Alternating and Gaussian Fermionic Isometric Tensor Network States

Yantao Wu1,*, Zhehao Dai2,3, Sajant Anand2, Sheng-Hsuan Lin4, Qi Yang1,5, Lei Wang1, Frank Pollmann4, and Michael P. Zaletel2,6

  • *Contact author: yantaow@iphy.ac.cn
PDF

PRX Quantum 6, 040324 – Published 5 November, 2025

DOI: https://doi.org/10.1103/8ypw-c8t4

Abstract

Isometric tensor networks in two dimensions enable efficient and accurate study of quantum many-body states, yet the effect of the isometric restriction on the represented quantum states is not fully understood. We address this question in two main contributions. First, we introduce an improved variant of isometric tensor network states (isoTNS) in two dimensions, where the isometric arrows on the columns of the network alternate between pointing upward and downward; hence the name alternating isometric tensor network states. Second, we introduce a numerical tool—the isometric Gaussian fermionic TNS (isoGfTNS)—that incorporates isometric constraints into the framework of Gaussian fermionic tensor network states. We demonstrate in numerous ways that alternating isoTNSs represent many-body ground states of two-dimensional quantum systems significantly better than the original isoTNSs. First, we show that the entanglement in an isoTNS is mediated along the isometric arrows and that alternating isoTNSs mediate entanglement more efficiently than conventional isoTNSs. Second, alternating isoTNSs correspond to a deeper, and thus more representative, sequential-circuit construction of depth O(Lx⋅Ly) compared to the original isoTNSs of depth O(Lx+Ly). Third, using the Gaussian framework and gradient-based energy minimization, we provide numerical evidence of better bond-dimension scaling and variational energy of alternating isoGfTNSs for ground states of various free-fermionic models, including the Fermi surface, the band insulator, and the px+ipy mean-field superconductor. Finally, benchmarking on the transverse-field Ising model, we demonstrate that an alternating isoTNS provides substantially improved performance and stability relative to the original isoTNS for the ground-state search algorithm in interacting systems.

View figure in article

Physics Subject Headings (PhySH)

Popular Summary

Quantum many-body systems—ensembles of many interacting particles—are at the heart of some of the most intriguing phenomena in physics, from superconductors to magnets. The difficulty of simulating these systems on classical computers is related to the amount of “quantum entanglement” in a system. Tensor network methods offer a promising way to tackle this by compressing quantum states into manageable chunks. However, an open question remains: How is entanglement mediated by tensor networks?

In this work, we explore a special class of tensor networks known as “isometric tensor network states,” which can be thought of as providing a blueprint for how a quantum state could be built or “prepared” as a quantum circuit. We introduce a new layout—called alternating isometric tensor networks—that we show can more effectively channel entanglement in two dimensions. To show this, we also develop a related framework called isometric Gaussian fermion tensor networks, which allows us to test how well these representations capture the ground states of various fermionic quantum systems. Across a variety of models, we find that our new layout more accurately represents the true quantum states, without any added computational cost.

Looking ahead, this approach could open the door to more efficient simulations of complex quantum materials and could even inform new ways to build quantum circuits on actual quantum computers. By optimizing how we structure these tensor networks, we hope to push the frontier of classical simulations of quantum systems—and better understand which exotic states of matter can be realistically modeled today.

Article Text

References (71)

  1. F. Verstraete and J. I. Cirac, Renormalization algorithms for quantum-many body systems in two and higher dimensions, ArXiv:cond-mat/0407066.
  2. H. Niggemann, A. Klümper, and J. Zittartz, Quantum phase transition in spin-3/2 systems on the hexagonal lattice—optimum ground state approach, Z. Phys. B Condens. Matter 104, 103 (1997).
  3. T. Nishino and K. Okunishi, A density matrix algorithm for 3D classical models, J. Phys. Soc. Jpn. 67, 3066 (1998).
  4. G. Sierra, in Proceedings of the Workshop on the Exact Renormalization Group (World Scientific, Faro, Portugal, 1998).
  5. S.-J. Ran, E. Tirrito, C. Peng, X. Chen, L. Tagliacozzo, G. Su, and M. Lewenstein, Tensor Network Contractions: Methods and Applications to Quantum Many-Body Systems (Springer Nature, 2020).
  6. J. I. Cirac, D. Pérez-García, N. Schuch, and F. Verstraete, Matrix product states and projected entangled pair states: Concepts, symmetries, theorems, Rev. Mod. Phys. 93, 045003 (2021).
  7. M. C. Bañuls, Tensor network algorithms: A route map, Annu. Rev. Condens. Matter Phys. 14, 173 (2023).
  8. J. Naumann, E. L. Weerda, M. Rizzi, J. Eisert, and P. Schmoll, An introduction to infinite projected entangled-pair state methods for variational ground state simulations using automatic differentiation, SciPost Phys. Lect. Notes 86 (2024).
  9. S. R. White, Density matrix formulation for quantum renormalization groups, Phys. Rev. Lett. 69, 2863 (1992).
  10. U. Schollwöck, The density-matrix renormalization group, Rev. Mod. Phys. 77, 259 (2005).
  11. G. Vidal, Efficient classical simulation of slightly entangled quantum computations, Phys. Rev. Lett. 91, 147902 (2003).
  12. J. Haegeman, C. Lubich, I. Oseledets, B. Vandereycken, and F. Verstraete, Unifying time evolution and optimization with matrix product states, Phys. Rev. B 94, 165116 (2016).
  13. M. P. Zaletel and F. Pollmann, Isometric tensor network states in two dimensions, Phys. Rev. Lett. 124, 037201 (2020).
  14. R. Haghshenas, M. J. O’Rourke, and G. Kin-Lic Chan, Conversion of projected entangled pair states into a canonical form, Phys. Rev. B 100, 054404 (2019).
  15. K. Hyatt and E. M. Stoudenmire, DMRG approach to optimizing two-dimensional tensor networks, ArXiv:1908.08833.
  16. C. Schön, E. Solano, F. Verstraete, J. I. Cirac, and M. M. Wolf, Sequential generation of entangled multiqubit states, Phys. Rev. Lett. 95, 110503 (2005).
  17. Y.-J. Liu, K. Shtengel, and F. Pollmann, Simulating two-dimensional topological quantum phase transitions on a digital quantum computer, Phys. Rev. Research 6, 043256 (2024).
  18. X. Chen, A. Dua, M. Hermele, D. T. Stephen, N. Tantivasadakarn, R. Vanhove, and J.-Y. Zhao, Sequential quantum circuits as maps between gapped phases, Phys. Rev. B 109, 075116 (2024).
  19. X. Chen, M. Hermele, and D. T. Stephen, Sequential adiabatic generation of chiral topological states, ArXiv:2402.03433.
  20. H.-K. Zhang, S. Liu and S.-X. Zhang, Absence of Barren Plateaus in finite local-depth circuits with long-range entanglement, Phys. Rev. Lett. 132, 150603 (2024).
  21. S.-H. Lin, M. P. Zaletel, and F. Pollmann, Efficient simulation of dynamics in two-dimensional quantum spin systems with isometric tensor networks, Phys. Rev. B 106, 245102 (2022).
  22. Y. Wu, S. Anand, S.-H. Lin, F. Pollmann, and M. P. Zaletel, Two-dimensional isometric tensor networks on an infinite strip, Phys. Rev. B 107, 245118 (2023).
  23. Z. Dai, Y. Wu, T. Wang, and M. P. Zaletel, Fermionic isometric tensor network states in two dimensions, Phys. Rev. Lett. 134, 026502 (2025).
  24. W. Kadow, F. Pollmann, and M. Knap, Isometric tensor network representations of two-dimensional thermal states, Phys. Rev. B 107, 205106 (2023).
  25. C. V. Kraus, N. Schuch, F. Verstraete, and J. I. Cirac, Fermionic projected entangled pair states, Phys. Rev. A 81, 052338 (2010).
  26. T. B. Wahl, H.-H. Tu, N. Schuch, and J. I. Cirac, Projected entangled-pair states can describe chiral topological states, Phys. Rev. Lett. 111, 236805 (2013).
  27. J. Dubail and N. Read, Tensor network trial states for chiral topological phases in two dimensions and a no-go theorem in any dimension, Phys. Rev. B 92, 205307 (2015).
  28. Q. Yang, X.-Y. Zhang, H.-J. Liao, H.-H. Tu, and L. Wang, Projected d-wave superconducting state: A fermionic projected entangled pair state study, Phys. Rev. B 107, 125128 (2023).
  29. Q. Mortier, N. Schuch, F. Verstraete, and J. Haegeman, Tensor networks can resolve Fermi surfaces, Phys. Rev. Lett. 129, 206401 (2022).
  30. R. Masaoka, S. Ono, H. C. Po, and H. Watanabe, Frustration-free free fermions and beyond, ArXiv:2503.12879.
  31. Z.-Y. Wei, D. Malz, and J. I. Cirac, Sequential generation of projected entangled-pair states, Phys. Rev. Lett. 128, 010607 (2022).
  32. F. Pollmann, S. Mukerjee, A. M. Turner, and J. E. Moore, Theory of finite-entanglement scaling at one-dimensional quantum critical points, Phys. Rev. Lett. 102, 255701 (2009).
  33. N. Bao, C. Cao, S. M. Carroll, A. Chatwin-Davies, N. Hunter-Jones, J. Pollack, and G. N. Remmen, Consistency conditions for an AdS multiscale entanglement renormalization ansatz correspondence, Phys. Rev. D 91, 125036 (2015).
  34. C. Schön, K. Hammerer, M. M. Wolf, J. I. Cirac, and E. Solano, Sequential generation of matrix-product states in cavity QED, Phys. Rev. A 75, 032311 (2007).
  35. M.-C. Banuls, D. Pérez-García, M. M. Wolf, F. Verstraete, and J. I. Cirac, Sequentially generated states for the study of two-dimensional systems, Phys. Rev. A 77, 052306 (2008).
  36. Z.-Y. Wei, D. Malz, A. González-Tudela, and J. I. Cirac, Generation of photonic matrix product states with Rydberg atomic arrays, Phys. Rev. Res. 3, 023021 (2021).
  37. M. Foss-Feig, D. Hayes, J. M. Dreiling, C. Figgatt, J. P. Gaebler, S. A. Moses, J. M. Pino, and A. C. Potter, Holographic quantum algorithms for simulating correlated spin systems, Phys. Rev. Res. 3, 033002 (2021).
  38. S. Anand, J. Hauschild, Y. Zhang, A. C. Potter, and M. P. Zaletel, Holographic quantum simulation of entanglement renormalization circuits, PRX Quantum 4, 030334 (2023).
  39. R. Haghshenas, E. Chertkov, M. DeCross, T. M. Gatterman, J. A. Gerber, K. Gilmore, D. Gresh, N. Hewitt, C. V. Horst, M. Matheny, T. Mengle, B. Neyenhuis, D. Hayes, and M. Foss-Feig, Probing critical states of matter on a digital quantum computer, Phys. Rev. Lett. 133, 266502 (2024).
  40. L. Slattery and B. K. Clark, Quantum circuits for two-dimensional isometric tensor networks, ArXiv:2108.02792.
  41. Due to the isometry conditions on each tensor, with physical dimension d=2 one cannot have a nontrivial uniform bond dimension χ>1 for all virtual legs at the boundary. As shown in Figs. 5 and 5, the vertical bond dimensions of the leftmost column (i.e., furthest from the OC) are trivial. Thus, tensors in the final column, when viewed as a gates of the resulting quantum circuit, can be applied in parallel with other gates. This is a boundary effect. For the alt-isoTNS, only one unitary gate can be applied at each time step inside the bulk. Therefore, the depth of an alt-isoTNS circuit is O(Lx⋅Ly).
  42. I. H. Kim, Holographic quantum simulation, ArXiv:1702.02093.
  43. Y. Du, T. Huang, S. You, M.-H. Hsieh, and D. Tao, Quantum circuit architecture search for variational quantum algorithms, npj Quantum Inf. 8, 62 (2022).
  44. Y. Du, Z. Tu, X. Yuan, and D. Tao, Efficient measure for the expressivity of variational quantum algorithms, Phys. Rev. Lett. 128, 080506 (2022).
  45. L. Funcke, T. Hartung, K. Jansen, S. Kühn, and P. Stornati, Dimensional expressivity analysis of parametric quantum circuits, Quantum 5, 422 (2021).
  46. Y. Wu, J. Yao, P. Zhang, and H. Zhai, Expressivity of quantum neural networks, Phys. Rev. Res. 3, L032049 (2021).
  47. T. Haug, K. Bharti, and M.S. Kim, Capacity and quantum geometry of parametrized quantum circuits, PRX Quantum 2, 040309 (2021).
  48. Q. Miao and T. Barthel, Isometric tensor network optimization for extensive Hamiltonians is free of barren plateaus, Phys. Rev. A 109, L050402 (2024).
  49. T. Barthel and Q. Miao, Absence of barren plateaus and scaling of gradients in the energy optimization of isometric tensor network states, Commun. Math. Phys. 406, 86 (2025).
  50. M. A. Levin and X.-G. Wen, String-net condensation: A physical mechanism for topological phases, Phys. Rev. B 71, 045110 (2005).
  51. I. H. Kim and D. Ranard, Classifying 2D topological phases: Mapping ground states to string-nets, ArXiv:2405.17379.
  52. T. Soejima, K. Siva, N. Bultinck, S. Chatterjee, F. Pollmann, and M. P. Zaletel, Isometric tensor network representation of string-net liquids, Phys. Rev. B 101, 085117 (2020).
  53. A. Kitaev, Fault-tolerant quantum computation by anyons, Ann. Phys. (NY) 303, 2 (2003).
  54. N. Schuch, I. Cirac, and D. Pérez-García, PEPS as ground states: Degeneracy and topology, Ann. Phys. (NY) 325, 2153 (2010).
  55. The left-regular matrix representation of a group G is defined as follows. Consider the vector space spanned by all group elements: V=span{g|g∈G}, where all gs are defined to be linearly independent. The matrix representation ϕ(g) of g in V is a permutation matrix the action of which is defined on the basis of V as ϕ(g)|g′⟩=|gg′⟩∀g′∈G. This is clearly a, possibly reducible, matrix representation of G, because ϕ(g)ϕ(g′)=ϕ(gg′). All ϕ(g) are traceless expect when g=e.
  56. When nv is even, a GfTNS can be constructed as a conventional TNS with bond dimension 2nv/2. When nv is odd, this is no longer possible, yet the odd-nv GfTNS is still well defined. Thus, one should take χ=2nv as a continuation from even nv to odd nv.
  57. S. Bravyi, Lagrangian representation for fermionic linear optics, Quantum Inf. Comput. 5, 216 (2005).
  58. D. Gioev and I. Klich, Entanglement entropy of fermions in any dimension and the Widom conjecture, Phys. Rev. Lett. 96, 100503 (2006).
  59. B. Swingle, Entanglement entropy and the Fermi surface, Phys. Rev. Lett. 105, 050502 (2010).
  60. From basic solid state physics, the directionality in the k-space translates into the same directionality in the real space.
  61. J. Hasik, M. Van Damme, D. Poilblanc, and L. Vanderstraeten, Simulating chiral spin liquids with projected entangled-pair states, Phys. Rev. Lett. 129, 177201 (2022).
  62. E. L. Weerda and M. Rizzi, Fractional quantum Hall states with variational projected entangled-pair states: A study of the bosonic Harper-Hofstadter model, Phys. Rev. B 109, L241117 (2024).
  63. A. Kitaev, Anyons in an exactly solved model and beyond, Ann. Phys. 321, 2 (2006), January Special Issue.
  64. H. C. Jiang, Z. Y. Weng, and T. Xiang, Accurate determination of tensor network state of quantum lattice models in two dimensions, Phys. Rev. Lett. 101, 090603 (2008).
  65. The PEPS SU data have been provided by an anonymous referee, to whom we are grateful.
  66. M. Lubasch, J. I. Cirac, and M.-C. Bañuls, Algorithms for finite projected entangled pair states, Phys. Rev. B 90, 064425 (2014).
  67. W.-Y. Liu, Y.-Z. Huang, S.-S. Gong, and Z.-C. Gu, Accurate simulation for finite projected entangled pair states in two dimensions, Phys. Rev. B 103, 235155 (2021).
  68. T. Vieijra, J. Haegeman, F. Verstraete, and L. Vanderstraeten, Direct sampling of projected entangled-pair states, Phys. Rev. B 104, 235141 (2021).
  69. S. Anand, S. Thanvantri, Y. Wu, and M. P. Zaletel, Perfect sampling of isometric tensor networks and applications to finite temperature thermodynamics (to be published).
  70. X.-H. Yu, J. I. Cirac, P. Kos, and G. Styliaris, Dual-isometric projected entangled pair states, Phys. Rev. Lett. 133, 190401 (2024).
  71. Y. Wu, Z. Dai, S. Anand, S.-H. Lin, Q. Yang, L. Wang, F. Pollmann, and M. Zaletel, GitHub data repository, https://github.com/yantaow/open_data/tree/main/wu2025alternating, 2025.
