Surfing locomotion of elastic sheets driven by curvature mismatch

Omri Y. Cohen, Yael Klein, and Eran Sharon*

  • *Contact author: erans@mail.huji.ac.il
PDF

Phys. Rev. Research 7, L032065 – Published 22 September, 2025

DOI: https://doi.org/10.1103/qbjj-7qvy

Abstract

The locomotion of flexible membranes on top of curved surfaces appears in different contexts and scales, from cells to tissue and to cm-scale organisms. We present an experimental and theoretical study of curvature-driven locomotion, using gel ribbons that surf on a curved fluid-fluid interface via autonomous periodic modulation of their curvature. We derive a mechanical model in which forces and torques emerge from the curvature mismatch between the ribbon and the substrate. Analytic and numerical solutions of the equations of motion successfully predict the experimentally measured velocity profiles. We conclude by highlighting the relevance of this curvature-driven mode of locomotion to other mechanical, as well as biological systems.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (33)

  1. L. Pieuchot et al., Curvotaxis directs cell migration through cell-scale curvature landscapes, Nat. Commun. 9, 3995 (2018).
  2. M. Werner, A. Petersen, N. A. Kurniawan, and C. V. C. Bouten, Cell-perceived substrate curvature dynamically coordinates the direction, speed, and persistence of stromal cell migration, Adv. Biosyst. 3, 10 (2019).
  3. N. D. Bade, T. Xu, R. D. Kamien, R. K. Assoian, and K. J. Stebe, Gaussian curvature directs stress fiber orientation and cell migration, Biophys. J. 114, 1467 (2018).
  4. S. J. P. Callens, R. J. C. Uyttendaele, L. E. Fratila-Apachitei, and A. A. Zadpoor, Substrate curvature as a cue to guide spatiotemporal cell and tissue organization, Biomater. 232, 119739 (2020).
  5. Y. Y. Biton and S. A. Safran, The cellular response to curvature-induced stress, Phys. Biol. 6, 046010 (2009).
  6. J. A. Sanz-Herrera, P. Moreo, J. M. García-Aznar, and M. Doblaré, On the effect of substrate curvature on cell mechanics, Biomater. 30, 6674 (2009).
  7. P. A. Kralchevsky and K. Nagayama, Capillary interactions between particles bound to interfaces, liquid films and biomembranes, Adv. Colloid Interface Sci. 85, 145 (2000).
  8. Y. Yu, M. Guo, X. Li, and Q.-S. Zheng, Meniscus-climbing behavior and its minimum free-energy mechanism, Langmuir 23, 10546 (2007).
  9. G. Xie, P. Li, P. Y. Kim, P. Y. Gu, B. A. Helms, P. D. Ashby, L. Jiang, and T. P. Russell, Continuous, autonomous subsurface cargo shuttling by nature-inspired meniscus-climbing systems, Nat. Chem. 14, 208 (2022).
  10. L. Botto, E. P. Lewandowski, M. Cavallaro, and K. J. Stebe, Capillary interactions between anisotropic particles, Soft Matter 8, 9957 (2012).
  11. M. Cavallaro, L. Botto, E. P. Lewandowski, M. Wang, and K. J. Stebe, Curvature-driven capillary migration and assembly of rod-like particles, Proc. Natl Acad. Sci. USA 108, 20923 (2011).
  12. M. Barakat and T. M. Squires, Curvature-mediated forces on elastic inclusions in fluid interfaces, Langmuir 38, 1099 (2022).
  13. D. Hu and J. Bush, Meniscus-climbing insects, Nature (London) 437, 733 (2005).
  14. See Supplemental Material at http://link.aps.org/supplemental/10.1103/qbjj-7qvy for technical information, mathematical derivations and additional data, which includes Refs.  [31, 32, 33].
  15. R. Yoshida, T. Takahashi, T. Yamaguchi, and H. Ichijo, Self-oscillating gel, J. Am. Chem. Soc. 118, 5134 (1996).
  16. I. Levin, R. Deegan, and E. Sharon, Self-oscillating membranes: Chemomechanical sheets show autonomous periodic shape transformation, Phys. Rev. Lett. 125, 178001 (2020).
  17. C. Py, P. Reverdy, L. Doppler, J. Bico, B. Roman, and C. N. Baroud, Capillary origami: Spontaneous wrapping of a droplet with an elastic sheet, Phys. Rev. Lett. 98, 156103 (2007).
  18. P. M. Reis, J. Hure, S. Jung, J. W. M. Bush, and C. Clanet, Grabbing water, Soft Matter 6, 5705 (2010).
  19. J. Bico, B. Roman, L. Moulin, and A. Boudaoud, Elastocapillary coalescence in wet hair, Nature (London) 432, 690 (2004).
  20. E. Efrati, E. Sharon, and R. Kupferman, Elastic theory of unconstrained non-Euclidean plates, J. Mech. Phys. Solids 57, 762 (2009).
  21. S. Armon, E. Efrati, R. Kupferman, and E. Sharon, Geometry and mechanics in the opening of chiral seed pods, Science 333, 1726 (2011).
  22. J. Kim, J. A. Hanna, R. C. Hayward, and C. D. Santangelo, Thermally responsive rolling of thin gel strips with discrete variations in swelling, Soft Matter 8, 2375 (2012).
  23. H. King, R. D. Schroll, B. Davidovitch, and N. Menon, Elastic sheet on a liquid drop reveals wrinkling and crumpling as distinct symmetry-breaking instabilities, Proc. Natl Acad. Sci. USA 109, 9716 (2012).
  24. J. Huro, B. Roman, and J. Bico, Wrapping an adhesive sphere with an elastic sheet, PRL 106, 174301 (2011).
  25. J. Huang, B. Davidovitch, C. D. Santangelo, T. P. Russell, and N. Menon, Smooth cascade of wrinkles at the edge of a floating elastic film, PRL 105, 038302 (2010).
  26. B. Roman and J Bico, Elasto-capillarity: Deforming an elastic structure with a liquid droplet, J. Phys. Condens. Matter 22, 493101 (2010).
  27. Z. Hu, W. Fang, Q. Li, X. Q. Feng, and J. Lv, Optocapillarity-driven assembly and reconfiguration of liquid crystal polymer actuators, Nat. Commun. 11, 5780 (2020).
  28. Note that the ribbons oscillate a few times before settling at their equilibrium points. This indicates that the assumption of negligible inertia term is not valid at the final stage of the motion.
  29. Z. Mao, M. Kuroki, Y. Otsuka, and S. Maeda, Contraction waves in self-oscillating polymer gels, Extreme Mech. Lett. 39, 100830 (2020).
  30. H. Aharoni, J. M. Kolinski, M. Moshe, I. Meirzada, and E. Sharon, Internal stresses lead to net forces and torques on extended elastic bodies, Phys. Rev. Lett. 117, 124101 (2016).
  31. S. Maeda, Y. Hara, T. Sakai, R. Yoshida, and S. Hashimoto, Self-walking gel, Adv. Mater. 19, 3480 (2007).
  32. F. Box, C. Jacquemot, M. Adda-Bedia, and D. Vella, Cloaking by coating: How effectively does a thin, stiff coating hide a soft substrate? Soft Matter 16, 4574 (2020).
  33. A. Lee, P.-T. Brun, J. Marthelot, G. Balestra, F. Gallaire, and P. M. Reis, Fabrication of slender elastic shells by the coating of curved surfaces, Nat. Commun. 7, 11155 (2016).

Outline

Information

Phys. Rev. Research 7, L032065– Published 22 September, 2025
  • Received 5 May 2024
  • Revised 12 March 2025
  • Accepted 2 July 2025
