In situ observation of proton-induced DNA fragmentation in the Bragg peak: Evidence for protective role of water

R. Liénard1, P. Barberet1, K. Chatzipapas2, G. Devès1, T. Dhôte1, T. Guérin3, H. Seznec1, and F. Gobet1,*

  • *Contact author: gobet@lp2ib.in2p3.fr
PDF

Phys. Rev. Research 7, 043004 – Published 1 October, 2025

DOI: https://doi.org/10.1103/t6st-wwyt

Abstract

We report in situ single-molecule measurements of proton-induced double-strand breaks (DSBs) in DNA immersed in water, using real-time fluorescence tracking along the entire proton path, including the Bragg peak region. By chemically suppressing radical-mediated processes, we isolate direct DNA damage mechanisms and determine DSB cross sections as a function of depth. Near the Bragg peak, we observe a tenfold reduction in DSB cross sections in aqueous DNA compared to dry DNA, providing quantitative evidence for the protective role of water. These findings highlight the importance of intermolecular energy dissipation in mitigating radiation-induced damage in condensed biological matter, with implications for radiobiology and proton therapy modeling.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (58)

  1. B. Chicana and C. M. Termini, Radical recovery from radiation, Nat. Rev. Mol. Cell Biol. 24, 605 (2023).
  2. L. Sanche, Beyond radical thinking, Nature (London) 461, 358 (2009).
  3. G. Gopakumar, I. Unger, P. Slavíček, U. Hergenhahn, G. Öhrwall, S. Malerz, D. Céolin, F. Trinter, B. Winter, I. Wilkinson et al., Radiation damage by extensive local water ionization from two-step electron-transfer-mediated decay of solvated ions, Nat. Chem. 15, 1408 (2023).
  4. C. Shepard, D. C. Yost, and Y. Kanai, Electronic excitation response of DNA to high-energy proton radiation in water, Phys. Rev. Lett. 130, 118401 (2023).
  5. M. Durante, J. Debus, and J. S. Loeffler, Physics and biomedical challenges of cancer therapy with accelerated heavy ions, Nat. Rev. Phys. 3, 777 (2021).
  6. M.-C. Vozenin, J. Bourhis, and M. Durante, Towards clinical translation of flash radiotherapy, Nat. Rev. Clin. Oncol. 19, 791 (2022).
  7. M. Durante and F. A. Cucinotta, Heavy ion carcinogenesis and human space exploration, Nat. Rev. Cancer 8, 465 (2008).
  8. S. Datz, Condensed Matter: Applied Atomic Collision Physics (Academic Press, Orlando, 1983), Vol. 4.
  9. M. Durante and J. S. Loeffler, Charged particles in radiation oncology, Nat. Rev. Clin. Oncol. 7, 37 (2010).
  10. A. Asaithamby, B. Hu, and D. J. Chen, Unrepaired clustered DNA lesions induce chromosome breakage in human cells, Proc. Natl. Acad. Sci. USA 108, 8293 (2011).
  11. E. T. Vitti and J. L. Parsons, The radiobiological effects of proton beam therapy: Impact on DNA damage and repair, Cancers 11, 946 (2019).
  12. K. R. Siefermann, Y. Liu, E. Lugovoy, O. Link, M. Faubel, U. Buck, B. Winter, and B. Abel, Binding energies, lifetimes and implications of bulk and interface solvated electrons in water, Nat. Chem. 2, 274 (2010).
  13. E. Alizadeh and L. Sanche, Precursors of solvated electrons in radiobiological physics and chemistry, Chem. Rev. 112, 5578 (2012).
  14. L. Vyšín, K. Pachnerová Brabcová, V. Štěpán, P. Moretto-Capelle, B. Bugler, G. Legube, P. Cafarelli, R. Casta, J. P. Champeaux, M. Sence et al., Proton-induced direct and indirect damage of plasmid DNA, Radiat. Environ. Biophys. 54, 343 (2015).
  15. D. Ohsawa, Y. Hiroyama, A. Kobayashi, T. Kusumoto, H. Kitamura, S. Hojo, S. Kodaira, and T. Konishi, DNA strand break induction of aqueous plasmid DNA exposed to 30 MeV protons at ultra-high dose rate, J. Radiat. Res. 63, 255 (2022).
  16. B. Liu, S. B. Nielsen, P. Hvelplund, H. Zettergren, H. Cederquist, B. Manil, and B. Huber, Collision-induced dissociation of hydrated adenosine monophosphate nucleotide ions: Protection of the ion in water nanoclusters, Phys. Rev. Lett. 97, 133401 (2006).
  17. P. Markush, P. Bolognesi, A. Cartoni, P. Rousseau, S. Maclot, R. Delaunay, A. Domaracka, J. Kocisek, M. C. Castrovilli, B. A. Huber et al., The role of the environment in the ion induced fragmentation of uracil, Phys. Chem. Chem. Phys. 18, 16721 (2016).
  18. A. Domaracka, M. Capron, S. Maclot, J.-Y. Chesnel, A. Méry, J.-C. Poully, J. Rangama, L. Adoui, P. Rousseau, and B. A. Huber, Ion interaction with biomolecular systems and the effect of the environment, J. Phys.: Conf. Ser. 373, 012005 (2012).
  19. B. Barc, M. Ryszka, J.-C. Poully, E. J. Al Maalouf, Z. El Otell, J. Tabet, R. Parajuli, P. J. van der Burgt, P. Limão-Vieira, P. Cahillane et al., Multi-photon and electron impact ionisation studies of reactivity in adenine–water clusters, Int. J. Mass Spectrom. 365–366, 194 (2014).
  20. M. Johny, C. A. Schouder, A. Al-Refaie, L. He, J. Wiese, H. Stapelfeldt, S. Trippel, and J. Küpper, Water is a radiation protection agent for ionised pyrrole, Phys. Chem. Chem. Phys. 26, 13118 (2024).
  21. H. Abdoul-Carime, F. Berthias, L. Feketeová, M. Marciante, F. Calvo, V. Forquet, H. Chermette, B. Farizon, M. Farizon, and T. D. Märk, Velocity of a molecule evaporated from a water nanodroplet: Maxwell–Boltzmann statistics versus non-ergodic events, Angew. Chem. 127, 14898 (2015).
  22. F. Berthias, L. Feketeová, H. Chermette, V. Forquet, C. Morell, H. Abdoul-Carime, B. Farizon, M. Farizon, and T. D. Märk, Proton migration in clusters consisting of protonated pyridine solvated by water molecules, ChemPhysChem 16, 3151 (2015).
  23. J. Kočišek, A. Pysanenko, M. Fárník, and J. Fedor, Microhydration prevents fragmentation of uracil and thymine by low-energy electrons, J. Phys. Chem. Lett. 7, 3401 (2016).
  24. C. Richter, D. Hollas, C.-M. Saak, M. Förstel, T. Miteva, M. Mucke, O. Björneholm, N. Sisourat, P. Slavíček, and U. Hergenhahn, Competition between proton transfer and intermolecular Coulombic decay in water, Nat. Commun. 9, 4988 (2018).
  25. T. Jahnke, H. Sann, T. Havermeier, K. Kreidi, C. Stuck, M. Meckel, M. Schöffler, N. Neumann, R. Wallauer, S. Voss et al., Ultrafast energy transfer between water molecules, Nat. Phys. 6, 139 (2010).
  26. X. Ren, E. Wang, A. D. Skitnevskaya, A. B. Trofimov, K. Gokhberg, and A. Dorn, Experimental evidence for ultrafast intermolecular relaxation processes in hydrated biomolecules, Nat. Phys. 14, 1062 (2018).
  27. E. Wang, X. Ren, W. Baek, H. Rabus, T. Pfeifer, and A. Dorn, Water acting as a catalyst for electron-driven molecular break-up of tetrahydrofuran, Nat. Commun. 11, 2194 (2020).
  28. A. R. Milosavljević, K. Jänkälä, M. L. Ranković, F. Canon, J. Bozek, C. Nicolas, and A. Giuliani, Oxygen K-shell spectroscopy of isolated progressively solvated peptide, Phys. Chem. Chem. Phys. 22, 12909 (2020).
  29. M. Souici, T. T. Khalil, D. Muller, Q. Raffy, R. Barillon, A. Belafrites, C. Champion, and M. Fromm, Single- and double-strand breaks of dry DNA exposed to protons at Bragg-peak energies, J. Phys. Chem. B 121, 497 (2017).
  30. C. M. Frame, Y. Chen, J. Gagnon, Y. Yuan, T. Ma, A. Dritschilo, and D. Pang, Proton induced DNA double strand breaks at the Bragg peak: Evidence of enhanced LET effect, Front. Oncol. 12, 930393 (2022).
  31. G. Muggiolu, M. Pomorski, G. Claverie, G. Berthet, C. Mer-Calfati, S. Saada, G. Devès, M. Simon, H. Seznec, and P. Barberet, Single α-particle irradiation permits real-time visualization of RNF8 accumulation at DNA damaged sites, Sci. Rep. 7, 41764 (2017).
  32. M. J. Berger, J. S. Coursey, M. A. Zucker, and J. Chang, ESTAR, PSTAR, and ASTAR: Computer Programs for Calculating Stopping-Power and Range Tables for Electrons, Protons, and Helium Ions (version 1.2.3), National Institute of Standards and Technology, Gaithersburg, MD, 2023, http://physics.nist.gov/Star.
  33. R. C. Ogden and D. A. Adams, Electrophoresis in agarose and acrylamide gels, Methods Enzymol 152, 61 (1987).
  34. J. Stanton, G. Taucher-Scholz, M. Schneider, J. Heilmann, and G. Kraft, Protection of DNA from high LET radiation by two OH radical scavengers, tris(hydroxymethyl)aminomethane and 2-mercaptoethanol, Radiat. Environ. Biophys. 32, 21 (1993).
  35. E. S. Miller, E. Kutter, G. Mosig, F. Arisaka, T. Kunisawa, and W. Rüger, Bacteriophage T4 genome, Microbiol. Mol. Biol. Rev. 67, 86 (2003).
  36. A. Larsson, C. Carlsson, and M. Jonsson, Characterization of the binding of YO to [poly(dA−dT)]2 and [poly(dG−dC)]2, and of the fluorescent properties of YO and YOYO complexed with the polynucleotides and double-stranded DNA, Biopolymers 36, 153 (1995).
  37. See Supplemental Material at http://link.aps.org/supplemental/10.1103/t6st-wwyt for experimental details, characteristics of the T4 DNA solution, cross sections as a function of dye loading and β-Mercaptoethanol concentration, and full description of the unfolding techniques, which includes Refs. [38, 39, 40, 41, 42, 43, 44, 45, 46, 47, 48, 49].
  38. J. C. Crocker and D. G. Grier, Methods of digital video microscopy for colloidal studies, J. Colloid Interface Sci. 179, 298 (1996).
  39. M. Doi, S. F. Edwards, and S. F. Edwards, The Theory of Polymer Dynamics (Clarendon Press, Oxford, 1988), Vol. 73.
  40. S. Redner, A Guide to First-Passage Processes (Cambridge University Press, Cambridge, 2001).
  41. J. Rotne and S. Prager, Variational treatment of hydrodynamic interaction in polymers, J. Chem. Phys. 50, 4831 (1969).
  42. E. Wajnryb, K. A. Mizerski, P. J. Zuk, and P. Szymczak, Generalization of the Rotne–Prager–Yamakawa mobility and shear disturbance tensors, J. Fluid Mech. 731, R3 (2013).
  43. H. W. Engl and R. Ramlau, Regularization of inverse problems, Encyclopedia of Applied and Computational Mathematics (Springer, Berlin, Heidelberg, 2015).
  44. A. Buccini, M. Donatelli, and L. Reichel, Iterated Tikhonov regularization with a general penalty term, Numer. Linear Algebra Appl. 24, e2089 (2017).
  45. S. Incerti, G. Baldacchino, M. Bernal, R. Capra, C. Champion, Z. Francis, P. Gueye, A. Mantero, B. Mascialino, P. Moretto et al., The Geant4-DNA project, Int. J. Model. Simul. Sci. Comput. 01, 157 (2010).
  46. S. Incerti, I. Kyriakou, M. Bernal, M. Bordage, Z. Francis, S. Guatelli, V. Ivanchenko, M. Karamitros, N. Lampe, S. B. Lee et al., Geant4-DNA example applications for track structure simulations in liquid water: A report from the Geant4-DNA project, Med. Phys. 45, e722 (2018).
  47. H. Nikjoo, D. Emfietzoglou, T. Liamsuwan, R. Taleei, D. Liljequist, and S. Uehara, Radiation track, DNA damage and response—A review, Rep. Prog. Phys. 79, 116601 (2016).
  48. W. Friedland, P. Jacob, P. Bernhardt, H. G. Paretzke, and M. Dingfelder, Simulation of DNA damage after proton irradiation, Radiat. Res. 159, 401 (2003).
  49. K. P. Chatzipapas, H. N. Tran, M. Dordevic, D. Sakata, S. Incerti, D. Visvikis, and J. Bert, Development of a novel computational technique to create DNA and cell geometrical models for Geant4-DNA, Phys. Med. 127, 104839 (2024).
  50. D. E. Smith, T. T. Perkins, and S. Chu, Dynamical scaling of DNA diffusion coefficients, Macromolecules 29, 1372 (1996).
  51. S. Berg, D. Kutra, T. Kroeger, C. N. Straehle, B. X. Kausler, C. Haubold, M. Schiegg, J. Ales, T. Beier, M. Rudy et al., Ilastik: Interactive machine learning for (bio)image analysis, Nat. Methods 16, 1226 (2019).
  52. K. Kucharska, M. Pilz, K. Bielec, T. Kalwarczyk, P. Kuźma, and R. Hołyst, Two intercalation mechanisms of oxazole yellow dimer (YOYO-1) into DNA, Molecules 26, 3748 (2021).
  53. P. Beaudier, S. A. Zein, K. Chatzipapas, H. Ngoc Tran, G. Devès, L. Plawinski, R. Liénard, D. Dupuy, P. Barberet, S. Incerti et al., Quantitative analysis of dose dependent DNA fragmentation in dry pBR322 plasmid using long read sequencing and monte carlo simulations, Sci. Rep. 14, 18650 (2024).
  54. J. F. Ziegler, M. D. Ziegler, and J. P. Biersack, SRIM–The stopping and range of ions in matter (2010), Nucl. Instrum. Methods Phys. Res. Sect. B 268, 1818 (2010).
  55. M. McAllister, N. Kazemigazestane, L. T. Henry, B. Gu, I. Fabrikant, G. A. Tribello, and J. Kohanoff, Solvation effects on dissociative electron attachment to thymine, J. Phys. Chem. B 123, 1537 (2019).
  56. M.-a. H. Du Penhoat, A. Souchaud, A. Rajpal, R. Vuilleumier, M.-P. Gaigeot, I. Tavernelli, K. Fujii, A. Yokoya, S. Díaz-Tendero, and M.-F. Politis, Ultrafast fragmentation of highly-excited doubly-ionized deoxyribose: Role of the liquid water environment, Phys. Chem. Chem. Phys. 26, 15693 (2024).
  57. K. P. Chatzipapas, N. H. Tran, M. Dordevic, S. Zivkovic, S. Zein, W.-G. Shin, D. Sakata, N. Lampe, J. M. Brown, A. Ristic-Fira et al., Simulation of DNA damage using Geant4-DNA: An overview of the “molecularDNA” example application, Precis. Radiat. Oncol. 7, 4 (2023).
  58. D. Sakata, O. Belov, M.-C. Bordage, D. Emfietzoglou, S. Guatelli, T. Inaniwa, V. Ivanchenko, M. Karamitros, I. Kyriakou, N. Lampe et al., Fully integrated Monte Carlo simulation for evaluating radiation induced DNA damage and subsequent repair using Geant4-DNA, Sci. Rep. 10, 20788 (2020).
