Collider-quality electron bunches from an all-optical plasma photoinjector

Arohi Jain1,*, Jiayang Yan1, Jacob R. Pierce2, Tanner T. Simpson3, Mikhail Polyanskiy4, William Li4, Marcus Babzien4, Mark Palmer4, Michael Downer5 et al.

Roman Samulyak1, Chan Joshi2, Warren B. Mori2, John P. Palastro3, and Navid Vafaei-Najafabadi1,†

  • *Contact author: arohi.jain@stonybrook.edu
  • †Contact author: navid.vafaei-najafabadi@stonybrook.edu
PDF

Phys. Rev. Research 8, 023213 – Published 27 May, 2026

DOI: https://doi.org/10.1103/q36y-6jqn

Abstract

We present an approach for generating collider-quality electron bunches using a plasma photoinjector. The approach leverages recently developed techniques for the spatiotemporal control of laser pulses to produce a moving ionization front in a nonlinear plasma wave. The moving ionization front generates an electron bunch with a current profile that balances the longitudinal electric field of an electron beam-driven plasma wave, creating a uniform accelerating field across the bunch. Particle-in-cell (PIC) simulations of the ionization stage show the formation of an electron bunch with 220 pC charge and low emittance (ɛx=171 nm rad, ɛy=76 nm rad). Quasistatic PIC simulations of the acceleration stage show that the bunch is efficiently accelerated to 24 GeV over 2 m with a final energy spread of less than 1% and emittances of ɛx=189 nm rad and ɛy=80 nm rad. This high-quality electron bunch meets the requirements outlined by the Snowmass process for intermediate-energy colliders and compares favorably to the beam quality of proposed and existing accelerator facilities. The results establish the feasibility of plasma photoinjectors for future collider applications making a significant step toward the realization of high-luminosity, compact accelerators for particle physics research.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (54)

  1. S. P. D. Mangles, C. D. Murphy, Z. Najmudin, A. G. R. Thomas, J. L. Collier, A. E. Dangor, E. J. Divall, P. S. Foster, J. G. Gallacher, C. J. Hooker, D. A. Jaroszynski, A. J. Langley, W. B. Mori, P. A. Norreys, F. S. Tsung, R. Viskup, B. R. Walton, and K. Krushelnick, Monoenergetic beams of relativistic electrons from intense laser–plasma interactions, Nature (London) 431, 535 (2004).
  2. C. G. R. Geddes, C. Toth, J. van Tilborg, E. Esarey, C. B. Schroeder, D. Bruhwiler, C. Nieter, J. Cary, and W. P. Leemans, High-quality electron beams from a laser wakefield accelerator using plasma-channel guiding, Nature (London) 431, 538 (2004).
  3. J. Faure, Y. Glinec, A. Pukhov, S. Kiselev, S. Gordienko, E. Lefebvre, J.-P. Rousseau, F. Burgy, and V. Malka, A laser–plasma accelerator producing monoenergetic electron beams, Nature (London) 431, 541 (2004).
  4. C. Schroeder et al., Linear colliders based on laser-plasma accelerators, J. Instrum. 18, T06001 (2023).
  5. S. Bulanov et al., The science case for an intermediate energy advanced and novel accelerator linear collider facility, J. Instrum. 19, T01010 (2024).
  6. J. Faure, Plasma Injection Schemes for Laser-Plasma Accelerators, Technical Report No. 2016-001 (CERN, Geneva, 2016).
  7. M. Fuchs et al., Plasma-based particle sources, J. Instrum. 19, T01004 (2024).
  8. D. Froula et al., Flying focus: Spatial and temporal control of intensity for laser-based applications, Phys. Plasmas 26, 032109 (2019).
  9. X. L. Xu et al., Low emittance electron beam generation from a laser wakefield accelerator using two laser pulses with different wavelengths, Phys. Rev. ST Accel. Beams 17, 061301 (2014).
  10. L.-L. Yu, E. Esarey, C. B. Schroeder, J.-L. Vay, C. Benedetti, C. G. R. Geddes, M. Chen, and W. P. Leemans, Two-color laser-ionization injection, Phys. Rev. Lett. 112, 125001 (2014).
  11. C. B. Schroeder, C. Benedetti, S. Bulanov, M. Chen, E. Esarey, C. C. G. R. Geddes, J.-L. Vay, L. Yu, and W. P. Leemans, Ultra-low emittance beam generation using two-color ionization injection in laser-plasma accelerators, in Laser Acceleration of Electrons, Protons, and Ions III; and Medical Applications of Laser-Generated Beams of Particles III, International Society for Optics and Photonics Vol. 9514 (SPIE, Bellingham, WA, 2015), p. 951408.
  12. J. P. Palastro, J. L. Shaw, P. Franke, D. Ramsey, T. T. Simpson, and D. H. Froula, Dephasingless laser wakefield acceleration, Phys. Rev. Lett. 124, 134802 (2020).
  13. M. Tzoufras, W. Lu, F. S. Tsung, C. Huang, W. B. Mori, T. Katsouleas, J. Vieira, R. A. Fonseca, and L. O. Silva, Beam loading in the nonlinear regime of plasma-based acceleration, Phys. Rev. Lett. 101, 145002 (2008).
  14. S. Li, G. Li, Q. Ain, M. S. Hur, A. C. Ting, V. V. Kulagin, C. Kamperidis, and N. A. Hafz, A laser-plasma accelerator driven by two-color relativistic femtosecond laser pulses, Sci. Adv. 5, eaav7940 (2019).
  15. W. Lu, C. Huang, M. Zhou, W. B. Mori, and T. Katsouleas, Nonlinear theory for relativistic plasma wakefields in the blowout regime, Phys. Rev. Lett. 96, 165002 (2006).
  16. D. H. Froula et al., Spatiotemporal control of laser intensity, Nat. Photon. 12, 262 (2018).
  17. J. P. Palastro, D. Turnbull, S.-W. Bahk, R. K. Follett, J. L. Shaw, D. Haberberger, J. Bromage, and D. H. Froula, Ionization waves of arbitrary velocity driven by a flying focus, Phys. Rev. A 97, 033835 (2018).
  18. D. Turnbull, P. Franke, J. Katz, J. Palastro, I. Begishev, R. Boni, J. Bromage, A. Milder, J. Shaw, and D. Froula, Ionization waves of arbitrary velocity, Phys. Rev. Lett. 120, 225001 (2018).
  19. J. Palastro, B. Malaca, J. Vieira, D. Ramsey, T. Simpson, P. Franke, J. Shaw, and D. Froula, Laser-plasma acceleration beyond wave breaking, Phys. Plasmas 28, 013109 (2021).
  20. K. G. Miller, J. R. Pierce, M. V. Ambat, J. L. Shaw, K. Weichman, W. B. Mori, D. H. Froula, and J. P. Palastro, Dephasingless laser wakefield acceleration in the bubble regime, Sci. Rep. 13, 21306 (2023).
  21. J. Pigeon, P. Franke, M. L. P. Chong, J. Katz, R. Boni, C. Dorrer, J. Palastro, and D. Froula, Ultrabroadband flying-focus using an axiparabola-echelon pair, Opt. Express 32, 576 (2024).
  22. A. Sainte-Marie, O. Gobert, and F. Quere, Controlling the velocity of ultrashort light pulses in vacuum through spatio-temporal couplings, Optica 4, 1298 (2017).
  23. C. Caizergues, S. Smartsev, V. Malka, and C. Thaury, Phase-locked laser-wakefield electron acceleration, Nat. Photon. 14, 475 (2020).
  24. K. Oubrerie, I. A. Andriyash, R. Lahaye, S. Smartsev, V. Malka, and C. Thaury, Axiparabola: A new tool for high-intensity optics, J. Opt. 24, 045503 (2022).
  25. E. Oz et al., Ionization-induced electron trapping in ultrarelativistic plasma wakes, Phys. Rev. Lett. 98, 084801 (2007).
  26. A. Pak, K. Marsh, S. Martins, W. Lu, W. Mori, and C. Joshi, Injection and trapping of tunnel-ionized electrons into laser-produced wakes, Phys. Rev. Lett. 104, 025003 (2010).
  27. C. McGuffey et al., Ionization induced trapping in a laser wakefield accelerator, Phys. Rev. Lett. 104, 025004 (2010).
  28. X. L. Xu, J. F. Hua, F. Li, C. J. Zhang, L. X. Yan, Y. C. Du, W. H. Huang, H. B. Chen, C. X. Tang, W. Lu, P. Yu, W. An, C. Joshi, and W. B. Mori, Phase-space dynamics of ionization injection in plasma-based accelerators, Phys. Rev. Lett. 112, 035003 (2014).
  29. J.-P. Delahaye, E. Adli, S. Gessner, M. Hogan, T. Raubenheimer, W. An, C. Joshi, and W. Mori, A beam driven plasma-wakefield linear collider from Higgs factory to multi-TeV, in Proceedings of the 5th International Particle Accelerator Conference (IPAC'14, Dresden, Germany, 2014), pp. 3791–3793.
  30. A. Abada et al., FCC-ee: The Lepton collider, Eur. Phys. J.: Spec. Top. 228, 261 (2019).
  31. T. Raubenheimer et al., The LCLS-II-HE, a high energy upgrade of the LCLS-II, in 60th ICFA Advanced Beam Dynamics Workshop on Future Light Sources (JACoW Publishing, Geneva, 2018), pp. 6–11.
  32. C. Schroeder, J.-L. Vay, E. Esarey, S. Bulanov, C. Benedetti, L.-L. Yu, M. Chen, C. Geddes, and W. Leemans, Thermal emittance from ionization-induced trapping in plasma accelerators, Phys. Rev. ST Accel. Beams 17, 101301 (2014).
  33. M. Tzoufras, W. Lu, F. S. Tsung, C. Huang, W. B. Mori, T. Katsouleas, J. Vieira, R. Fonseca, and L. Silva, Beam loading by electrons in nonlinear plasma wakes, Phys. Plasmas 16, 056705 (2009).
  34. M. J. Hogan et al., Plasma wakefield acceleration experiments at FACET, New J. Phys. 12, 055030 (2010).
  35. J. Frederico, M. Hogan, Y. Nosochkov, M. Litos, and T. Raubenheimer, FACET emittance growth, Technical Report SLAC-PUB-14441, SLAC National Accelerator Laboratory, Menlo Park, California, 2011.
  36. I. V. Pogorelsky, M. N. Polyanskiy, M. Babzien, A. Simmonds, and M. A. Palmer, Terawatt-class femtosecond long-wave infrared laser, Front. Phys. 12, 1390225 (2024).
  37. R. A. Fonseca, L. O. Silva, F. S. Tsung, V. K. Decyk, W. Lu, C. Ren, W. B. Mori, S. Deng, S. Lee, T. Katsouleas, and J. C. Adam, Osiris: A three-dimensional, fully relativistic particle in cell code for modeling plasma based accelerators, Computational Science—ICCS 2002 (Springer Berlin Heidelberg, Berlin, 2002), pp. 342–351.
  38. A. Davidson, A. Tableman, W. An, F. Tsung, W. Lu, J. Vieira, R. Fonseca, L. Silva, and W. Mori, Implementation of a hybrid particle code with a PIC description in r–z and a gridless description in ϕ into OSIRIS, J. Comput. Phys. 281, 1063 (2015).
  39. F. Li, K. G. Miller, X. Xu, F. S. Tsung, V. K. Decyk, W. An, R. A. Fonseca, and W. B. Mori, A new field solver for modeling of relativistic particle-laser interactions using the particle-in-cell algorithm, Comput. Phys. Commun. 258, 107580 (2021).
  40. D. L. Bruhwiler, D. Dimitrov, J. R. Cary, E. Esarey, W. Leemans, and R. E. Giacone, Particle-in-cell simulations of tunneling ionization effects in plasma-based accelerators, Phys. Plasmas 10, 2022 (2003).
  41. F. Li, W. An, V. K. Decyk, X. Xu, M. J. Hogan, and W. B. Mori, A quasi-static particle-in-cell algorithm based on an azimuthal Fourier decomposition for highly efficient simulations of plasma-based acceleration: QPAD, Comput. Phys. Commun. 261, 107784 (2021).
  42. J. R. Pierce, J. P. Palastro, F. Li, B. Malaca, D. Ramsey, J. Vieira, K. Weichman, and W. B. Mori, Arbitrarily structured laser pulses, Phys. Rev. Res. 5, 013085 (2023).
  43. P. Franke, D. Ramsey, T. T. Simpson, D. Turnbull, D. Froula, and J. Palastro, Optical shock-enhanced self-photon acceleration, Phys. Rev. A 104, 043520 (2021).
  44. X. Xu, Phase Space Dynamics in Plasma Based Wakefield Acceleration, Springer Theses (Springer Nature Singapore, Singapore, 2020).
  45. M. Galletti, R. Assmann, M. Couprie, M. Ferrario, L. Giannessi, A. Irman, R. Pompili, and W. Wang, Prospects for free-electron lasers powered by plasma-wakefield-accelerated beams, Nat. Photon. 18, 780 (2024).
  46. M. Hogan et al., Plasma wakefield experiments at FACET, in 2011 Particle Accelerator Conference (IEEE, New York, NY, 2011), pp. 534–536.
  47. M. Yessenov and A. F. Abouraddy, Accelerating and decelerating space-time optical wave packets in free space, Phys. Rev. Lett. 125, 233901 (2020).
  48. H. E. Kondakci and A. F. Abouraddy, Diffraction-free space–time light sheets, Nat. Photon. 11, 733 (2017).
  49. T. T. Simpson, D. Ramsey, P. Franke, N. Vafaei-Najafabadi, D. Turnbull, D. H. Froula, and J. P. Palastro, Nonlinear spatiotemporal control of laser intensity, Opt. Express 28, 38516 (2020).
  50. T. T. Simpson, D. Ramsey, P. Franke, K. Weichman, M. V. Ambat, D. Turnbull, D. H. Froula, and J. P. Palastro, Spatiotemporal control of laser intensity through cross-phase modulation, Opt. Express 30, 9878 (2022).
  51. R. Kupfer, NIR laser plans, in 23rd ATF Users Meeting (Yaphank, New York, 2020).
  52. Cycle GmbH, PULSE—timing distribution system (2025), https://www.cyclelasers.com/timing-distribution/pulse/.
  53. N. Vafaei-Najafabadi, Direct measurement of fields and radiation in self-modulated plasma wakefield regime, in 26th ATF Users Meeting (Yaphank, New York, 2024).
  54. Y. Wu, Z. Wang, X. Lin, C. Xia, Z. Wang, and Z.-M. Sheng, Numerical investigation of two-color ionization injection with a flying focus, Phys. Plasmas 31, 072108 (2024).
