One-particle density matrix framework for mode-shell correspondence: Characterizing topology in amorphous higher-order topological insulators

Miguel F. Martínez1, Lucien Jezequel1, Jens H. Bardarson1, Thomas Klein Kvorning1, and Julia D. Hannukainen2

PDF

Phys. Rev. Research 8, 023320 – Published 22 June, 2026

DOI: https://doi.org/10.1103/rt48-gpfm

Abstract

We present a framework for characterizing higher-order topological phases directly from the one-particle density matrix, without any reference to an underlying Hamiltonian. Our approach extends the mode-shell correspondence, originally formulated for single-particle Hamiltonians, to Gaussian states subject to chiral constraints. In this correspondence, the mode index counts topological boundary modes, while the shell index quantifies the bulk topology in a region surrounding the modes, providing a bulk-boundary diagnostic. In one-dimensional topological insulators, the shell index reduces to the local chiral marker, recovering the winding number in the translation-invariant limit. We apply the mode-shell correspondence to a C4-symmetric higher-order topological insulator with a chiral constraint and show that a fractional shell index implies that the higher-order phase is intrinsic. The one-particle density matrix is formulated in real space, so the mode-shell correspondence also applies to models without translation invariance. By introducing structural disorder into the C4-symmetric higher-order insulator, we show that the mode-shell correspondence remains a meaningful diagnostic in amorphous structures. The mode-shell correspondence generalizes to interacting states with a gapped bulk spectrum in the one-particle density matrix, providing a practical and diverse route to characterize higher-order topology from the quantum state itself.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (97)

  1. A. P. Schnyder, S. Ryu, A. Furusaki, and A. W. W. Ludwig, Classification of topological insulators and superconductors in three spatial dimensions, Phys. Rev. B 78, 195125 (2008).
  2. A. Kitaev, Periodic table for topological insulators and superconductors, AIP Conf. Proc. 1134, 22 (2009).
  3. S. Ryu, A. P. Schnyder, A. Furusaki, and A. W. W. Ludwig, Topological insulators and superconductors: Tenfold way and dimensional hierarchy, New J. Phys. 12, 065010 (2010).
  4. A. W. W. Ludwig, Topological phases: Classification of topological insulators and superconductors of non-interacting fermions, and beyond, Phys. Scr. T168, 014001 (2016).
  5. E. Cartan, Sur une classe remarquable d'espaces de Riemann, Bul. Soc. Math. France 54, 214 (1926).
  6. M. R. Zirnbauer, Riemannian symmetric superspaces and their origin in random matrix theory, J. Math. Phys. 37, 4986 (1996).
  7. A. Altland and M. R. Zirnbauer, Nonstandard symmetry classes in mesoscopic normal-superconducting hybrid structures, Phys. Rev. B 55, 1142 (1997).
  8. Y. Ando and L. Fu, Topological crystalline insulators and topological superconductors: From concepts to materials, Annu. Rev. Condens. Matter Phys. 6, 361 (2015).
  9. T. Neupert and F. Schindler, Topological crystalline insulators, in Topological Matter, edited by D. Bercioux, J. Cayssol, M. G. Vergniory, and M. R. Calvo (Springer International Publishing, Cham, Switzerland, 2018), pp. 31–61.
  10. W. A. Benalcazar, B. A. Bernevig, and T. L. Hughes, Quantized electric multipole insulators, Science 357, 61 (2017).
  11. J. Langbehn, Y. Peng, L. Trifunovic, F. von Oppen, and P. W. Brouwer, Reflection-symmetric second-order topological insulators and superconductors, Phys. Rev. Lett. 119, 246401 (2017).
  12. M. Geier, L. Trifunovic, M. Hoskam, and P. W. Brouwer, Second-order topological insulators and superconductors with an order-two crystalline symmetry, Phys. Rev. B 97, 205135 (2018).
  13. F. Schindler, A. M. Cook, M. G. Vergniory, Z. Wang, S. S. P. Parkin, B. A. Bernevig, and T. Neupert, Higher-order topological insulators, Sci. Adv. 4, eaat0346 (2018).
  14. L. Trifunovic and P. W. Brouwer, Higher-order bulk-boundary correspondence for topological crystalline phases, Phys. Rev. X 9, 011012 (2019).
  15. L. Trifunovic and P. W. Brouwer, Higher-order topological band structures, Phys. Status Solidi (B) 258, 2000090 (2021).
  16. A. Y. Chaou, P. W. Brouwer, and N. Sedlmayr, Hinge states of second-order topological insulators as a Mach-Zehnder interferometer, Phys. Rev. B 107, 035430 (2023).
  17. B. Xie, H.-X. Wang, X. Zhang, P. Zhan, J.-H. Jiang, M. Lu, and Y. Chen, Higher-order band topology, Nat. Rev. Phys. 3, 520 (2021).
  18. D. Varjas, A. Lau, K. Pöyhönen, A. R. Akhmerov, D. I. Pikulin, and I. C. Fulga, Topological phases without crystalline counterparts, Phys. Rev. Lett. 123, 196401 (2019).
  19. A. Agarwala, V. Juričić, and B. Roy, Higher-order topological insulators in amorphous solids, Phys. Rev. Res. 2, 012067(R) (2020).
  20. Y.-L. Tao, J.-H. Wang, and Y. Xu, Average symmetry protected higher-order topological amorphous insulators, SciPost Phys. 15, 193 (2023).
  21. T. Peng, C.-B. Hua, R. Chen, Z.-R. Liu, H.-M. Huang, and B. Zhou, Density-driven higher-order topological phase transitions in amorphous solids, Phys. Rev. B 106, 125310 (2022).
  22. A. Y. Chaou, M. Moreno-Gonzalez, A. Altland, and P. W. Brouwer, Disordered topological crystalline phases, Phys. Rev. B 112, 035167 (2025).
  23. E. Prodan, Non-commutative tools for topological insulators, New J. Phys. 12, 065003 (2010).
  24. T. A. Loring and M. B. Hastings, Disordered topological insulators via C*-algebras, Europhys. Lett. 92, 67004 (2010).
  25. E. Prodan, Disordered topological insulators: A non-commutative geometry perspective, J. Phys. A 44, 113001 (2011).
  26. R. Bianco and R. Resta, Mapping topological order in coordinate space, Phys. Rev. B 84, 241106(R) (2011).
  27. T. A. Loring, K-theory and pseudospectra for topological insulators, Ann. Phys. (NY) 356, 383 (2015).
  28. H. Huang and F. Liu, Theory of spin Bott index for quantum spin Hall states in nonperiodic systems, Phys. Rev. B 98, 125130 (2018).
  29. B. Irsigler, J.-H. Zheng, and W. Hofstetter, Microscopic characteristics and tomography scheme of the local Chern marker, Phys. Rev. A 100, 023610 (2019).
  30. T. A. Loring, A guide to the bott index and localizer index, arXiv:1907.11791.
  31. I. Mondragon-Shem and T. L. Hughes, Robust topological invariants of topological crystalline phases in the presence of impurities, Phys. Rev. B 110, 035146 (2024).
  32. L. Jezequel, C. Tauber, and P. Delplace, Estimating bulk and edge topological indices in finite open chiral chains, J. Math. Phys. 63, 121901 (2022).
  33. J. D. Hannukainen, M. F. Martínez, J. H. Bardarson, and T. K. Kvorning, Local topological markers in odd spatial dimensions and their application to amorphous topological matter, Phys. Rev. Lett. 129, 277601 (2022).
  34. J. D. Hannukainen, M. F. Martínez, J. H. Bardarson, and T. K. Kvorning, Interacting local topological markers: A one-particle density matrix approach for characterizing the topology of interacting and disordered states, Phys. Rev. Res. 6, L032045 (2024).
  35. A. Marrazzo and R. Resta, Locality of the anomalous Hall conductivity, Phys. Rev. B 95, 121114(R) (2017).
  36. N. Baù and A. Marrazzo, Local Chern marker for periodic systems, Phys. Rev. B 109, 014206 (2024).
  37. M. D. Caio, G. Möller, N. R. Cooper, and M. J. Bhaseen, Topological marker currents in Chern insulators, Nat. Phys. 15, 257 (2019).
  38. P. d’Ornellas, R. Barnett, and D. K. K. Lee, Quantized bulk conductivity as a local Chern marker, Phys. Rev. B 106, 155124 (2022).
  39. A. Kitaev, Anyons in an exactly solved model and beyond, Ann. Phys. 321, 2 (2006).
  40. T. A. Loring and H. Schulz-Baldes, Spectral flow argument localizing an odd index pairing, Can. Math. Bull. 62, 373 (2019).
  41. T. A. Loring and H. Schulz-Baldes, The spectral localizer for even index pairings, J. Noncommut. Geom. 14, 1 (2020).
  42. H. Schulz-Baldes and T. Stoiber, The spectral localizer for semifinite spectral triples, Proc. Am. Math. Soc. 149, 121 (2021).
  43. H. Schulz-Baldes and T. Stoiber, Invariants of disordered semimetals via the spectral localizer, Europhys. Lett. 136, 27001 (2021).
  44. H. Schulz-Baldes and T. Stoiber, Spectral localization for semimetals and Callias operators, J. Math. Phys. 64, 081901 (2023).
  45. S. Franca and A. G. Grushin, Topological zero-modes of the spectral localizer of trivial metals, Phys. Rev. B 109, 195107 (2024).
  46. T. Stoiber, A spectral localizer approach to strong topological invariants in the mobility gap regime, Commun. Math. Phys. 406, 184 (2025).
  47. N. Doll and H. Schulz-Baldes, Skew localizer and Z2-flows for real index pairings, Adv. Math. 392, 108038 (2021).
  48. A. Cerjan, L. Koekenbier, and H. Schulz-Baldes, Spectral localizer for line-gapped non-Hermitian systems, J. Math. Phys. 64, 082102 (2023).
  49. N. Doll, T. Loring, and H. Schulz-Baldes, Topological indices for periodic gapped Hamiltonians and fuzzy tori, J. Math. Phys. Anal. Geom. 28, 13 (2025).
  50. H. Schulz-Baldes, Topological indices in condensed matter, in Encyclopedia of Mathematical Physics, 2nd ed., edited by R. Szabo and M. Bojowald (Academic Press, Oxford, 2025), pp. 17–26.
  51. L. Jezequel, J. H. Bardarson, and A. G. Grushin, Explicit equivalence between the spectral localizer and local Chern and winding markers, SciPost Phys. 20, 118 (2026).
  52. O. Penrose and L. Onsager, Bose-Einstein condensation and liquid helium, Phys. Rev. 104, 576 (1956).
  53. E. Koch and S. Goedecker, Locality properties and Wannier functions for interacting systems, Solid State Commun. 119, 105 (2001).
  54. S. Bera, H. Schomerus, F. Heidrich-Meisner, and J. H. Bardarson, Many-body localization characterized from a one-particle perspective, Phys. Rev. Lett. 115, 046603 (2015).
  55. S. Bera, T. Martynec, H. Schomerus, F. Heidrich-Meisner, and J. H. Bardarson, One-particle density matrix characterization of many-body localization, Ann. Phys. (NY) 529, 1600356 (2017).
  56. T. L. M. Lezama, S. Bera, H. Schomerus, F. Heidrich-Meisner, and J. H. Bardarson, One-particle density matrix occupation spectrum of many-body localized states after a global quench, Phys. Rev. B 96, 060202(R) (2017).
  57. G. Kells, N. Moran, and D. Meidan, Localization enhanced and degraded topological order in interacting p-wave wires, Phys. Rev. B 97, 085425 (2018).
  58. A. Agarwala and V. B. Shenoy, Topological insulators in amorphous systems, Phys. Rev. Lett. 118, 236402 (2017).
  59. S. Mansha and Y. D. Chong, Robust edge states in amorphous gyromagnetic photonic lattices, Phys. Rev. B 96, 121405(R) (2017).
  60. M. Xiao and S. Fan, Photonic Chern insulator through homogenization of an array of particles, Phys. Rev. B 96, 100202(R) (2017).
  61. N. P. Mitchell, L. M. Nash, D. Hexner, A. M. Turner, and W. T. M. Irvine, Amorphous topological insulators constructed from random point sets, Nat. Phys. 14, 380 (2018).
  62. C. Bourne and E. Prodan, Non-commutative Chern numbers for generic aperiodic discrete systems, J. Phys. A: Math. Theor. 51, 235202 (2018).
  63. K. Pöyhönen, I. Sahlberg, A. Westström, and T. Ojanen, Amorphous topological superconductivity in a Shiba glass, Nat. Commun. 9, 2103 (2018).
  64. E. L. Minarelli, K. Pöyhönen, G. A. R. van Dalum, T. Ojanen, and L. Fritz, Engineering of Chern insulators and circuits of topological edge states, Phys. Rev. B 99, 165413 (2019).
  65. G.-W. Chern, Topological insulator in an atomic liquid, Europhys. Lett. 126, 37002 (2019).
  66. T. Mano and T. Ohtsuki, Application of convolutional neural network to quantum percolation in topological insulators, J. Phys. Soc. Jpn. 88, 123704 (2019).
  67. M. Costa, G. R. Schleder, M. Buongiorno Nardelli, C. Lewenkopf, and A. Fazzio, Toward realistic amorphous topological insulators, Nano Lett. 19, 8941 (2019).
  68. Q. Marsal, D. Varjas, and A. G. Grushin, Topological Weaire–Thorpe models of amorphous matter, Proc. Natl. Acad. Sci. USA 117, 30260 (2020).
  69. I. Sahlberg, A. Westström, K. Pöyhönen, and T. Ojanen, Topological phase transitions in glassy quantum matter, Phys. Rev. Res. 2, 013053 (2020).
  70. M. N. Ivaki, I. Sahlberg, and T. Ojanen, Criticality in amorphous topological matter: Beyond the universal scaling paradigm, Phys. Rev. Res. 2, 043301 (2020).
  71. J.-H. Wang, Y.-B. Yang, N. Dai, and Y. Xu, Structural-disorder-induced second-order topological insulators in three dimensions, Phys. Rev. Lett. 126, 206404 (2021).
  72. B. Focassio, G. R. Schleder, M. Costa, A. Fazzio, and C. Lewenkopf, Structural and electronic properties of realistic two-dimensional amorphous topological insulators, 2D Mater. 8, 025032 (2021).
  73. N. P. Mitchell, A. M. Turner, and W. T. M. Irvine, Real-space origin of topological band gaps, localization, and reentrant phase transitions in gyroscopic metamaterials, Phys. Rev. E 104, 025007 (2021).
  74. H. Spring, A. Akhmerov, and D. Varjas, Amorphous topological phases protected by continuous rotation symmetry, SciPost Phys. 11, 022 (2021).
  75. C. Wang, T. Cheng, Z. Liu, F. Liu, and H. Huang, Structural amorphization-induced topological order, Phys. Rev. Lett. 128, 056401 (2022).
  76. A. J. Uría-Álvarez, D. Molpeceres-Mingo, and J. J. Palacios, Deep learning for disordered topological insulators through their entanglement spectrum, Phys. Rev. B 105, 155128 (2022).
  77. D. Muñoz-Segovia, P. Corbae, D. Varjas, F. Hellman, S. M. Griffin, and A. G. Grushin, Structural spillage: An efficient method to identify noncrystalline topological materials, Phys. Rev. Res. 5, L042011 (2023).
  78. G. Cassella, P. d’Ornellas, T. Hodson, W. M. H. Natori, and J. Knolle, An exact chiral amorphous spin liquid, Nat. Commun. 14, 6663 (2023).
  79. A. G. Grushin and C. Repellin, Amorphous and polycrystalline routes toward a chiral spin liquid, Phys. Rev. Lett. 130, 186702 (2023).
  80. P. Corbae, J. D. Hannukainen, Q. Marsal, D. Muñoz-Segovia, and A. G. Grushin, Amorphous topological matter: Theory and experiment, Europhys. Lett. 142, 16001 (2023).
  81. S. Manna, S. K. Das, and B. Roy, Noncrystalline topological superconductors, Phys. Rev. B 109, 174512 (2024).
  82. Q. Marsal, D. Varjas, and A. G. Grushin, Obstructed insulators and flat bands in topological phase-change materials, Phys. Rev. B 107, 045119 (2023).
  83. A. J. Uría-Álvarez and J. J. Palacios, Amorphization-induced topological and insulator-metal transitions in bidimensional BixSb1−x alloys, Phys. Rev. Res. 7, 043263 (2025).
  84. A. Alexandradinata, X. Dai, and B. A. Bernevig, Wilson-loop characterization of inversion-symmetric topological insulators, Phys. Rev. B 89, 155114 (2014).
  85. W. A. Benalcazar, B. A. Bernevig, and T. L. Hughes, Electric multipole moments, topological multipole moment pumping, and chiral hinge states in crystalline insulators, Phys. Rev. B 96, 245115 (2017).
  86. R. J. Zijderveld, I. A. Day, and A. R. Akhmerov, Scattering theory of higher order topological phases, SciPost Phys. 19, 058 (2025).
  87. A. Cerjan, T. A. Loring, and H. Schulz-Baldes, Local markers for crystalline topology, Phys. Rev. Lett. 132, 073803 (2024).
  88. L. Jezequel and P. Delplace, Mode-shell correspondence, a unifying phase space theory in topological physics - Part I: Chiral number of zero-modes, SciPost Phys. 17, 060 (2024).
  89. L. Jezequel and P. Delplace, Mode-shell correspondence, a unifying phase space theory in topological physics - Part II: Higher-dimensional spectral invariants, SciPost Phys. 18, 193 (2025).
  90. C. L. Kane and T. C. Lubensky, Topological boundary modes in isostatic lattices, Nat. Phys. 10, 39 (2014).
  91. M. Guzmán, D. Bartolo, and D. Carpentier, Geometry and topology tango in ordered and amorphous chiral matter, SciPost Phys. 12, 038 (2022).
  92. H. Yang, L. Song, Y. Cao, and P. Yan, Experimental realization of two-dimensional weak topological insulators, Nano Lett. 22, 3125 (2022).
  93. Z. Ringel, Y. E. Kraus, and A. Stern, Strong side of weak topological insulators, Phys. Rev. B 86, 045102 (2012).
  94. K. Kobayashi, T. Ohtsuki, and K.-I. Imura, Disordered weak and strong topological insulators, Phys. Rev. Lett. 110, 236803 (2013).
  95. I. C. Fulga, D. I. Pikulin, and T. A. Loring, Aperiodic weak topological superconductors, Phys. Rev. Lett. 116, 257002 (2016).
  96. B. Yan, L. Müchler, and C. Felser, Prediction of weak topological insulators in layered semiconductors, Phys. Rev. Lett. 109, 116406 (2012).
  97. M. F. Martínez, L. Jezequel, J. H. Bardarson, T. K. Kvorning, and J. D. Hannukainen, A one-particle density matrix framework for mode-shell correspondence: Characterizing topology in amorphous higher-order topological insulators, Zenodo, 2025, doi:10.5281/zenodo.17175143.
