Gate Reflectometry in a Minimal Kitaev Chain Device

Yining Zhang, Ivan Kulesh, Sebastiaan L.D. ten Haaf, Nick van Loo, Francesco Zatelli, Tijl Degroote, Christian G. Prosko, and Srijit Goswami*

  • *Contact author: s.goswami@tudelft.nl
PDF

PRX Quantum 7, 020317 – Published 28 April, 2026

DOI: https://doi.org/10.1103/7367-wbp9

Abstract

Hybrid quantum dot (QD)-superconductor system can be used to realize Majorana zero modes in artificial Kitaev chains. These chains provide a promising platform for the realization of Majorana qubits. Radio-frequency gate reflectometry is a fast, noninvasive, and sensitive technique that can be used to read out such qubits. In this work, we use gate reflectometry to probe two QDs coupled via a semiconductor-superconductor hybrid segment. We demonstrate that gate sensing can resolve charge stability diagrams and clearly distinguish between elastic cotunneling and crossed-Andreev reflection, the two key processes that allow one to form a Kitaev chain. Furthermore, we show that this information is accessible, even when the system is completely decoupled from the normal leads. In this closed regime, we show that the observed quantum-capacitance signal is indicative of parity switching between the even and odd ground states. Our measurements in both open and closed regimes confirm that gate reflectometry captures the essential features of interdot coupling and parity dynamics.

View figure in article

Physics Subject Headings (PhySH)

Popular Summary

Artificial Kitaev chains could be used to create Majorana-based qubits; however, it is important to develop tools to read out such qubits. Here, we show that a fast and noninvasive technique called gate reflectometry can probe a pair of quantum dots coupled through a superconductor. This approach can distinguish how the two quantum dots coupled to each other, which is crucial information to engineer the system to the Majorana sweet spot. It also works when the device is fully isolated from external leads, revealing changes in the system’s parity through its capacitive response. Together, these results demonstrate that gate reflectometry can capture both coupling and parity dynamics in quantum dot-superconductor hybrid devices. This technique could become an important tool for building and operating future Majorana-based qubits.

Article Text

Supplemental Material

References (43)

  1. J. D. Sau and S. D. Sarma, Realizing a robust practical Majorana chain in a quantum-dot-superconductor linear array, Nat. Commun. 3, 964 (2012).
  2. M. Leijnse and K. Flensberg, Parity qubits and poor man’s Majorana bound states in double quantum dots, Phys. Rev. B: Condens. Matter Mater. Phys. 86, 134528 (2012).
  3. A. Tsintzis, R. S. Souto, and M. Leijnse, Creating and detecting poor man’s Majorana bound states in interacting quantum dots, Phys. Rev. B 106, L201404 (2022).
  4. A. Y. Kitaev, Unpaired Majorana fermions in quantum wires, Phys.-Usp. 44, 131 (2001).
  5. T. Dvir, G. Wang, N. van Loo, C.-X. Liu, G. P. Mazur, A. Bordin, S. L. D. ten Haaf, J.-Y. Wang, D. van Driel, F. Zatelli et al., Realization of a minimal Kitaev chain in coupled quantum dots, Nature 614, 445 (2023).
  6. S. L. D. ten Haaf, Q. Wang, A. M. Bozkurt, C.-X. Liu, I. Kulesh, P. Kim, D. Xiao, C. Thomas, M. J. Manfra, T. Dvir et al., A two-site Kitaev chain in a two-dimensional electron gas, Nature 630, 329 (2024).
  7. G. Széchenyi and A. Pályi, Parity-to-charge conversion for readout of topological Majorana qubits, Phys. Rev. B 101, 235441 (2020).
  8. A. Tsintzis, R. S. Souto, K. Flensberg, J. Danon, and M. Leijnse, Majorana qubits and non-Abelian physics in quantum dot–based minimal Kitaev chains, PRX Quantum 5, 010323 (2024).
  9. C.-X. Liu, H. Pan, F. Setiawan, M. Wimmer, and J. D. Sau, Fusion protocol for Majorana modes in coupled quantum dots, Phys. Rev. B 108, 085437 (2023).
  10. P. Boross and A. Pályi, Braiding-based quantum control of a Majorana qubit built from quantum dots, Phys. Rev. B 109, 125410 (2024).
  11. M. Esterli, R. Otxoa, and M. Gonzalez-Zalba, Small-signal equivalent circuit for double quantum dots at low-frequencies, Appl. Phys. Lett. 114, 253505 (2019).
  12. F. Vigneau, F. Fedele, A. Chatterjee, D. Reilly, F. Kuemmeth, M. F. Gonzalez-Zalba, E. Laird, and N. Ares, Probing quantum devices with radio-frequency reflectometry, Appl. Phys. Rev. 10, 021305 (2023).
  13. M. Urdampilleta, A. Chatterjee, C. C. Lo, T. Kobayashi, J. Mansir, S. Barraud, A. C. Betz, S. Rogge, M. F. Gonzalez-Zalba, and J. J. Morton, Charge dynamics and spin blockade in a hybrid double quantum dot in silicon, Phys. Rev. X 5, 031024 (2015).
  14. D. De Jong, J. Van Veen, L. Binci, A. Singh, P. Krogstrup, L. P. Kouwenhoven, W. Pfaff, and J. D. Watson, Rapid detection of coherent tunneling in an in as nanowire quantum dot through dispersive gate sensing, Phys. Rev. Appl. 11, 044061 (2019).
  15. D. Reilly, C. Marcus, M. Hanson, and A. Gossard, Fast single-charge sensing with a RF quantum point contact, Appl. Phys. Lett. 91, 162101 (2007).
  16. C. Barthel, M. Kjærgaard, J. Medford, M. Stopa, C. M. Marcus, M. Hanson, and A. C. Gossard, Fast sensing of double-dot charge arrangement and spin state with a radio-frequency sensor quantum dot, Phys. Rev. B: Condens. Matter Mater. Phys. 81, 161308 (2010).
  17. C. Prosko, I. Kulesh, M. Chan, L. Han, D. Xiao, C. Thomas, M. Manfra, S. Goswami, and F. K. Malinowski, Flux-tunable hybridization in a double quantum dot interferometer, SciPost Phys. 17, 074 (2024).
  18. F. Fedele, A. Chatterjee, S. Fallahi, G. C. Gardner, M. J. Manfra, and F. Kuemmeth, Simultaneous operations in a two-dimensional array of singlet-triplet qubits, PRX Quantum 2, 040306 (2021).
  19. A. West, B. Hensen, A. Jouan, T. Tanttu, C.-H. Yang, A. Rossi, M. F. Gonzalez-Zalba, F. Hudson, A. Morello, D. J. Reilly et al., Gate-based single-shot readout of spins in silicon, Nat. Nanotechnol. 14, 437 (2019).
  20. A. Betz, R. Wacquez, M. Vinet, X. Jehl, A. Saraiva, M. Sanquer, A. Ferguson, and M. Gonzalez-Zalba, Dispersively detected Pauli spin-blockade in a silicon nanowire field-effect transistor, Nano Lett. 15, 4622 (2015).
  21. D. de Jong, C. G. Prosko, L. Han, F. K. Malinowski, Y. Liu, L. P. Kouwenhoven, and W. Pfaff, Controllable single cooper pair splitting in hybrid quantum dot systems, Phys. Rev. Lett. 131, 157001 (2023).
  22. J. Van Veen, D. De Jong, L. Han, C. Prosko, P. Krogstrup, J. D. Watson, L. P. Kouwenhoven, and W. Pfaff, Revealing charge-tunneling processes between a quantum dot and a superconducting island through gate sensing, Phys. Rev. B 100, 174508 (2019).
  23. G. C. Ménard, F. K. Malinowski, D. Puglia, D. I. Pikulin, T. Karzig, B. Bauer, P. Krogstrup, and C. M. Marcus, Suppressing quasiparticle poisoning with a voltage-controlled filter, Phys. Rev. B 100, 165307 (2019).
  24. H. Nguyen, D. Sabonis, D. Razmadze, E. Mannila, V. Maisi, D. van Zanten, E. O’Farrell, P. Krogstrup, F. Kuemmeth, J. Pekola et al., Electrostatic control of quasiparticle poisoning in a hybrid semiconductor-superconductor island, Phys. Rev. B 108, L041302 (2023).
  25. M. A. Quantum, M. Aghaee, A. A. Ramirez, Z. Alam, R. Ali, M. Andrzejczuk, A. Antipov, M. Astafev, A. Barzegar, B. Bauer et al., Interferometric single-shot parity measurement in InAs–Al hybrid devices, Nature 638, 651 (2025).
  26. N. van Loo, F. Zatelli, G. O. Steffensen, B. Roovers, G. Wang, T. Van Caekenberghe, A. Bordin, D. van Driel, Y. Zhang, W. D. Huisman et al., Single-shot parity readout of a minimal Kitaev chain, Nature 650, 334 (2026).
  27. C. M. Moehle, C. T. Ke, Q. Wang, C. Thomas, D. Xiao, S. Karwal, M. Lodari, V. van de Kerkhof, R. Termaat, G. C. Gardner et al., InSbAs two-dimensional electron gases as a platform for topological superconductivity, Nano Lett. 21, 9990 (2021).
  28. See Supplemental Material at http://link.aps.org/supplemental/10.1103/7367-wbp9, which includes Refs. [17, 35, 40, 41, 42, 43].
  29. J. Hornibrook, J. Colless, A. Mahoney, X. Croot, S. Blanvillain, H. Lu, A. Gossard, and D. Reilly, Frequency multiplexing for readout of spin qubits, Appl. Phys. Lett. 104, 103108 (2014).
  30. R. Ashoori, H. Stormer, J. Weiner, L. Pfeiffer, S. Pearton, K. Baldwin, and K. West, Single-electron capacitance spectroscopy of discrete quantum levels, Phys. Rev. Lett. 68, 3088 (1992).
  31. K. Petersson, C. Smith, D. Anderson, P. Atkinson, G. Jones, and D. Ritchie, Charge and spin state readout of a double quantum dot coupled to a resonator, Nano Lett. 10, 2789 (2010).
  32. R. Mizuta, R. Otxoa, A. Betz, and M. F. Gonzalez-Zalba, Quantum and tunneling capacitance in charge and spin qubits, Phys. Rev. B 95, 045414 (2017).
  33. G. Wang, T. Dvir, G. P. Mazur, C.-X. Liu, N. van Loo, S. L. D. ten Haaf, A. Bordin, S. Gazibegovic, G. Badawy, E. P. Bakkers et al., Singlet and triplet cooper pair splitting in hybrid superconducting nanowires, Nature 612, 448 (2022).
  34. Q. Wang, S. L. D. ten Haaf, I. Kulesh, D. Xiao, C. Thomas, M. J. Manfra, and S. Goswami, Triplet correlations in Cooper pair splitters realized in a two-dimensional electron gas, Nat. Commun. 14, 4876 (2023).
  35. F. Zatelli, D. van Driel, D. Xu, G. Wang, C.-X. Liu, A. Bordin, B. Roovers, G. P. Mazur, N. van Loo, J. C. Wolff et al., Robust poor man’s Majorana zero modes using Yu-Shiba-Rusinov states, Nat. Commun. 15, 7933 (2024).
  36. C.-X. Liu, G. Wang, T. Dvir, and M. Wimmer, Tunable superconducting coupling of quantum dots via Andreev bound states in semiconductor-superconductor nanowires, Phys. Rev. Lett. 129, 267701 (2022).
  37. G. Goldstein and C. Chamon, Decay rates for topological memories encoded with Majorana fermions, Phys. Rev. B: Condens. Matter Mater. Phys. 84, 205109 (2011).
  38. J. C. Budich, S. Walter, and B. Trauzettel, Failure of protection of Majorana based qubits against decoherence, Phys. Rev. B 85, 121405 (2012).
  39. Y. Zhang, Data and code for “probing a minimal Kitaev chain with gate reflectometry” (2025), https://zenodo.org/records/15848623.
  40. I. Kulesh, S. L. D. ten Haaf, Q. Wang, V. P. M. Sietses, Y. Zhang, S. R. Roelofs, C. G. Prosko, D. Xiao, C. Thomas, M. J. Manfra, and S. Goswami, Flux-controlled two-site Kitaev chain, Phys. Rev. Lett. 135, 056301 (2025).
  41. S. Probst, F. Song, P. A. Bushev, A. V. Ustinov, and M. Weides, Efficient and robust analysis of complex scattering data under noise in microwave resonators, Rev. Sci. Instrum. 86, 024706 (2015).
  42. M. S. Khalil, M. Stoutimore, F. Wellstood, and K. Osborn, An analysis method for asymmetric resonator transmission applied to superconducting devices, J. Appl. Phys. 111, 054510 (2012).
  43. F. K. Malinowski, L. Han, D. De Jong, J.-Y. Wang, C. G. Prosko, G. Badawy, S. Gazibegovic, Y. Liu, P. Krogstrup, E. P. Bakkers et al., Radio-frequency C-V measurements with subattofarad sensitivity, Phys. Rev. Appl. 18, 024032 (2022).
