Variational Optical Phase Learning on a Continuous-Variable Quantum Compiler

Matthew A. Feldman1,2,*, Tyler Volkoff3,†, Seongjin Hong2, Claire E. Marvinney1,2, Zoë Holmes4, Raphael C. Pooser1,2, Andrew Sornborger5,2, and Alberto M. Marino1,2,‡

  • *Contact author: feldmanma@ornl.gov
  • †Contact author: volkoff@lanl.gov
  • ‡Contact author: marinoa@ornl.gov
PDF

PRX Quantum 7, 010358 – Published 23 March, 2026

DOI: https://doi.org/10.1103/7l8z-zn2m

Abstract

Quantum process learning is a fundamental primitive that draws inspiration from machine learning with the goal of better studying the dynamics of quantum systems. One approach to quantum process learning is quantum compilation, whereby an analog quantum operation is digitized by compiling it into a series of basic gates. While there has been significant focus on quantum compiling for discrete-variable systems, the continuous-variable (CV) framework has received comparatively less attention. We present an experimental implementation of a CV quantum compiler that uses two-mode squeezed light to learn a Gaussian unitary operation. We demonstrate the compiler by learning a parameterized linear phase unitary through the use of target and control phase unitaries to demonstrate a factor of 5.4 increase in the precision of the phase estimation and a 3.6-fold acceleration in the time-to-solution metric when leveraging quantum resources. We further show how our approach can be extended to higher-dimensional compilation tasks. Our results are enabled by the tunable control of our cost landscape via variable squeezing, thus providing a critical framework to simultaneously increase precision and reduce time-to-solution.

View figure in article

Physics Subject Headings (PhySH)

Popular Summary

Inspired by the techniques of machine learning, we have developed a novel experimental approach for learning quantum optical operations. Our research introduces a continuous-variable (CV) quantum compiler that uses squeezed light to learn phase operations with remarkable precision and efficiency. In quantum technologies, compilation focuses on learning a quantum digital twin for a complex quantum process. Our approach is particularly unique because it uses CV systems—quantum systems that rely on smoothly varying properties like the amplitude and phase of an electromagnetic field—rather than the more familiar discrete systems used to implement qubits.

In our study, we successfully compiled an optical phase operation by employing light in a two-mode squeezed state, an entangled state of light. This type of light, where the quantum fluctuations in two beams are correlated, serves as a valuable quantum resource for the learning process. By tuning the strength of the quantum correlations through the squeezing parameter, we were able to significantly improve the precision with which the system learns, achieving a factor of 5.4 increase in phase precision, while also accelerating the training process by 3.6 times.

One of the most interesting outcomes of this work is how the tunable squeezing capability impacts the landscape of the cost function, a mathematical measure of how close we are to our target operation. By adjusting the level of squeezing, we show that we can make the cost function more favorable for learning, resulting in faster convergence and higher accuracy. Overall, our work provides an important advance in using quantum light to learn quantum processes. The results demonstrate a practical framework to achieve both high precision and fast learning in quantum compilation, potentially enabling more efficient quantum algorithms and operations for future quantum technologies.

Article Text

Supplemental Material

References (91)

  1. Maria Schuld, I. Sinayskiy, and F. Petruccione, An introduction to quantum machine learning, Contemp. Phys. 56, 172 (2015).
  2. Y. Zhang and Q. Ni, Recent advances in quantum machine learning, Quantum Eng. 2, e34 (2020).
  3. S. Khatri, R. LaRose, A. Poremba, L. Cincio, A. T. Sornborger, and P. J. Coles, Quantum-assisted quantum compiling, Quantum 3, 140 (2019).
  4. K. Heya, Y. Suzuki, Y. Nakamura, and K. Fujii, Variational quantum gate optimization, arXiv:1810.12745.
  5. K. Poland, K. Beer, and T. J. Osborne, No free lunch for quantum machine learning, arXiv:2003.14103.
  6. K. Sharma, M. Cerezo, Z. Holmes, L. Cincio, A. Sornborger, and P. J. Coles, Reformulation of the no-free-lunch theorem for entangled datasets, Phys. Rev. Lett. 128, 070501 (2022).
  7. N. Killoran, T. R. Bromley, J. M. Arrazola, M. Schuld, N. Quesada, and S. Lloyd, Continuous-variable quantum neural networks, Phys. Rev. Res. 1, 033063 (2019).
  8. C. Cirstoiu, Z. Holmes, J. Iosue, L. Cincio, P. J. Coles, and A. Sornborger, Variational fast forwarding for quantum simulation beyond the coherence time, Npj Quantum Inf. 6, 1 (2020).
  9. J. Gibbs, K. Gili, Z. Holmes, B. Commeau, A. Arrasmith, L. Cincio, P. J. Coles, and A. Sornborger, Long-time simulations for fixed input states on quantum hardware, Npj Quantum Inf. 8, 135 (2022).
  10. J. Gibbs, Z. Holmes, M. C. Caro, N. Ezzell, H.-Y. Huang, L. Cincio, A. T. Sornborger, and P. J. Coles, Dynamical simulation via quantum machine learning with provable generalization, Phys. Rev. Res. 6, 013241 (2024).
  11. M. R. Geller, Z. Holmes, P. J. Coles, and A. Sornborger, Experimental quantum learning of a spectral decomposition, Phys. Rev. Res. 3, 033200 (2021).
  12. H.-Y. Huang, M. Broughton, J. Cotler, S. Chen, J. Li, M. Mohseni, H. Neven, R. Babbush, R. Kueng, J. Preskill, and J. R. McClean, Quantum advantage in learning from experiments, Science 376, 1182 (2022).
  13. M. C. Caro, H.-Y. Huang, M. Cerezo, K. Sharma, A. Sornborger, L. Cincio, and P. J. Coles, Generalization in quantum machine learning from few training data, Nat. Commun. 13, 4919 (2022).
  14. M. C. Caro, H.-Y. Huang, N. Ezzell, J. Gibbs, A. T. Sornborger, L. Cincio, P. J. Coles, and Z. Holmes, Out-of-distribution generalization for learning quantum dynamics, Nat. Commun. 14, 3751 (2023).
  15. H.-Y. Huang, S. Chen, and J. Preskill, Learning to predict arbitrary quantum processes, PRX Quantum 4, 040337 (2023).
  16. M. C. Caro, Learning quantum processes and Hamiltonians via the Pauli transfer matrix, ACM Trans. Quantum Comput. 5, 1 (2024).
  17. S. Jerbi, J. Gibbs, M. S. Rudolph, M. C. Caro, P. J. Coles, H.-Y. Huang, and Z. Holmes, The power and limitations of learning quantum dynamics incoherently, arXiv:2303.12834.
  18. V. T. Hai and L. B. Ho, Universal compilation for quantum state tomography, Sci. Rep. 13, 3750 (2023).
  19. T. Haug and M. S. Kim, Generalization of quantum machine learning models using quantum fisher information metric, Phys. Rev. Lett. 133, 050603 (2024).
  20. R. Kaubruegger, P. Silvi, C. Kokail, R. van Bijnen, A. M. Rey, J. Ye, A. M. Kaufman, and P. Zoller, Variational spin-squeezing algorithms on programmable quantum sensors, Phys. Rev. Lett. 123, 260505 (2019).
  21. R. Kaubruegger, A. Shankar, D. V. Vasilyev, and P. Zoller, Optimal and variational multiparameter quantum metrology and vector-field sensing, PRX Quantum 4, 020333 (2023).
  22. C. Huerta Alderete, M. H. Gordon, F. Sauvage, A. Sone, A. T. Sornborger, P. J. Coles, and M. Cerezo, Inference-based quantum sensing, Phys. Rev. Lett. 129, 190501 (2022).
  23. F. A. Mele, A. A. Mele, L. Bittel, J. Eisert, V. Giovannetti, L. Lami, L. Leone, and S. F. E. Oliviero, Learning quantum states of continuous variable systems, Nat. Phys. 21, 2002 (2025).
  24. V. T. Hai, N. T. Viet, and L. B. Ho, Variational preparation of entangled states on quantum computers, arXiv:2306.17422.
  25. L. Cincio, Y. Subaşı, A. T. Sornborger, and P. J. Coles, Learning the quantum algorithm for state overlap, New J. Phys. 20, 113022 (2018).
  26. T. Volkoff, Z. Holmes, and A. Sornborger, Universal compiling and (No-)Free-Lunch theorems for continuous-variable quantum learning, PRX Quantum 2, 040327 (2021).
  27. T. Volkoff and A. T. Sornborger, Learning linear optical circuits with coherent states, J. Phys. A: Math. Theor. 57, 305302 (2024).
  28. T. J. Volkoff, Strategies for variational quantum compiling of a zero-phase beam splitter on the Xanadu X8 processor, J. Russ. Laser Res. 43, 448 (2022).
  29. T. Jones and S. C. Benjamin, Robust quantum compilation and circuit optimisation via energy minimisation, Quantum 6, 628 (2022).
  30. L. S. Madsen, F. Laudenbach, M. F. Askarani, F. Rortais, T. Vincent, J. F. F. Bulmer, F. M. Miatto, L. Neuhaus, L. G. Helt, M. J. Collins, A. E. Lita, T. Gerrits, S. W. Nam, V. D. Vaidya, M. Menotti, I. Dhand, Z. Vernon, N. Quesada, and J. Lavoie, Quantum computational advantage with a programmable photonic processor, Nature 606, 75 (2022).
  31. M. Schuld and N. Killoran, Quantum machine learning in feature Hilbert spaces, Phys. Rev. Lett. 122, 040504 (2019).
  32. B. J. Lawrie, P. D. Lett, A. M. Marino, and R. C. Pooser, Quantum sensing with squeezed light, ACS Photonics 6, 1307 (2019).
  33. C. Hua, C. E. Marvinney, S. Hong, M. Feldman, Y.-Y. Pai, M. Chilcote, J. Rabinowitz, R. C. Pooser, A. M. Marino, and B. J. Lawrie, Quantum enhanced probes of magnetic circular dichroism, Adv. Quantum Technol. 8, 2300126 (2025).
  34. X. Guo, C. R. Breum, J. Borregaard, S. Izumi, M. V. Larsen, T. Gehring, M. Christandl, J. S. Neergaard-Nielsen, and U. L. Andersen, Distributed quantum sensing in a continuous-variable entangled network, Nat. Phys. 16, 281 (2020).
  35. M. V. Larsen, X. Guo, C. R. Breum, J. S. Neergaard-Nielsen, and U. L. Andersen, Deterministic generation of a two-dimensional cluster state, Science 366, 369 (2019).
  36. W. Asavanant, Y. Shiozawa, S. Yokoyama, B. Charoensombutamon, H. Emura, R. N. Alexander, S. Takeda, J. Yoshikawa, N. C. Menicucci, H. Yonezawa, and A. Furusawa, Generation of time-domain-multiplexed two-dimensional cluster state, Science 366, 373 (2019).
  37. D. Gottesman, A. Kitaev, and J. Preskill, Encoding a qubit in an oscillator, Phys. Rev. A 64, 012310 (2001).
  38. A. L. Grimsmo, J. Combes, and B. Q. Baragiola, Quantum computing with rotation-symmetric bosonic codes, Phys. Rev. X 10, 011058 (2020).
  39. V. V. Albert, K. Noh, K. Duivenvoorden, D. J. Young, R. T. Brierley, P. Reinhold, C. Vuillot, L. Li, C. Shen, S. M. Girvin, B. M. Terhal, and L. Jiang, Performance and structure of single-mode bosonic codes, Phys. Rev. A 97, 032346 (2018).
  40. T. J. Volkoff, Nonclassical properties and quantum resources of hierarchical photonic superposition states, J. Exp. Theor. Phys. 121, 770 (2015).
  41. H.-K. Lau, R. Pooser, G. Siopsis, and C. Weedbrook, Quantum machine learning over infinite dimensions, Phys. Rev. Lett. 118, 080501 (2017).
  42. J. A. H. Nielsen, M. J. Kicinski, T. N. Arge, K. Vijayadharan, J. Foldager, J. Borregaard, J. J. Meyer, J. S. Neergaard-Nielsen, T. Gehring, and U. L. Andersen, Variational quantum algorithm for enhanced continuous variable optical phase sensing, Npj Quantum Inf. 11, 70 (2025).
  43. Y. Enomoto, K. Anai, K. Udagawa, and S. Takeda, Continuous-variable quantum approximate optimization on a programmable photonic quantum processor, Phys. Rev. Res. 5, 043005 (2023).
  44. C. Oh, S. Chen, Y. Wong, S. Zhou, H. Y. Huang, Jens A. H. Nielsen, Z. H. Liu, J. S. Neergaard-Nielsen, U. L. Andersen, L. Jiang, and J. Preskill, Entanglement-enabled advantage for learning a bosonic random displacement channel, Phys. Rev. Lett. 133, 230604 (2024).
  45. J. M. Arrazola, T. R. Bromley, J. Izaac, C. R. Myers, K. Brádler, and N. Killoran, Machine learning method for state preparation and gate synthesis on photonic quantum computers, Quantum Sci. Technol. 4, 024004 (2019).
  46. H. M. Wiseman, Adaptive phase measurements of optical modes: Going beyond the marginal q distribution, Phys. Rev. Lett. 75, 4587 (1995).
  47. M. A. Rodríguez-García and F. E. Becerra, Adaptive phase estimation with squeezed vacuum approaching the quantum limit, Quantum 8, 1480 (2024).
  48. S. Ataman, Optimal Mach-Zehnder phase sensitivity with Gaussian states, Phys. Rev. A 100, 063821 (2019).
  49. L. Pezzé and A. Smerzi, Mach-Zehnder interferometry at the Heisenberg limit with coherent and squeezed-vacuum light, Phys. Rev. Lett. 100, 073601 (2008).
  50. J. Yu, Y. Qin, J.-L. Qin, Z.-H. Yan, and X.-J. Jia, Quantum phase estimation with a stable squeezed state, Eur. Phys. J. D 74, 76 (2020).
  51. J. Yu, Y. Qin, J. Qin, H. Wang, Z. Yan, X. Jia, and K. Peng, Quantum enhanced optical phase estimation with a squeezed thermal state, Phys. Rev. Appl. 13, 024037 (2020).
  52. A. Serafini, Quantum Continuous Variables: A Primer of Theoretical Methods (CRC Press, Boca Raton, Florida, 2017).
  53. See Supplemental Material at http://link.aps.org/supplemental/10.1103/7l8z-zn2m which includes additional theoretical derivations of the cost function, analysis of the cost landscape under thermal noise and loss, details of the experimental model fitting procedure, numerical/algorithmic details of gradient estimation and optimization, and a Bayesian bootstrap uncertainty analysis.
  54. K. Zhang, S. Liu, Y. Chen, X. Wang, and J. Jing, Optical quantum states based on hot atomic ensembles and their applications, Photonics Insights 1, R06 (2022).
  55. I. Goodfellow, Y. Bengio, and A. Courville, Deep Learning (MIT Press, 2016).
  56. S. Becker, N. Datta, L. Lami, and C. RouzÅLe, Energy-constrained discrimination of unitaries, quantum speed limits, and a Gaussian Solovay-Kitaev theorem, Phys. Rev. Lett. 126, 190504 (2021).
  57. W. H. Press, S. A. Teukolsky, W. T. Vetterling, and B. P. Flannery, Numerical Recipes: The Art of Scientific Computing (Cambridge University Press, Cambridge, 2007), 3rd ed., pp. 807–817.
  58. M. Jasperse, L. D. Turner, and R. E. Scholten, Relative intensity squeezing by four-wave mixing with loss: An analytic model and experimental diagnostic, Opt. Express 19, 3765 (2011).
  59. M. T. Turnbull, P. G. Petrov, C. S. Embrey, A. M. Marino, and V. Boyer, Role of the phase-matching condition in nondegenerate four-wave mixing in hot vapors for the generation of squeezed states of light, Phys. Rev. A 88, 033845 (2013).
  60. P. Gupta, R. W. Speirs, K. M. Jones, and P. D. Lett, Effect of imperfect homodyne visibility on multi-spatial-mode two-mode squeezing measurements, Opt. Express 28, 652 (2020).
  61. K. Usami, Y. Nambu, Y. Tsuda, K. Matsumoto, and K. Nakamura, Accuracy of quantum-state estimation utilizing Akaike’s information criterion, Phys. Rev. A 68, 022314 (2003).
  62. H. Yano and N. Yamamoto, Quantum information criteria for model selection in quantum state estimation, J. Phys. A: Math. Theor. 56, 405301 (2023).
  63. P. Lougovski and S. J. van Enk, Characterizing entanglement sources, Phys. Rev. A 80, 052324 (2009).
  64. J. O. S. Yin and S. J. van Enk, Information criteria for efficient quantum state estimation, Phys. Rev. A 83, 062110 (2011).
  65. A. M. Vadiraj, A. Ask, T. G. McConkey, I. Nsanzineza, C. W. S. Chang, A. F. Kockum, and C. M. Wilson, Engineering the level structure of a giant artificial atom in waveguide quantum electrodynamics, Phys. Rev. A 103, 023710 (2021).
  66. S. J. van Enk and R. Blume-Kohout, When quantum tomography goes wrong: drift of quantum sources and other errors, New J. Phys. 15, 025024 (2013).
  67. Q.-C. Liu, T.-F. Li, X.-Q. Luo, H. Zhao, W. Xiong, Y.-S. Zhang, Z. Chen, J. S. Liu, W. Chen, F. Nori, J. S. Tsai, and J. Q. You, Method for identifying electromagnetically induced transparency in a tunable circuit quantum electrodynamics system, Phys. Rev. A 93, 053838 (2016).
  68. K. P. Burnham and D. R. Anderson, Model Selection and Multimodel Inference: A Practical Information-Theoretic Approach (Springer Science & Business Media, New York, NY, 2002), 2nd ed.
  69. C. M. Caves, Quantum-mechanical noise in an interferometer, Phys. Rev. D 23, 1693 (1981).
  70. A. Arrasmith, Z. Holmes, M. Cerezo, and P. J. Coles, Equivalence of quantum barren plateaus to cost concentration and narrow gorges, Quantum Sci. Technol. 7, 045015 (2022).
  71. T. J. Volkoff, Efficient trainability of linear optical modules in quantum optical neural networks, J. Russ. Laser Res. 42, 250 (2021).
  72. B. Zhang and Q. Zhuang, Energy-dependent barren plateau in bosonic variational quantum circuits, Quantum Sci. Technol. 10, 015009 (2024).
  73. M. Cerezo, M. Larocca, D. García-Martí, N. L. Diaz, P. Braccia, E. Fontana, M. S. Rudolph, P. Bermejo, A. Ijaz, S. Thanasilp, E. R. Anschuetz, and Z. Holmes, Does provable absence of barren plateaus imply classical simulability? or, why we need to rethink variational quantum computing, Nat. Commun. 16, 7907 (2025).
  74. J. R. McClean, S. Boixo, V. N. Smelyanskiy, R. Babbush, and H. Neven, Barren plateaus in quantum neural network training landscapes, Nat. Commun. 9, 4812 (2018).
  75. Z. Holmes, K. Sharma, M. Cerezo, and P. J. Coles, Connecting ansatz expressibility to gradient magnitudes and barren plateaus, PRX Quantum 3, 010313 (2022).
  76. M. Cerezo, A. Sone, T. Volkoff, L. Cincio, and P. J. Coles, Cost function dependent barren plateaus in shallow parametrized quantum circuits, Nat. Commun. 12, 1 (2021).
  77. C. Ortiz Marrero, M. Kieferová, and N. Wiebe, Entanglement-induced barren plateaus, PRX Quantum 2, 040316 (2021).
  78. Z. Holmes, A. Arrasmith, B. Yan, P. J. Coles, A. Albrecht, and A. T. Sornborger, Barren plateaus preclude learning scramblers, Phys. Rev. Lett. 126, 190501 (2021).
  79. E. Fontana, D. Herman, S. Chakrabarti, N. Kumar, R. Yalovetzky, J. Heredge, S. H. Sureshbabu, and M. Pistoia, Characterizing barren plateaus in quantum ansätze with the adjoint representation, Nat. Commun. 15, 7171 (2024).
  80. M. Ragone, B. N. Bakalov, F. Sauvage, A. F. Kemper, C. Ortiz Marrero, M. Larocca, and M. Cerezo, A Lie algebraic theory of barren plateaus for deep parameterized quantum circuits, Nat. Commun. 15, 7172 (2024).
  81. C. F. McCormick, V. Boyer, E. Arimondo, and P. D. Lett, Strong relative intensity squeezing by four-wave mixing in rubidium vapor, Opt. Lett. 32, 178 (2007).
  82. C. F. McCormick, A. M. Marino, V. Boyer, and P. D. Lett, Strong low-frequency quantum correlations from a four-wave-mixing amplifier, Phys. Rev. A 78, 043816 (2008).
  83. B. E. Anderson, P. Gupta, B. L. Schmittberger, T. Horrom, C. Hermann-Avigliano, K. M. Jones, and P. D. Lett, Phase sensing beyond the standard quantum limit with a variation on the SU(1,1) interferometer, Optica 4, 752 (2017).
  84. V. Boyer, A. M. Marino, R. C. Pooser, and P. D. Lett, Entangled images from four-wave mixing, Science 321, 544 (2008).
  85. P. Hariharan and M. Roy, A geometric-phase interferometer, J. Mod. Opt. 39, 1811 (1992).
  86. J. Brendel, W. Dultz, and W. Martienssen, Geometric phases in two-photon interference experiments, Phys. Rev. A 52, 2551 (1995).
  87. J. Nocedal and S. Wright, Numerical Optimization (Springer, New York, New York, 2006).
  88. L. Armijo, Minimization of functions having Lipschitz continuous first partial derivatives, Pacific J. Math. 16, 1 (1966).
  89. J. Duchi, E. Hazan, and Y. Singer, Adaptive subgradient methods for online learning and stochastic optimization, J. Mach. Learn. Res. 12, 2121 (2011).
  90. S. Machnes, U. Sander, S. J. Glaser, P. de Fouquières, A. Gruslys, S. Schirmer, and T. Schulte-Herbrüggen, Comparing, optimizing, and benchmarking quantum-control algorithms in a unifying programming framework, Phys. Rev. A 84, 022305 (2011).
  91. S. L. Braunstein and H. J. Kimble, Teleportation of continuous quantum variables, Phys. Rev. Lett. 80, 869 (1998).
