Experimental demonstration of dephasing reduction in an optically guided laser-plasma accelerator

Ronan Lahaye*, Igor A. Andriyash, Julien Gautier, Olena Kononenko, Adrien Leblanc, Jean-Philippe Goddet, Amar Tafzi, and Cédric Thaury†

  • *Contact author: ronan.lahaye@ensta.org
  • †Contact author: cedric.thaury@ensta.fr
PDF

Phys. Rev. Research 8, 023274 – Published 10 June, 2026

DOI: https://doi.org/10.1103/pc2y-hxj9

Abstract

Laser-plasma accelerators offer a compact means of producing high-energy electron beams, but their performance is fundamentally limited by dephasing between the accelerated electrons and the plasma wave. To overcome this limitation, we investigate the combination of plasma density tapering and optical guiding to extend the effective acceleration length. Using a Joule-class femtosecond laser coupled into an optical-field-ionized plasma waveguide with a controlled density gradient, we experimentally achieve electron beam energies exceeding 1.6 GeV, a 40% increase compared to the constant-density case. Particle-in-cell simulations reproduce the main experimental features and reveal the central roles of delayed injection, nonlinear laser evolution, and self-focusing in enhancing energy gain.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (36)

  1. Y. B. Fainberg, Acceleration of particles in a plasma, Sov. J. At. Energy 6, 297 (1960).
  2. T. Tajima and J. M. Dawson, Laser electron accelerator, Phys. Rev. Lett. 43, 267 (1979).
  3. C. G. Durfee, III and H. M. Milchberg, Light pipe for high intensity laser pulses, Phys. Rev. Lett. 71, 2409 (1993).
  4. R. J. Shalloo, C. Arran, L. Corner, J. Holloway, J. Jonnerby, R. Walczak, H. M. Milchberg, and S. M. Hooker, Hydrodynamic optical-field-ionized plasma channels, Phys. Rev. E 97, 053203 (2018).
  5. B. Miao, J. E. Shrock, L. Feder, R. C. Hollinger, J. Morrison, R. Nedbailo, A. Picksley, H. Song, S. Wang, J. J. Rocca, and H. M. Milchberg, Multi-GeV electron bunches from an all-optical laser wakefield accelerator, Phys. Rev. X 12, 031038 (2022).
  6. J. E. Shrock, E. Rockafellow, B. Miao, M. Le, R. C. Hollinger, S. Wang, A. J. Gonsalves, A. Picksley, J. J. Rocca, and H. M. Milchberg, Guided mode evolution and ionization injection in meter-scale multi-GeV laser wakefield accelerators, Phys. Rev. Lett. 133, 045002 (2024).
  7. A. Picksley, J. Stackhouse, C. Benedetti, K. Nakamura, H. E. Tsai, R. Li, B. Miao, J. E. Shrock, E. Rockafellow, H. M. Milchberg, C. B. Schroeder, J. van Tilborg, E. Esarey, C. G. R. Geddes, and A. J. Gonsalves, Matched guiding and controlled injection in dark-current-free, 10-GeV-class, channel-guided laser-plasma accelerators, Phys. Rev. Lett. 133, 255001 (2024).
  8. K. Oubrerie, A. Leblanc, O. Kononenko, R. Lahaye, I. A. Andriyash, J. Gautier, J.-P. Goddet, L. Martelli, A. Tafzi, K. Ta Phuoc, S. Smartsev, and C. Thaury, Controlled acceleration of GeV electron beams in an all-optical plasma waveguide, Light Sci. Appl. 11, 180 (2022).
  9. E. Esarey, C. B. Schroeder, and W. P. Leemans, Physics of laser-driven plasma-based electron accelerators, Rev. Mod. Phys. 81, 1229 (2009).
  10. P. Sprangle, E. Esarey, A. Ting, and G. Joyce, Laser wakefield acceleration and relativistic optical guiding, Appl. Phys. Lett. 53, 2146 (1988).
  11. P. Sprangle, B. Hafizi, J. R. Peñano, R. F. Hubbard, A. Ting, C. I. Moore, D. F. Gordon, A. Zigler, D. Kaganovich, and T. M. Antonsen, Wakefield generation and GeV acceleration in tapered plasma channels, Phys. Rev. E 63, 056405 (2001).
  12. J. Kim, G. J. Kim, and S. H. Yoo, Energy enhancement using upward density ramp in laser wakefield acceleration, J. Korean Phy. Soc. 59, 3166 (2011).
  13. M. S. Kim, D. G. Jang, T. H. Lee, I. H. Nam, I. W. Lee, and H. Suk, Characteristics of a tapered capillary plasma waveguide for laser wakefield acceleration, Appl. Phys. Lett. 102, 204103 (2013).
  14. C. Aniculaesei, V. B. Pathak, H. T. Kim, K. H. Oh, B. J. Yoo, E. Brunetti, Y. H. Jang, C. I. Hojbota, J. H. Shin, J. H. Jeon, S. Cho, M. H. Cho, J. H. Sung, S. K. Lee, B. M. Hegelich, and C. H. Nam, Electron energy increase in a laser wakefield accelerator using up-ramp plasma density profiles, Sci. Rep. 9, 11249 (2019).
  15. E. Guillaume, A. Döpp, C. Thaury, K. Ta Phuoc, A. Lifschitz, G. Grittani, J. P. Goddet, A. Tafzi, S. W. Chou, L. Veisz, and V. Malka, Electron rephasing in a laser-wakefield accelerator, Phys. Rev. Lett. 115, 155002 (2015).
  16. S. Bulanov, N. Naumova, F. Pegoraro, and J. Sakai, Particle injection into the wave acceleration phase due to nonlinear wake wave breaking, Phys. Rev. E 58, R5257 (1998).
  17. A. Pukhov and I. Kostyukov, Control of laser-wakefield acceleration by the plasma-density profile, Phys. Rev. E 77, 025401 (2008).
  18. A. Döpp, E. Guillaume, C. Thaury, A. Lifschitz, K. Ta Phuoc, and V. Malka, Energy boost in laser wakefield accelerators using sharp density transitions, Phys. Plasmas 23, 056702 (2016).
  19. M. Streeter and S. McLoughlin, Optimised density tailoring for dephasing mitigation in laser wakefield accelerators, presented at the 6th European Advanced Accelerator Concepts Workshop (2023).
  20. W. Lu, M. Tzoufras, C. Joshi, F. S. Tsung, W. B. Mori, J. Vieira, R. A. Fonseca, and L. O. Silva, Generating multi-GeV electron bunches using single stage laser wakefield acceleration in a 3D nonlinear regime, Phys. Rev. ST Accel. Beams 10, 061301 (2007).
  21. J. E. Shrock, B. Miao, L. Feder, and H. M. Milchberg, Meter-scale plasma waveguides for multi-GeV laser wakefield acceleration, Phys. Plasmas 29, 073101 (2022).
  22. C. Benedetti, C. B. Schroeder, E. Esarey, and W. P. Leemans, Quasi-matched propagation of ultra-short, intense laser pulses in plasma channels, Phys. Plasmas 19, 053101 (2012).
  23. C. Benedetti, F. Rossi, C. B. Schroeder, E. Esarey, and W. P. Leemans, Pulse evolution and plasma-wave phase velocity in channel-guided laser-plasma accelerators, Phys. Rev. E 92, 023109 (2015).
  24. S. Smartsev, C. Caizergues, K. Oubrerie, J. Gautier, J.-P. Goddet, A. Tafzi, K. T. Phuoc, V. Malka, and C. Thaury, Axiparabola: A long-focal-depth, high-resolution mirror for broadband high-intensity lasers, Opt. Lett. 44, 3414 (2019).
  25. A. Morozov, A. Goltsov, Q. Chen, M. Scully, and S. Suckewer, Ionization assisted self-guiding of femtosecond laser pulses, Phys. Plasmas 25, 053110 (2018).
  26. L. Feder, B. Miao, J. E. Shrock, A. Goffin, and H. M. Milchberg, Self-waveguiding of relativistic laser pulses in neutral gas channels, Phys. Rev. Res. 2, 043173 (2020).
  27. A. Picksley, A. Alejo, R. J. Shalloo, C. Arran, A. von Boetticher, L. Corner, J. A. Holloway, J. Jonnerby, O. Jakobsson, C. Thornton, R. Walczak, and S. M. Hooker, Meter-scale conditioned hydrodynamic optical-field-ionized plasma channels, Phys. Rev. E 102, 053201 (2020).
  28. K. Oubrerie, I. A. Andriyash, R. Lahaye, S. Smartsev, V. Malka, and C. Thaury, Axiparabola: A new tool for high-intensity optics, J. Opt. 24, 045503 (2022).
  29. G. Genoud, F. Wojda, M. Burza, A. Persson, and C.-G. Wahlström, Active control of the pointing of a multi-terawatt laser, Rev. Sci. Instrum. 82, 033102 (2011).
  30. C. Thaury, E. Guillaume, A. Lifschitz, K. Ta Phuoc, M. Hansson, G. Grittani, J. Gautier, J. P. Goddet, A. Tafzi, O. Lundh, and V. Malka, Shock assisted ionization injection in laser-plasma accelerators, Sci. Rep. 5, 16310 (2015).
  31. M. Chen, Z.-M. Sheng, Y.-Y. Ma, and J. Zhang, Electron injection and trapping in a laser wakefield by field ionization to high-charge states of gases, J. Appl. Phys. 99, 056109 (2006).
  32. R. Lehe, M. Kirchen, I. A. Andriyash, B. B. Godfrey, and J.-L. Vay, A spectral, quasi-cylindrical and dispersion-free particle-in-cell algorithm, Comput. Phys. Commun. 203, 66 (2016).
  33. T.-Y. Chien, C.-L. Chang, C.-H. Lee, J.-Y. Lin, J. Wang, and S.-Y. Chen, Spatially localized self-injection of electrons in a self-modulated laser-wakefield accelerator by using a laser-induced transient density ramp, Phys. Rev. Lett. 94, 115003 (2005).
  34. R. Li, A. Picksley, C. Benedetti, F. Filippi, J. Stackhouse, L. Fan-Chiang, H. E. Tsai, K. Nakamura, C. B. Schroeder, J. van Tilborg, E. Esarey, C. G. R. Geddes, and A. J. Gonsalves, Longitudinal tapering in gas jets for increased efficiency of 10-GeV class laser plasma accelerators, Rev. Sci. Instrum. 96, 043306 (2025).
  35. B. Miao, J. E. Shrock, E. Rockafellow, A. J. Sloss, and H. M. Milchberg, Meter-scale supersonic gas jets for multi-GeV laser-plasma accelerators, Rev. Sci. Instrum. 96, 043003 (2025).
  36. T. Kurz, J. P. Couperus, J. M. Krämer, H. Ding, S. Kuschel, A. Köhler, O. Zarini, D. Hollatz, D. Schinkel, R. D'Arcy, J.-P. Schwinkendorf, J. Osterhoff, A. Irman, U. Schramm, and S. Karsch, Calibration and cross-laboratory implementation of scintillating screens for electron bunch charge determination, Rev. Sci. Instrum. 89, 093303 (2018).
