Observation of excitonic Floquet states in a one-dimensional organic Mott insulator using mid-infrared pump near-infrared probe reflection spectroscopy

R. Ikeda1,*, D. Sakai1, T. Yamakawa1, T. Miyamoto1,2, H. Kishida3, T. Hasegawa4, and H. Okamoto1,†

  • *Contact author: r.ikeda@edu.k.u-tokyo.ac.jp
  • †Contact author: okamotoh@k.u-tokyo.ac.jp
PDF

Phys. Rev. Research 7, 033230 – Published 9 September, 2025

DOI: https://doi.org/10.1103/rl4c-w66n

Abstract

When an electric field of light with a frequency of Ω is applied to a solid, Floquet states, consisting of sidebands with an interval of ℏΩ around an electronic state, are expected to be formed. However, only a few studies have experimentally detected such sidebands. Here, we apply mid-infrared pump near-infrared reflection probe spectroscopy to a one-dimensional Mott insulator, bis(ethylenedithio)tetrathiafulvalene-difluorotetracyanoquinodimethane (ET−F2TCNQ), to detect the transient change in reflectivity R, ΔR/R, due to the formation of excitonic Floquet states. Analyses, considering both odd- and even-parity excitons, demonstrate that the ΔR/R spectrum reflects the formation of the first-order Floquet sidebands of excitons, and its spectral shape strongly depends on the widths of excitonic states. The experimental and analytical approach reported here is effective in demonstrating excitonic Floquet states in various solids.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (42)

  1. J. H. Shirley, Solution of the Schrödinger equation with a Hamiltonian periodic in time, Phys. Rev. 138, B979 (1965).
  2. H. Sambe, Steady states and quasienergies of a quantum-mechanical system in an oscillating field, Phys. Rev. A 7, 2203 (1973).
  3. D. H. Dunlap and V. M. Kenkre, Dynamic localization of a charged particle moving under the influence of an electric field, Phys. Rev. B 34, 3625 (1986).
  4. S. I. Chu and D. A. Telnovc, Beyond the Floquet theorem: Generalized Floquet formalisms and quasienergy methods for atomic and molecular multiphoton processes in intense laser fields, Phys. Rep. 390, 1 (2004).
  5. A. Eckardt, Colloquium: Atomic quantum gases in periodically driven optical lattices, Rev. Mod. Phys. 89, 011004 (2017).
  6. D. N. Basov, R. D. Averitt, and D. Hsieh, Towards properties on demand in quantum materials, Nat. Mater. 16, 1077 (2017).
  7. T. Oka and S. Kitamura, Floquet engineering of quantum materials, Annu. Rev. Condens. Matter Phys. 10, 387 (2019).
  8. U. D. Giovannini and H. Hübener, Floquet analysis of excitations in materials, J. Phys. Mater. 3, 012001 (2019).
  9. M. S. Rudner and M. H. Lindner, Band structure engineering and non-equilibrium dynamics in Floquet topological insulators, Nat. Rev. Phys. 2, 229 (2020).
  10. M. R. Vega, M. Vogl, and G. A. Fiete, Low-frequency and Moiré–Floquet engineering: A review, Ann. Phys. 435, 168434 (2021).
  11. J. Bloch, A. Cavalleri, V. Galitski, M. Hafezi, and A. Rubio, Strongly correlated electron–photon systems, Nature (London) 606, 41 (2022).
  12. N. Tsuji, T. Oka, and H. Aoki, Correlated electron systems periodically driven out of equilibrium: Floquet + DMFT formalism, Phys. Rev. B 78, 235124 (2008).
  13. H. Aoki, N. Tsuji, M. Eckstein, M. Kollar, T. Oka, and P. Werner, Nonequilibrium dynamical mean-field theory and its applications, Rev. Mod. Phys. 86, 779 (2014).
  14. H. Hübener, U. De Giovannini, and A. Rubio, Phonon driven Floquet matter, Nano Lett. 18, 1535 (2018).
  15. Y. H. Wang, H. Steinberg, P. Jarillo-Herrero, and N. Gedik, Observation of Floquet-Bloch states on the surface of a topological insulator, Science 342, 453 (2013).
  16. F. Mahmood, C-K. Chan, Z. Alpichshev, D. Gardner, Y. Lee, P. A. Lee, and N. Gedik, Selective scattering between Floquet–Bloch and Volkov states in a topological insulator, Nat. Phys. 12, 306 (2016).
  17. S. Aeschlimann, S. A. Sato, R. Krause, M. Chávez-Cervantes, U. D. Giovannini, H. Hübener, S. Forti, C. Coletti, K. Hanff, K. Rossnagel, A. Rubio, and Is. Gierz, Survival of Floquet–Bloch states in the presence of scattering, Nano Lett. 21, 5028 (2021).
  18. S. Zhou, C. Bao, B. Fan, H. Zhou, Q. Gao, H. Zhong, T. Lin, H. Liu, P. Yu, P. Tang, S. Meng, W. Duan, and S. Zhou, Pseudospin-selective Floquet band engineering in black phosphorus, Nature (London) 614, 75 (2023).
  19. S. Ito, M. Schüler, M. Meierhofer, S. Schlauderer, J. Freudenstein, J. Reimann, D. Afanasiev, K. A. Kokh, O. E. Tereshchenko, J. Güdde, M. A. Sentef, U. Höfer, and R. Huber, Build-up and dephasing of Floquet–Bloch bands on subcycle timescales, Nature (London) 616, 696 (2023).
  20. T. Yamakawa, T. Miyamoto, D. Sakai, and H. Okamoto, Dynamical aspects of excitonic Floquet states generated by a phase locked mid-infrared pulse in a one-dimensional Mott insulator, New J. Phys. 25, 093044 (2023).
  21. A. Sell, A. Leitenstorfer, and R. Huber, Phase-locked generation and field-resolved detection of widely tunable terahertz pulses with amplitudes exceeding 100 MV/cm, Opt. Lett. 33, 2767 (2008).
  22. T. Yamakawa, N. Sono, T. Kitao, T. Morimoto, N. Kida, T. Miyamoto, and H. Okamoto, Long-term stabilization of carrier envelope phases of mid-infrared pulses for the precise detection of phase-sensitive responses to electromagnetic waves, AIP Adv. 10, 025311 (2020).
  23. Y. Kobayashi, C. Heide, A. C. Johnson, V. Tiwari, F. Liu, D. A. Reis, T. F. Heinz, and S. Ghimire, Floquet engineering of strongly driven excitons in monolayer tungsten disulfide, Nat. Phys. 19, 171 (2023).
  24. T. Hasegawa, S. Kagoshima, T. Mochida, S. Sugiura, and Y. Iwasa, Electronic states and anti-ferromagnetic order in mixed-stack charge-transfer compound (BEDT-TTF) (F2TCNQ), Solid State Commun. 103, 489 (1997).
  25. H. Okamoto, H. Matsuzaki, T. Wakabayashi, Y. Takahashi, and T. Hasegawa, Photoinduced metallic state mediated by spin-charge separation in a one-dimensional organic Mott insulator, Phys. Rev. Lett. 98, 037401 (2007).
  26. H. Uemura, H. Matsuzaki, Y. Takahashi, T. Hasegawa, and H. Okamoto, Ultrafast charge dynamics in one-dimensional organic Mott insulators, J. Phys. Soc. Jpn. 77, 113714 (2008).
  27. S. Wall, D. Brida, S. R. Clark, H. P. Ehrke, D. Jaksch, A. Ardavan, S. Bonora, H. Uemura, Y. Takahashi, T. Hasegawa, H. Okamoto, G. Cerullo, and A. Cavalleri, Quantum interference between charge excitation paths in a solid-state Mott insulator, Nat. Phys. 7, 114 (2011).
  28. H. Kishida, H. Matsuzaki, H. Okamoto, T. Manabe, M. Yamashita, Y. Taguchi, and Y. Tokura, Gigantic optical nonlinearity in one-dimensional Mott–Hubbard insulators, Nature (London) 405, 929 (2000).
  29. M. Ono, K. Miura, A. Maeda, H. Matsuzaki, H. Kishida, Y. Taguchi, Y. Tokura, M. Yamashita, and H. Okamoto, Linear and nonlinear optical properties of one-dimensional Mott insulators consisting of Ni-halogen chain and CuO-chain compounds, Phys. Rev. B 70, 085101 (2004).
  30. T. Miyamoto, T. Kakizaki, T. Terashige, D. Hata, H. Yamakawa, T. Morimoto, N. Takamura, H. Yada, Y. Takahashi, T. Hasegawa, H. Matsuzaki, T. Tohyama, and H. Okamoto, Biexciton in one-dimensional Mott insulators, Commun. Phys. 2, 131 (2019).
  31. T. Yamaguchi, K. Iwano, T. Miyamoto, N. Takamura, N. Kida, Y. Takahashi, T. Hasegawa, and H. Okamoto, Excitonic optical spectra and energy structures in a one-dimensional Mott insulator demonstrated by applying a many-body Wannier functions method to a charge model, Phys. Rev. B 103, 045124 (2021).
  32. Y. Mizuno, K. Tsutsui, T. Tohyama, and S. Maekawa, Nonlinear optical response and spin-charge separation in one-dimensional Mott insulators, Phys. Rev. B 62, R4769 (2000).
  33. H. Kishida, M. Ono, K. Miura, H. Okamoto, M. Izumi, T. Manako, M. Kawasaki, Y. Taguchi, Y. Tokura, T. Tohyama, K. Tsutsui, and S. Maekawa, Large third-order optical nonlinearity of Cu-O chains investigated by third-harmonic generation spectroscopy, Phys. Rev. Lett. 87, 177401 (2001).
  34. M. Ono, H. Kishida, and H. Okamoto, Direct observation of excitons and a continuum of one-dimensional Mott insulators: A reflection-type third-harmonic-generation study of Ni-halogen chain compounds, Phys. Rev. Lett. 95, 087401 (2005).
  35. H. Yada, T. Miyamoto, and H. Okamoto, Terahertz-field-driven sub-picosecond optical switching enabled by large third-order optical nonlinearity in a one-dimensional Mott insulator, Appl. Phys. Lett. 102, 091104 (2013).
  36. R. Singla, G. Cotugno, S. Kaiser, M. Forst, M. Mitrano, H. Y. Liu, A. Cartella, C. Manzoni, H. Okamoto, T. Hasegawa, S. R. Clark, D. Jaksch, and A. Cavalleri, THz-Frequency Modulation of the Hubbard U in an organic Mott insulator, Phys. Rev. Lett. 115, 187401 (2015).
  37. N. Takamura, T. Miyamoto, S. Liang, K. Asada, T. Terashige, Y. Takahashi, T. Hasegawa, and H. Okamoto, Efficient Mott insulator-metal transition by an intense terahertz electric field pulse via quantum tunneling, Phys. Rev. B 107, 085147 (2023).
  38. EMIR(∼2.2MV/cm) was evaluated from the temporal width (130 fs) and fluence (0.9mJ/cm2) reported in Ref. [36].
  39. N. Sono, T. Otaki, T. Kitao, T. Yamakawa, D. Sakai, T. Morimoto, T. Miyamoto, and H. Okamoto, Phonon-dressed states in an organic Mott insulator, Commun. Phys. 5, 72 (2022).
  40. D. Sakai, T. Yamakawa, H. Ueda, R. Ikeda, T. Miyamoto, and H. Okamoto, Destabilization of spin-Peierls phase via a charge-spin modulated Floquet state induced by intramolecular vibrational excitation, Commun. Phys. 7, 40 (2024).
  41. P. N. Butcher and D. Cotter, The Elements of Nonlinear Optics. Cambridge Studies in Modern Optics (Cambridge University Press, Cambridge, UK, 1990).
  42. T. Terashige, T. Ono, T. Miyamoto, T. Morimoto, H. Yamakawa, N. Kida, T. Ito, T. Sasagawa, T. Tohyama, and H. Okamoto, Doublon-holon pairing mechanism via exchange interaction in two-dimensional cuprate Mott insulators, Sci. Adv. 5, eaav2187 (2019).
