Optimized laser wakefield acceleration: Generating stable, high-energy, monoenergetic electron beams and demonstrating extreme-ultraviolet free-electron lasers

Zhan Jin1,3,*, Masaki Kando2,3,1,†, Yan-Jun Gu1,3, Kai Huang2,3, Nobuhiko Nakanii2,3, Izuru Daito2, Zhenzhe Lei1, Shingo Sato1, Hiroaki Sano1 et al.

Toshiya Muto1, Shigeru Yamamoto4,3, and Tomonao Hosokai1,3

  • *Contact author: jin@sanken.osaka-u.ac.jp
  • †Contact author: kando.masaki@qst.go.jp
PDF

Phys. Rev. Research 8, 013207 – Published 24 February, 2026

DOI: https://doi.org/10.1103/qvg7-ng8n

Abstract

Free electron lasers (FELs) are powerful, tunable light sources capable of delivering ultrashort, coherent radiation over a wide spectral range, but their broad scientific and technological impact is limited by the size and cost of large-scale accelerators. Laser wakefield acceleration (LWFA) offers a compact alternative via the ultrahigh accelerating gradients, though achieving FEL gain with such beams remains a major challenge due to the stringent beam-quality requirements. Here, we present a successful demonstration of a laser-plasma accelerator-driven FEL operating at a central wavelength of 40nm with a highly nonlinear gain. A compact 0.8J laser system, combined with precise control over the plasma-density profile, injection conditions, and the stability of both laser wave front and gas jet, enabled the generation of high-quality monoenergetic electron beams with excellent shot-to-shot reproducibility. A comprehensive start-to-end simulation framework was established, incorporating beam acceleration, transport, and FEL generation. Each stage of the simulation shows good agreement with the experimental diagnostics. The resulting FEL radiation exhibits clear exponential gain of approximately 20 times. This work highlights a reliable route toward compact, tunable, x-ray FELs driven by LWFA, and represents a significant step toward practical applications of laser-plasma-based light sources.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (39)

  1. T. Tajima and J. M. Dawson, Laser electron-accelerator, Phys. Rev. Lett. 43, 267 (1979).
  2. D. Strickland and G. Mourou, Compression of amplified chirped optical pulses, Opt. Commun. 56, 219 (1985).
  3. W. P. Leemans, B. Nagler, A. J. Gonsalves, Cs. Tóth, K. Nakamura, C. G. R. Geddes, E. Esarey, C. B. Schroeder, and S. M. Hooker, GeV electron beams from a centimetre-scale accelerator, Nat. Phys. 2, 696 (2006).
  4. W. P. Leemans, A. J. Gonsalves, H.-S. Mao, K. Nakamura, C. Benedetti, C. B. Schroeder, Cs. Tóth, J. Daniels, D. E. Mittelberger, S. S. Bulanov, J.-L. Vay, C. G. R. Geddes, and E. Esarey, Multi-GeV electron beams from capillary-discharge-guided subpetawatt laser pulses in the self-trapping regime, Phys. Rev. Lett. 113, 245002 (2014).
  5. A. J. Gonsalves, et al., Petawatt laser guiding and electron beam acceleration to 8 GeV in a laser-heated capillary discharge waveguide, Phys. Rev. Lett. 122, 084801 (2019).
  6. A. R. Maier, N. Delbos, T. Eichner, L. Hubner, S. Jalas, L. Jeppe, S. W. Jolly, M. Kirchen, V. Leroux, P. Messner, M. Schnepp, M. Trunk, P. A. Walker, C. Werle, and P. Winkler, Decoding sources of energy variability in a laser-plasma accelerator, Phys. Rev. X 10, 031039 (2020).
  7. C. Emma, et al., Free electron lasers driven by plasma accelerators: Status and near-term prospects, High Power Laser Sci. Eng. 9, e57 (2021).
  8. W. Wang, et al., Free-electron lasing at 27 nanometres based on a laser wakefield accelerator, Nature (London) 595, 516 (2021).
  9. M. Labat, et al., Seeded free-electron laser driven by a compact laser plasma accelerator, Nat. Photon. 17, 150 (2023).
  10. S. K. Barber, et al., Greater than 1000-fold gain in a free-electron laser driven by a laser-plasma accelerator with high reliability, Phys. Rev. Lett. 135, 055001 (2025).
  11. T. André, et al., Control of laser plasma accelerated electrons for light sources, Nat. Commun. 9, 1334 (2018).
  12. A. Pukhov and J. Meyer-ter-vehn, Laser wake field acceleration: The highly non-linear broken-wave regime, Appl. Phys. B 74, 355 (2002).
  13. Z.-M.  Sheng, M. Chen, Y.-Y.  Ma, and J. Zhang, Theory of ionization-induced trapping in laser-plasma accelerators, J. Appl. Phys. 99, 056109 (2006).
  14. A. Pak, K. A. Marsh, S. F. Martins, W. Lu, W. B.  Mori, and C.  Joshi, Injection and trapping of tunnel-ionized electrons into laser-produced wakes, Phys. Rev. Lett. 104, 025003 (2010).
  15. R. Lehe, A. F. Lifschitz, X. Davoine, C. Thaury, and V. Malka, Optical transverse injection in laser-plasma acceleration, Phys. Rev. Lett. 111, 085005 (2013).
  16. A. Buck, J. Wenz, J. Xu, K. Khrennikov, K. Schmid, M. Heigoldt, J. M. Mikhailova, M. Geissler, B. Shen, F. Krausz, S. Karsch, and L. Veisz, Shock-front injector for high-quality laser-plasma acceleration, Phys. Rev. Lett. 110, 185006 (2013).
  17. M. Kirchen, S. Jalas, P. Messner, P. Winkler, T. Eichner, L. Hübner, T. Hülsenbusch, L. Jeppe, T. Parikh, M. Schnepp, and A. R. Maier, Optimal beam loading in a laser-plasma accelerator, Phys. Rev. Lett. 126, 174801 (2021).
  18. J. Götzfried, A. Döpp, M.  F. Gilljohann, F.  M. Foerster, H. Ding, S. Schindler, G. Schilling, A. Buck, L. Veisz, and S. Karsch, Physics of high-charge electron beams in laser-plasma wakefields, Phys. Rev. X 10, 041015 (2020).
  19. N. Nakanii, K. Huang, K. Kondo, H. Kiriyama, and M. Kando, Precise pointing control of high-energy electron beam from laser wakefield acceleration using an aperture, Appl. Phys. Express 16, 026001 (2023).
  20. C. Zhu, J. Wang, Y. Li, J. Feng, D. Li, Y. He, J. Tan, J. Ma, X. Lu, Y. Li, and L. Chen, Optical steering of electron beam in laser plasma accelerators, Opt. Express 28, 11609 (2020).
  21. Z. Lei, Y. Gu, Z. Jin, S. Sato, A. Zhidkov, A. Rondepierre, K. Huang, N. Nakanii, I. Daito, M. Kando, and T. Hosokai, Supersonic gas jet stabilization in laser–plasma acceleration, High Power Laser Sci. Eng. 11, e91 (2023).
  22. Z. Lei, Z. Jin, Y. Gu, S. Sato, A. Zhidkov, A. Rondepierre, K. Huang, N. Nakanii, I. Daito, M. Kando, and T. Hosokai, Modular supersonic nozzle for the stable laser-driven electron acceleration, Rev. Sci. Instrum. 95, 015111 (2024).
  23. Y. Gu, Z. Jin, Z. Lei, S. Sato, K. Huang, N. Nakanii, I. Daito, M. Kando, and T. Hosokai, Generation of highly stable electron beam via the control of hydrodynamic instability, Sci. Rep. 14, 31162 (2024).
  24. G. G. Manahan, A. F. Habib, P. Scherkl, P. Delinikolas, A. Beaton, A. Knetsch, O. Karger, G. Wittig, T. Heinemann, Z. M. Sheng, J. R. Cary, D. L. Bruhwiler, J. B. Rosenzweig, and B. Hidding, Single-stage plasma-based correlated energy spread compensation for ultrahigh 6D brightness electron beams, Nat. Commun. 8, 15705 (2017).
  25. R. Lehe, M. Kirchen, I. A. Andriyash, B. B. Godfrey, and J.-L. Vay, A spectral, quasi-cylindrical and dispersionfree particle-in-cell algorithm, Comput. Phys. Commun. 203, 66 (2016).
  26. S. Y. Kalmykov, S. A. Yi, A. Beck, A. F. Lifschitz, X. Davoine, E. Lefebvre, V. Khudik, G. Shvets, and M. C. Downer, Dark-current-free petawatt laser-driven wakefield accelerator based on electron self-injection into an expanding plasma bubble, Plasma Phys. Controlled Fusion 53, 014006 (2011).
  27. A. Döpp, C. Thaury, E. Guillaume, F. Massimo, A. Lifschitz, I. Andriyash, J.-P. Goddet, A. Tazfi, K. Ta Phuoc, and V. Malka, Energy-chirp compensation in a laser wakefield accelerator, Phys. Rev. Lett. 121, 074802 (2018).
  28. L. Ke, C. Yu, K. Feng, Z. Qin, K. Jiang, H. Wang, S. Luan, X. Yang, Y. Xu, Y. Leng, W. Wang, J. Liu, and R. Li, Optimization of electron beams based on plasma-density modulation in a laser-driven wakefield accelerator, Appl. Sci. 11, 2560 (2021).
  29. H.-E. Tsai, K. K. Swanson, S. K. Barber, R. Lehe, H.-S. Mao, D. E. Mittelberger, S. Steinke, K. Nakamura, J. van Tilborg, C. Schroeder, E. Esarey, C. G. R. Geddes, and W. Leemans, Control of quasi-monoenergetic electron beams from laser-plasma accelerators with adjustable shock density profile, Phys. Plasmas 25, 043107 (2018).
  30. F. Irshad, S. Karsch, and A. Döpp, Multi-objective and multi-fidelity Bayesian optimization of laser-plasma acceleration, Phys. Rev. Res. 5, 013063 (2023).
  31. Pulsar Physics, General Particle Tracer, www.pulsar.nl/gpt.
  32. T. Tanaka, simplex: Simulator and postprocessor for free-electron laser experiments, J. Synchrotron Radiat. 22, 1319 (2015).
  33. T. Tanaka, Accelerating the convergence of free electron laser simulations by retrieving a spatially coherent component of microbunching, Phys. Rev. Accel. Beams 27, 030703 (2024).
  34. S. Yamamoto, Undulator light source with a compact slender and light frame based on a magnet technology developed for very-short-period undulators, J. Phys.: Conf. Ser. 3010, 012028 (2025).
  35. T. Tanaka and H. Kitamura, spectra: A synchrotron radiation calculation code, J. Synchrotron Radiat. 8, 1221 (2001).
  36. T. Tanaka, Major upgrade of the synchrotron radiation calculation code spectra, J. Synchrotron Radiat. 28, 1267 (2021).
  37. S. Yamamoto, A novel attempt to develop very short period undulators, J. Phys.: Conf. Ser. 425, 032014 (2013).
  38. S. Yamamoto, Development of very short period undulators, in Proc. IPAC18, Vancouver, BC, Canada, WEXGBD1 (2018), p. 1735.
  39. S. Yamamoto, S. Kashiwagi, S. Masuda, N. Nakanii, T. Hosokai, M. Kando, T. Muto, K. Nanbu, F. Hinode, and H. Hama, Light source based on a 100 mm-long monolithic undulator magnet with a very short 4 mm-period length, J. Synchrotron Radiat. 26, 1902 (2019).
