Quasi-phase-matched spontaneous parametric down-conversion in chiral ferroelectric nematic liquid crystals

Aljaž Kavčič1,2, Nerea Sebastián1, and Matjaž Humar1,2,3,*

  • *Contact author: matjaz.humar@ijs.si
PDF

Phys. Rev. Research 8, 013119 – Published 2 February, 2026

DOI: https://doi.org/10.1103/wgb3-clj5

Abstract

For high-intensity photon pair generation via spontaneous parametric down-conversion, phase matching or quasi-phase-matching must be realized. The most common method is to use periodically poled crystals, where quasi-phase-matching is achieved through the periodic modulation of the nonlinear susceptibility. In contrast to solid-state materials typically employed, an alternative approach is demonstrated here by using chiral ferroelectric nematic liquid crystals (FNLCs). It involves the spontaneous formation of a twisted periodic arrangement of liquid crystal molecules that depends only on the concentration of chiral dopants. This enables the rapid and scalable fabrication of nonlinear optical media with a tunable periodicity of the structure. We show that within only 20µm, we can enhance the signal by 2 orders of magnitude compared to the maximal achievable rate for the non-phase-matched case. This process enables us to achieve a significantly enhanced photon pair generation rate of over 1200 Hz/mW in a very short interaction length while simultaneously maintaining a high degree of polarization entanglement. These results establish chiral FNLCs as a versatile, reconfigurable, and low-cost platform for nonlinear and quantum photonics.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (42)

  1. C. Couteau, Spontaneous parametric down-conversion, Contemp. Phys. 59, 291 (2018).
  2. P. G. Kwiat, K. Mattle, H. Weinfurter, A. Zeilinger, A. V. Sergienko, and Y. Shih, New high-intensity source of polarization-entangled photon pairs, Phys. Rev. Lett. 75, 4337 (1995).
  3. R. W. Boyd, A. L. Gaeta, and E. Giese, Nonlinear optics, in Springer Handbook of Atomic, Molecular, and Optical Physics, editrd by W. F. D. Gordon (Springer, Cham, 2008), pp. 1097–1110.
  4. A. Burlakov, M. Chekhova, O. Karabutova, and S. Kulik, Collinear two-photon state with spectral properties of type-I and polarization properties of type-II spontaneous parametric down-conversion: Preparation and testing, Phys. Rev. A 64, 041803 (2001).
  5. R. L. Byer, Quasi-phase-matched nonlinear interactions and devices, J. Nonlinear Opt. Phys. Mater. 6, 549 (1997).
  6. K. L. Vodopyanov et al., Optical parametric oscillation in quasi-phase-matched GaAs, Opt. Lett. 29, 1912 (2004).
  7. L. Gordon et al., Diffusion-bonded stacked GaAs for quasi-phase-matched second-harmonic generation of a carbon dioxide laser, Electron. Lett. 29, 1942 (1993).
  8. L. E. Myers et al., Quasi-phase-matched optical parametric oscillators in bulk periodically poled LiNbO3, J. Opt. Soc. Am. B 12, 2102 (1995).
  9. G. D. Miller, Periodically Poled Lithium Niobate: Modeling, Fabrication, and Nonlinear Optical Performance (Stanford University, Stanford, California, USA, 1998).
  10. S. Tanzilli et al., Highly efficient photon-pair source using periodically poled lithium niobate waveguide, Electron. Lett. 37, 26 (2001).
  11. G. Tawy et al., Temperature-tunable UV generation using an Alexandrite laser and PPLN waveguides, Opt. Express 31, 22757 (2023).
  12. V. Sultanov et al., Tunable entangled photon-pair generation in a liquid crystal, Nature (London) 631, 294 (2024).
  13. H. Nishikawa et al., A fluid liquid-crystal material with highly polar order, Adv. Mater. 29, 1702354 (2017).
  14. R. J. Mandle, S. J. Cowling, and J. W. Goodby, A nematic to nematic transformation exhibited by a rod-like liquid crystal, Phys. Chem. Chem. Phys. 19, 11429 (2017).
  15. X. Chen et al., First-principles experimental demonstration of ferroelectricity in a thermotropic nematic liquid crystal: Polar domains and striking electro-optics, Proc. Natl. Acad. Sci. USA 117, 14021 (2020).
  16. N. Sebastián, L. Cmok, R. J. Mandle, M. R. delaFuente, I. DrevensekOlenik, M. Copic, and A. Mertelj, Ferroelectric-ferroelastic phase transition in a nematic liquid crystal, Phys. Rev. Lett. 124, 037801 (2020).
  17. N. Sebastián, R. J. Mandle, A. Petelin, A. Eremin, and A. Mertelj, Electrooptics of mm-scale polar domains in the ferroelectric nematic phase, Liq. Cryst. 48, 2055 (2021).
  18. C. L. Folcia, J. Ortega, R. Vidal, T. Sierra, and J. Etxebarria, The ferroelectric nematic phase: An optimum liquid crystal candidate for nonlinear optics, Liq. Cryst. 49, 899 (2022).
  19. H. Nishikawa and F. Araoka, A new class of chiral nematic phase with helical polar order, Adv. Mater. 33, 2101305 (2021).
  20. X. Zhao et al., Spontaneous helielectric nematic liquid crystals: Electric analog to helimagnets, Proc. Natl. Acad. Sci. USA 118, e2111101118 (2021).
  21. C. Feng et al., Electrically tunable reflection color of chiral ferroelectric nematic liquid crystals, Adv. Opt. Mater. 9, 2101230 (2021).
  22. P.-G. De Gennes and J. Prost, The Physics of Liquid Crystals (Oxford University Press, Oxford, 1993).
  23. C. Bahr and H.-S. Kitzerow, Chirality in Liquid Crystals (Springer, New York, 2001).
  24. X. Zhao et al., Nontrivial phase matching in helielectric polarization helices: Universal phase matching theory, validation, and electric switching, Proc. Natl. Acad. Sci. USA 119, e2205636119 (2022).
  25. X. Zhao, J. Li, M. Huang, and S. Aya, High-g-factor phase-matched circular dichroism of second harmonic generation in chiral polar liquids, J. Mater. Chem. C 11, 8547 (2023).
  26. J.-T. Pan et al., Nonreciprocal quantum photon-pair source with chiral ferroelectric nematics, arXiv:2503.11399.
  27. K. Thapa et al., Confinement and magnetic-field effect on chiral ferroelectric nematic liquid crystals in Grandjean-Cano wedge cells, Phys. Rev. E 109, 054702 (2024).
  28. O. Lavrentovich and D.-K. Yang, Cholesteric cellular patterns with electric-field-controlled line tension, Phys. Rev. E 57, R6269 (1998).
  29. M. Bock, A. Lenhard, C. Chunnilall, and C. Becher, Highly efficient heralded single-photon source for telecom wavelengths based on a PPLN waveguide, Opt. Express 24, 23992 (2016).
  30. F. Steinlechner et al., A high-brightness source of polarization-entangled photons optimized for applications in free space, Opt. Express 20, 9640 (2012).
  31. Omshankar, V. Venkataraman, and J. Ghosh, Bright source of narrowband polarization-entangled photons from a thick type-II ppKTP crystal, Opt. Express 32, 3470 (2024).
  32. A. Burlakov, L. Krivitskii, S. Kulik, G. Maslennikov, and M. Chekhova, Measurement of qutrits, Opt. Spectrosc. 94, 684 (2003).
  33. C. C. Gerry and P. L. Knight, Introductory Quantum Optics (Cambridge University Press, Cambridge, UK, 2023).
  34. A. Burlakov, M. Chekhova, O. Karabutova, D. Klyshko, and S. Kulik, Polarization state of a biphoton: Quantum ternary logic, Phys. Rev. A 60, R4209 (1999).
  35. A. Burlakov and D. Klyshko, Polarized biphotons as “optical quarks”, J. Exp. Theor. Phys. Lett. 69, 839 (1999).
  36. V. Sultanov, T. Santiago-Cruz, and M. V. Chekhova, Flat-optics generation of broadband photon pairs with tunable polarization entanglement, Opt. Lett. 47, 3872 (2022).
  37. M. Fedorov, P. Volkov, J. M. Mikhailova, S. Straupe, and S. Kulik, Entanglement of biphoton states: Qutrits and ququarts, New J. Phys. 13, 083004 (2011).
  38. M. Fedorov and N. Miklin, Schmidt modes and entanglement, Contemp. Phys. 55, 94 (2014).
  39. J. Karcz et al., Spontaneous chiral symmetry breaking in polar fluid–heliconical ferroelectric nematic phase, Science 384, 1096 (2024).
  40. M. S. H. Himel et al., Electrically tunable chiral ferroelectric nematic liquid crystal reflectors, Adv. Funct. Mater. 35, 2413674 (2025).
  41. J. Ortega, C. L. Folcia, J. Etxebarria, and T. Sierra, Ferroelectric chiral nematic liquid crystals: New photonic materials with multiple bandgaps controllable by low electric fields, Liq. Cryst. 49, 2128 (2022).
  42. M. Humar, A. Kavčič, and N. Sebastian, Data for SPDC in FNLC, Zenodo (2025), doi:http://doi.org/10.5281/zenodo.16263027.
