Persistence of small polarons into the superconducting doping range of Ba1−xKxBiO3

Muntaser Naamneh1, Eric C. O’Quinn2, Eugenio Paris3, Daniel McNally3, Yi Tseng3, Wojciech R. Pudełko3, Dariusz J. Gawryluk4, Jacob Shamblin2, Benjamin Cohen-Stead5,6 et al.

Ming Shi3,7, Milan Radovic3, Maik K. Lang2, Thorsten Schmitt3, Steven Johnston5,6,*, and Nicholas C. Plumb3,†

  • *Contact author: sjohn145@utk.edu
  • †Contact author: nicholas.plumb@psi.ch
PDF

Phys. Rev. Research 7, 043082 – Published 21 October, 2025

DOI: https://doi.org/10.1103/s3p1-cy1s

Abstract

Bipolaronic superconductivity is an exotic pairing mechanism proposed for materials like Ba1−xKxBiO3 (BKBO); however, conclusive experimental evidence for a (bi)polaron metallic state in this material remains elusive. Here, we combine resonant inelastic x-ray and neutron total scattering techniques with advanced modeling to study the local lattice distortions, electronic structure, and electron-phonon (e−ph) coupling in BKBO as a function of doping. Data for the parent compound (x=0) indicate that the electronic gap opens in predominantly oxygen-derived states strongly coupled to a long-range ordered breathing distortion of the oxygen sublattice. Upon doping, short-range breathing distortions and sizable e-ph coupling persist into the superconducting regime (x=0.4). Comparisons with exact diagonalization and determinant quantum Monte Carlo calculations further support this conclusion. Our results provide compelling evidence that BKBO’s metallic phase hosts a liquid of small (bi)polarons derived from local breathing distortions of the lattice, with implications for understanding the low-temperature superconducting instability.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (76)

  1. B. Keimer, S. A. Kivelson, M. R. Norman, S. Uchida, and J. Zaanen, From quantum matter to high-temperature superconductivity in copper oxides, Nature (London) 518, 179 (2015).
  2. G. R. Stewart, Superconductivity in iron compounds, Rev. Mod. Phys. 83, 1589 (2011).
  3. I. Plokhikh, C. Mielke, H. Nakamura, V. Petricek, Y. Qin, V. Sazgari, J. Küspert, I. Biało, S. Shin, O. Ivashko, J. N. Graham, M. v. Zimmermann, M. Medarde, A. Amato, R. Khasanov, H. Luetkens, M. H. Fischer, M. Z. Hasan, J.-X. Yin, and T. Neupert, Discovery of charge order above room-temperature in the prototypical kagome superconductor La(Ru1−xFex)3Si2, Commun. Phys. 7, 182 (2024).
  4. A. W. Sleight, Bismuthates: BaBiO3 and related superconducting phases, Physica C 514, 152 (2015).
  5. M. Kim, G. M. McNally, H.-H. Kim, M. Oudah, A. S. Gibbs, P. Manuel, R. J. Green, R. Sutarto, T. Takayama, A. Yaresko, U. Wedig, M. Isobe, R. K. Kremer, D. A. Bonn, B. Keimer, and H. Takagi, Superconductivity in (Ba,K)SbO3, Nat. Mater. 21, 627 (2022).
  6. E. Fradkin, S. A. Kivelson, and J. M. Tranquada, Colloquium: Theory of intertwined orders in high temperature superconductors, Rev. Mod. Phys. 87, 457 (2015).
  7. R. J. Cava, B. Batlogg, J. J. Krajewski, R. Farrow, L. W. Rupp, A. E. White, K. Short, W. F. Peck, and T. Kometani, Superconductivity near 30 K without copper: The Ba0.6K0.4BiO3 perovskite, Nature (London) 332, 814 (1988).
  8. Y. Nagata, A. Mishiro, T. Uchida, M. Ohtsuka, and H. Samata, Normal-state transport properties of Ba1−xKxBiO3 crystals, J. Phys. Chem. Solids 60, 1933 (1999).
  9. J. Ayres, M. Berben, M. Čulo, Y. T. Hsu, E. van Heumen, Y. Huang, J. Zaanen, T. Kondo, T. Takeuchi, J. R. Cooper, C. Putzke, S. Friedemann, A. Carrington, and N. E. Hussey, Incoherent transport across the strange-metal regime of overdoped cuprates, Nature (London) 595, 661 (2021).
  10. R. Kuentzler, C. Hornick, Y. Dossman, S. Wegner, R. El Farsi, and M. Drillon, Superconductivity of Pb, K and Rb-doped BaBiO3, Physica C 184, 316 (1991).
  11. S. Kondoh, M. Sera, Y. Ando, and M. Sato, Normal state properties and oxygen isotope effect of (Ba,K)BiO3, Physica C 157, 469 (1989).
  12. G.-m. Zhao, K. Conder, M. Angst, S. M. Kazakov, J. Karpinski, M. Maciejewski, C. Bougerol, J. S. Pshirkov, and E. V. Antipov, Large oxygen-isotope effect in Sr0.4K0.6BiO3: Evidence for phonon-mediated superconductivity, Phys. Rev. B 62, R11977 (2000).
  13. A. Snezhko and R. Prozorov, Temperature dependence of magnetic penetration depth in Bi1−xKxBiO3 superconductor, Physica C 403, 200 (2004).
  14. T. Shang, D. J. Gawryluk, M. Naamneh, Z. Salman, Z. Guguchia, M. Medarde, M. Shi, N. C. Plumb, and T. Shiroka, Strong- to weak-coupling superconductivity in high-Tc bismuthates: Revisiting the phase diagram via μSR, Phys. Rev. B 101, 014508 (2020).
  15. N. C. Plumb, D. J. Gawryluk, Y. Wang, Z. Ristić, J. Park, B. Q. Lv, Z. Wang, C. E. Matt, N. Xu, T. Shang, K. Conder, J. Mesot, S. Johnston, M. Shi, and M. Radović, Momentum-resolved electronic structure of the high-Tc superconductor parent compound BaBiO3, Phys. Rev. Lett. 117, 037002 (2016).
  16. C. H. P. Wen, H. C. Xu, Q. Yao, R. Peng, X. H. Niu, Q. Y. Chen, Z. T. Liu, D. W. Shen, Q. Song, X. Lou, Y. F. Fang, X. S. Liu, Y. H. Song, Y. J. Jiao, T. F. Duan, H. H. Wen, P. Dudin, G. Kotliar, Z. P. Yin, and D. L. Feng, Unveiling the superconducting mechanism of Ba0.51K0.49BiO3, Phys. Rev. Lett. 121, 117002 (2018).
  17. B. Cohen-Stead, K. Barros, R. Scalettar, and S. Johnston, A hybrid monte carlo study of bond-stretching electron–phonon interactions and charge order in BaBiO3, npj Comput. Mater. 9, 40 (2023).
  18. J. F. Federici, B. I. Greene, E. H. Hartford, and E. S. Hellman, Optical characterization of excited states in BaBiO3, Phys. Rev. B 42, 923 (1990).
  19. C. Franchini, G. Kresse, and R. Podloucky, Polaronic hole trapping in doped BaBiO3, Phys. Rev. Lett. 102, 256402 (2009).
  20. Z. P. Yin, A. Kutepov, and G. Kotliar, Correlation-enhanced electron-phonon coupling: Applications of GW and screened hybrid functional to bismuthates, chloronitrides, and other high-Tc superconductors, Phys. Rev. X 3, 021011 (2013).
  21. A. Khazraie, K. Foyevtsova, I. Elfimov, and G. A. Sawatzky, Bond versus charge disproportionation in the bismuth perovskites, Phys. Rev. B 98, 205104 (2018).
  22. A. Khazraie, K. Foyevtsova, I. Elfimov, and G. A. Sawatzky, Oxygen Holes and hybridization in the bismuthates, Phys. Rev. B 97, 075103 (2018).
  23. S. Li and S. Johnston, Quantum Monte Carlo study of lattice polarons in the two-dimensional three-orbital Su–Schrieffer–Heeger model, npj Quantum Mater. 5, 40 (2020).
  24. M. Jiang, G. A. Sawatzky, M. Berciu, and S. Johnston, Polaron and bipolaron tendencies in a semiclassical model for hole-doped bismuthates, Phys. Rev. B 103, 115129 (2021).
  25. Y. G. Pashkevich, V. P. Gnezdilov, A. V. Eremenko, P. Lemmens, G. Güntherodt, W. Reichardt, M. Braden, S. V. Shiryaev, S. N. Barilo, and A. G. Soldatov, Local distortions in Ba1−xKxBiO3 observed in low frequency phonon Raman scattering, Int. J. Mod. Phys. B 14, 3637 (2000).
  26. A. P. Menushenkov, I. A. Troyan, and M. I. Eremets, Resonant Raman scattering in superconducting Ba1−xKxBiO3, JEPT Lett. 77, 521 (2003).
  27. S. Sugai, S. Uchida, K. Kitazawa, S. Tanaka, and A. Katsui, Lattice vibrations in the strong electron-phonon-interaction system BaPb1−xBixO3 studied by Raman scattering, Phys. Rev. Lett. 55, 426 (1985).
  28. S. Tajima, S. Uchida, A. Masaki, H. Takagi, K. Kitazawa, S. Tanaka, and S. Sugai, Electronic states of BaPb1−xBixO3 in the semiconducting phase investigated by optical measurements, Phys. Rev. B 35, 696 (1987).
  29. S. M. Heald, D. DiMarzio, M. Croft, M. S. Hegde, S. Li, and M. Greenblatt, X-ray-absorption study of charge-density ordering in (Ba1−xKx)BiO3, Phys. Rev. B 40, 8828 (1989).
  30. A. P. Menushenkov and K. V. Klementev, Extended x-ray absorption fine-structure indication of a double-well potential for oxygen vibration in Ba1−xKxBiO3, J. Phys.: Condens. Matter 12, 3767 (2000).
  31. B. Kim, Y. Kim, H.-T. Kim, K.-Y. Kang, and J. Lee, EXAFS observation of two distinct Bi–O distances below Tc for a Ba0.6K0.4BiO3 single crystal, Physica C 392–396, 286 (2003).
  32. M. Braden, W. Reichardt, S. Shiryaev, and S. Barilo, Giant phonon anomalies in the bond-stretching modes in doped BaBiO3: Comparison to cuprates manganites and nickelates, Physica C 378-381, 89 (2002).
  33. K. F. McCarty, H. B. Radousky, D. G. Hinks, Y. Zheng, A. W. Mitchell, T. J. Folkerts, and R. N. Shelton, Electron-phonon coupling in superconducting Ba0.6K0.4BiO3: A Raman scattering study, Phys. Rev. B 40, 2662 (1989).
  34. S. Salem-Sugui, E. E. Alp, S. M. Mini, M. Ramanathan, J. C. Campuzano, G. Jennings, M. Faiz, S. Pei, B. Dabrowski, Y. Zheng, D. R. Richards, and D. G. Hinks, Determination of the local structure in Ba1−xKxBiO3 by x-ray-absorption spectroscopy, Phys. Rev. B 43, 5511 (1991).
  35. S. Tajima, M. Yoshida, N. Koshizuka, H. Sato, and S. Uchida, Raman-scattering study of the metal-insulator transition in Ba1−xKxBiO3, Phys. Rev. B 46, 1232 (1992).
  36. S. Griffitt, M. Spaić, J. Joe, Z. W. Anderson, D. Zhai, M. J. Krogstad, R. Osborn, D. Pelc, and M. Greven, Local inversion-symmetry breaking in a bismuthate high-Tc superconductor, Nat. Commun. 14, 845 (2023).
  37. L. J. P. Ament, M. van Veenendaal, and J. van den Brink, Determining the electron-phonon coupling strength from resonant inelastic x-ray scattering at transition metal L-edges, Europhys. Lett. 95, 27008 (2011).
  38. W. S. Lee, S. Johnston, B. Moritz, J. Lee, M. Yi, K. J. Zhou, T. Schmitt, L. Patthey, V. Strocov, K. Kudo, Y. Koike, J. van den Brink, T. P. Devereaux, and Z. X. Shen, Role of lattice coupling in establishing electronic and magnetic properties in quasi-one-dimensional cuprates, Phys. Rev. Lett. 110, 265502 (2013).
  39. T. P. Devereaux, A. M. Shvaika, K. Wu, K. Wohlfeld, C. J. Jia, Y. Wang, B. Moritz, L. Chaix, W.-S. Lee, Z.-X. Shen, G. Ghiringhelli, and L. Braicovich, Directly characterizing the relative strength and momentum dependence of electron-phonon coupling using resonant inelastic x-ray scattering, Phys. Rev. X 6, 041019 (2016).
  40. K. Bieniasz, S. Johnston, and M. Berciu, Beyond the single-site approximation modeling of electron-phonon coupling effects on resonant inelastic x-ray scattering spectra, SciPost Phys. 11, 062 (2021).
  41. J. Thomas, D. Banerjee, A. Nocera, and S. Johnston, Theory of electron-phonon interactions in extended correlated systems probed by resonant inelastic x-ray scattering, Phys. Rev. X 15, 021030 (2025).
  42. See Supplemental Material at http://link.aps.org/supplemental/10.1103/s3p1-cy1s for additional details about Rietveld refinement of the neutron diffraction data, analysis of the neutron PDFs, DQMC simulations, RIXS analysis and high-temperature measurements, and characterizations of the thin film samples, which also contains Refs. [72, 73, 74].
  43. K. Robinson, G. V. Gibbs, and P. H. Ribbe, Quadratic elongation: A quantitative measure of distortion in coordination polyhedra, Science 172, 567 (1971).
  44. L. J. P. Ament, M. van Veenendaal, T. P. Devereaux, J. P. Hill, and J. van den Brink, Resonant inelastic x-ray scattering studies of elementary excitations, Rev. Mod. Phys. 83, 705 (2011).
  45. K. Gilmore, Quantifying vibronic coupling with resonant inelastic x-ray scattering, Phys. Chem. Chem. Phys. 25, 217 (2022).
  46. K. Foyevtsova, A. Khazraie, I. Elfimov, and G. A. Sawatzky, Hybridization effects and bond disproportionation in the bismuth perovskites, Phys. Rev. B 91, 121114 (2015).
  47. A. Damascelli, Probing the electronic structure of complex systems by ARPES, Phys. Scr. 2004, 61 (2004).
  48. M. E. Kozlov, X. Ji, H. Minami, and H. Uwe, Change of IR spectra of Ba1−xKxBiO3 crystals at the low-temperature phase transition, Phys. Rev. B 56, 12211 (1997).
  49. J. Ahmad and H. Uwe, Small-polaron excitations in Ba1−xKxBiO3 studied by optical reflectivity measurements, Phys. Rev. B 72, 125103 (2005).
  50. H. Uwe and K. Tachibana, Indirect excitons in three-dimensional charge-density-wave system of BaBiO3, in Advances in Superconductivity VII, edited by K. Yamafuji and T. Morishita (Springer Japan, Tokyo, 1995), pp. 165–168.
  51. A. Kotani and Y. Toyozawa, Theoretical aspects of inner-level spectroscopy, in Synchrotron Radiation: Techniques and Applications, edited by C. Kunz (Springer, Berlin, 1979), pp. 169–229.
  52. A. Geondzhian and K. Gilmore, Generalization of the franck-condon model for phonon excitations by resonant inelastic x-ray scattering, Phys. Rev. B 101, 214307 (2020).
  53. A. Geondzhian and K. Gilmore, Demonstration of resonant inelastic x-ray scattering as a probe of exciton-phonon coupling, Phys. Rev. B 98, 214305 (2018).
  54. H. Minami, T. Uzumaki, and H. Uwe, Characterization of Ba1−xKxBiO3−y synthesized by an electrochemical method with the influences of heat treatment, in Advances in Superconductivity VIII, edited by H. Hayakawa and Y. Enomoto (Springer Japan, Tokyo, 1996), pp. 429–432.
  55. H. Park, A. J. Millis, and C. A. Marianetti, Site-selective mott transition in rare-earth-element nickelates, Phys. Rev. Lett. 109, 156402 (2012).
  56. S. Johnston, A. Mukherjee, I. Elfimov, M. Berciu, and G. A. Sawatzky, Charge disproportionation without charge transfer in the rare-earth-element nickelates as a possible mechanism for the metal-insulator transition, Phys. Rev. Lett. 112, 106404 (2014).
  57. V. Bisogni, S. Catalano, R. J. Green, M. Gibert, R. Scherwitzl, Y. Huang, V. N. Strocov, P. Zubko, S. Balandeh, J.-M. Triscone, G. Sawatzky, and T. Schmitt, Ground-state oxygen holes and the metal–insulator transition in the negative charge-transfer rare-earth nickelates, Nat. Commun. 7, 13017 (2016).
  58. G. M. Dalpian, Q. Liu, J. Varignon, M. Bibes, and A. Zunger, Bond disproportionation, charge self-regulation, and ligand holes in s–p and in d-electron ABX3 perovskites by density functional theory, Phys. Rev. B 98, 075135 (2018).
  59. M. R. Benam, K. Foyevtsova, A. Khazraie, I. Elfimov, and G. A. Sawatzky, Bond versus charge disproportionation and nature of the holes in s–pABX3 perovskites, Phys. Rev. B 104, 195141 (2021).
  60. B. Li, D. Louca, S. Yano, L. G. Marshall, J. Zhou, and J. B. Goodenough, Insulating pockets in metallic LaNiO3, Adv. Electron. Mater. 2, 1500261 (2016).
  61. J. Shamblin, M. Heres, H. Zhou, J. Sangoro, M. Lang, J. Neuefeind, J. A. Alonso, and S. Johnston, Experimental evidence for bipolaron condensation as a mechanism for the metal-insulator transition in rare-earth nickelates, Nat. Commun. 9, 86 (2018).
  62. M. Tyunina, M. Savinov, O. Pacherova, and A. Dejneka, Small-polaron transport in perovskite nickelates, Sci. Rep. 13, 12493 (2023).
  63. J. Neuefeind, M. Feygenson, J. Carruth, R. Hoffmann, and K. K. Chipley, The nanoscale ordered materials diffractometer NOMAD at the spallation neutron source SNS, Nucl. Instrum. Methods Phys. Res., Sect. B 287, 68 (2012).
  64. B. H. Toby and R. B. Von Dreele, GSAS-II: The genesis of a modern open-source all purpose crystallography software package, J. Appl. Crystallogr. 46, 544 (2013).
  65. C. L. Farrow, P. Juhas, J. W. Liu, D. Bryndin, E. S. Božin, J. Bloch, T. Proffen, and S. J. L. Billinge, PDFfit2 and PDFgui: Computer programs for studying nanostructure in crystals, J. Phys.: Condens. Matter 19, 335219 (2007).
  66. M. Naamneh, M. Yao, J. Jandke, J. Ma, Z. Ristić, J. Teyssier, A. Stucky, D. van der Marel, D. J. Gawryluk, T. Shang, M. Medarde, E. Pomjakushina, S. Li, T. Berlijn, S. Johnston, M. Müller, J. Mesot, M. Shi, M. Radović, and N. C. Plumb, Cooling a polaronic liquid: Phase mixture and pseudogap-like spectra in superconducting Ba1−xKxBiO3, arXiv:1808.06135.
  67. V. N. Strocov, T. Schmitt, U. Flechsig, T. Schmidt, A. Imhof, Q. Chen, J. Raabe, R. Betemps, D. Zimoch, J. Krempasky, X. Wang, M. Grioni, A. Piazzalunga, and L. Patthey, High-resolution soft x-ray beamline ADRESS at the Swiss Light Source for resonant inelastic x-ray scattering and angle-resolved photoelectron spectroscopies, J. Synchrotron Radiat. 17, 631 (2010).
  68. V. Meregalli and S. Y. Savrasov, Electron-phonon coupling and properties of doped BaBiO3, Phys. Rev. B 57, 14453 (1998).
  69. B. Cohen-Stead, S. M. Costa, J. Neuhaus, A. T. Ly, Y. Zhang, R. Scalettar, K. Barros, and S. Johnston, SmoQyDQMC.jl: A flexible implementation of determinant quantum monte carlo for hubbard and electron-phonon interactions, SciPost Phys. Codebases 29 (2024).
  70. B. Cohen-Stead, S. M. Costa, J. Neuhaus, A. T. Ly, Y. Zhang, R. Scalettar, K. Barros, and S. Johnston, Codebase release r0.3 for SmoQyDQMC.jl, SciPost Phys. Codebases 29 (2024).
  71. C. Miles, B. Cohen-Stead, O. Bradley, S. Johnston, R. Scalettar, and K. Barros, Dynamical tuning of the chemical potential to achieve a target particle number in grand canonical monte carlo simulations, Phys. Rev. E 105, 045311 (2022).
  72. I. M. Gussev, E. C. O’Quinn, M. Tucker, R. C. Ewing, C. Overstreet, J. Neuefeind, M. Everett, Q. Zhang, D. Sprouster, D. Olds, G. Baldinozzi, and M. Lang, Systematic study of short- and long-range correlations in RE3TaO7 weberite-type compounds by neutron total scattering and x-ray diffraction, J. Mater. Chem. A 11, 8886 (2023).
  73. J.-F. Bérar and P. Lelann, E.S.D.’s and estimated probable error obtained in rietveld refinements with local correlations, J. Appl. Crystallogr. 24, 1 (1991).
  74. S. Pei, J. D. Jorgensen, B. Dabrowski, D. G. Hinks, D. R. Richards, A. W. Mitchell, J. M. Newsam, S. K. Sinha, D. Vaknin, and A. J. Jacobson, Structural phase diagram of the Ba1−xKxBiO3 system, Phys. Rev. B 41, 4126 (1990).
  75. Code available at https://github.com/SmoQySuite/SmoQyDQMC.jl.
  76. Data available at https://doi.org/10.5281/zenodo.17280978.
