Spectral and temporal properties of type-II parametric down-conversion: The impact of losses during state generation

Denis A. Kopylov1,2,*, Michael Stefszky2,3, Torsten Meier1,2, Christine Silberhorn2,3, and Polina R. Sharapova1

  • 1Department of Physics, Paderborn University, Warburger Str. 100, D-33098 Paderborn, Germany
  • 2Institute for Photonic Quantum Systems (PhoQS), Paderborn University, Warburger Str. 100, D-33098 Paderborn, Germany
  • 3Integrated Quantum Optics, Paderborn University, Warburger Str. 100, D-33098 Paderborn, Germany

  • *Contact author: denis.kopylov@uni-paderborn.de
PDF

Phys. Rev. Research 7, 033122 – Published 5 August, 2025

DOI: https://doi.org/10.1103/zp72-7qwl

Abstract

In this paper, we theoretically study the spectral and temporal properties of pulsed spontaneous parametric down-conversion (SPDC) generated in lossy waveguides. Our theoretical approach is based on the formalism of Gaussian states and the Langevin equation, which is elaborated for weak parametric down-conversion and photon-number-unresolved click detection. Using the example of frequency-degenerate type-II SPDC generated under the pump-idler group-velocity-matching condition, we show how the joint-spectral intensity, mode structure, normalized second-order correlation function, and Hong-Ou-Mandel interference pattern depend on internal losses of the SPDC process. We found that the joint-spectral intensity is almost insensitive to internal losses, while the second-order correlation function shows a strong dependence on them, being different for the signal and idler beams in the presence of internal losses. Based on the sensitivity of the normalized second-order correlation function, we show how its measurement can be used to experimentally determine internal losses.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (51)

  1. E. Pelucchi, G. Fagas, I. Aharonovich, D. Englund, E. Figueroa, Q. Gong, H. Hannes, J. Liu, C.-Y. Lu, N. Matsuda, J.-W. Pan, F. Schreck, F. Sciarrino, C. Silberhorn, J. Wang, and K. D. Jöns, The potential and global outlook of integrated photonics for quantum technologies, Nat. Rev. Phys. 4, 194 (2022).
  2. M. N. Satyanarayan, A. Deepthy, and H. L. Bhat, Potassium titanyl phosphate and its isomorphs: Growth, properties, and applications, Crit. Rev. Solid State Mater. Sci. 24, 103 (1999).
  3. G. Poberaj, H. Hu, W. Sohler, and P. Günter, Lithium niobate on insulator (LNOI) for micro-photonic devices, Laser Photon. Rev. 6, 488 (2012).
  4. E. J. Stanton, J. Chiles, N. Nader, G. Moody, N. Volet, L. Chang, J. E. Bowers, S. Woo Nam, and R. P. Mirin, Efficient second harmonic generation in nanophotonic GaAs-on-insulator waveguides, Opt. Express 28, 9521 (2020).
  5. G. P. Agrawal, Nonlinear Fiber Optics, 5th ed. (Elsevier, Academic Press, Oxford, UK, 2013).
  6. J. Mishra, M. Jankowski, A. Y. Hwang, H. S. Stokowski, T. P. McKenna, C. Langrock, E. Ng, D. Heydari, H. Mabuchi, A. H. Safavi-Naeini, and M. M. Fejer, Ultra-broadband mid-infrared generation in dispersion-engineered thin-film lithium niobate, Opt. Express 30, 32752 (2022).
  7. D. Melati, A. Melloni, and F. Morichetti, Real photonic waveguides: Guiding light through imperfections, Adv. Opt. Photon. 6, 156 (2014).
  8. M. Hammer, S. Babel, H. Farheen, L. Padberg, J. C. Scheytt, C. Silberhorn, and J. Förstner, Estimation of losses caused by sidewall roughness in thin-film lithium niobate rib and strip waveguides, Opt. Express 32, 22878 (2024).
  9. M. Placke, J. Schlegel, F. Mann, P. Della Casa, A. Thies, M. Weyers, G. Tränkle, and S. Ramelow, Telecom-band spontaneous parametric down-conversion in AlGaAs-on-insulator waveguides, Laser Photon. Rev. 18, 2301293 (2024).
  10. J. Schuhmann, L. Lazzari, M. Morassi, A. Lemaître, I. Sagnes, G. Beaudoin, M. Amanti, F. Boeuf, F. Raineri, F. Baboux, and S. Ducci, Hybrid III-V/silicon quantum photonic device generating broadband entangled photon pairs, PRX Quantum 5, 040321 (2024).
  11. C. K. Hong, Z. Y. Ou, and L. Mandel, Measurement of subpicosecond time intervals between two photons by interference, Phys. Rev. Lett. 59, 2044 (1987).
  12. M. Avenhaus, A. Eckstein, P. J. Mosley, and C. Silberhorn, Fiber-assisted single-photon spectrograph, Opt. Lett. 34, 2873 (2009).
  13. A. Christ, K. Laiho, A. Eckstein, K. N. Cassemiro, and C. Silberhorn, Probing multimode squeezing with correlation functions, New J. Phys. 13, 033027 (2011).
  14. K. Zielnicki, K. Garay-Palmett, D. Cruz-Delgado, H. Cruz-Ramirez, M. F. O'Boyle, B. Fang, V. O. Lorenz, A. B. U'Ren, and P. G. Kwiat, Joint spectral characterization of photon-pair sources, J. Mod. Opt. 65, 1141 (2018).
  15. F. Graffitti, J. Kelly-Massicotte, A. Fedrizzi, and A. M. Brańczyk, Design considerations for high-purity heralded single-photon sources, Phys. Rev. A 98, 053811 (2018).
  16. C. J. Xin, J. Mishra, C. Chen, D. Zhu, A. Shams-Ansari, C. Langrock, N. Sinclair, F. N. C. Wong, M. M. Fejer, and M. Lončar, Spectrally separable photon-pair generation in dispersion engineered thin-film lithium niobate, Opt. Lett. 47, 2830 (2022).
  17. N. A. Lange, T. Schapeler, J. P. Höpker, M. Protte, and T. J. Bartley, Degenerate photons from a cryogenic spontaneous parametric down-conversion source, Phys. Rev. A 108, 023701 (2023).
  18. D. A. Kopylov, T. Meier, and P. R. Sharapova, Theory of multimode squeezed light generation in lossy media, Quantum 9, 1621 (2025).
  19. C. Weedbrook, S. Pirandola, R. García-Patrón, N. J. Cerf, T. C. Ralph, J. H. Shapiro, and S. Lloyd, Gaussian quantum information, Rev. Mod. Phys. 84, 621 (2012).
  20. B. Huttner, S. Serulnik, and Y. Ben-Aryeh, Quantum analysis of light propagation in a parametric amplifier, Phys. Rev. A 42, 5594 (1990).
  21. D. B. Horoshko, Generator of spatial evolution of the electromagnetic field, Phys. Rev. A 105, 013708 (2022).
  22. W. Vogel and D.-G. Welsch, Quantum Optics (Wiley-VCH, Berlin, 2006).
  23. A. Christ, B. Brecht, W. Mauerer, and C. Silberhorn, Theory of quantum frequency conversion and type-II parametric down-conversion in the high-gain regime, New J. Phys. 15, 053038 (2013).
  24. P. R. Sharapova, G. Frascella, M. Riabinin, A. M. Pérez, O. V. Tikhonova, S. Lemieux, R. W. Boyd, G. Leuchs, and M. V. Chekhova, Properties of bright squeezed vacuum at increasing brightness, Phys. Rev. Res. 2, 013371 (2020).
  25. D. S. Phillips, M. Walschaers, J. J. Renema, I. A. Walmsley, N. Treps, and J. Sperling, Benchmarking of Gaussian boson sampling using two-point correlators, Phys. Rev. A 99, 023836 (2019).
  26. E. Wolf, New theory of partial coherence in the space–frequency domain. Part I: Spectra and cross spectra of steady-state sources, J. Opt. Soc. Am. 72, 343 (1982).
  27. L. Mandel and E. Wolf, Optical Coherence and Quantum Optics (Cambridge University Press, Cambridge, UK, 1995).
  28. C. Fabre and N. Treps, Modes and states in quantum optics, Rev. Mod. Phys. 92, 035005 (2020).
  29. A. Eckstein, A. Christ, P. J. Mosley, and C. Silberhorn, Highly efficient single-pass source of pulsed single-mode twin beams of light, Phys. Rev. Lett. 106, 013603 (2011).
  30. I. V. Dyakonov, P. R. Sharapova, T. S. Iskhakov, and G. Leuchs, Direct Schmidt number measurement of high-gain parametric down conversion, Laser Phys. Lett. 12, 065202 (2015).
  31. W. P. Grice and I. A. Walmsley, Spectral information and distinguishability in type-II down-conversion with a broadband pump, Phys. Rev. A 56, 1627 (1997).
  32. C. Drago and A. M. Braczyk, Hong–Ou–Mandel interference: A spectral–temporal analysis, Canadian J. Phys. 102, 411 (2024).
  33. D. A. Antonosyan, A. S. Solntsev, and A. A. Sukhorukov, Effect of loss on photon-pair generation in nonlinear waveguide arrays, Phys. Rev. A 90, 043845 (2014).
  34. D. N. Vavulin and A. A. Sukhorukov, Effect of loss on single photon parametric amplification, Opt. Commun. 390, 117 (2017).
  35. M. Gräfe, D. A. Antonosyan, A. S. Solntsev, A. A. Sukhorukov, and A. Szameit, Optical emulation of photon-pair generation in nonlinear lossy waveguides, Europhys. Lett. 118, 54001 (2017).
  36. L. G. Helt, M. J. Steel, and J. E. Sipe, Spontaneous parametric downconversion in waveguides: What's loss got to do with it? New J. Phys. 17, 013055 (2015).
  37. A. N. Poddubny, I. V. Iorsh, and A. A. Sukhorukov, Generation of photon-plasmon quantum states in nonlinear hyperbolic metamaterials, Phys. Rev. Lett. 117, 123901 (2016).
  38. M. Banic, L. Zatti, M. Liscidini, and J. E. Sipe, Two strategies for modeling nonlinear optics in lossy integrated photonic structures, Phys. Rev. A 106, 043707 (2022).
  39. S. Babel, L. Bollmers, M. Massaro, K. H. Luo, M. Stefszky, F. Pegoraro, P. Held, H. Herrmann, C. Eigner, B. Brecht, L. Padberg, and C. Silberhorn, Demonstration of Hong-Ou-Mandel interference in an LNOI directional coupler, Opt. Express 31, 23140 (2023).
  40. G. Spedalieri, C. Weedbrook, and S. Pirandola, A limit formula for the quantum fidelity, J. Phys. A: Math. Theor. 46, 025304 (2013).
  41. L. Banchi, S. L. Braunstein, and S. Pirandola, Quantum fidelity for arbitrary Gaussian states, Phys. Rev. Lett. 115, 260501 (2015).
  42. N. Quesada, J. M. Arrazola, and N. Killoran, Gaussian boson sampling using threshold detectors, Phys. Rev. A 98, 062322 (2018).
  43. R. J. Glauber, The quantum theory of optical coherence, Phys. Rev. 130, 2529 (1963).
  44. F. Boitier, A. Godard, N. Dubreuil, P. Delaye, C. Fabre, and E. Rosencher, Two-photon-counting interferometry, Phys. Rev. A 87, 013844 (2013).
  45. D. A. Kopylov, A. V. Rasputnyi, T. V. Murzina, and M. V. Chekhova, Spectral properties of second, third and fourth harmonics generation from broadband multimode bright squeezed vacuum, Laser Phys. Lett. 17, 075401 (2020).
  46. T. S. Iskhakov, A. M. Pérez, K. Y. Spasibko, M. V. Chekhova, and G. Leuchs, Superbunched bright squeezed vacuum state, Opt. Lett. 37, 1919 (2012).
  47. A. V. Rasputnyi and D. A. Kopylov, Quantum spatial dynamics of high-gain parametric down-conversion accompanied by cascaded up-conversion, Phys. Rev. A 104, 013702 (2021).
  48. J. Flórez, J. S. Lundeen, and M. V. Chekhova, Pump depletion in parametric down-conversion with low pump energies, Opt. Lett. 45, 4264 (2020).
  49. K. Chinni and N. Quesada, Beyond the parametric approximation: Pump depletion, entanglement, and squeezing in macro- scopic down-conversion, Phys. Rev. A 110, 013712 (2024).
  50. N. Quesada, L. G. Helt, M. Menotti, M. Liscidini, and J. E. Sipe, Beyond photon pairs—nonlinear quantum photonics in the high-gain regime: A tutorial, Adv. Opt. Photon. 14, 291 (2022).
  51. D. Kopylov, M. Stefszky, T. Meier, C. Silberhorn, and P. Sharapova, Spectral and temporal properties of type-II parametric down-conversion: The impact of losses during state generation [Data set], Zenodo (2025), DOI: 10.5281/zenodo.14802394.
