Monolithic 4H-SiC nanomechanical resonators with high intrinsic quality factors

A. Hochreiter1,*, P. Bredol2,*, F. David2, B. Demiralp2, H.B. Weber1, and E.M. Weig2,3,4,†

  • *These authors contributed equally to this work.
  • †Contact author: eva.weig@tum.de
PDF

Phys. Rev. Applied 24, 034005 – Published 3 September, 2025

DOI: https://doi.org/10.1103/vclj-v8qx

Abstract

We present an extensive study of 4H-SiC nanomechanical resonators electrochemically etched out of a monocrystalline wafer. Combining piezo-driven interferometric determination of the mechanical spectra with scanning laser Doppler vibrometry, an unambiguous assignment of resonance peaks to flexural and torsional modes is achieved. The investigation of multiple harmonic eigenmodes of singly and doubly clamped resonators with varying geometry allows for a comprehensive characterization. Excellent intrinsic mechanical quality factors up to 2×105 are found at room temperature, approaching the thermoelastic limit at eigenfrequencies exceeding 10 MHz. Mechanical stress is essentially absent. Young’s modulus is in agreement with the literature. These findings are robust under postprocessing treatments, in particular atomic layer etching and high-temperature thermal annealing. The resulting on-chip high-quality mechanical resonators represent a valuable technological element for a broad range of applications. In particular, the monolithic architecture meets the requirements of spin-based photonic quantum technologies on the upcoming SiC platform.
