Interaction-range-controlled crossover from first-order to continuous melting in two-dimensional diplon crystals

Paulo S. Branicio*

  • *Contact author: branicio@usc.edu
PDF

APS Open Sci. 1, 000117 – Published 31 August, 2026

DOI: https://doi.org/10.1103/r36h-bzv9

Abstract

Molecular dynamics simulations of two-dimensional (2D) diplon crystals (electrons on helium films) reveal a melting crossover from first order to continuous as film thickness d grows relative to lattice constant a. At small d/a, hysteresis persists at N=40000 alongside a strong Binder-cumulant anomaly. At large d/a, hysteresis vanishes and orientational correlations decay algebraically with η6=0.31±0.04, near the Kosterlitz-Thouless-Halperin-Nelson-Young bound of 1/4, consistent with continuous melting within the investigated system sizes and numerical resolution; disclination unbinding limits any hexatic phase to ΔT/Tm<0.5%. The diplon system thus tunes 2D melting, relevant to electrons-on-helium quantum computing.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (38)

  1. J. M. Kosterlitz and D. J. Thouless, Ordering, metastability and phase transitions in two-dimensional systems, J. Phys. C 6, 1181 (1973).
  2. B. I. Halperin and D. R. Nelson, Theory of two-dimensional melting, Phys. Rev. Lett. 41, 121 (1978).
  3. D. R. Nelson and B. I. Halperin, Dislocation-mediated melting in two dimensions, Phys. Rev. B 19, 2457 (1979).
  4. A. P. Young, Melting and the vector Coulomb gas in two dimensions, Phys. Rev. B 19, 1855 (1979).
  5. Y. Han, N. Y. Ha, A. M. Alsayed, and A. G. Yodh, Melting of two-dimensional tunable-diameter colloidal crystals, Phys. Rev. E 77, 041406 (2008).
  6. P. Dillmann, G. Maret, and P. Keim, Comparison of 2D melting criteria in a colloidal system, J. Phys.: Condens. Matter 24, 464118 (2012).
  7. K. Zahn and G. Maret, Dynamic criteria for melting in two dimensions, Phys. Rev. Lett. 85, 3656 (2000).
  8. E. P. Bernard and W. Krauth, Two-step melting in two dimensions: First-order liquid-hexatic transition, Phys. Rev. Lett. 107, 155704 (2011).
  9. S. C. Kapfer and W. Krauth, Two-dimensional melting: From liquid-hexatic coexistence to continuous transitions, Phys. Rev. Lett. 114, 035702 (2015).
  10. S. T. Chui, Grain-boundary theory of melting in two dimensions, Phys. Rev. Lett. 48, 933 (1982).
  11. K. J. Strandburg, Two-dimensional melting, Rev. Mod. Phys. 60, 161 (1988).
  12. S. Deutschlander, T. Horn, H. Lowen, G. Maret, and P. Keim, Two-dimensional melting under quenched disorder, Phys. Rev. Lett. 111, 098301 (2013).
  13. R. E. Kusner, J. A. Mann, J. Kerins, and A. J. Dahm, Two-stage melting of a two-dimensional collodial lattice with dipole interactions, Phys. Rev. Lett. 73, 3113 (1994).
  14. E. Oguz, R. Messina, and H. Lowen, Crystalline multilayers of the confined Yukawa system, Europhys. Lett. 86, 28002 (2009).
  15. P. Hartmann, G. J. Kalman, Z. Donko, and K. Kutasi, Equilibrium properties and phase diagram of two-dimensional Yukawa systems, Phys. Rev. E 72, 026409 (2005).
  16. G. J. Kalman, P. Hartmann, Z. Donko, and M. Rosenberg, Two-dimensional Yukawa liquids: Correlation and dynamics, Phys. Rev. Lett. 92, 065001 (2004).
  17. P. S. Branicio, J.-P. Rino, and N. Studart, Melting and orientational order of the screened Wigner crystal on helium films, Phys. Rev. B 64, 193413 (2001).
  18. P. M. Platzman and M. I. Dykman, Quantum computing with electrons floating on liquid helium, Science 284, 1967 (1999).
  19. G. Yang, A. Fragner, G. Koolstra, L. Ocola, D. A. Czaplewski, R. J. Schoelkopf, and D. I. Schuster, Coupling an ensemble of electrons on superfluid helium to a superconducting circuit, Phys. Rev. X 6, 011031 (2016).
  20. C. C. Grimes and G. Adams, Evidence for a liquid-to-crystal phase transition in a classical, two-dimensional sheet of electrons, Phys. Rev. Lett. 42, 795 (1979).
  21. D. S. Fisher, B. I. Halperin, and P. M. Platzman, Phonon-ripplon coupling and the two-dimensional electron solid on a liquid-helium surface, Phys. Rev. Lett. 42, 798 (1979).
  22. R. Mehrotra, B. M. Guenin, and A. J. Dahm, Ripplon-limited mobility of a two-dimensional crystal of electrons: Experiment, Phys. Rev. Lett. 48, 641 (1982).
  23. D. C. Glattli, E. Y. Andrei, and F. I. B. Williams, Thermodynamic measurement on the melting of a two-dimensional electron solid, Phys. Rev. Lett. 60, 420 (1988).
  24. Yu. P. Monarkha, Cyclotron resonance of a two-dimensional Wigner solid, Low Temp. Phys. 27, 463 (2001).
  25. Yu. P. Monarkha and V. B. Shikin, Low-dimensional electronic systems on a liquid helium surface (Review), Sov. J. Low Temp. Phys. 8, 279 (1982).
  26. P. S. Branicio, J.-P. Rino, and N. Studart, Molecular-dynamics studies of charge complexes in liquid helium, J. Mol. Struct.: THEOCHEM 464, 87 (1999).
  27. P. P. Ewald, Die Berechnung optischer und elektrostatischer Gitterpotentiale, Ann. Phys. 369, 253 (1921).
  28. S. W. de Leeuw, J. W. Perram, and E. R. Smith, Simulation of electrostatic systems in periodic boundary conditions. I. Lattice sums and dielectric constants, Proc. R. Soc. London A 373, 27 (1980).
  29. B. Leimkuhler and C. Matthews, Rational construction of stochastic numerical methods for molecular sampling, Appl. Math. Res. Express 2013, 34 (2013).
  30. See Supplemental Material at http://link.aps.org/supplemental/10.1103/r36h-bzv9 for BAOAB Langevin validation and quantitative thermostat-shift table (Secs. S1–S5); sensitivity of Tm to defining criterion (Sec. S6); equilibration, seed-convergence, and heating-rate tests (Sec. S7); finite-size scaling and Frank-constant analysis at d=5000Å (Sec. S8); and core-energy, latent-heat, and defect-count diagnostics supporting the first-order classification at small d/a (Sec. S9).
  31. A. L. Thorneywork, J. L. Abbott, D. G. A. L. Aarts, and R. P. A. Dullens, Two-dimensional melting of colloidal hard spheres, Phys. Rev. Lett. 118, 158001 (2017).
  32. Y. Saito, Monte Carlo studies of two-dimensional melting: Dislocation vector systems, Phys. Rev. B 26, 6239 (1982).
  33. W. Janke and H. Kleinert, Monte Carlo study of two-step defect melting, Phys. Rev. B 41, 6848 (1990).
  34. L. Radzihovsky, E. Frey, and D. R. Nelson, Novel phases and reentrant melting of two-dimensional colloidal crystals, Phys. Rev. E 63, 031503 (2001).
  35. Y. Tang, L. Li, T. Li, Y. Xu, S. Liu, K. Barmak, K. Watanabe, T. Taniguchi, A. H. MacDonald, J. Shan, and K. F. Mak, Simulation of Hubbard model physics in WSe2/WS2 moiré superlattices, Nature (London) 579, 353 (2020).
  36. Y. Xu, S. Liu, D. A. Rhodes, K. Watanabe, T. Taniguchi, J. Hone, V. Elser, K. F. Mak, and J. Shan, Correlated insulating states at fractional fillings of moiré superlattices, Nature (London) 587, 214 (2020).
  37. https://carc.usc.edu.
  38. P. S. Branicio, Interaction-range-controlled crossover from first-order to continuous melting in two-dimensional diplon crystals: Code and data, Zenodo, 2026, https://doi.org/10.5281/zenodo.20039656.
