Analytical singular-value structure of analytic-continuation kernels from Slepian information theory

Masayuki Ohzeki*

  • Graduate School of Information Sciences, Tohoku University, Sendai 980-8579, Japan; Department of Physics, Institute of Science Tokyo, Tokyo 152-8551, Japan; Research and Education Institute for Semiconductors and Informatics, Kumamoto University, Kumamoto 860-8555, Japan; and Sigma-i Co., Ltd., Tokyo 108-0075, Japan

  • *Contact author: mohzeki@tohoku.ac.jp
PDF

APS Open Sci. 1, 000145 – Published 21 September, 2026

DOI: https://doi.org/10.1103/8yw5-dhd4

Abstract

Analytic continuation from imaginary-time Green’s functions to real-frequency spectra is a central ill-posed inverse problem in quantum many-body physics. We show that the thermal kernel admits an analytical generalized singular-value structure once its purely dynamical part is separated from the statistical weight imposed by the heat bath. The dynamical kernel is the imaginary-bandwidth continuation of Slepian’s finite Fourier transform and is governed by the same Sturm-Liouville algebra that yields prolate spheroidal wave functions. Fermionic and bosonic statistics then enter as gauge transformations of the frequency-space inner product, giving a generalized singular system and self-adjoint effective potentials in the corresponding weighted space. The Shannon number, Nc=βωmax/π, fixes the upper information capacity of this pure Laplace channel. Finally, the optimal sampling points are obtained as eigenvalues of a Legendre colleague matrix, giving a deterministic compressed-sensing grid without iterative root searches.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (25)

  1. M. Jarrell and J. E. Gubernatis, Bayesian inference and the analytic continuation of imaginary-time quantum Monte Carlo data, Phys. Rep. 269, 133 (1996).
  2. H. J. Vidberg and J. W. Serene, Solving the Eliashberg equations by means of N-point Padé approximants, J. Low Temp. Phys. 29, 179 (1977).
  3. R. N. Silver, D. S. Sivia, and J. E. Gubernatis, Maximum-entropy method for analytic continuation of quantum Monte Carlo data, Phys. Rev. B 41, 2380 (1990).
  4. A. W. Sandvik, Stochastic method for analytic continuation of quantum Monte Carlo data, Phys. Rev. B 57, 10287 (1998).
  5. H. Shao and A. W. Sandvik, Progress on stochastic analytic continuation of quantum Monte Carlo data, Phys. Rep. 1003, 1 (2023).
  6. J. Otsuki, M. Ohzeki, H. Shinaoka, and K. Yoshimi, Sparse modeling approach to analytical continuation of imaginary-time quantum Monte Carlo data, Phys. Rev. E 95, 061302 (2017).
  7. K. Yoshimi, J. Otsuki, Y. Motoyama, M. Ohzeki, and H. Shinaoka, SpM: Sparse modeling tool for analytic continuation of imaginary-time Green’s function, Comput. Phys. Commun. 244, 319 (2019).
  8. H. Shinaoka, J. Otsuki, M. Ohzeki, and K. Yoshimi, Compressing Green’s function using intermediate representation between imaginary-time and real-frequency domains, Phys. Rev. B 96, 035147 (2017).
  9. J. Li, M. Wallerberger, N. Chikano, C.-N. Yeh, E. Gull, and H. Shinaoka, Sparse sampling approach to efficient ab initio calculations at finite temperature, Phys. Rev. B 101, 035144 (2020).
  10. H. Shinaoka, D. Geffroy, M. Wallerberger, J. Otsuki, K. Yoshimi, E. Gull, and J. Kuneš, Sparse sampling and tensor network representation of two-particle Green’s functions, SciPost Phys. 8, 012 (2020).
  11. J. Kaye, K. Chen, and O. Parcollet, Discrete Lehmann representation of imaginary time Green’s functions, Phys. Rev. B 105, 235115 (2022).
  12. J. Kaye, K. Chen, and H. U. R. Strand, libdlr: Efficient imaginary time calculations using the discrete Lehmann representation, Comput. Phys. Commun. 280, 108458 (2022).
  13. Y. Motoyama, K. Yoshimi, and J. Otsuki, Robust analytic continuation combining the advantages of the sparse modeling approach and the Padé approximation, Phys. Rev. B 105, 035139 (2022).
  14. J. Fei, C.-N. Yeh, and E. Gull, Nevanlinna analytical continuation, Phys. Rev. Lett. 126, 056402 (2021).
  15. D. Huang and Y.-F. Yang, Learned optimizers for analytic continuation, Phys. Rev. B 105, 075112 (2022).
  16. L. Huang, ACFlow 2.0: An open source toolkit for analytic continuation of quantum Monte Carlo data, Comput. Phys. Commun. 321, 110038 (2026).
  17. T. Misawa, Analytic origin of Green-function compression in the intermediate representation, arXiv:2605.24814.
  18. D. Slepian and H. O. Pollak, Prolate spheroidal wave functions, Fourier analysis and uncertainty. I, Bell Syst. Tech. J. 40, 43 (1961).
  19. H. J. Landau and H. O. Pollak, Prolate spheroidal wave functions, Fourier analysis and uncertainty. II, Bell Syst. Tech. J. 40, 65 (1961).
  20. H. J. Landau and H. O. Pollak, Prolate spheroidal wave functions, Fourier analysis and uncertainty. III: The dimension of the space of essentially time- and band-limited signals, Bell Syst. Tech. J. 41, 1295 (1962).
  21. D. Slepian, Prolate spheroidal wave functions, Fourier analysis and uncertainty. V: The discrete case, Bell Syst. Tech. J. 57, 1371 (1978).
  22. G. H. Golub and J. H. Welsch, Calculation of Gauss quadrature rules, Math. Comput. 23, 221 (1969).
  23. H. Xiao, V. Rokhlin, and N. Yarvin, Prolate spheroidal wavefunctions, quadrature and interpolation, Inverse Probl. 17, 805 (2001).
  24. I. J. Good, The colleague matrix, a Chebyshev analogue of the companion matrix, Q. J. Math. 12, 61 (1961).
  25. V. Noferini and J. Pérez, Chebyshev rootfinding via computing eigenvalues of colleague matrices: When is it stable?, Math. Comput. 86, 1741 (2017).
