Generation and amplification of microwave signals via planar waveguides with embedded paramagnetic color centers

Stefano Lagomarsino*

Mario Agio†

  • *Contact author: stefano.lagomarsino@ino.cnr.it
  • †Contact author: mario.agio@cnr.it
PDF

Phys. Rev. Applied 26, 034028 – Published 14 September, 2026

DOI: https://doi.org/10.1103/ydkl-pjfx

Abstract

A concept for microwave (MW) amplification and maser generation in compact planar waveguides embedding a thin layer of paramagnetic color centers is presented. The ground state of the color centers can be optically or electrically spin-polarized, while population inversion is attained by Zeeman shifting of one spin sublevel below the populated state. A signal traveling along the waveguide, if resonant with the spin transition, can be amplified, or a self-sustained MW oscillation can be generated. A general analysis of the conditions for amplification and self-oscillation is developed for nitrogen-vacancy-rich diamond films, together with practical examples of impedance matching and resonator design. The proposed architecture combines near-unity filling factors with relatively low electromagnetic quality factors, enabling operation in strongly coupled configurations and broad frequency tunability through the external magnetic field. The same formalism naturally extends to compact lumped-element resonators operating at a few gigahertz while preserving millimeter-scale dimensions. Compared with the present state of the art of diamond masers, the approach offers reduced size, simplified integration with external electronics, and relaxed requirements on cavity quality factor.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (27)

  1. P. Hlawiczka, The maser and its application to satellite communication systems, J. Brit. I.R.E. 22, 219 (1961).
  2. J. Giordmaine, L. Alsop, C. Mayer, and C. Townes, A maser amplifier for radio astronomy at x-bands, Proc. IRE 47, 1062 (1959).
  3. M. W. Pospieszalski, Extremely low-noise amplification with cryogenic FETs and HFETs: 1970–2004, IEEE Microw. Mag. 6, 62 (2005).
  4. N. Bergeal, F. Schackert, M. Metcalfe, R. Vijay, V. E. Manucharyan, L. Frunzio, D. E. Prober, R. J. Schoelkopf, S. M. Girvin, and M. H. Devoret, Phase-preserving amplification near the quantum limit with a Josephson ring modulator, Nature (London) 465, 64 (2010).
  5. B. H. Eom, P. K. Day, H. G. LeDuc, and J. Zmuidzinas, A wideband, low-noise superconducting amplifier with high dynamic range, Nat. Phys. 8, 623 (2012).
  6. S. D. Lacey, B. T. Hughes, and J. C. Vokes, A low-noise room-temperature 12-GHz parametric amplifier, IEEE Trans. Microw. Theory Tech. 22, 1329 (1974).
  7. H. Zhang, G. Qian, W. Zhong, and C. Liu, A 3–15 GHz ultra-wideband 0.15−μm phemt low noise amplifier design, Proceedings of the IEEE International Conference on Communication Systems (ICCS) (Shenzhen, China, 2016), p. 1.
  8. Y.-L. Tang, N. Wadefalk, M. A. Morgan, and S. Weinreb, Full ka-band high performance Inp Mmic lna module, in Proceedings of the IEEE MTT-S International Microwave Symposium Digest (San Francisco, CA, USA, 2006), p. 81.
  9. M. Oxborrow, J. D. Breeze, and N. M. Alford, Room-temperature solid-state maser, Nature (London) 488, 353 (2012).
  10. J. D. Breeze, E. Salvadori, J. Sathian, N. M. N. Alford, and C. W. M. Kay, Continuous-wave room-temperature diamond maser, Nature (London) 555, 493 (2018).
  11. L. Jin, M. Pfender, N. Aslam, P. Neumann, S. Yang, J. Wrachtrup, and R.-B. Liu, Proposal for a room-temperature diamond maser, Nat. Commun. 6, 8251 (2015).
  12. A. Sherman, O. Zgadzai, B. Koren, I. Peretz, E. Laster, and A. Blank, Diamond-based microwave quantum amplifier, Sci. Adv. 8, eade6527 (2022).
  13. M. Ohta, C.-P. Lee, V. P. M. Sietses, I. Kostylev, J. R. Ball, P. Moroshkin, T. Hamamoto, Y. Kobayashi, S. Onoda, T. Ohshima, J. Isoya, H. Takahashi, and Y. Kubo, A near-quantum limited diamond maser amplifier operating at millikelvin temperatures, arXiv:2505.05705.
  14. C. W. Zollitsch and J. D. Breeze, Quantum theory of the diamond maser: Stimulated and superradiant emission, Phys. Rev. A 111, 053714 (2025).
  15. H. Kraus, V. A. Soltamov, D. Riedel, S. Väth, F. Fuchs, A. Sperlich, P. G. Baranov, V. Dyakonov, and G. V. Astakhov, Room-temperature quantum microwave emitters based on spin defects in silicon carbide, Nat. Phys. 10, 157 (2014).
  16. S. Ogawa and M. Kimata, Metal-insulator-metal-based plasmonic metamaterial absorbers at visible and infrared wavelengths: A review, Materials 11, 458 (2018).
  17. S. Lagomarsino, N. Markešević, Z. Rashid, A. M. Flatae, S. Mägdefessel, S. Hernández-Gómez, G. Bianchini, F. Sledz, N. Gelli, L. Giuntini, M. Massi, S. Sciortino, C. Corsi, V. Cimalla, P. Knittel, M. Kunzer, M. Bellini, N. Fabbri, and M. Agio, Enhanced activation yield of nitrogen-vacancy and silicon-vacancy diamond color centers by proton and carbon irradiation, Diam. Relat. Mater. 158, 112632 (2025).
  18. M. Fischer, A. Sperlich, H. Kraus, T. Ohshima, G V. Astakhov, and V. Dyakonov, Highly efficient optical pumping of spin defects in silicon carbide for stimulated microwave emission, Phys. Rev. Appl. 9, 054006 (2018).
  19. O. Bulancea-Lindvall, N. T. Son, I. A. Abrikosov, and V. Ivády, Dipolar spin relaxation of divacancy qubits in silicon carbide, npj Comput. Mater. 7, 213 (2021).
  20. S. Lagomarsino and M. Agio, Near-field planar antenna for microwave excitation of paramagnetic quantum emitters, Phys. Rev. Appl. 26, 034029 (2026).
  21. R. E. Collin, Foundations for Microwave Engineering (McGraw–Hill, New York, 1966).
  22. A. E. Siegman, Microwave Solid-State Masers (McGraw-Hill, New York, 1964).
  23. A. Jarmola, V. M. Acosta, K. Jensen, S. Chemerisov, and D. Budker, Temperature- and magnetic-field-dependent longitudinal spin relaxation in nitrogen-vacancy ensembles in diamond, Phys. Rev. Appl. 108, 197601 (2012).
  24. R. Chapman and T. Plakhotnik, Anomalous saturation effects due to optical spin depolarization in nitrogen vacancy centers in diamond nanocrystals, Phys. Rev. B 86, 045204 (2012).
  25. T. Plakhotnik and H. Aman, NV-centers in Nanodiamonds: How good they are, Diam. Relat. Mater. 82, 87 (2018).
  26. L. Robledo, H. Bernien, T. van der Sar, and R. Hanson, Spin dynamics in the optical cycle of single nitrogen vacancy centres in diamond, New J. Phys. 13, 025013 (2011).
  27. Y. Varshavsky, O. Zgadzai, and A. Blank, Solid-state maser with microwatt output power at moderate cryogenic temperatures, AIP Adv. 15, 115009 (2025).
