Event soliton formation in mixed energy-momentum gaps of nonlinear spacetime crystals

Liang Zhang1, Zhiwei Fan2,*, and Yiming Pan1,†

  • 1School of Physical Science and Technology and Center for Transformative Science, ShanghaiTech University, Shanghai 200031, China
  • 2School of Engineering, Newcastle University, Newcastle upon Tyne NE1 7RU, United Kingdom

  • *Contact author: zhiwei.fan@newcastle.ac.uk
  • †Contact author: yiming.pan@shanghaitech.edu.cn
PDF

Phys. Rev. Research 8, 023107 – Published 1 May, 2026

DOI: https://doi.org/10.1103/q226-dkk4

Abstract

We report the formation of a soliton—termed “event soliton”—in nonlinear photonic spacetime crystals (STCs). In these media, simultaneous spatiotemporal periodic modulation of the dielectric constant generates mixed frequency (ω) and wave vector (k) gaps. Under Kerr nonlinearity, the event solitons emerge as fully localized entities in both spacetime and energy-momentum domains, providing a tangible demonstration of the concept of “event” in relativity. The ωk-gap mixture arises from the coexistence and competition between time-reflected and Bragg-reflected waves due to the spatiotemporal modulation. We propose a partial differential equation to capture various spatiotemporal patterns and present numerical simulations to validate our theoretical predictions, reflecting a three-way balance among k-gap opening, ω-gap opening, and nonlinearity. Our work opens avenues for fundamental studies and fosters experimental prospects for implementing spacetime crystals and pattern formation in time-varying photonics.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (56)

  1. Y. Sharabi, A. Dikopoltsev, E. Lustig, Y. Lumer, and M. Segev, Spatiotemporal photonic crystals, Optica 9, 585 (2022).
  2. C. Caloz and Z.-L. Deck-Léger, Spacetime metamaterials—Part I: General concepts, IEEE Trans. Antennas Propag. 68, 1569 (2019).
  3. C. Caloz and Z.-L. Deck-Leger, Spacetime metamaterials—Part II: Theory and applications, IEEE Trans. Antennas Propag. 68, 1583 (2019).
  4. E. Yablonovitch, Inhibited spontaneous emission in solid-state physics and electronics, Phys. Rev. Lett. 58, 2059 (1987).
  5. F. R. Morgenthaler, Velocity modulation of electromagnetic waves, IRE Trans. Microwave Theory Tech. 6, 167 (1958).
  6. D. Holberg and K. Kunz, Parametric properties of fields in a slab of time-varying permittivity, IEEE Trans. Antennas Propag. 14, 183 (1966).
  7. J. R. Zurita-Sánchez, P. Halevi, and J. C. Cervantes-Gonzalez, Reflection and transmission of a wave incident on a slab with a time-periodic dielectric function ε(t), Phys. Rev. A 79, 053821 (2009).
  8. A. M. Shaltout, J. Fang, A. V. Kildishev, and V. M. Shalaev, Photonic time-crystals and momentum band-gaps, in Conference on Lasers and Electro-Optics, OSA Technical Digest (online) (Optica Publishing Group, 2016), paper FM1D.4.
  9. J. S. Martínez-Romero and P. Halevi, Parametric resonances in a temporal photonic crystal slab, Phys. Rev. A 98, 053852 (2018).
  10. N. Wang, Z.-Q. Zhang, and C. T. Chan, Photonic Floquet media with a complex time-periodic permittivity, Phys. Rev. B 98, 085142 (2018).
  11. J. S. Martínez-Romero, O. M. Becerra-Fuentes, and P. Halevi, Temporal photonic crystals with modulations of both permittivity and permeability, Phys. Rev. A 93, 063813 (2016).
  12. E. Galiffi, R. Tirole, S. Yin, H. Li, S. Vezzoli, P. A. Huidobro, M. G. Silveirinha, R. Sapienza, A. Alù, and J. B. Pendry, Photonics of time-varying media, Adv. Photon. 4, 14002 (2022).
  13. Z. Hayran, J. B. Khurgin, and F. Monticone, ℏω versus ℏk: Dispersion and energy constraints on time-varying photonic materials and time crystals, Opt. Mater. Express 12, 3904 (2022).
  14. H. Moussa, G. Xu, S. Yin, E. Galiffi, Y. Ra’di, and A. Alù, Observation of temporal reflection and broadband frequency translation at photonic time interfaces, Nat. Phys. 19, 863 (2023).
  15. S. Sadhukhan and S. Ghosh, Momentum controlled optical pulse amplification in photonic time crystals, arXiv:2301.09390.
  16. M. Xiao, Z. Q. Zhang, and C. T. Chan, Surface impedance and bulk band geometric phases in one-dimensional systems, Phys. Rev. X 4, 021017 (2014).
  17. M. Baggioli, M. Vasin, V. Brazhkin, and K. Trachenko, Gapped momentum states, Phys. Rep. 865, 1 (2020).
  18. J. T. Mendonça and P. K. Shukla, Time refraction and time reflection: Two basic concepts, Phys. Scr. 65, 160 (2002).
  19. O. Shahriar and M. R. C. Mahdy, An idea of implementing photonic space-time crystals using metasurfaces, arXiv:2409.00139.
  20. J. W. Thomas, Dispersion and dissipation, in Numerical Partial Differential Equations: Finite Difference Methods, Texts in Applied Mathematics Vol. 22 (Springer, New York, NY, 1995), p. 361.
  21. J. B. Pendry, E. Galiffi, and P. A. Huidobro, Gain mechanism in time-dependent media, Optica 8, 636 (2021).
  22. Y. Yerin, A. A. Varlamov, R. Felici, and A. Di Carlo, Dielectric properties and plasmon modes of gapped momentum systems of different dimensionality, Phys. Rev. B 108, 075134 (2023).
  23. E. I. Kiselev, Y. Pan, and N. H. Lindner, Light-controlled terahertz plasmonic time-varying media: Momentum gaps, entangled plasmon pairs, and pulse-induced time reversal, Phys. Rev. B 110, L241411 (2024).
  24. M. Lyubarov, Y. Lumer, A. Dikopoltsev, E. Lustig, Y. Sharabi, and M. Segev, Amplified emission and lasing in photonic time crystals, Science (1979) 377, 425 (2022).
  25. A. Dikopoltsev, Y. Sharabi, M. Lyubarov, Y. Lumer, S. Tsesses, E. Lustig, I. Kaminer, and M. Segev, Light emission by free electrons in photonic time-crystals, Proc. Natl. Acad. Sci. USA 119, e2119705119 (2022).
  26. D. L. Mills and S. E. Trullinger, Gap solitons in nonlinear periodic structures, Phys. Rev. B 36, 947 (1987).
  27. W. Chen and D. L. Mills, Gap solitons and the nonlinear optical response of superlattices, Phys. Rev. Lett. 58, 160 (1987).
  28. D. N. Christodoulides and R. I. Joseph, Slow bragg solitons in nonlinear periodic structures, Phys. Rev. Lett. 62, 1746 (1989).
  29. B. J. Eggleton, R. E. Slusher, C. M. De Sterke, P. A. Krug, and J. E. Sipe, Bragg grating solitons, Phys. Rev. Lett. 76, 1627 (1996).
  30. W. C. K. Mak, P. L. Chu, and B. A. Malomed, Solitary waves in coupled nonlinear waveguides with Bragg gratings, J. Opt. Soc. Am. B 15, 1685 (1998).
  31. B. J. Eggleton, C. M. de Sterke, and R. E. Slusher, Bragg solitons in the nonlinear Schrödinger limit: Experiment and theory, J. Opt. Soc. Am. B 16, 587 (1999).
  32. D. Mandelik, R. Morandotti, J. S. Aitchison, and Y. Silberberg, Gap solitons in waveguide arrays, Phys. Rev. Lett. 92, 093904 (2004).
  33. A. B. Aceves and S. Wabnitz, Self-induced transparency solitons in nonlinear refractive periodic media, Phys. Lett. A 141, 37 (1989).
  34. J. E. Sipe and H. G. Winful, Nonlinear Schrödinger solitons in a periodic structure, Opt. Lett. 13, 132 (1988).
  35. Y. Pan, M.-I. Cohen, and M. Segev, Superluminal k-gap solitons in nonlinear photonic time crystals, Phys. Rev. Lett. 130, 233801 (2023).
  36. P. D. Drummond and M. Hillery, The Quantum Theory of Nonlinear Optics (Cambridge University Press, New York, 2014).
  37. N. Quesada and J. E. Sipe, Why you should not use the electric field to quantize in nonlinear optics, Opt. Lett. 42, 3443 (2017).
  38. H. Kogelnik and C. V. Shank, Coupled-wave theory of distributed feedback lasers, J. Appl. Phys. 43, 2327 (1972).
  39. See Supplemental Material at http://link.aps.org/supplemental/10.1103/q226-dkk4 for additional details on the band-structure engineering, the derivation of Eq. (6), and the numerical results.
  40. E. I. Kiselev and Y. Pan, Symmetry breaking and spatiotemporal pattern formation in photonic time crystals, Phys. Rev. A 111, 053509 (2025).
  41. D. H. Peregrine, Water waves, nonlinear Schrödinger equations and their solutions, ANZIAM J. 25, 16 (1983).
  42. B. Kibler, J. Fatome, C. Finot, G. Millot, F. Dias, G. Genty, N. Akhmediev, and J. M. Dudley, The Peregrine soliton in nonlinear fibre optics, Nat. Phys. 6, 790 (2010).
  43. V. I. Shrira and V. V. Geogjaev, What makes the Peregrine soliton so special as a prototype of freak waves? J. Eng. Math. 67, 11 (2010).
  44. D. R. Solli, C. Ropers, P. Koonath, and B. Jalali, Optical rogue waves, Nature (London) 450, 1054 (2007).
  45. Y. Silberberg, Collapse of optical pulses, Opt. Lett. 15, 1282 (1990).
  46. F. W. Wise, Generation of light bullets, Physics 3, 107 (2010).
  47. J. R. Reyes-Ayona and P. Halevi, Observation of genuine wave vector (k or β) gap in a dynamic transmission line and temporal photonic crystals, Appl. Phys. Lett. 107, (2015).
  48. J. R. Reyes-Ayona and P. Halevi, Electromagnetic wave propagation in an externally modulated low-pass transmission line, IEEE Trans. Microwave Theory Tech. 64, 3449 (2016).
  49. E. Lustig, O. Segal, S. Saha, E. Bordo, S. N. Chowdhury, Y. Sharabi, A. Fleischer, A. Boltasseva, O. Cohen, and V. M. Shalaev, Time-refraction optics with single cycle modulation, Nanophotonics 12, 2221 (2023).
  50. Z. Sun, A. Martinez, and F. Wang, Optical modulators with 2D layered materials, Nat. Photon. 10, 227 (2016).
  51. R. Maas, J. Parsons, N. Engheta, and A. Polman, Experimental realization of an epsilon-near-zero metamaterial at visible wavelengths, Nat. Photon. 7, 907 (2013).
  52. D. M. Solis and N. Engheta, A theoretical explanation for enhanced nonlinear response in epsilon-near-zero media, in 2020 Conference on Lasers and Electro-Optics (CLEO) (IEEE, Piscataway, NJ, 2020), pp. 1–2.
  53. Y. Zhou, M. Z. Alam, M. Karimi, J. Upham, O. Reshef, C. Liu, A. E. Willner, and R. W. Boyd, Broadband frequency translation through time refraction in an epsilon-near-zero material, Nat. Commun. 11, 2180 (2020).
  54. V. Bruno, S. Vezzoli, C. DeVault, E. Carnemolla, M. Ferrera, A. Boltasseva, V. M. Shalaev, D. Faccio, and M. Clerici, Broad frequency shift of parametric processes in epsilon-near-zero time-varying media, Appl. Sci. 10, 1318 (2020).
  55. X. Wang, M. S. Mirmoosa, V. S. Asadchy, C. Rockstuhl, S. Fan, and S. A. Tretyakov, Metasurface-based realization of photonic time crystals, Sci. Adv. 9, eadg7541 (2023).
  56. J. Feis, S. Weidemann, T. Sheppard, H. M. Price, and A. Szameit, Space-time-topological events in photonic quantum walks, Nat. Photon. 19, 518 (2025).
