Flow of dynamical causal structures with an application to correlations

Ämin Baumeler* and Stefan Wolf

  • *Contact author: amin.baumeler@usi.ch
PDF

Phys. Rev. Research 7, 033278 – Published 24 September, 2025

DOI: https://doi.org/10.1103/jsmm-tq72

Abstract

Causal models capture cause-effect relations both qualitatively—via the graphical causal structure—and quantitatively—via the model parameters. They offer a powerful framework for analyzing and constructing processes. Here, we introduce a tool—the flow of causal structures—to visualize and explore the dynamical aspect of classical-deterministic processes, arguably like those present in general relativity. The flow describes all possible ways in which the causal structure of a process can evolve. We also present an algorithm to construct its supergraph—the superflow—from the causal structure only, without invoking the model parameters. As an application, we show that if all leaves of a flow are trivial, then the corresponding process produces causal correlations only, i.e., correlations where future data cannot influence past events. This strengthens the result that processes, where every directed cycle in their causal structure is chordless, establish causal correlations only. We also discuss the main difficulties for the quantum generalization of the present algorithms.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (30)

  1. L. Hardy, Probability theories with dynamic causal structure: A new framework for quantum gravity, arXiv:gr-qc/0509120.
  2. T. Colnaghi, G. M. D'Ariano, S. Facchini, and P. Perinotti, Quantum computation with programmable connections between gates, Phys. Lett. A 376, 2940 (2012).
  3. O. Oreshkov, F. Costa, and Č. Brukner, Quantum correlations with no causal order, Nat. Commun. 3, 1092 (2012).
  4. C. Portmann, C. Matt, U. Maurer, R. Renner, and B. Tackmann, Causal boxes: Quantum information-processing systems closed under composition, IEEE Trans. Inf. Theory 63, 3277 (2017).
  5. G. Chiribella, G. M. D'Ariano, P. Perinotti, and B. Valiron, Quantum computations without definite causal structure, Phys. Rev. A 88, 022318 (2013).
  6. J. Pearl, Causality (Cambridge University Press, Cambridge, 2009).
  7. H. Reichenbach, The principle of the common cause, in The Direction of Time, edited by M. Reichenbach (University of California Press, Berkeley, CA, 1971), Chap. 19, pp. 157–167.
  8. J. S. Bell, On the Einstein Podolsky Rosen paradox, Phys. Phys. Fiz. 1, 195 (1964).
  9. T. Fritz, Beyond Bell’s theorem II: Scenarios with arbitrary causal structure, Commun. Math. Phys. 341, 391 (2016).
  10. F. Costa and S. Shrapnel, Quantum causal modelling, New J. Phys. 18, 063032 (2016).
  11. J. M. A. Allen, J. Barrett, D. C. Horsman, C. M. Lee, and R. W. Spekkens, Quantum common causes and quantum causal models, Phys. Rev. X 7, 031021 (2017).
  12. J. Barrett, R. Lorenz, and O. Oreshkov, Quantum causal models, arXiv:1906.10726.
  13. M. Araújo, A. Feix, M. Navascués, and Č. Brukner, A purification postulate for quantum mechanics with indefinite causal order, Quantum 1, 10 (2017).
  14. T. Richardson and J. M. Robins, Single world intervention graphs (SWIGs): Unifying the counterfactual and graphical approaches to causality, Working Paper 128, Center for the Statistics and the Social Sciences, University of Washington, Seattle, WA, 2013.
  15. E.-E. Tselentis and Ä. Baumeler, Admissible causal structures and correlations, PRX Quantum 4, 040307 (2023).
  16. Two vertices u,v in a directed graph D are siblings, whenever they share at least one parent, i.e., whenever PaD(u)∩PaD)(v≠∅, for PaD(ℓ):={k∣k↣ℓ∈E(D)}.
  17. Ä. Baumeler and E.-E. Tselentis, Equivalence of grandfather and information antinomy under intervention, in Proceedings of the 17th International Conference on Quantum Physics and Logic, Electronic Proceedings in Theoretical Computer Science, edited by B. Valiron, S. Mansfield, P. Arrighi, and P. Panangaden (Open Publishing Association, 2021), Vol. 340, pp. 1–12.
  18. A flow graph is a rooted directed graph: For every vertex v, there exists a directed path from the root r to v.
  19. Ä. Baumeler and S. Wolf, Perfect signaling among three parties violating predefined causal order, in 2014 IEEE International Symposium on Information Theory (ISIT) (IEEE, Piscataway, NJ, 2014), pp. 526–530.
  20. C. Branciard, M. Araújo, A. Feix, F. Costa, and Č. Brukner, The simplest causal inequalities and their violation, New J. Phys. 18, 013008 (2015).
  21. Ä. Baumeler, A. S. Gilani, and J. Rashid, Unlimited non-causal correlations and their relation to non-locality, Quantum 6, 673 (2022).
  22. Ä. Baumeler, F. Costa, T. C. Ralph, S. Wolf, and M. Zych, Reversible time travel with freedom of choice, Class. Quantum Grav. 36, 224002 (2019).
  23. O. Oreshkov and C. Giarmatzi, Causal and causally separable processes, New J. Phys. 18, 093020 (2016).
  24. A. A. Abbott, C. Giarmatzi, F. Costa, and C. Branciard, Multipartite causal correlations: Polytopes and inequalities, Phys. Rev. A 94, 032131 (2016).
  25. M.-D. Choi, Completely positive linear maps on complex matrices, Linear Algebra Appl. 10, 285 (1975).
  26. Ä. Baumeler and S. Wolf, Computational tameness of classical non-causal models, Proc. R. Soc. A 474, 20170698 (2018).
  27. M. Araújo, P. Allard Guérin, and Ä. Baumeler, Quantum computation with indefinite causal structures, Phys. Rev. A 96, 052315 (2017).
  28. V. Vilasini and R. Renner, Fundamental limits for realizing quantum processes in spacetime, Phys. Rev. Lett. 133, 080201 (2024).
  29. Ä. Baumeler, Superflow (2025), https://git.indyfac.ch/amin/superflow.
  30. Ä. Baumeler and E.-E. Tselentis, SOC Observation Code (2023), https://git.indyfac.ch/amin/SOC-Observation-Code.
