Waveform control of terahertz light via electron beam longitudinal phase-space manipulation

Yifan Liang1, Xiaofan Wang1,*, Tong Li2, Jitao Sun1, Zhuoyuan Liu2, Jiayue Yang3, Yong Yu1, Qili Tian2, Zhigang He3 et al.

Hongfei Wang1, Li Zeng1, Hao Sun1, Qinghao Zhu1, Xuan Liu1, Guorong Wu3,†, Weiqing Zhang3,‡, Xueming Yang3, Chuanxiang Tang2, and Lixin Yan2,§

  • *Contact author: wangxf@mail.iasf.ac.cn
  • †Contact author: wugr@dicp.ac.cn
  • ‡Contact author: weiqingzhang@dicp.ac.cn
  • §Contact author: yanlx@mail.tsinghua.edu.cn
PDF

Phys. Rev. Research 8, 023113 – Published 4 May, 2026

DOI: https://doi.org/10.1103/xw7z-5c2d

Abstract

Synthesizing intense terahertz (THz) waveforms with user-defined electric field profiles represents a pivotal challenge for controlling matter at ultrafast timescales. While relativistic electron beams can serve as a versatile source of coherent radiation, conventional schemes lack the ability to deterministically sculpt the temporal structure of the emitted light. Here, we experimentally demonstrate a paradigm for generating tailored THz waveforms by manipulating the longitudinal phase space of the electron beam. By controlling the nonlinear longitudinal correlation of an energy-chirped electron beam, we generate a microbunch train with a chirped density modulation. When coupled to a tapered undulator, this structured beam produces coherent radiation, whose spectral-temporal properties are tunable via adjustment of the undulator taper. Autocorrelation measurements confirm the emission of chirped pulses spanning 8–13 THz, with spectral characteristics that align with simulations of the beam structure. Our approach, establishing a direct link between beam dynamics and light-field synthesis, opens a pathway toward customizable high-field waveforms for advanced coherent control experiments.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (42)

  1. S. Baierl, M. Hohenleutner, T. Kampfrath, A. K. Zvezdin, A. V. Kimel, R. Huber, and R. V. Mikhaylovskiy, Nonlinear spin control by terahertz-driven anisotropy fields, Nat. Photon. 10, 715 (2016).
  2. T. L. Cocker, D. Peller, P. Yu, J. Repp, and R. Huber, Tracking the ultrafast motion of a single molecule by femtosecond orbital imaging, Nature (London) 539, 263 (2016).
  3. V. Jelic, K. Iwaszczuk, P. H. Nguyen, C. Rathje, G. J. Hornig, H. M. Sharum, J. R. Hoffman, M. R. Freeman, and F. A. Hegmann, Ultrafast terahertz control of extreme tunnel currents through single atoms on a silicon surface, Nat. Phys. 13, 591 (2017).
  4. S. Schlauderer, C. Lange, S. Baierl, T. Ebnet, C. P. Schmid, D. C. Valovcin, A. K. Zvezdin, A. V. Kimel, R. V. Mikhaylovskiy, and R. Huber, Temporal and spectral fingerprints of ultrafast all-coherent spin switching, Nature (London) 569, 383 (2019).
  5. L. Luo, X. Yang, X. Liu, Z. Liu, C. Vaswani, D. Cheng, M. Mootz, X. Zhao, Y. Yao, C. Z. Wang, K. M. Ho, I. E. Perakis, M. Dobrowolska, J. K. Furdyna, and J. Wang, Ultrafast manipulation of topologically enhanced surface transport driven by mid-infrared and terahertz pulses in Bi2Se3, Nat. Commun. 10, 607 (2019).
  6. E. A. Mashkovich, K. A. Grishunin, R. M. Dubrovin, A. K. Zvezdin, R. V. Pisarev, and A. V. Kimel, Terahertz light–driven coupling of antiferromagnetic spins to lattice, Science 374, 1608 (2021).
  7. M. Basini, M. Pancaldi, B. Wehinger, M. Udina, V. Unikandanunni, T. Tadano, M. C. Hoffmann, A. V. Balatsky, and S. Bonetti, Terahertz electric-field-driven dynamical multiferroicity in SrTiO3, Nature (London) 628, 534 (2024).
  8. Z. Zhang, F. Y. Gao, Y.-C. Chien, Z.-J. Liu, J. B. Curtis, E. R. Sung, X. Ma, W. Ren, S. Cao, P. Narang, A. von Hoegen, E. Baldini, and K. A. Nelson, Terahertz-field-driven magnon upconversion in an antiferromagnet, Nat. Phys. 20, 788 (2024).
  9. J. A. Fülöp, S. Tzortzakis, and T. Kampfrath, Laser-driven strong-field terahertz sources, Adv. Opt. Mater. 8, 1900681 (2020).
  10. X. Wu, D. Kong, S. Hao, Y. Zeng, X. Yu, B. Zhang, M. Dai, S. Liu, J. Wang, Z. Ren, et al., Generation of 13.9-mJ terahertz radiation from lithium niobate materials, Adv. Mater. 35, 2208947 (2023).
  11. X. Zhu, D. R. Bacon, J. Madéo, and K. M. Dani, High field single- to few-cycle THz generation with lithium niobate, Photonics 8, 183 (2021).
  12. L.-H. Yu, M. Babzien, I. Ben-Zvi, L. F. DiMauro, A. Doyuran, W. Graves, E. Johnson, S. Krinsky, R. Malone, I. Pogorelsky, et al., High-gain harmonic-generation free-electron laser, Science 289, 932 (2000).
  13. S. E. Korbly, A. S. Kesar, J. R. Sirigiri, and R. J. Temkin, Observation of frequency-locked coherent terahertz Smith-Purcell radiation, Phys. Rev. Lett. 94, 054803 (2005).
  14. E. Hemsing, M. Dunning, B. Garcia, C. Hast, T. Raubenheimer, G. Stupakov, and D. Xiang, Echo-enabled harmonics up to the 75th order from precisely tailored electron beams, Nat. Photon. 10, 512 (2016).
  15. Y. Ding, K. L. F. Bane, W. Colocho, F.-J. Decker, P. Emma, J. Frisch, M. W. Guetg, Z. Huang, R. Iverson, J. Krzywinski, H. Loos, A. Lutman, T. J. Maxwell, H.-D. Nuhn, D. Ratner, J. Turner, J. Welch, and F. Zhou, Beam shaping to improve the free-electron laser performance at the Linac Coherent Light Source, Phys. Rev. Accel. Beams 19, 100703 (2016).
  16. S. Huang, Y. Ding, Y. Feng, E. Hemsing, Z. Huang, J. Krzywinski, A. A. Lutman, A. Marinelli, T. J. Maxwell, and D. Zhu, Generating single-spike hard x-ray pulses with nonlinear bunch compression in free-electron lasers, Phys. Rev. Lett. 119, 154801 (2017).
  17. C. Feng and H. Deng, Review of fully coherent free-electron lasers, Nucl. Sci. Tech. 29, 160 (2018).
  18. P. Franz, S. Li, T. Driver, R. R. Robles, D. Cesar, E. Isele, Z. Guo, J. Wang, J. P. Duris, K. Larsen, et al., Terawatt-scale attosecond X-ray pulses from a cascaded superradiant free-electron laser, Nat. Photon. 18, 698 (2024).
  19. J. Yan, W. Qin, Y. Chen, W. Decking, P. Dijkstal, M. Guetg, I. Inoue, N. Kujala, S. Liu, T. Long, N. Mirian, and G. Geloni, Terawatt-attosecond hard x-ray free-electron laser at high repetition rate, Nat. Photon. 18, 1293 (2024).
  20. C. Emma, N. Majernik, K. K. Swanson, R. Ariniello, S. Gessner, R. Hessami, M. J. Hogan, A. Knetsch, K. A. Larsen, A. Marinelli, B. O’Shea, S. Perez, I. Rajkovic, R. Robles, D. Storey, and G. Yocky, Experimental generation of extreme electron beams for advanced accelerator applications, Phys. Rev. Lett. 134, 085001 (2025).
  21. P. Muggli, V. Yakimenko, M. Babzien, E. Kallos, and K. P. Kusche, Generation of trains of electron microbunches with adjustable subpicosecond spacing, Phys. Rev. Lett. 101, 054801 (2008).
  22. S. Bielawski, C. Evain, T. Hara, M. Hosaka, M. Katoh, S. Kimura, A. Mochihashi, M. Shimada, C. Szwaj, T. Takahashi, and Y. Takashima, Tunable narrowband terahertz emission from mastered laser–electron beam interaction, Nat. Phys. 4, 390 (2008).
  23. Y.-E. Sun, P. Piot, A. Johnson, A. H. Lumpkin, T. J. Maxwell, J. Ruan, and R. Thurman-Keup, Tunable subpicosecond electron-bunch-train generation using a transverse-to-longitudinal phase-space exchange technique, Phys. Rev. Lett. 105, 234801 (2010).
  24. Y. Shen, X. Yang, G. L. Carr, Y. Hidaka, J. B. Murphy, and X. Wang, Tunable few-cycle and multicycle coherent terahertz radiation from relativistic electrons, Phys. Rev. Lett. 107, 204801 (2011).
  25. P. Musumeci, R. K. Li, and A. Marinelli, Nonlinear longitudinal space charge oscillations in relativistic electron beams, Phys. Rev. Lett. 106, 184801 (2011).
  26. S. Antipov, C. Jing, M. Fedurin, W. Gai, A. Kanareykin, K. Kusche, P. Schoessow, V. Yakimenko, and A. Zholents, Experimental observation of energy modulation in electron beams passing through terahertz dielectric wakefield structures, Phys. Rev. Lett. 108, 144801 (2012).
  27. S. Antipov, M. Babzien, C. Jing, M. Fedurin, W. Gai, A. Kanareykin, K. Kusche, V. Yakimenko, and A. Zholents, Subpicosecond bunch train production for a tunable mJ level THz source, Phys. Rev. Lett. 111, 134802 (2013).
  28. Z. Zhang, L. Yan, Y. Du, Z. Zhou, X. Su, L. Zheng, D. Wang, Q. Tian, W. Wang, J. Shi, H. Chen, W. Huang, W. Gai, and C. Tang, Tunable high-intensity electron bunch train production based on nonlinear longitudinal space charge oscillation, Phys. Rev. Lett. 116, 184801 (2016).
  29. F. Lemery, P. Piot, G. Amatuni, P. Boonpornprasert, Y. Chen, J. Good, B. Grigoryan, M. Groß, M. Krasilinikov, O. Lishilin, G. Loisch, A. Oppelt, S. Philipp, H. Qian, Y. Renier, F. Stephan, and I. Zagorodnov, Passive ballistic microbunching of nonultrarelativistic electron bunches using electromagnetic wakefields in dielectric-lined waveguides, Phys. Rev. Lett. 122, 044801 (2019).
  30. G. Zhao, S. Zhao, S. Huang, and K. Liu, Strong electron density modulation with a low-power THz source for generating THz superradiant undulator radiation, Phys. Rev. Accel. Beams 22, 060701 (2019).
  31. H. Feng, Z. Zhou, Y. Wu, Z. Gao, Y. Liang, N. Huang, L. Yan, H. Deng, Y. Du, R. Li, W. Lu, W. Huang, and C. Tang, Generation of tunable 10-mJ-level terahertz pulses through nonlinear plasma wakefield modulation, Phys. Rev. Appl. 15, 044032 (2021).
  32. Y. Liang, Z. Liu, Q. Tian, T. Li, X. Lin, L. Yan, Y. Du, R. Li, J. Shi, C. Cheng, W. Huang, and C. Tang, Widely tunable electron bunch trains for the generation of high-power narrowband 1–10 THz radiation, Nat. Photon. 17, 259 (2023).
  33. T. Tanaka, Proposal to generate an isolated monocycle X-ray pulse by counteracting the slippage effect in free-electron lasers, Phys. Rev. Lett. 114, 044801 (2015).
  34. V. A. Goryashko, Quasi-half-cycle pulses of light from a tapered undulator, Phys. Rev. Accel. Beams 20, 080703 (2017).
  35. H. Zhang, W. Wang, S. Jiang, C. Li, Z. He, Q. Jia, L. Wang, and D. He, Generation of frequency-chirped density modulation electron beam for producing ultrashort THz radiation pulse, Phys. Rev. Accel. Beams 23, 020704 (2020).
  36. S. Ma, H. Zhang, J. Pang, C. Liu, and Z. He, Enhancement of chirped density modulation in electron beam for generating ultrashort THz radiation pulse, Phys. Rev. Accel. Beams 28, 044402 (2025).
  37. X. Li, Y. Yu, Q. Li, S. Liu, C. Wang, J. Zhou, F. Yin, X. Shi, J. Sun, J. Shao, X. Wang, Z. He, W. Dong, L. Jiang, J. Yang, G. Wu, W. Zhang, and X. Yang, Wavelength switching and scanning of the high-gain harmonic generation free-electron laser at the Dalian Coherent Light Source, Phys. Rev. Accel. Beams 28, 100701 (2025).
  38. DESY mpyflo, https://www.desy.de/mpyflo/, accessed 6 June (2025).
  39. T. Tanaka and H. Kitamura, SPECTRA: A synchrotron radiation calculation code, J. Synchrotron Rad. 8, 1221 (2001).
  40. A. Murokh, J. Rosenzweig, M. Hogan, H. Suk, G. Travish, and U. Happek, Bunch length measurement of picosecond electron beams from a photoinjector using coherent transition radiation, Nucl. Instrum. Methods Phys. Res. Sec. A 410, 452 (1998).
  41. M. Castellano, V. A. Verzilov, L. Catani, A. Cianchi, G. Orlandi, and M. Geitz, Measurements of coherent diffraction radiation and its application for bunch length diagnostics in particle accelerators, Phys. Rev. E 63, 056501 (2001).
  42. https://cstr.cn/31127.02.dcls.
