Open channels and radiation trapping eigenstates in complex resonant media

Romain Rescanieres, Romain Pierrat, and Arthur Goetschy*

  • *Contact author: arthur.goetschy@espci.psl.eu
PDF

Phys. Rev. Research 7, 033273 – Published 23 September, 2025

DOI: https://doi.org/10.1103/wqrf-tkty

Abstract

We present a statistical study of the transmission and dwell-time matrices in disordered media composed of resonators, focusing on how frequency detuning influences their eigenvalue distributions. Our analysis reveals that the distribution of transmission eigenvalues undergoes a transition from a monomodal to a bimodal profile, and back to monomodal, as the frequency approaches the resonant frequency of the particles. Moreover, the distribution of dwell-time eigenvalues broadens significantly near resonance, with the longest lifetimes exceeding the median by several orders of magnitude. These results are explained by examining how frequency ω affects the transport mean free path of light ℓ(ω) and the energy transport velocity vE(ω), which in turn shape the observed distributions. We demonstrate the strong potential of wavefront shaping to synthesize wavefronts associated with eigenstates that enhance transmission and energy storage (or radiation trapping) in resonant disordered media. In the diffusive regime, where the system thickness L exceeds the mean free path, both transmission and dwell time can be enhanced by a factor ∝L/ℓ(ω)≫1 when using wavefronts associated with the largest eigenvalues instead of plane waves. In the localized regime, the enhancements become ∝Ne2L/ξ for transmission and ∝Nξ/L for dwell time, where ξ is the localization length and N is the number of controlled scattering channels. Finally, we show that employing high-Q resonators instead of low-Q ones increases energy storage within the medium by a factor of ∝Q/kℓ(ω) in both the diffusive and localized regimes.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (65)

  1. Z. Shi and A. Z. Genack, Transmission eigenvalues and the bare conductance in the crossover to Anderson localization, Phys. Rev. Lett. 108, 043901 (2012).
  2. R. Sarma, A. G. Yamilov, S. Petrenko, Y. Bromberg, and H. Cao, Control of energy density inside a disordered medium by coupling to open or closed channels, Phys. Rev. Lett. 117, 086803 (2016).
  3. N. Bender, A. Yamilov, A. Goetschy, H. Yılmaz, C. W. Hsu, and H. Cao, Depth-targeted energy delivery deep inside scattering media, Nat. Phys. 18, 309 (2022).
  4. S. M. Popoff, G. Lerosey, R. Carminati, M. Fink, A. C. Boccara, and S. Gigan, Measuring the transmission matrix in optics: An approach to the study and control of light propagation in disordered media, Phys. Rev. Lett. 104, 100601 (2010).
  5. C. W. Hsu, S. F. Liew, A. Goetschy, H. Cao, and A. D. Stone, Correlation-enhanced control of wave focusing in disordered media, Nat. Phys. 13, 497 (2017).
  6. Y. Choi, C. Yoon, M. Kim, T. D. Yang, C. Fang-Yen, R. R. Dasari, K. J. Lee, and W. Choi, Scanner-free and wide-field endoscopic imaging by using a single multimode optical fiber, Phys. Rev. Lett. 109, 203901 (2012).
  7. M. Plöschner, T. Tyc, and T. Čižmár, Seeing through chaos in multimode fibres, Nat. Photon. 9, 529 (2015).
  8. M. W. Matthès, Y. Bromberg, J. de Rosny, and S. M. Popoff, Learning and avoiding disorder in multimode fibers, Phys. Rev. X 11, 021060 (2021).
  9. A. Badon, V. Barolle, K. Irsch, A. C. Boccara, M. Fink, and A. Aubry, Distortion matrix concept for deep optical imaging in scattering media, Sci. Adv. 6, eaay7170 (2020).
  10. H. Lee, S. Yoon, P. Loohuis, J. H. Hong, S. Kang, and W. Choi, High-throughput volumetric adaptive optical imaging using compressed time-reversal matrix, Light Sci. Appl. 11, 16 (2022).
  11. A. Lagendijk, A. P. Mosk, M. Fink, and G. Lerosey, Controlling waves in space and time for imaging and focusing in complex media (review), Nat. Photon. 6, 283 (2012).
  12. H. Cao, A. P. Mosk, and S. Rotter, Shaping the propagation of light in complex media, Nat. Phys. 18, 994 (2022).
  13. C. Texier, Wigner time delay and related concepts: Application to transport in coherent conductors, Physica E 82, 16 (2016).
  14. S. Rotter and S. Gigan, Light fields in complex media: Mesoscopic scattering meets wave control, Rev. Mod. Phys. 89, 015005 (2017).
  15. M. Durand, S. M. Popoff, R. Carminati, and A. Goetschy, Optimizing light storage in scattering media with the dwell-time operator, Phys. Rev. Lett. 123, 243901 (2019).
  16. A. Yariv, Y. Xu, R. K. Lee, and A. Scherer, Coupled-resonator optical waveguide: A proposal and analysis, Opt. Lett. 24, 711 (1999).
  17. A. Goetschy and S. E. Skipetrov, Euclidean matrix theory of random lasing in a cloud of cold atoms, Europhys. Lett. 96, 34005 (2011).
  18. C. W. Hsu, B. Zhen, A. D. Stone, J. D. Joannopoulos, and M. Soljacic, Bound states in the continuum, Nat. Rev. Mater. 1, 16048 (2016).
  19. M. F. Limonov, M. V. Rybin, A. N. Poddubny, and Y. S. Kivshar, Fano resonances in photonics, Nat. Photon. 11, 543 (2017).
  20. E. Shahmoon, D. S. Wild, M. D. Lukin, and S. F. Yelin, Cooperative resonances in light scattering from two-dimensional atomic arrays, Phys. Rev. Lett. 118, 113601 (2017).
  21. P. Lalanne, W. Yan, K. Vynck, C. Sauvan, and J.-P. Hugonin, Light interaction with photonic and plasmonic resonances, Laser Photon. Rev. 12, 1700113 (2018).
  22. D. E. Chang, J. S. Douglas, A. González-Tudela, C.-L. Hung, and H. J. Kimble, Colloquium: Quantum matter built from nanoscopic lattices of atoms and photons, Rev. Mod. Phys. 90, 031002 (2018).
  23. P. del Hougne, R. Sobry, O. Legrand, F. Mortessagne, U. Kuhl, and M. Davy, Experimental realization of optimal energy storage in resonators embedded in scattering media, Laser Photon. Rev. 15, 2000335 (2021).
  24. P. Hong, O. S. Ojambati, A. Lagendijk, A. P. Mosk, and W. L. Vos, Three-dimensional spatially resolved optical energy density enhanced by wavefront shaping, Optica 5, 844 (2018).
  25. G. Labeyrie, E. Vaujour, C. A. Müller, D. Delande, C. Miniatura, D. Wilkowski, and R. Kaiser, Slow diffusion of light in a cold atomic cloud, Phys. Rev. Lett. 91, 223904 (2003).
  26. R. Sapienza, P. D. García, J. Bertolotti, M. D. Martín, A. Blanco, L. Viña, C. López, and D. S. Wiersma, Observation of resonant behavior in the energy velocity of diffused light, Phys. Rev. Lett. 99, 233902 (2007).
  27. B. Tallon, T. Brunet, and J. H. Page, Impact of strong scattering resonances on ballistic and diffusive wave transport, Phys. Rev. Lett. 119, 164301 (2017).
  28. F. Lemoult, N. Kaina, M. Fink, and G. Lerosey, Wave propagation control at the deep subwavelength scale in metamaterials, Nat. Phys. 9, 55 (2013).
  29. L. V. Hau, S. E. Harris, Z. Dutton, and C. H. Behroozi, Light speed reduction to 17 metres per second in an ultracold atomic gas, Nature (London) 397, 594 (1999).
  30. A. Lagendijk and B. A. van Tiggelen, Resonant multiple scattering of light, Phys. Rep. 270, 143 (1996).
  31. R. Pierrat, B. Grémaud, and D. Delande, Enhancement of radiation trapping for quasiresonant scatterers at low temperature, Phys. Rev. A 80, 013831 (2009).
  32. P. Weiss, M. O. Araújo, R. Kaiser, and W. Guerin, Subradiance and radiation trapping in cold atoms, New J. Phys. 20, 063024 (2018).
  33. A. Glicenstein, A. Apoorva, D. B. Orenes, H. Letellier, A. M. G.  de Melo, R. Saint-Jalm, and R. Kaiser, In situ measurements of light diffusion in an optically dense atomic ensemble, Phys. Rev. Lett. 133, 233401 (2024).
  34. E. Akkermans and G. Montambaux, Mesoscopic Physics of Electrons and Photons (Cambridge University Press, Cambridge, 2007).
  35. D. S. Fisher and P. A. Lee, Relation between conductivity and transmission matrix, Phys. Rev. B 23, 6851 (1981).
  36. C. W. J. Beenakker, Random-matrix theory of quantum transport, Rev. Mod. Phys. 69, 731 (1997).
  37. R. Carminati and J. Schotland, Principles of Scattering and Transport of Light (Cambridge University Press, Cambridge, 2021).
  38. R. Monsarrat, R. Pierrat, A. Tourin, and A. Goetschy, Pseudogap and Anderson localization of light in correlated disordered media, Phys. Rev. Res. 4, 033246 (2022).
  39. O. Dorokhov, On the coexistence of localized and extended electronic states in the metallic phase, Solid State Commun. 51, 381 (1984).
  40. P. A. Mello, P. Pereyra, and N. Kumar, Macroscopic approach to multichannel disordered conductors, Ann. Phys. (NY) 181, 290 (1988).
  41. Y. Imry, Active transmission channels and universal conductance fluctuations, Europhys. Lett. 1, 249 (1986).
  42. V. A. Gopar and R. A. Molina, Controlling conductance statistics of quantum wires by driving ac fields, Phys. Rev. B 81, 195415 (2010).
  43. A. Abrikosov, The paradox with the static conductivity of a one-dimensional metal, Solid State Commun. 37, 997 (1981).
  44. M. Davy, Z. Shi, J. Park, C. Tian, and A. Genack, Universal structure of transmission eigenchannels inside opaque media, Nat. Commun. 6, 6893 (2015).
  45. P. Fang, C. Tian, L. Zhao, Y. P. Bliokh, V. Freilikher, and F. Nori, Universality of eigenchannel structures in dimensional crossover, Phys. Rev. B 99, 094202 (2019).
  46. A. Ishimaru, Wave Propagation and Scattering in Random Media (Oxford University Press, Tokyo, 1997).
  47. A. Peña, A. Girschik, F. Libisch, S. Rotter, and A. A. Chabanov, The single-channel regime of transport through random media, Nat. Commun. 5, 3488 (2014).
  48. M. Davy and A. Z. Genack, Selectively exciting quasi-normal modes in open disordered systems, Nat. Commun. 9, 4714 (2018).
  49. L. Landau, L. Pitaevskii, and E. Lifshitz, Electrodynamics of Continuous Media, 2nd ed. (Elsevier, Moscow, 1984), Vol. 8.
  50. E. P. Wigner, Lower limit for the energy derivative of the scattering phase shift, Phys. Rev. 98, 145 (1955).
  51. F. T. Smith, Lifetime matrix in collision theory, Phys. Rev. 118, 349 (1960).
  52. R. Pierrat, P. Ambichl, S. Gigan, A. Haber, R. Carminati, and S. Rotter, Invariance property of wave scattering through disordered media, Proc. Natl. Acad. Sci. USA 111, 17765 (2014).
  53. C. Texier and A. Comtet, Universality of the Wigner time delay distribution for one-dimensional random potentials, Phys. Rev. Lett. 82, 4220 (1999).
  54. A. Ossipov, T. Kottos, and T. Geisel, Statistical properties of phases and delay times of the one-dimensional Anderson model with one open channel, Phys. Rev. B 61, 11411 (2000).
  55. C. J. Bolton-Heaton, C. J. Lambert, V. I. Fal’ko, V. Prigodin, and A. J. Epstein, Distribution of time constants for tunneling through a one-dimensional disordered chain, Phys. Rev. B 60, 10569 (1999).
  56. A. Ossipov, Scattering approach to Anderson localization, Phys. Rev. Lett. 121, 076601 (2018).
  57. T. Kottos, Statistics of resonances and delay times in random media: Beyond random matrix theory, J. Phys. A: Math. Gen. 38, 10761 (2005).
  58. D. Laurent, O. Legrand, P. Sebbah, C. Vanneste, and F. Mortessagne, Localized modes in a finite-size open disordered microwave cavity, Phys. Rev. Lett. 99, 253902 (2007).
  59. G. J. Aubry, L. S. Froufe-Pérez, U. Kuhl, O. Legrand, F. Scheffold, and F. Mortessagne, Experimental tuning of transport regimes in hyperuniform disordered photonic materials, Phys. Rev. Lett. 125, 127402 (2020).
  60. L. A. Razo-López, G. J. Aubry, F. A. Pinheiro, and F. Mortessagne, Strong localization of microwaves beyond two dimensions in aperiodic Vogel spirals, Phys. Rev. B 109, 014205 (2024).
  61. A. G. Yamilov, R. Sarma, B. Redding, B. Payne, H. Noh, and H. Cao, Position-dependent diffusion of light in disordered waveguides, Phys. Rev. Lett. 112, 023904 (2014).
  62. M. Lee, H. Hong, J. Yu, F. Mujid, A. Ye, C. Liang, and J. Park, Wafer-scale δ waveguides for integrated two-dimensional photonics, Science 381, 648 (2023).
  63. H. Ling, J. B. Khurgin, and A. R. Davoyan, Atomic-void van der Waals channel waveguides, Nano Lett. 22, 6254 (2022).
  64. L. Novotny and B. Hecht, Principles of Nano-Optics (Cambridge University Press, Cambridge, 2012).
  65. E. Castanié, R. Vincent, R. Pierrat, and R. Carminati, Absorption by an optical dipole antenna in a structured environment, Int. J. Opt. 2012, 452047 (2012).

Outline

Information

Phys. Rev. Research 7, 033273– Published 23 September, 2025
  • Received 9 December 2024
  • Accepted 25 July 2025
