Unraveling hydrogel resistance to particle deposition: Adhesion versus elastohydrodynamic lift

Aleksandr Leontev1,2,*, Axel Rosenhahn3, and Viatcheslav Freger4,†

  • *Contact author: 20259420al@scut.edu.cn
  • †Contact author: vfreger@technion.ac.il
PDF

Phys. Rev. Research 8, 023021 – Published 7 April, 2026

DOI: https://doi.org/10.1103/wbrn-979m

Abstract

Soft hydrogels are widely used as antifouling coatings because they strongly suppress deposition of particles, cells, and microorganisms from flowing aqueous suspensions, yet the physical origin of this resistance remains unclear, as several near-wall phenomena occur simultaneously over rapidly changing length scales. Here, we combine deposition kinetics, single-particle trajectory tracking, and independent measurements of adhesion dynamics to identify the key kinetic barrier. Using polystyrene microbeads depositing onto a submicron poly(ethylene glycol) hydrogel coating in a parallel-plate flow cell, we examine how the near-wall deceleration of depositing particles during the last few seconds preceding arrest compares with the one expected for particles rolling in contact with the surface and decelerating through adhesive force maturing over time. Estimating the latter using a braking model, derived from the adhesion dynamics extracted from AFM force spectroscopy using identical colloidal probes and surface, predicts immobilization of several orders of magnitude faster than observed. When further combined with attachment rate constants deduced from the variation of the deposition rate along the channel and their ionic-strength dependence, this disagreement rules out rolling-in-contact scenario. This implies that most particles stay hovering above the surface, separated from the hydrogel by a thin fluid gap maintained by a repulsive force. We further rule out as such force both the electric double-layer interactions, attractive in the present system, and the inertial lift, as it is negligible at the present shear rates. This points to elastohydrodynamic lift (EHL)—arising from pressure-deformation coupling in lubrication flow amplified by large compliance of the hydrogel—as the only plausible barrier force. Using mechanical parameters measured by AFM and established EHL scaling, we show that EHL can indeed impose a sufficient kinetic barrier at a few tens of nanometers from the surface, cutting off attractive adhesion forces and suppressing deposition.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (55)

  1. C. Shen, Y. Wang, Z. Tang, Y. Yao, Y. Huang, and X. Wang, Experimental study on the interaction between particulate fouling and precipitation fouling in the fouling process on heat transfer tubes, Int. J. Heat Mass Transfer 138, 1238 (2019).
  2. C. Henry, J.-P. Minier, and G. Lefèvre, Towards a description of particulate fouling: From single particle deposition to clogging, Adv. Colloid Interface Sci. 185–186, 34 (2012).
  3. S. Bauer, J. A. Finlay, I. Thomé, K. Nolte, S. C. Franco, E. Ralston, G. E. Swain, A. S. Clare, and A. Rosenhahn, Attachment of algal cells to zwitterionic self-assembled monolayers comprised of different anionic compounds, Langmuir 32, 5663 (2016).
  4. M. Mu, X. Wang, M. Akbulut, M. Taylor, and Y. Min, Multifunctional coatings for mitigating bacterial fouling and contamination, Colloid Interface Sci. Commun. 55, 100717 (2023).
  5. R. Donlan, W. Pipes, and T. Yohe, Biofilm formation on cast iron substrata in water distribution systems, Water Res. 28, 1497 (1994).
  6. H. Flemming, Reverse osmosis membrane biofouling, Exp. Therm Fluid Sci. 14, 382 (1997).
  7. M. Brunelle, Colloidal fouling of reverse osmosis membranes, Desalination 32, 127 (1980).
  8. H. Bai, N. Cochet, A. Pauss, and E. Lamy, Bacteria cell properties and grain size impact on bacteria transport and deposition in porous media, Colloids Surf. B 139, 148 (2016).
  9. J. Redman, S. Walker, and M. Elimelech, Bacterial adhesion and transport in porous media: Role of the secondary energy minimum, Environ. Sci. Technol. 38, 1777 (2004).
  10. T. Camesano and B. Logan, Influence of fluid velocity and cell concentration on the transport of motile and nonmotile bacteria in porous media, Environ. Sci. Technol. 32, 1699 (1998).
  11. O. Krehel, A. Muntean, and P. Knabner, Multiscale modeling of colloidal dynamics in porous media including aggregation and deposition, Adv. Water Resour. 86, 209 (2015).
  12. J. Genzer and K. Efimenko, Recent developments in superhydrophobic surfaces and their relevance to marine fouling: A review, Biofouling 22, 339 (2006).
  13. Z. Adamczyk and P. Weroński, Application of the DLVO theory for particle deposition problems, Adv. Colloid Interface Sci. 83, 137 (1999).
  14. M. Elimelech, J. Gregory, X. Jia, and R. Williams, Particle Deposition and Aggregation (Butterworth-Heinemann, Oxford, 1995).
  15. E. Margalit, A. Leshansky, and V. Freger, Modeling and analysis of hydrodynamic and physico-chemical effects in bacterial deposition on surfaces, Biofouling 29, 977 (2013).
  16. A. Vedadghavami, F. Minooeib, M. H. Mohammadi, S. Khetani, A. R. Kolahchid, S. Mashayekhan, and A. Sanati-Nezhad, Manufacturing of hydrogel biomaterials with controlled mechanical properties for tissue engineering applications, Acta Biomater. 62, 42 (2017).
  17. D. Yang, Recent advances in hydrogels, Chem. Mater. 34, 1987 (2022).
  18. L. E. Beckett, J. T. Lewis, T. K. Tonge, and L. T. J. Korley, Enhancement of the mechanical properties of hydrogels with continuous fibrous reinforcement, ACS Biomater. Sci. Eng. 6, 5453 (2020).
  19. T. Murosaki, N. Ahmed, and J. P. Gong, Antifouling properties of hydrogels, Sci. Technol. Adv. Mater. 12, 064706 (2011).
  20. A. Leontev, L. Rozental, and V. Freger, Dynamics of underwater microparticle adhesion to soft hydrated surfaces: Modeling and analysis by time-dependent AFM force spectroscopy, J. Colloid Interface Sci. 651, 464 (2023).
  21. G. Hoch, A. Chauhan, and C. J. Radke, Permeability and diffusivity for water transport through hydrogel membranes, J. Membrane Sci. 214, 199 (2003).
  22. M. K. Yazdi, V. Vatanpour, A. Taghizadeh, M. Taghizadeh, M. R. Ganjali, M. T. Munir, S. Habibzadeh, M. R. Saeb, and M. Ghaedi, Hydrogel membranes: A review, Mater. Sci. Eng. C 114, 111023 (2020).
  23. T. M. Squires and S. R. Quake, Microfluidics: Fluid physics at the nanoliter scale, Rev. Mod. Phys. 77, 977 (2005).
  24. H. A. Stone, A. D. Stroock, and A. Ajdari, Engineering flows in small devices: Microfluidics toward a lab-on-a-chip, Annu. Rev. Fluid Mech. 36, 381 (2004).
  25. J. Israelachvili, Intermolecular and Surface Forces, 3rd ed. (Academic Press, London, 2011).
  26. V. Privman, Recent theoretical results for nonequilibrium deposition of submicron particles, J. Adhesion 74, 421 (2000).
  27. M. Sadowska, M. Nattich-Rak, M. Morga, Z. Adamczyk, T. Basinska, D. Mickiewicz, and M. Gadzinowski, Anisotropic particle deposition kinetics from quartz crystal microbalance measurements: Beyond the sphere paradigm, Langmuir 40, 7907 (2024).
  28. M. Kazoe and M. Yoda, Dynamics of suspended colloidal particles near a wall, Phys. Fluids 23, 111301 (2011).
  29. S. Kalasin and M. M. Santore, Sustained rolling of microparticles in shear flow over an electrostatically patchy surface, Langmuir 26, 2317 (2010).
  30. M. Kerner, K. Schmidt, S. Schumacher, C. Asbach, and S. Antonyuk, Ageing of electret filter media due to deposition of submicron particles—Experimental and numerical investigations, Sep. Purif. Technol. 251, 117299 (2020).
  31. A. Unni and C. Yang, Brownian dynamics simulation of colloidal particle deposition in a microchannel flow, J. Colloid Interface Sci. 291, 28 (2005).
  32. T. Hu, C. Wang, K. Yang, and L. Chen, Gravity effect of silica and polystyrene particles on deposition pattern control and particle size distribution on hydrophobic surfaces, J. Ind. Eng. Chem. 106, 214 (2022).
  33. A. Leontev, R. Bar-On, M. Bass, M. Juric, C. Schmetz, and V. Freger, Spatial pattern and surface-specificity of particle and microorganism deposition and attachment: Modeling, analytic solution and experimental test, J. Colloid Interface Sci. 584, 45 (2021).
  34. I. Noichl and C. Schonecker, Inertial forces and elastohydrodynamic interaction of spherical particles in wall-bounded sedimentation experiments at low Re number, arXiv:2409.07209 (2024).
  35. L. Rozental, A. Leontev, C. Diesendruck, and V. Freger, Preparation, nano-mechanics and particle deposition behavior of thin, antifouling hydrogel coatings, Colloids Surf. C: Environ. Aspects 1, 100018 (2023).
  36. D. Di Carlo, Inertial microfluidics, Lab Chip 9, 3038 (2009).
  37. J. Klein, Hydration lubrication, Friction 1, 1 (2013).
  38. S. Krijt, C. Dominik, and A. G. G. M. Tielens, Rolling friction of adhesive microspheres, J. Phys. D Appl. Phys. 47, 175302 (2014).
  39. S. Scherrer, M. Ramakrishna, J. Wenner, and E. M. Furst, Measuring rolling friction at the nanoscale, Langmuir 40, 6750 (2024).
  40. J. M. Skotheim and L. Mahadevan, Soft lubrication, Phys. Fluids 17, 092101 (2005).
  41. V. Bertin, Y. Amarouchene, E. Raphaël, and T. Salez, Soft-lubrication interactions between a rigid sphere and an elastic wall, J. Fluid Mech. 933, A23 (2022).
  42. H. S. Davies, D. Débarre, N. El Amri, C. Verdier, R. P. Richter, and L. Bureau, Elastohydrodynamic lift at a soft wall, Phys. Rev. Lett. 120, 198001 (2018).
  43. A. Pandey, S. Karpitschka, C. H. Venner, and J. H. Snoeijer, Lubrication of soft viscoelastic solids, J. Fluid Mech. 799, 433 (2016).
  44. K. Chang, D. Tees, and D. A. Hammer, The state diagram for cell adhesion under flow: Leukocyte rolling and firm adhesion, Proc. Natl. Acad. Sci. USA 97, 11262 (2000).
  45. D. A. Hammer and S. M. Apte, Simulation of cell rolling and adhesion on surfaces in shear flow: General results and analysis of selectin-mediated neutrophil adhesion, Biophys. J. 63, 35 (1992).
  46. R. D. Duffadar and J. M. Davis, Dynamic adhesion behavior of micrometer-scale particles flowing over patchy surfaces with nanoscale electrostatic heterogeneity, J. Colloid Interface Sci. 326, 18 (2008).
  47. Z. Zhang, V. Bertin, M. Arshad, E. Raphaël, T. Salez, and A. Maali, Direct measurement of the elastohydrodynamic lift force at the nanoscale, Phys. Rev. Lett. 124, 054502 (2020).
  48. K. Briechle and U. D. Hanebeck, Template matching using fast normalized cross correlation, in Proceedings of the SPIE Meetings, Optical Pattern Recognition XII, Aerospace/Defence Sensing, Simulations, and Controls, edited by D. P. Casasent and T.-H. Chao (SPIE, Orlando, 2001), Vol. 4387.
  49. Y. R. Rao, N. Prathapani, and E. Nagabhooshanam, Application of normalized cross correlation to image registration, Int. J. Res. Eng. Technol. 03, 12 (2014).
  50. A. Tarnapolsky and V. Freger, Modeling QCM-D response to deposition and attachment of microparticles and living cells, Anal. Chem. 90, 13960 (2018).
  51. J. Urzay, Asymptotic theory of the elastohydrodynamic adhesion and gliding motion of a solid particle over soft and sticky substrates at low Reynolds numbers, J. Fluid Mech. 653, 391 (2010).
  52. B. Rallabandi, Fluid-elastic interactions near contact at low Reynolds number, Annu. Rev. Fluid. Mech. 56, 491 (2024).
  53. J. Urzay and S. G. L. Smith, The elastohydrodynamic force on a sphere near a soft wall, Phys. Fluids 19, 103106 (2007).
  54. M. Doi, Gel dynamics, J. Phys. Soc. Jpn. 78, 052001 (2009).
  55. Y. Achdou, O. Pironneau, and F. Valentin, Effective boundary conditions for laminar flows over periodic rough boundaries, J. Comput. Phys. 147, 187 (1998).
