- Open Access
Leakage-Protected Idle Operation of a Triangular Exchange-Only Spin Qubit
PRX Quantum 7, 020324 – Published 7 May, 2026
DOI: https://doi.org/10.1103/sljc-cmdw
Abstract
We characterize the coherence of a triangular exchange-only (EO) spin qubit operated at a leakage-protected idle (LPI) point. The triangular geometry enables independent control of all three pairwise exchange interactions, and the LPI condition occurs when these couplings are turned on simultaneously and tuned to equal strength. In this configuration, the exchange interaction induces an energy gap that suppresses leakage from the computational subspace while leaving the qubit state unaffected. We develop procedures to calibrate the LPI point and measure , and use these to characterize the qubit dephasing time over a broad range of gap energies. While operating with large always-on exchange couplings exposes the qubit to charge noise, we find that still exceeds that of conventional exchange-only spin qubits for MHz. The precise control of simultaneous, all-to-all connected exchange demonstrated here presents a natural path toward improving the performance of EO qubits and also enables alternative qubit encodings.
Physics Subject Headings (PhySH)
Popular Summary
Spin qubits encoded in gate-defined semiconductor quantum dots (QDs) are an advancing quantum computing platform, benefiting from small footprints, large charging energies, and compatibility with established semiconductor fabrication techniques. Among many spin-qubit modalities, the exchange-only (EO) qubit is particularly attractive for large-scale integration because it enables universal control using only baseband voltage modulation, eliminating the need for RF drives or local magnetic fields. However, because the EO qubit is encoded within a subsystem of a larger Hilbert space, it is susceptible to leakage, where information escapes the computational subspace. Leakage errors are particularly costly, as they are not directly compatible with standard quantum error-correction protocols.
Here, we demonstrate a leakage-protected idle (LPI) operating point for the EO qubit that suppresses leakage by energetically penalizing transitions out of the computational subspace. This protection is achieved by engineering a simultaneous, always-on exchange interaction among all three quantum dots comprising the EO qubit, opening an energy gap between the computational and leakage subspaces. We present methods for locating the LPI point and for measuring the induced gap. Using these, we characterize qubit coherence at the LPI point over a broad range of gap energies, identifying a regime in which leakage suppression and coherence are simultaneously enhanced.
More broadly, this work demonstrates precise coherent control of simultaneous exchange in an all-to-all-connected QD array. This gives rise to a virtual tunnel current with an associated direction, representing a distinct chiral quantum degree of freedom that could be used for alternative qubit designs or quantum simulations.
Article Text
Supplemental Material
References (37)
- R. Hanson, L. P. Kouwenhoven, J. R. Petta, S. Tarucha, and L. M. K. Vandersypen, Spins in few-electron quantum dots, Rev. Mod. Phys. 79, 1217 (2007).
- G. Burkard, T. D. Ladd, A. Pan, J. M. Nichol, and J. R. Petta, Semiconductor spin qubits, Rev. Mod. Phys. 95, 025003 (2023).
- C. H. Yang, R. C. C. Leon, J. C. C. Hwang, A. Saraiva, T. Tanttu, W. Huang, J. Camirand Lemyre, K. W. Chan, K. Y. Tan, F. E. Hudson, K. M. Itoh, A. Morello, M. Pioro-Ladrière, A. Laucht, and A. S. Dzurak, Operation of a silicon quantum processor unit cell above one kelvin, Nature 580, 350 (2020).
- L. Petit, H. G. J. Eenink, M. Russ, W. I. L. Lawrie, N. W. Hendrickx, S. G. J. Philips, J. S. Clarke, L. M. K. Vandersypen, and M. Veldhorst, Universal quantum logic in hot silicon qubits, Nature 580, 355 (2020).
- J. Y. Huang et al., High-fidelity spin qubit operation and algorithmic initialization above 1 K, Nature 627, 772 (2024).
- F. Ansaloni, A. Chatterjee, H. Bohuslavskyi, B. Bertrand, L. Hutin, M. Vinet, and F. Kuemmeth, Single-electron operations in a foundry-fabricated array of quantum dots, Nat. Commun. 11, 6399 (2020).
- W. Ha, S. D. Ha, M. D. Choi, Y. Tang, A. E. Schmitz, M. P. Levendorf, K. Lee, J. M. Chappell, T. S. Adams, D. R. Hulbert, E. Acuna, R. S. Noah, J. W. Matten, M. P. Jura, J. A. Wright, M. T. Rakher, and M. G. Borselli, A flexible design platform for / exchange-only qubits with low disorder, Nano Lett. 22, 1443 (2022).
- A. M. J. Zwerver et al., Qubits made by advanced semiconductor manufacturing, Nat. Electron. 5, 184 (2022).
- S. Neyens et al., Probing single electrons across 300-mm spin qubit wafers, Nature 629, 80 (2024).
- Y. Tokura, W. G. van der Wiel, T. Obata, and S. Tarucha, Coherent single electron spin control in a slanting Zeeman field, Phys. Rev. Lett. 96, 047202 (2006).
- M. Pioro-Ladrière, T. Obata, Y. Tokura, Y.-S. Shin, T. Kubo, K. Yoshida, T. Taniyama, and S. Tarucha, Electrically driven single-electron spin resonance in a slanting Zeeman field, Nat. Phys. 4, 776 (2008).
- D. P. DiVincenzo, D. Bacon, J. Kempe, G. Burkard, and K. B. Whaley, Universal quantum computation with the exchange interaction, Nature 408, 339 (2000).
- R. W. Andrews, C. Jones, M. D. Reed, A. M. Jones, S. D. Ha, M. P. Jura, J. Kerckhoff, M. Levendorf, S. Meenehan, S. T. Merkel, A. Smith, B. Sun, A. J. Weinstein, M. T. Rakher, T. D. Ladd, and M. G. Borselli, Quantifying error and leakage in an encoded / triple-dot qubit, Nat. Nanotechnol. 14, 747 (2019).
- T. D. Ladd, Hyperfine-induced decay in triple quantum dots, Phys. Rev. B 86, 125408 (2012).
- J. Kerckhoff, B. Sun, B. H. Fong, C. Jones, A. A. Kiselev, D. W. Barnes, R. S. Noah, E. Acuna, M. Akmal, S. D. Ha, J. A. Wright, B. Thomas, C. A. C. Jackson, L. F. Edge, K. Eng, R. S. Ross, and T. D. Ladd, Magnetic gradient fluctuations from quadrupolar in exchange-only qubits, PRX Quantum 2, 010347 (2021).
- J. Kempe, D. Bacon, D. P. DiVincenzo, and K. B. Whaley, Encoded universality from a single physical interaction, Quantum Inf. Comput. 1, 33 (2001a).
- K. Eng, T. D. Ladd, A. Smith, M. G. Borselli, A. A. Kiselev, B. H. Fong, K. S. Holabird, T. M. Hazard, B. Huang, P. W. Deelman, I. Milosavljevic, A. E. Schmitz, R. S. Ross, M. F. Gyure, and A. T. Hunter, Isotopically enhanced triple-quantum-dot qubit, Sci. Adv. 1, e1500214 (2015).
- Y. S. Weinstein and C. S. Hellberg, Energetic suppression of decoherence in exchange-only quantum computation, Phys. Rev. A 72, 022319 (2005).
- J. D. Broz, J. C. Hoke, E. Acuna, and J. R. Petta (in press), Demonstration of an always-on exchange-only spin qubit, Nat. Commun. (2026).
- I. Heinz, F. Borjans, M. J. Curry, R. Kotlyar, F. Luthi, M. T. Mądzik, F. A. Mohiyaddin, N. Bishop, and G. Burkard, Fast quantum gates for exchange-only qubits using simultaneous exchange pulses, PRX Quantum 6, 030353 (2025).
- A. J. Weinstein et al., Universal logic with encoded spin qubits in silicon, Nature 615, 817 (2023).
- M. D. Reed, B. M. Maune, R. W. Andrews, M. G. Borselli, K. Eng, M. P. Jura, A. A. Kiselev, T. D. Ladd, S. T. Merkel, I. Milosavljevic, E. J. Pritchett, M. T. Rakher, R. S. Ross, A. E. Schmitz, A. Smith, J. A. Wright, M. F. Gyure, and A. T. Hunter, Reduced sensitivity to charge noise in semiconductor spin qubits via symmetric operation, Phys. Rev. Lett. 116, 110402 (2016).
- E. Acuna, J. D. Broz, K. Shyamsundar, A. B. Mei, C. P. Feeney, V. Smetanka, T. Davis, K. Lee, M. D. Choi, B. Boyd, J. Suh, W. Ha, C. Jennings, A. S. Pan, D. S. Sanchez, M. D. Reed, and J. R. Petta, Coherent control of a triangular exchange-only spin qubit, Phys. Rev. Appl. 22, 044057 (2024).
- T. Hensgens, T. Fujita, L. Janssen, X. Li, C. J. Van Diepen, C. Reichl, W. Wegscheider, S. Das Sarma, and L. M. K. Vandersypen, Quantum simulation of a Fermi–Hubbard model using a semiconductor quantum dot array, Nature 548, 70 (2017).
- A. R. Mills, M. M. Feldman, C. Monical, P. J. Lewis, K. W. Larson, A. M. Mounce, and J. R. Petta, Computer-automated tuning procedures for semiconductor quantum dot arrays, Appl. Phys. Lett. 115, 113501 (2019).
- T.-K. Hsiao, C. van Diepen, U. Mukhopadhyay, C. Reichl, W. Wegscheider, and L. M. K. Vandersypen, Efficient orthogonal control of tunnel couplings in a quantum dot array, Phys. Rev. Appl. 13, 054018 (2020).
- J. Z. Blumoff et al., Fast and high-fidelity state preparation and measurement in triple-quantum-dot spin qubits, PRX Quantum 3, 010352 (2022).
- H. Qiao, Y. P. Kandel, K. Deng, S. Fallahi, G. C. Gardner, M. J. Manfra, E. Barnes, and J. M. Nichol, Coherent multispin exchange coupling in a quantum-dot spin chain, Phys. Rev. X 10, 031006 (2020).
- J. R. Petta, A. C. Johnson, J. M. Taylor, E. A. Laird, A. Yacoby, M. D. Lukin, C. M. Marcus, M. P. Hanson, and A. C. Gossard, Coherent manipulation of coupled electron spins in semiconductor quantum dots, Science 309, 2180 (2005).
- J. D. Broz, J. C. Hoke, E. Acuna, and J. R. Petta, Supplementary information for: Leakage-protected idle operation of a triangular exchange-only qubit spin qubit, http://link.aps.org/supplemental/10.1103/sljc-cmdw (2026).
- J. Kempe, D. Bacon, D. A. Lidar, and K. B. Whaley, Theory of decoherence-free fault-tolerant universal quantum computation, Phys. Rev. A 63, 042307 (2001).
- X. Zhou, Z.-W. Zhou, G.-C. Guo, and M. J. Feldman, Quantum computation with untunable couplings, Phys. Rev. Lett. 89, 197903 (2002).
- V. W. Scarola, K. Park, and S. Das Sarma, Chirality in quantum computation with spin cluster qubits, Phys. Rev. Lett. 93, 120503 (2004).
- C.-Y. Hsieh and P. Hawrylak, Quantum circuits based on coded qubits encoded in chirality of electron spin complexes in triple quantum dots, Phys. Rev. B 82, 205311 (2010).
- V. Srinivasa, J. Levy, and C. S. Hellberg, Flying spin qubits: A method for encoding and transporting qubits within a dimerized Heisenberg spin- chain, Phys. Rev. B 76, 094411 (2007).
- Y. Avishai, T. Kuzmenko, and K. Kikoin, Dynamical and point symmetry of the Kondo effect in triangular quantum dot, Physica E 29, 334 (2005).
- K. Ingersent, A. W. W. Ludwig, and I. Affleck, Kondo screening in a magnetically frustrated nanostructure: Exact results on a stable non-Fermi-liquid phase, Phys. Rev. Lett. 95, 257204 (2005).
