Rheology and yielding of charged vesicle gels: Experiments and simulations

N. Kolezakis1, R. Pastore1,*, F. Rusciano1, V. Guida2, P. L. Maffettone1, and G. D'Avino1

  • *Contact author: raffaele.pastore@unina.it
PDF

Phys. Rev. Research 8, 023359 – Published 30 June, 2026

DOI: https://doi.org/10.1103/r8js-bbkv

Abstract

The behavior of charged vesicle suspensions, commonly encountered in biological and industrial contexts, is largely governed by screened electrostatic repulsions. However, the addition of depletants such as polymers can induce attractive interactions and lead to gel formation. Here, we investigate the rheology and yielding behavior of such a vesicle gel, relevant to a class of consumer products. The combination of experiments and Brownian dynamics simulations enables us to establish connections between macroscopic rheology and microstructural features. Oscillatory tests reveal a predominantly elastic response at small deformations, followed by yielding upon increasing the strain amplitude. With increasing shear rate, the flow curves feature a yield stress regime, followed by shear thinning and, eventually, a Newtonian-like response (viscosity plateau). We find that, in both oscillatory and shear-rate-controlled tests, the yielding transition is accompanied by nonmonotonic trends in structural heterogeneity. Fitting the flow curves with the recently introduced three-component model reveals that structural heterogeneity peaks near the crossover from the yield stress plateau to shear thinning, while homogeneity is recovered in the Newtonian-like regime. Numerical creep tests exhibit rich phenomenology, including Andrade-like deformation, delayed yielding, and resolidification, whose persistence even above the dynamic yield stress highlights the ductile nature of gels with competing attractive and repulsive interactions. Overall, our study highlights distinctive rheological and structural features of gels with competing attractive and repulsive interactions, providing insight into how microscopic heterogeneity controls yielding and flow.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (54)

  1. S. Šegota et al., Spontaneous formation of vesicles, Adv. Colloid Interface Sci. 121, 51 (2006).
  2. V. Guida, Thermodynamics and kinetics of vesicles formation processes, Adv. Colloid Interface Sci. 161, 77 (2010).
  3. R. Lipowsky, The conformation of membranes, Nature (London) 349, 475 (1991).
  4. P. Walde and S. Ichikawa, Enzymes inside lipid vesicles: Preparation, reactivity and applications, Biomol. Eng. 18, 143 (2001).
  5. D. S. Murphy, Fabric softener technology: A review, J. Surfactants Deterg. 18, 199 (2015).
  6. P.-E. Hellberg, K. Bergström, and K. Holmberg, Cleavable surfactants, J. Surfactants Deterg. 3, 81 (2000).
  7. G. Porpora, F. Rusciano, V. Guida, F. Greco, and R. Pastore, Understanding charged vesicle suspensions as Wigner glasses: Dynamical aspects, J. Phys.: Condens. Matter 33, 104001 (2021).
  8. E. S. Thompson, M. Declercq, P. Saveyn, V. Guida, E. S. Robles, and M. M. Britton, Phase separation and collapse in almost density matched depletion induced colloidal gels in presence and absence of air bubbles: An MRI imaging study, J. Colloid Interface Sci. 582, 201 (2021).
  9. N. Kolezakis, S. Aime, R. Pastore, V. Guida, G. D'Avino, and P. Edera, Microscopic structure and dynamics of shear-thinning suspensions of polydisperse, repulsive vesicles, Soft Matter 21, 8130 (2025).
  10. A. Siciliano, R. Pastore, F. Greco, and F. Rusciano, An effective volume fraction controls both dynamics and thermodynamics in vesicle suspensions with tunable electrostatic interactions, Ind. Eng. Chem. Res. 64, 18938 (2025).
  11. M. Leivers, J. M. Seddon, M. Declercq, E. Robles, and P. Luckham, Measurement of forces between supported cationic bilayers by colloid probe atomic force microscopy: Electrolyte concentration and composition, Langmuir 35, 729 (2019).
  12. R. A. Mohamed Yunus, U. Gürel, A. Guzik, P. Dieudonné-George, M. C. Stuart, C. N. Likos, P. Raffa, D. Truzzolillo, A. Giuntoli, and D. Parisi, Glass transition and yielding of ultrasoft charged spherical micelles, Macromolecules 58, 9724 (2025).
  13. J. Y. Huh, M. L. Lynch, and E. M. Furst, Microscopic structure and collapse of depletion-induced gels in vesicle-polymer mixtures, Phys. Rev. E 76, 051409 (2007).
  14. J. Y. Huh, M. L. Lynch, and E. M. Furst, Poroelastic consolidation in the phase separation of vesicle-polymer suspensions, Ind. Eng. Chem. Res. 50, 78 (2011).
  15. E. Zaccarelli, Colloidal gels: Equilibrium and non-equilibrium routes, J. Phys.: Condens. Matter 19, 323101 (2007).
  16. E. Zaccarelli, P. J. Lu, F. Ciulla, D. A. Weitz, and F. Sciortino, Gelation as arrested phase separation in short-ranged attractive colloid–polymer mixtures, J. Phys.: Condens. Matter 20, 494242 (2008).
  17. W. Poon, Colloids as big atoms, Science 304, 830 (2004).
  18. N. Koumakis, E. Moghimi, R. Besseling, W. C. K. Poon, J. F. Brady, and G. Petekidis, Tuning colloidal gels by shear, Soft Matter 11, 4640 (2015).
  19. R. N. Zia, B. J. Landrum, and W. B. Russel, A micro-mechanical study of coarsening and rheology of colloidal gels: Cage building, cage hopping, and Smoluchowski's ratchet, J. Rheol. 58, 1121 (2014).
  20. P. J. Lu, E. Zaccarelli, F. Ciulla, A. B. Schofield, F. Sciortino, and D. A. Weitz, Gelation of particles with short-range attraction, Nature (London) 453, 499 (2008).
  21. S. Ramakrishnan, V. Gopalakrishnan, and C. Zukoski, Clustering and mechanics in dense depletion and thermal gels, Langmuir 21, 9917 (2005).
  22. G. Brambilla, S. Buzzaccaro, R. Piazza, L. Berthier, and L. Cipelletti, Highly nonlinear dynamics in a slowly sedimenting colloidal gel, Phys. Rev. Lett. 106, 118302 (2011).
  23. M. Spannuth and J. C. Conrad, Confinement-induced solidification of colloid-polymer depletion mixtures, Phys. Rev. Lett. 109, 028301 (2012).
  24. E. Moghimi, A. R. Jacob, N. Koumakis, and G. Petekidis, Colloidal gels tuned by oscillatory shear, Soft Matter 13, 2371 (2017).
  25. L. C. Johnson, R. N. Zia, E. Moghimi, and G. Petekidis, Influence of structure on the linear response rheology of colloidal gels, J. Rheol. 63, 583 (2019).
  26. W. C. Poon, The physics of a model colloid–polymer mixture, J. Phys.: Condens. Matter 14, R859 (2002).
  27. K.-M. Corominas, K. M. Quan, Y. Yang, and K. Peers, Method of producing a fabric softener composition, U.S. Patent Appl. 12/984663 (2014), https://patents.google.com/patent/US20110172137A1/en.
  28. M. Seth, A. Ramachandran, and L. G. Leal, Dilution technique to determine the hydrodynamic volume fraction of a vesicle suspension, Langmuir 26, 15169 (2010).
  29. S. Chiruvolu, J. Israelachvili, E. Naranjo, Z. Xu, J. Zasadzinski, E. Kaler, and K. Herrington, Measurement of forces between spontaneous vesicle-forming bilayers, Langmuir 11, 4256 (1995).
  30. J. N. Israelachvili, Intermolecular and Surface Forces, 3rd ed. (Academic Press, Burlington, MA, 2011).
  31. B. J. Landrum, W. B. Russel, and R. N. Zia, Delayed yield in colloidal gels: Creep, flow, and re-entrant solid regimes, J. Rheol. 60, 783 (2016).
  32. A. Sierou and J. F. Brady, Accelerated Stokesian dynamics simulations, J. Fluid Mech. 448, 115 (2001).
  33. X. Zhang, E. Lorenceau, T. Bourouina, P. Basset, T. Oerther, M. Ferrari, F. Rouyer, J. Goyon, and P. Coussot, Wall slip mechanisms in direct and inverse emulsions, J. Rheol. 62, 1495 (2018).
  34. D. Bonn, M. M. Denn, L. Berthier, T. Divoux, and S. Manneville, Yield stress materials in soft condensed matter, Rev. Mod. Phys. 89, 035005 (2017).
  35. M. Caggioni, V. Trappe, and P. T. Spicer, Variations of the Herschel–Bulkley exponent reflecting contributions of the viscous continuous phase to the shear rate-dependent stress of soft glassy materials, J. Rheol. 64, 413 (2020).
  36. W. H. Herschel and R. Bulkley, Konsistenzmessungen von Gummi-Benzollösungen, Kolloid-Z. 39, 291 (1926).
  37. A.-M. Philippe, D. Truzzolillo, J. Galvan-Myoshi, P. Dieudonné-George, V. Trappe, L. Berthier, and L. Cipelletti, Glass transition of soft colloids, Phys. Rev. E 97, 040601(R) (2018).
  38. A. Nicolas, E. E. Ferrero, K. Martens, and J.-L. Barrat, Deformation and flow of amorphous solids: Insights from elastoplastic models, Rev. Mod. Phys. 90, 045006 (2018).
  39. E. C. Bingham, Fluidity and Plasticity (McGraw-Hill Book Company, New York, 1922).
  40. L. Bocquet, A. Colin, and A. Ajdari, Kinetic theory of plastic flow in soft glassy materials, Phys. Rev. Lett. 103, 036001 (2009).
  41. P. Hébraud and F. Lequeux, Mode-coupling theory for the pasty rheology of soft glassy materials, Phys. Rev. Lett. 81, 2934 (1998).
  42. A. Nicolas, K. Martens, L. Bocquet, and J.-L. Barrat, Universal and non-universal features in coarse-grained models of flow in disordered solids, Soft Matter 10, 4648 (2014).
  43. H. He, H. Liang, M. Chu, Z. Jiang, J. J. de Pablo, M. V. Tirrell, S. Narayanan, and W. Chen, Bridging microscopic dynamics and rheology in the yielding of charged colloidal suspensions, Proc. Natl. Acad. Sci. USA 122, e2514216122 (2025).
  44. R. Pastore, G. Pesce, A. Sasso, and M. Pica Ciamarra, Many facets of intermittent dynamics in colloidal and molecular glasses, Colloids Surf. A 532, 87 (2017).
  45. E. Moghimi, A. B. Schofield, and G. Petekidis, Yielding and resolidification of colloidal gels under constant stress, J. Phys.: Condens. Matter 33, 284002 (2021).
  46. J. Sprakel, S. B. Lindström, T. E. Kodger, and D. A. Weitz, Stress enhancement in the delayed yielding of colloidal gels, Phys. Rev. Lett. 106, 248303 (2011).
  47. E. N. D. C. Andrade, On the viscous flow in metals, and allied phenomena, Proc. R. Soc. Lond. Ser. A 84, 1 (1910).
  48. S. M. Fielding, P. Sollich, and M. E. Cates, Aging and rheology in soft materials, J. Rheol. 44, 323 (2000).
  49. V. B. Nguyen, T. Darnige, A. Bruand, and E. Clement, Creep and fluidity of a real granular packing near jamming, Phys. Rev. Lett. 107, 138303 (2011).
  50. M. Siebenbürger, M. Ballauff, and T. Voigtmann, Creep in colloidal glasses, Phys. Rev. Lett. 108, 255701 (2012).
  51. V. Gopalakrishnan and C. Zukoski, Delayed flow in thermo-reversible colloidal gels, J. Rheol. 51, 623 (2007).
  52. B. Baldewa and Y. M. Joshi, Delayed yielding in creep, time–stress superposition and effective time theory for a soft glass, Soft Matter 8, 789 (2012).
  53. R. Pastore, M. Pica Ciamarra, and A. Coniglio, Pacman percolation and the glass transition, Fractals 21, 1350021 (2013).
  54. https://cordis.europa.eu/project/id/955605.
