Symmetry-Protected Topological Optical Lattice Clock

Tianrui Xu1,2,3,*, Anjun Chu1,2,4, Kyungtae Kim1, James K. Thompson1, Jun Ye1, Tilman Esslinger5, and Ana Maria Rey1,2,†

  • *Contact author: tianruixc@gmail.com
  • †Contact author: arey@jilau1.colorado.edu
PDF

PRX Quantum 6, 030322 – Published 6 August, 2025

DOI: https://doi.org/10.1103/h1nh-thg9

Abstract

We theoretically propose a tunable implementation of symmetry-protected topological phases of matter in a synthetic superlattice, taking advantage of the long coherence time and exquisite spectral resolutions offered by gravity-tilted optical lattice clocks. We describe a protocol similar to Rabi spectroscopy that can be used to probe the distinct topological properties of our system. We then demonstrate how the sensitivity of clocks and interferometers can be protected from unwanted experimental imperfections offered by the underlying topological robustness. The proposed implementation opens a path to exploiting the unique opportunities offered by symmetry-protected topological phases in state-of-the-art quantum sensors.

View figure in article

Physics Subject Headings (PhySH)

Popular Summary

Optical lattice clocks (OLCs) use the splitting between two long-lived electronic levels in an atom to provide an unrivaled definition of the second. These clocks have reached record levels of precision, but they will soon reach the point where their steady progress will be limited by small but unwanted experimental imperfections. Therefore, finding protocols to make OLCs more robust is an important milestone.

In this paper, we propose a way to make a leap forward by taking advantage of the robustness offered by “symmetry-protected topological” (SPT) phases. An SPT phase is a type of quantum matter, which minimizes the energy of a Hamiltonian that obeys specific “symmetries.” Its topological character stems from the fact that it remains unaffected to all perturbations that preserve these symmetries. Here, first we show how to create an SPT phase in a tilted OLC and how to probe its topological robustness with standard spectroscopic tools. Next, we show that the intrinsic robustness of such a phase can indeed help to reduce the statistical noise arising from certain experimental imperfections and thus help to improve phase-estimation tasks relevant for frequency standards and inertial sensing.

Our work bridges several rapidly developing fields in physics and may help open up a new experimental paradigm, which benefits from topologically robust states of matter for enhanced quantum sensing.

Article Text

References (63)

  1. T. L. Nicholson, S. L. Campbell, R. B. Hutson, G. E. Marti, B. J. Bloom, R. L. McNally, W. Zhang, M. D. Barrett, M. S. Safronova, G. F. Strouse, W. L. Tew, and J. Ye, Systematic evaluation of an atomic clock at 2×10−18 total uncertainty, Nat. Commun. 6, 6896 (2015).
  2. Andrew D. Ludlow, Martin M. Boyd, Jun Ye, E. Peik, and P. O. Schmidt, Optical atomic clocks, Rev. Mod. Phys. 87, 637 (2015).
  3. S. L. Campbell, R. B. Hutson, G. E. Marti, A. Goban, N. Darkwah Oppong, R. L. McNally, L. Sonderhouse, J. M. Robinson, W. Zhang, B. J. Bloom, and J. Ye, A Fermi-degenerate three-dimensional optical lattice clock, Science 358, 90 (2017).
  4. W. F. McGrew, X. Zhang, R. J. Fasano, S. A. Schäffer, K. Beloy, D. Nicolodi, R. C. Brown, N. Hinkley, G. Milani, M. Schioppo, T. H. Yoon, and A. D. Ludlow, Atomic clock performance enabling geodesy below the centimetre level, Nature 564, 87 (2018).
  5. E. Oelker, R. B. Hutson, C. J. Kennedy, L. Sonderhouse, T. Bothwell, A. Goban, D. Kedar, C. Sanner, J. M. Robinson, G. E. Marti, D. G. Matei, T. Legero, M. Giunta, R. Holzwarth, F. Riehle, U. Sterr, and J. Ye, Demonstration of 4.8×10−17 stability at 1 s for two independent optical clocks, Nat. Photonics 13, 714 (2019).
  6. Tobias Bothwell, Colin J. Kennedy, Alexander Aeppli, Dhruv Kedar, John M. Robinson, Eric Oelker, Alexander Staron, and Jun Ye, Resolving the gravitational redshift across a millimetre-scale atomic sample, Nature 602, 420 (2022).
  7. Xin Zheng, Jonathan Dolde, Varun Lochab, Brett N. Merriman, Haoran Li, and Shimon Kolkowitz, Differential clock comparisons with a multiplexed optical lattice clock, Nature 602, 425 (2022).
  8. Alexander Aeppli, Anjun Chu, Tobias Bothwell, Colin J. Kennedy, Dhruv Kedar, Peiru He, Ana Maria Rey, and Jun Ye, Hamiltonian engineering of spin-orbit–coupled fermions in a Wannier-Stark optical lattice clock, Sci. Adv. 8, eadc9242 (2022).
  9. Kyle Beloy et al., Frequency ratio measurements at 18-digit accuracy using an optical clock network, Nature 591, 564 (2021).
  10. Alexander Aeppli, Kyungtae Kim, William Warfield, Marianna S. Safronova, and Jun Ye, Clock with 8×10−19 systematic uncertainty, Phys. Rev. Lett. 133, 023401 (2024).
  11. N. R. Cooper, J. Dalibard, and I. B. Spielman, Topological bands for ultracold atoms, Rev. Mod. Phys. 91, 015005 (2019).
  12. Roberta Citro and Monika Aidelsburger, Thouless pumping and topology, Nat. Rev. Phys. 5, 87 (2023).
  13. W. P. Su, J. R. Schrieffer, and A. J. Heeger, Solitons in polyacetylene, Phys. Rev. Lett. 42, 1698 (1979).
  14. W. P. Su, J. R. Schrieffer, and A. J. Heeger, Soliton excitations in polyacetylene, Phys. Rev. B 22, 2099 (1980).
  15. M. J. Rice and E. J. Mele, Elementary excitations of a linearly conjugated diatomic polymer, Phys. Rev. Lett. 49, 1455 (1982).
  16. Marcos Atala, Monika Aidelsburger, Julio T. Barreiro, Dmitry Abanin, Takuya Kitagawa, Eugene Demler, and Immanuel Bloch, Direct measurement of the Zak phase in topological Bloch bands, Nat. Phys. 9, 795 (2013).
  17. M. Lohse, C. Schweizer, O. Zilberberg, M. Aidelsburger, and I. Bloch, A Thouless quantum pump with ultracold bosonic atoms in an optical superlattice, Nat. Phys. 12, 350 (2016).
  18. Shuta Nakajima, Takafumi Tomita, Shintaro Taie, Tomohiro Ichinose, Hideki Ozawa, Lei Wang, Matthias Troyer, and Yoshiro Takahashi, Topological Thouless pumping of ultracold fermions, Nat. Phys. 12, 296 (2016).
  19. Anne-Sophie Walter, Zijie Zhu, Marius Gächter, Joaquín Minguzzi, Stephan Roschinski, Kilian Sandholzer, Konrad Viebahn, and Tilman Esslinger, Quantization and its breakdown in a Hubbard–Thouless pump, Nat. Phys. 19, 1471 (2023).
  20. Eric J. Meier, Fangzhao Alex An, and Bryce Gadway, Observation of the topological soliton state in the Su-Schrieffer-Heeger model, Nat. Commun. 7, 13986 (2016).
  21. Eric J. Meier, Fangzhao Alex An, Alexandre Dauphin, Maria Maffei, Pietro Massignan, Taylor L. Hughes, and Bryce Gadway, Observation of the topological Anderson insulator in disordered atomic wires, Science 362, 929 (2018).
  22. Tao Yuan, Chao Zeng, Yi-Yi Mao, Fei-Fei Wu, Yan-Jun Xie, Wen-Zhuo Zhang, Han-Ning Dai, Yu-Ao Chen, and Jian-Wei Pan, Realizing robust edge-to-edge transport of atomic momentum states in a dynamically modulated synthetic lattice, Phys. Rev. Res. 5, L032005 (2023).
  23. Sylvain de Léséleuc, Vincent Lienhard, Pascal Scholl, Daniel Barredo, Sebastian Weber, Nicolai Lang, Hans Peter Büchler, Thierry Lahaye, and Antoine Browaeys, Observation of a symmetry-protected topological phase of interacting bosons with Rydberg atoms, Science 365, 775 (2019).
  24. S. K. Kanungo, J. D. Whalen, Y. Lu, M. Yuan, S. Dasgupta, F. B. Dunning, K. R. A. Hazzard, and T. C. Killian, Realizing topological edge states with Rydberg-atom synthetic dimensions, Nat. Commun. 13, 972 (2022).
  25. Martin Leder, Christopher Grossert, Lukas Sitta, Maximilian Genske, Achim Rosch, and Martin Weitz, Real-space imaging of a topologically protected edge state with ultracold atoms in an amplitude-chirped optical lattice, Nat. Commun. 7, 13112 (2016).
  26. Or Katz, Lei Feng, Diego Porras, and Christopher Monroe, Observing topological insulator phases with a programmable quantum simulator, ArXiv:2401.10362 [quant-ph].
  27. Dizhou Xie, Wei Gou, Teng Xiao, Bryce Gadway, and Bo Yan, Topological characterizations of an extended Su-Schrieffer-Heeger model, npj Quantum Inf. 5, 55 (2019).
  28. H.-I Lu, M. Schemmer, L. M. Aycock, D. Genkina, S. Sugawa, and I. B. Spielman, Geometrical pumping with a Bose-Einstein condensate, Phys. Rev. Lett. 116, 200402 (2016).
  29. J. Zak, Berry’s phase for energy bands in solids, Phys. Rev. Lett. 62, 2747 (1989).
  30. S. Kolkowitz, S. L. Bromley, T. Bothwell, M. L. Wall, G. E. Marti, A. P. Koller, X. Zhang, A. M. Rey, and J. Ye, Spin–orbit-coupled fermions in an optical lattice clock, Nature 542, 66 (2017).
  31. Cristian D. Panda, Matthew J. Tao, Miguel Ceja, Justin Khoury, Guglielmo M. Tino, and Holger Müller, Measuring gravitational attraction with a lattice atom interferometer, Nature 631, 515 (2024).
  32. B. Pelle, A. Hilico, G. Tackmann, Q. Beaufils, and F. Pereira dos Santos, State-labeling Wannier-Stark atomic interferometers, Phys. Rev. A 87, 023601 (2013).
  33. Anjun Chu, Peiru He, James K. Thompson, and Ana Maria Rey, Quantum enhanced cavity QED interferometer with partially delocalized atoms in lattices, Phys. Rev. Lett. 127, 210401 (2021).
  34. Lingfeng Yan, Stefan Lannig, William R. Milner, Max N. Frankel, Ben Lewis, Dahyeon Lee, Kyungtae Kim, and Jun Ye, A high-power clock laser spectrally tailored for high-fidelity quantum state engineering, ArXiv:2501.09343 [physics.atom-ph].
  35. S. Blatt, J. W. Thomsen, G. K. Campbell, A. D. Ludlow, M. D. Swallows, M. J. Martin, M. M. Boyd, and J. Ye, Rabi spectroscopy and excitation inhomogeneity in a one-dimensional optical lattice clock, Phys. Rev. A 80, 052703 (2009).
  36. Kyungtae Kim, Alexander Aeppli, Tobias Bothwell, and Jun Ye, Evaluation of lattice light shift at low 10−19 uncertainty for a shallow lattice sr optical clock, Phys. Rev. Lett. 130, 113203 (2023).
  37. Pierre Lemonde and Peter Wolf, Optical lattice clock with atoms confined in a shallow trap, Phys. Rev. A 72, 033409 (2005).
  38. Michael L. Wall, Andrew P. Koller, Shuming Li, Xibo Zhang, Nigel R. Cooper, Jun Ye, and Ana Maria Rey, Synthetic spin-orbit coupling in an optical lattice clock, Phys. Rev. Lett. 116, 035301 (2016).
  39. L. F. Livi, G. Cappellini, M. Diem, L. Franchi, C. Clivati, M. Frittelli, F. Levi, D. Calonico, J. Catani, M. Inguscio, and L. Fallani, Synthetic dimensions and spin-orbit coupling with an optical clock transition, Phys. Rev. Lett. 117, 220401 (2016).
  40. Shanchao Zhang and Gyu-Boong Jo, Recent advances in spin-orbit coupled quantum gases, J. Phys. Chem. Solids 128, 75 (2019).
  41. Simon Wili, Tilman Esslinger, and Konrad Viebahn, An accordion superlattice for controlling atom separation in optical potentials, New J. Phys. 25, 033037 (2023).
  42. D. J. Thouless, Quantization of particle transport, Phys. Rev. B 27, 6083 (1983).
  43. Q. Niu and D. J. Thouless, Quantised adiabatic charge transport in the presence of substrate disorder and many-body interaction, J. Phys. A: Math. Gen. 17, 2453 (1984).
  44. Di Xiao, Ming-Che Chang, and Qian Niu, Berry phase effects on electronic properties, Rev. Mod. Phys. 82, 1959 (2010).
  45. R. Wang and Z. Song, Robustness of the pumping charge to dynamic disorder, Phys. Rev. B 100, 184304 (2019).
  46. Alexander Impertro, Simon Karch, Julian F. Wienand, SeungJung Huh, Christian Schweizer, Immanuel Bloch, and Monika Aidelsburger, Local readout and control of current and kinetic energy operators in optical lattices, Phys. Rev. Lett. 133, 063401 (2024).
  47. M. S. Rudner and L. S. Levitov, Topological transition in a non-Hermitian quantum walk, Phys. Rev. Lett. 102, 065703 (2009).
  48. Filippo Cardano, Alessio D’Errico, Alexandre Dauphin, Maria Maffei, Bruno Piccirillo, Corrado de Lisio, Giulio de Filippis, Vittorio Cataudella, Enrico Santamato, Lorenzo Marrucci, Maciej Lewenstein, and Pietro Massignan, Detection of Zak phases and topological invariants in a chiral quantum walk of twisted photons, Nat. Commun. 8, 15516 (2017).
  49. Maria Maffei, Alexandre Dauphin, Filippo Cardano, Maciej Lewenstein, and Pietro Massignan, Topological characterization of chiral models through their long time dynamics, New J. Phys. 20, 013023 (2018).
  50. Bernd Lücke, Jan Peise, Giuseppe Vitagliano, Jan Arlt, Luis Santos, Géza Tóth, and Carsten Klempt, Detecting multiparticle entanglement of Dicke states, Phys. Rev. Lett. 112, 155304 (2014).
  51. Lucas Gabardos, Bihui Zhu, Steven Lepoutre, Ana Maria Rey, Bruno Laburthe-Tolra, and Laurent Vernac, Relaxation of the collective magnetization of a dense 3D array of interacting dipolar S =3 atoms, Phys. Rev. Lett. 125, 143401 (2020).
  52. Achim Peters, Keng Yeow Chung, and Steven Chu, Measurement of gravitational acceleration by dropping atoms, Nature 400, 849 (1999).
  53. G. Rosi, F. Sorrentino, L. Cacciapuoti, M. Prevedelli, and G. M. Tino, Precision measurement of the Newtonian gravitational constant using cold atoms, Nature 510, 518 (2014).
  54. P. Cladé, S. Guellati-Khélifa, C. Schwob, F. Nez, L. Julien, and F. Biraben, A promising method for the measurement of the local acceleration of gravity using Bloch oscillations of ultracold atoms in a vertical standing wave, Europhys. Lett. 71, 730 (2005).
  55. Renée Charrière, Malo Cadoret, Nassim Zahzam, Yannick Bidel, and Alexandre Bresson, Local gravity measurement with the combination of atom interferometry and Bloch oscillations, Phys. Rev. A 85, 013639 (2012).
  56. Xian Zhang, Ruben Pablo del Aguila, Tommaso Mazzoni, Nicola Poli, and Guglielmo M. Tino, Trapped-atom interferometer with ultracold Sr atoms, Phys. Rev. A 94, 043608 (2016).
  57. Victoria Xu, Matt Jaffe, Cristian D. Panda, Sofus L. Kristensen, Logan W. Clark, and Holger Müller, Probing gravity by holding atoms for 20 seconds, Science 366, 745 (2019).
  58. Cristian D. Panda, Matthew Tao, James Egelhoff, Miguel Ceja, Victoria Xu, and Holger Müller, Coherence limits in lattice atom interferometry at the one-minute scale, Nat. Phys. 20, 1234 (2024).
  59. Holger Müller, Sheng-wey Chiow, Quan Long, Sven Herrmann, and Steven Chu, Atom interferometry with up to 24-photon-momentum-transfer beam splitters, Phys. Rev. Lett. 100, 180405 (2008).
  60. Wenjie Liu, Yongguan Ke, and Chaohong Lee, Shortcuts to adiabatic Thouless pumping, ArXiv:2401.17081.
  61. Y.-T. Lin, D. M. Kennes, M. Pletyukhov, C. S. Weber, H. Schoeller, and V. Meden, Interacting Rice-Mele model: Bulk and boundaries, Phys. Rev. B 102, 085122 (2020).
  62. Lintao Li, William Huie, Neville Chen, Brian DeMarco, and Jacob P. Covey, Active cancellation of servo-induced noise on stabilized lasers via feedforward, Phys. Rev. Appl. 18, 064005 (2022).
  63. ∑kJν+k(u)Jk(u)eikα=Jν(2usin(α2))e−iν(π+α)/2.
