Soft mode-driven reduction of switching energy barriers in fluorite ferroelectric

Jinhyeong Jo1,*, Pawan Kumar1,*, and Jun Hee Lee1,2,†

  • 1Department of Energy Engineering, School of Energy and Chemical Engineering, UNIST, Ulsan 44919, Republic of Korea
  • 2Graduate School of Semiconductor Materials and Devices Engineering, UNIST, Ulsan 44919, Republic of Korea

  • *These authors contributed equally to this work.
  • †Contact author: junhee@unist.ac.kr
PDF

Phys. Rev. Research 7, 043046 – Published 14 October, 2025

DOI: https://doi.org/10.1103/kkk8-s3lk

Abstract

The low coercive field (Ec) is highly desirable for developing efficient and durable ferroelectric-based devices. However, fluorite ferroelectrics such as HfO2 and ZrO2, which are attracting significant attention as next-generation semiconductor materials due to their compatibility with complementary metal-oxide-semiconductor technology and robust ferroelectric properties, exhibit a significantly high Ec, severely limiting their application in memory devices. Here, using group theory and first-principles simulations, we reveal that phonon engineering can induce a new soft mode in the polar Pca21 phase of HfO2 and ZrO2. This mode dominates the intermediate transition state during polarization switching and drastically reduces the energy barriers for both homogeneous switching and the uniquely observed local switching, which enables ultrahigh memory density. Furthermore, the discovery of a ternary state during local switching points to the possibility of implementing ternary logic at the material level. Our findings introduce a new pathway to lowering Ec in fluorite ferroelectrics by exploiting intrinsic lattice dynamics, offering an alternative to conventional strategies such as doping or defect engineering, and open a promising direction for future material design.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (45)

  1. G. Lauhoff, R. Sinha, and W. Imaino, Storage infrastructure in the AI era using tape, HDD, and NAND flash memory, IEEE Trans. Magn. 61, 3100106 (2025).
  2. A. Basu, J. Acharya, T. Karnik, H. Liu, H. Li, J.-S. Seo, and C. Song, Low-power, adaptive neuromorphic systems: Recent progress and future directions, IEEE J. Emerg. Sel. Top. Circuits Syst. 8, 6 (2018).
  3. S. Li, M.-S. Lin, W.-C. Chen, and C.-C. Tsai, High-bandwidth chiplet interconnects for advanced packaging technologies in AI/ML applications: Challenges and solutions, IEEE Open J. Solid-State Circuits Soc. 4, 351 (2024).
  4. K. Yu, S. Kim, and J. R. Choi, Trends and challenges in computing-in-memory for neural network model: A review from device design to application-side optimization, IEEE Access 12, 186679 (2024).
  5. A. Keshavarzi and W. van den Hoek, Edge intelligence—On the challenging road to a trillion smart connected IoT devices, IEEE Des. Test 36, 41 (2019).
  6. A. Keshavarzi, K. Ni, W. Van Den Hoek, S. Datta, and A. Raychowdhury, Ferroelectronics for edge intelligence, IEEE Micro 40, 33 (2020).
  7. C. Tan, H. Wu, M. Zhao, X. Jili, L. Yang, L. Gao, and Z. Wang, Gate-switchable BST ferroelectric MoS2 FETs for non-volatile digital memory and analog memristor, Adv. Funct. Mater. 34, 2405293 (2024).
  8. C.-P. Yeh, M. Lisker, B. Kalkofen, and E. P. Burte, Fabrication and investigation of three-dimensional ferroelectric capacitors for the application of Feram, AIP Adv. 6, 035128 (2016).
  9. C.-U. Pinnow and T. Mikolajick, Material aspects in emerging nonvolatile memories, J. Electrochem. Soc. 151, K13 (2004).
  10. T. M. Shaw, S. Trolier-McKinstry, and P. C. McIntyre, The properties of ferroelectric films at small dimensions, Annu. Rev. Mater. Res. 30, 263 (2000).
  11. M. Yashima, T. Hoshina, D. Ishimura, S. Kobayashi, W. Nakamura, T. Tsurumi, and S. Wada, Size effect on the crystal structure of barium titanate nanoparticles, J. Appl. Phys. 98, 014313 (2005).
  12. R. R. Mehta, B. D. Silverman, and J. T. Jacobs, Depolarization fields in thin ferroelectric films, J. Appl. Phys. 44, 3379 (1973).
  13. T. S. Böscke, J. Müller, D. Bräuhaus, U. Schröder, and U. Böttger, Ferroelectricity in hafnium oxide thin films, Appl. Phys. Lett. 99, 102903 (2011).
  14. H.-J. Lee, M. Lee, K. Lee, J. Jo, H. Yang, Y. Kim, S. C. Chae, U. Waghmare, and J. H. Lee, Scale-free ferroelectricity induced by flat phonon bands in HfO2, Science 369, 1343 (2020).
  15. S. S. Cheema et al., Ultrathin ferroic HfO2−ZrO2 superlattice gate stack for advanced transistors, Nature (London) 604, 65 (2022).
  16. T. Mikolajick, S. Slesazeck, M. H. Park, and U. Schroeder, Ferroelectric hafnium oxide for ferroelectric random-access memories and ferroelectric field-effect transistors, MRS Bull. 43, 340 (2018).
  17. M.-K. Kim and J.-S. Lee, Ferroelectric analog synaptic transistors, Nano Lett. 19, 2044 (2019).
  18. D. Zhou, Y. Guan, M. M. Vopson, J. Xu, H. Liang, F. Cao, X. Dong, J. Mueller, T. Schenk, and U. Schroeder, Electric field and temperature scaling of polarization reversal in silicon doped hafnium oxide ferroelectric thin films, Acta Mater. 99, 240 (2015).
  19. C. Alessandri, P. Pandey, A. Abusleme, and A. Seabaugh, Switching dynamics of ferroelectric Zr-doped HfO2, IEEE Electron Device Lett. 39, 1780 (2018).
  20. P. Cai, H. Li, Z. Liu, T. Zhu, M. Zeng, Z. Ji, Y. Wu, A. Padovani, L. Larcher, M. Pešić, R. Wang, and R. Huang, Investigation of coercive field shift during cycling in HfZrOx ferroelectric capacitors, IEEE Trans. Electron Devices 69, 2384 (2022).
  21. K. Toprasertpong, K. Tahara, Y. Hikosaka, K. Nakamura, H. Saito, M. Takenaka, and S. Takagi, Low operating voltage, improved breakdown tolerance, and high endurance in Hf0.5Zr0.5O2 ferroelectric capacitors achieved by thickness scaling down to 4 nm for embedded ferroelectric memory, ACS Appl. Mater. Interfaces 14, 51137 (2022).
  22. M. K. Lenox, S. T. Jaszewski, S. S. Fields, N. Shukla, and J. F. Ihlefeld, Impact of electric field pulse duration on ferroelectric hafnium zirconium oxide thin film capacitor endurance, Phys. Status Solidi (A) 221, 2300566 (2024).
  23. D. Gupta, P. Kumar, and J. H. Lee, Doping engineering to reduce the coercive field of ferroelectric ZrO2, Phys. Rev. Appl. 22, 064039 (2024).
  24. A. G. Chernikova, M. G. Kozodaev, D. V. Negrov, E. V. Korostylev, M. H. Park, U. Schroeder, C. S. Hwang, and A. M. Markeev, Improved ferroelectric switching endurance of La-doped Hf0.5Zr0.5O2 thin films, ACS Appl. Mater. Interfaces 10, 2701 (2018).
  25. Y.-C. Li, T. Huang, X.-X. Li, X.-N. Zhu, D. W. Zhang, and H.-L. Lu, Domain switching characteristics in Ga-doped HfO2 ferroelectric thin films with low coercive field, Nano Lett. 24, 6585 (2024).
  26. X. Shao, J. Chai, F. Tian, X. Ke, M. Liao, S. Dai, H. Fan, X. Sun, H. Xu, K. Han, J. Xiang, X. Wang, J. Zhang, W. Wang, and T. Ye, Evidence of oxygen vacancy generation as physical origin of endurance fatigue of Si FeFET with TiN/Hf0.5Zr0.5O2/SiOx/Si gate-stacks, IEEE Trans. Electron Devices 71, 7461 (2024).
  27. K. Bao, J. Liao, F. Yan, S. Jia, B. Zeng, Q. Yang, M. Liao, and Y. Zhou, Enhanced endurance and imprint properties in Hf0.5Zr0.5O2−δ ferroelectric capacitors by tailoring the oxygen vacancy, ACS Appl. Electron. Mater. 5, 4615 (2023).
  28. See Supplemental Material at http://link.aps.org/supplemental/10.1103/kkk8-s3lk for computational methods, distortion mode analysis, and additional polarization-switching NEB results.
  29. G. Kresse and J. Furthmüller, Efficient iterative schemes for ab initio total-energy calculations using a plane-wave basis set, Phys. Rev. B 54, 11169 (1996).
  30. G. Kresse and J. Furthmüller, Efficiency of ab-initio total energy calculations for metals and semiconductors using a plane-wave basis set, Comput. Mater. Sci. 6, 15 (1996).
  31. J. P. Perdew, K. Burke, and M. Ernzerhof, Generalized gradient approximation made simple, Phys. Rev. Lett. 77, 3865 (1996).
  32. G. Kresse and D. Joubert, From ultrasoft pseudopotentials to the projector augmented-wave method, Phys. Rev. B 59, 1758 (1999).
  33. H. J. Monkhorst and J. D. Pack, Special points for Brillouin-zone integrations, Phys. Rev. B 13, 5188 (1976).
  34. S. E. Reyes-Lillo, K. F. Garrity, and K. M. Rabe, Antiferroelectricity in thin-film ZrO2 from first principles, Phys. Rev. B 90, 140103 (2014).
  35. Y.-W. Chen and C. W. Liu, Effects of shear strain on HZO ferroelectric orthorhombic phases, Appl. Phys. Lett. 123, 112901 (2023).
  36. R. Terki, G. Bertrand, H. Aourag, and C. Coddet, Cubic-to-tetragonal phase transition of HfO2 from computational study, Mater. Lett. 62, 1484 (2008).
  37. P. Kumar, D. Gupta, and J. H. Lee, Negative gradient energy facilitates charged domain walls in HfO2, Phys. Rev. Lett. 134, 166101 (2025).
  38. P. Kumar and J. H. Lee, Interface engineering for facile switching of bulk-strong polarization in Si-compatible vertical superlattices, Sci. Rep. 14, 6811 (2024).
  39. G. Mills, H. Jónsson, and G. K. Schenter, Reversible work transition state theory: Application to dissociative adsorption of hydrogen, Surf. Sci. 324, 305 (1995).
  40. Y. Wu, Y. Zhang, J. Jiang, L. Jiang, M. Tang, Y. Zhou, M. Liao, Q. Yang, and E. Y. Tsymbal, Unconventional polarization-switching mechanism in (Hf,Zr)O2 ferroelectrics and its implications, Phys. Rev. Lett. 131, 226802 (2023).
  41. P. Nukala, M. Ahmadi, Y. Wei, S. de Graaf, E. Stylianidis, T. Chakrabortty, S. Matzen, H. W. Zandbergen, A. Björling, D. Mannix, D. Carbone, B. Kooi, and B. Noheda, Reversible oxygen migration and phase transitions in hafnia-based ferroelectric devices, Science 372, 630 (2021).
  42. J. W. Jeong, Y.-E. Choi, W.-S. Kim, J.-H. Park, S. Kim, S. Shin, K. Lee, J. Chang, S.-J. Kim, and K. R. Kim, Tunnelling-based ternary metal–oxide–semiconductor technology, Nat. Electron. 2, 307 (2019).
  43. J. Nam, H. Lee, M. Lee, and J. H. Lee, Nonvolatile balanced ternary memory based on the multiferroelectric material GeSnTe2, J. Phys. Chem. Lett. 10, 7470 (2019).
  44. A. Acosta, J. M. P. Martirez, N. Lim, J. P. Chang, and E. A. Carter, Relationship between ferroelectric polarization and stoichiometry of HfO2 surfaces, Phys. Rev. Mater. 5, 124417 (2021).
  45. A. Acosta, J. M. P. Martirez, N. Lim, J. P. Chang, and E. A. Carter, Effect of thickness and surface composition on the stability of polarization in ferroelectric HfxZr1−xO2 thin films, Phys. Rev. Mater. 7, 124401 (2023).
