band structures in antiferromagnets without spin-orbit coupling: Procedure on the basis of augmented multipoles, Phys. Rev. B 102, 144441 (2020).
  7. L.-D. Yuan, Z. Wang, J.-W. Luo, and A. Zunger, Prediction of low-Z collinear and noncollinear antiferromagnetic compounds having momentum-dependent spin splitting even without spin-orbit coupling, Phys. Rev. Mater. 5, 014409 (2021).
  8. L. Šmejkal, J. Sinova, and T. Jungwirth, Beyond conventional ferromagnetism and antiferromagnetism: A phase with nonrelativistic spin and crystal rotation symmetry, Phys. Rev. X 12, 031042 (2022).
  9. S. Sheoran and P. Dev, Spontaneous anomalous Hall effect in two-dimensional altermagnets, Phys. Rev. B 111, 184407 (2025).
  10. S. Das, D. Suri, and A. Soori, Transport across junctions of altermagnets with normal metals and ferromagnets, J. Phys.: Condens. Matter 35, 435302 (2023).
  11. J. Železný, H. Gao, A. Manchon, F. Freimuth, Y. Mokrousov, J. Zemen, J. Mašek, J. Sinova, and T. Jungwirth, Spin-orbit torques in locally and globally noncentrosymmetric crystals: Antiferromagnets and ferromagnets, Phys. Rev. B 95, 014403 (2017).
  12. B. Flebus, Y. Tserkovnyak, and G. A. Fiete, Interfacial spin Seebeck effect in noncollinear magnetic systems, Phys. Rev. B 99, 224410 (2019).
  13. S.-W. Cheong and F.-T. Huang, Altermagnetism with non-collinear spins, npj Quantum Mater. 9, 13 (2024).
  14. R. González-Hernández, L. Šmejkal, K. Výborný, Y. Yahagi, J. Sinova, T. Jungwirth, and J. Železný, Efficient electrical spin splitter based on nonrelativistic collinear antiferromagnetism, Phys. Rev. Lett. 126, 127701 (2021).
  15. H. Vakili, E. Schwartz, and A. A. Kovalev, Spin-transfer torque in altermagnets with magnetic textures, Phys. Rev. Lett. 134, 176401 (2025).
  16. A. Bose, N. J. Schreiber, R. Jain, D.-F. Shao, H. P. Nair, J. Sun, X. S. Zhang, D. A. Muller, E. Y. Tsymbal, D. G. Schlom, et al., Tilted spin current generated by the collinear antiferromagnet ruthenium dioxide, Nat. Electron. 5, 267 (2022).
  17. K. D. Belashchenko, Giant strain-induced spin splitting effect in MnTe, a g-wave altermagnetic semiconductor, Phys. Rev. Lett. 134, 086701 (2025).
  18. B. Karetta, X. H. Verbeek, R. Jaeschke-Ubiergo, L. Šmejkal, and J. Sinova, Strain controlled g-to d-wave transition in altermagnetic CrSb, Phys. Rev. B 112, 094454 (2025).
  19. L. Šmejkal, Altermagnetic multiferroics and altermagnetoelectric effect, arXiv:2411.19928.
  20. D. Wang, H. Wang, L. Liu, J. Zhang, and H. Zhang, Electric-field-induced switchable two-dimensional altermagnets, Nano Lett. 25, 498 (2025).
  21. I. Mazin, R. González-Hernández, and L. Šmejkal, Induced monolayer altermagnetism in MnP (S,Se)3 and FeSe, arXiv:2309.02355.
  22. J. Callaway, Quantum Theory of the Solid State, 2nd ed. (Academic Press, San Diego, 1991).
  23. D. Vanderbilt, Soft self-consistent pseudopotentials in a generalized eigenvalue formalism, Phys. Rev. B 41, 7892 (1990).
  24. P. Giannozzi, S. Baroni, N. Bonini, M. Calandra, R. Car, C. Cavazzoni, D. Ceresoli, G. L. Chiarotti, M. Cococcioni, I. Dabo, et al., QUANTUMespresso: A modular and open-source software project for quantumsimulations of materials, J. Phys.: Condens. Matter 21, 395502 (2009).
  25. J. P. Perdew, K. Burke, and M. Ernzerhof, Generalized gradient approximation made simple, Phys. Rev. Lett. 77, 3865 (1996).
  26. N. Marzari and D. Vanderbilt, Maximally localized generalized Wannier functions for composite energy bands, Phys. Rev. B 56, 12847 (1997).
  27. A. A. Mostofi, J. R. Yates, Y.-S. Lee, I. Souza, D. Vanderbilt, and N. Marzari, WANNIER90: A tool for obtaining maximally-localised Wannier functions, Comput. Phys. Commun. 178, 685 (2008).
  28. See Supplemental Material at http://link.aps.org/supplemental/10.1103/159t-fq4k for band structures, comparison of intraband and interband contributions to spin conductivity and spin conductivity along any arbitrary direction, which also includes Ref. [14].
  29. H. T. Stokes and D. M. Hatch, FINDSYM: Program for identifying the space-group symmetry of a crystal, J. Appl. Crystallogr. 38, 237 (2005).
  30. M. I. Aroyo, J. M. Perez-Mato, C. Capillas, E. Kroumova, S. Ivantchev, G. Madariaga, A. Kirov, and H. Wondratschek, Bilbao Crystallographic Server: I. Databases and crystallographic computing programs, Z. Kristallogr.-Cryst. Mater. 221, 15 (2006).
  31. X. Chen, J. Ren, Y. Zhu, Y. Yu, A. Zhang, P. Liu, J. Li, Y. Liu, C. Li, and Q. Liu, Enumeration and representation theory of spin space groups, Phys. Rev. X 14, 031038 (2024).
  32. R.-C. Xiao, Y. Jin, Z.-F. Zhang, Z.-H. Feng, D.-F. Shao, and M. Tian, TensorSymmetry: A package to get symmetry-adapted tensors disentangling spin-orbit coupling effect and establishing analytical relationship with magnetic order, Comput. Phys. Commun. 318, 109872 (2026).
  33. D. B. Litvin and W. Opechowski, Spin groups, Physica 76, 538 (1974).
  34. A. Cracknell, Symmetry properties of the transport coefficients of magnetic crystals, Phys. Rev. B 7, 2145 (1973).
  35. W. Chen, M. Gu, J. Li, P. Wang, and Q. Liu, Role of hidden spin polarization in nonreciprocal transport of antiferromagnets, Phys. Rev. Lett. 129, 276601 (2022).
  36. M. Ezawa, Third-order and fifth-order nonlinear spin-current generation in g-wave and i-wave altermagnets and perfectly nonreciprocal spin current in f-wave magnets, Phys. Rev. B 111, 125420 (2025).
  37. M. Roig, A. Kreisel, Y. Yu, B. M. Andersen, and D. F. Agterberg, Minimal models for altermagnetism, Phys. Rev. B 110, 144412 (2024).
  38. E. Galindez-Ruales, R. Gonzalez-Hernandez, C. Schmitt, S. Das, F. Fuhrmann, A. Ross, E. Golias, A. Akashdeep, L. Lünenbürger, E. Baek, et al., Revealing the altermagnetism in hematite via XMCD imaging and anomalous Hall electrical transport, Adv. Mater. 37, e05019 (2025).
  39. B. Jiang, M. Hu, J. Bai, Z. Song, C. Mu, G. Qu, W. Li, W. Zhu, H. Pi, Z. Wei, et al., A metallic room-temperature d-wave altermagnet, Nat. Phys. 21, 754 (2025).
  40. F. Zhang, X. Cheng, Z. Yin, C. Liu, L. Deng, Y. Qiao, Z. Shi, S. Zhang, J. Lin, Z. Liu, et al., Crystal-symmetry-paired spin-valley locking in a layered room-temperature metallic altermagnet candidate, Nat. Phys. 21, 760 (2025).
  41. M. Hu, X. Cheng, Z. Huang, and J. Liu, Catalog of C-paired spin-momentum locking in antiferromagnetic systems, Phys. Rev. X 15, 021083 (2025).
  42. M. Milivojević, M. Orozović, S. Picozzi, M. Gmitra, and S. Stavrić, Interplay of altermagnetism and weak ferromagnetism in two-dimensional RuF4, 2D Mater. 11, 035025 (2024).
  43. R. Peng, S. Fang, P. Ho, F. Liu, T. Zhou, J. Liu, and Y. S. Ang, Ferroelastic altermagnetism, npj Quantum Mater. 11, 5 (2025).
  44. B. B. Krichevtsov, V. V. Pavlov, R. V. Pisarev, and V. N. Gridnev, Magnetoelectric spectroscopy of electronic transitions in antiferromagnetic Cr2O3, Phys. Rev. Lett. 76, 4628 (1996).
  45. X. H. Verbeek, A. Urru, and N. A. Spaldin, Hidden orders and (anti-) magnetoelectric effects in Cr2O3 and α-Fe2O3, Phys. Rev. Res. 5, L042018 (2023).
  46. A. L. Wysocki, S. Shi, and K. D. Belashchenko, Microscopic origin of the structural phase transitions at the Cr2O3 (0001) surface, Phys. Rev. B 86, 165443 (2012).
  47. S. Li, Y. Zhang, A. Bahri, X. Zhang, and C. Jia, Altermagnetism and strain induced altermagnetic transition in Cairo pentagonal monolayer, npj Quantum Mater. 10, 83 (2025).
  48. N. Ding, H. Ye, S.-S. Wang, and S. Dong, Ferroelastically tunable altermagnets, Phys. Rev. B 112, L220410 (2025).
  49. H. Mavani, K. Huang, K. Samanta, and E. Y. Tsymbal, Two-dimensional antiferromagnets with nonrelativistic spin splitting switchable by electric polarization, Phys. Rev. B 112, L060401 (2025).
  50. S. Sheoran and S. Bhattacharya, Nonrelativistic spin splittings and altermagnetism in twisted bilayers of centrosymmetric antiferromagnets, Phys. Rev. Mater. 8, L051401 (2024).
  51. X. Tao, Q. Liu, B. Miao, R. Yu, Z. Feng, L. Sun, B. You, J. Du, K. Chen, S. Zhang, et al., Self-consistent determination of spin Hall angle and spin diffusion length in Pt and Pd: The role of the interface spin loss, Sci. Adv. 4, eaat1670 (2018).
  52. J. Son, K.-H. Kim, Y. H. Ahn, H.-W. Lee, and J. Lee, Strain engineering of the Berry curvature dipole and valley magnetization in monolayer MoS2, Phys. Rev. Lett. 123, 036806 (2019).
  53. S. Sheoran, M. Jain, R. Moulik, and S. Bhattacharya, Probing the uniaxial strain-dependent valley drift and Berry curvature in monolayer MoSi2N4, Phys. Rev. Mater. 7, 114003 (2023).
  54. Z. Feng, W. Lu, T. Lu, F. Liu, J. R. Sheeran, M. Ye, J. Xia, T. Kurumaji, and L. Ye, Nonvolatile nematic order manipulated by strain and magnetic field in a layered antiferromagnet, arXiv:2507.05486.
