Nonlinear quantum transduction of weak topological impurities

Jiahao Duan1, Maomao Gong1,*, Yongjun Cheng1, and Song Bin Zhang1,2,†

  • *Contact author: gongmm@snnu.edu.cn
  • †Contact author: song-bin.zhang@snnu.edu.cn
PDF

APS Open Sci. 1, 000157 – Published 1 October, 2026

DOI: https://doi.org/10.1103/8tqj-y91q

Abstract

Detecting weak field perturbations at an optical-vortex node is a fundamental challenge across wave physics, as the local signal contrast typically scales quadratically with the impurity amplitude when no reference field is used. Here, we propose a complementary, spatially resolved diagnostic that exploits the strongly nonlinear response of an electromagnetically induced transparency (EIT) medium to transduce weak topological impurities into probe transmission. Using a vortex beam with a weak coherent admixture as a concrete realization, we show theoretically that EIT coherence converts the weak field that lifts the nominal vortex node into a highly sensitive, macroscopic transmission contrast. A resonant weak-probe model with representative cold-Rb87 parameters predicts a per-exposure detection floor for the impurity amplitude at the level of a few ×10−3, relative to a separately characterized, preaveraged pure-vortex reference. We quantify the intrinsic and experimental limits of this response, analyzing its dependence on coupling strength, ground-state decoherence, optical depth, two-photon detuning, and Maxwell-Boltzmann thermal motion. While not a complete, basis-independent measurement of modal purity, this method provides a calibrated, local all-optical diagnostic for weak coherent field admixtures at a known vortex node.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (38)

  1. J. F. Nye and M. V. Berry, Dislocations in wave trains, Proc. R. Soc. London A 336, 165 (1974).
  2. L. Allen, M. W. Beijersbergen, R. J. C. Spreeuw, and J. P. Woerdman, Orbital angular momentum of light and the transformation of Laguerre-Gaussian laser modes, Phys. Rev. A 45, 8185 (1992).
  3. M. S. Soskin and M. V. Vasnetsov, Singular optics, in Progress in Optics, edited by E. Wolf (Elsevier, Amsterdam, 2001), Vol. 42, pp. 219–276.
  4. G. Molina-Terriza, J. P. Torres, and L. Torner, Twisted photons, Nat. Phys. 3, 305 (2007).
  5. A. M. Yao and M. J. Padgett, Orbital angular momentum: Origins, behavior and applications, Adv. Opt. Photon. 3, 161 (2011).
  6. H. Rubinsztein-Dunlop et al., Roadmap on structured light, J. Opt. 19, 013001 (2017).
  7. A. Forbes, M. de Oliveira, and M. R. Dennis, Structured light, Nat. Photon. 15, 253 (2021).
  8. A. Mair, A. Vaziri, G. Weihs, and A. Zeilinger, Entanglement of the orbital angular momentum states of photons, Nature (London) 412, 313 (2001).
  9. A. C. Dada, J. Leach, G. S. Buller, M. J. Padgett, and E. Andersson, Experimental high-dimensional two-photon entanglement and violations of generalized Bell inequalities, Nat. Phys. 7, 677 (2011).
  10. M. Krenn, M. Huber, R. Fickler, R. Lapkiewicz, S. Ramelow, and A. Zeilinger, Generation and confirmation of a (100×100)-dimensional entangled quantum system, Proc. Natl. Acad. Sci. USA 111, 6243 (2014).
  11. M. Mirhosseini, O. S. Magaña-Loaiza, M. N. O’Sullivan, B. Rodenburg, M. Malik, M. P. J. Lavery, M. J. Padgett, D. J. Gauthier, and R. W. Boyd, High-dimensional quantum cryptography with twisted light, New J. Phys. 17, 033033 (2015).
  12. J. Wang, J.-Y. Yang, I. M. Fazal, N. Ahmed, Y. Yan, H. Huang, Y. Ren, Y. Yue, S. Dolinar, M. Tur, and A. E. Willner, Terabit free-space data transmission employing orbital angular momentum multiplexing, Nat. Photon. 6, 488 (2012).
  13. N. Bozinovic, Y. Yue, Y. Ren, M. Tur, P. Kristensen, H. Huang, A. E. Willner, and S. Ramachandran, Terabit-scale orbital angular momentum mode division multiplexing in fibers, Science 340, 1545 (2013).
  14. A. E. Willner, H. Huang, Y. Yan, Y. Ren, N. Ahmed, G. Xie, C. Bao, L. Li, Y. Cao, Z. Zhao, J. Wang, M. P. J. Lavery, M. Tur, S. Ramachandran, A. F. Molisch, N. Ashrafi, and S. Ashrafi, Optical communications using orbital angular momentum beams, Adv. Opt. Photon. 7, 66 (2015).
  15. D. G. Grier, A revolution in optical manipulation, Nature (London) 424, 810 (2003).
  16. K. Dholakia and T. Čižmár, Shaping the future of manipulation, Nat. Photon. 5, 335 (2011).
  17. M. Babiker, W. L. Power, and L. Allen, Light-induced torque on moving atoms, Phys. Rev. Lett. 73, 1239 (1994).
  18. M. Babiker, C. R. Bennett, D. L. Andrews, and L. C. Dávila Romero, Orbital angular momentum exchange in the interaction of twisted light with molecules, Phys. Rev. Lett. 89, 143601 (2002).
  19. C. T. Schmiegelow, J. Schulz, H. Kaufmann, T. Ruster, U. G. Poschinger, and F. Schmidt-Kaler, Transfer of optical orbital angular momentum to a bound electron, Nat. Commun. 7, 12998 (2016).
  20. S. A.-L. Schulz, A. A. Peshkov, R. A. Müller, R. Lange, N. Huntemann, C. Tamm, E. Peik, and A. Surzhykov, Generalized excitation of atomic multipole transitions by twisted light modes, Phys. Rev. A 102, 012812 (2020).
  21. J. Leach, M. J. Padgett, S. M. Barnett, S. Franke-Arnold, and J. Courtial, Measuring the orbital angular momentum of a single photon, Phys. Rev. Lett. 88, 257901 (2002).
  22. J. Leach, J. Courtial, K. Skeldon, S. M. Barnett, S. Franke-Arnold, and M. J. Padgett, Interferometric methods to measure orbital and spin, or the total angular momentum of a single photon, Phys. Rev. Lett. 92, 013601 (2004).
  23. E. Bolduc, N. Bent, E. Santamato, E. Karimi, and R. W. Boyd, Exact solution to simultaneous intensity and phase encryption with a single phase-only hologram, Opt. Lett. 38, 3546 (2013).
  24. A. Forbes, A. Dudley, and M. McLaren, Creation and detection of optical modes with spatial light modulators, Adv. Opt. Photon. 8, 200 (2016).
  25. M. Mirhosseini, M. Malik, Z. Shi, and R. W. Boyd, Efficient separation of the orbital angular momentum eigenstates of light, Nat. Commun. 4, 2781 (2013).
  26. G. C. G. Berkhout, M. P. J. Lavery, J. Courtial, M. W. Beijersbergen, and M. J. Padgett, Efficient sorting of orbital angular momentum states of light, Phys. Rev. Lett. 105, 153601 (2010).
  27. M. P. J. Lavery, D. J. Robertson, G. C. G. Berkhout, G. D. Love, M. J. Padgett, and J. Courtial, Refractive elements for the measurement of the orbital angular momentum of a single photon, Opt. Express 20, 2110 (2012).
  28. D. Flamm, D. Naidoo, C. Schulze, A. Forbes, and M. Duparré, Mode analysis with a spatial light modulator as a correlation filter, Opt. Lett. 37, 2478 (2012).
  29. M. Bahl, G. M. Koutentakis, M. Maslov, T. Jungnickel, T. Gaßen, M. Lemeshko, and O. H. Heckl, The R-index: A universal metric for evaluating OAM content and mode purity in optical fields, J. Phys. Photon. 8, 015071 (2026).
  30. R. P. Schmidt, S. Ramakrishna, A. A. Peshkov, N. Huntemann, E. Peik, S. Fritzsche, and A. Surzhykov, Atomic photoexcitation as a tool for probing purity of twisted light modes, Phys. Rev. A 109, 033103 (2024).
  31. N. S. Mallick and S. De, Phase-controlled efficient detection of topological charge of vortex Bessel beam, Appl. Phys. B 131, 168 (2025).
  32. N. B. Phillips, G. V. Romanov, W. F. Ames, and I. Novikova, Optical vortex filtering for the detection of electromagnetically induced transparency, J. Opt. Soc. Am. B 28, 2129 (2011).
  33. See Supplemental Material at http://link.aps.org/supplemental/10.1103/8tqj-y91q for the coupling-field parametrization, detailed derivation of the EIT susceptibility, sensitivity calibration, detuning dependence, and transverse-motion analysis, which includes Refs. [34, 35, 36, 38].
  34. R. S. N. Moreira, J. C. de Aquino Carvalho, and J. W. R. Tabosa, Amplification and storage of light carrying orbital angular momentum via magnetically assisted gain in cold atoms, J. Opt. 25, 024003 (2023).
  35. Y. Wang, M. Guo, J. Wu, J. Liu, X. Yang, and J. Li, Propagation of Gaussian vortex beams in electromagnetically induced transparency media, Opt. Express 30, 43426 (2022).
  36. J. Gea-Banacloche, Y.-Q. Li, S.-Z. Jin, and M. Xiao, Electromagnetically induced transparency in ladder-type inhomogeneously broadened media: Theory and experiment, Phys. Rev. A 51, 576 (1995).
  37. M. Shuker, O. Firstenberg, R. Pugatch, A. Ron, and N. Davidson, Storing images in warm atomic vapor, Phys. Rev. Lett. 100, 223601 (2008).
  38. O. Firstenberg, M. Shuker, R. Pugatch, D. R. Fredkin, N. Davidson, and A. Ron, Theory of thermal motion in electromagnetically induced transparency: Effects of diffusion, Doppler broadening, and Dicke and Ramsey narrowing, Phys. Rev. A 77, 043830 (2008).
