Self-organized dynamics and emergent shape spaces of active isotropic fluid surfaces

Da Gao1, Huayang Sun1, Rui Ma1,*, and Alexander Mietke2,†

  • 1Department of Physics, College of Physical Science and Technology, Xiamen University, Xiamen 361005, People's Republic of China
  • 2Rudolf Peierls Centre for Theoretical Physics, Department of Physics, University of Oxford, Parks Road, Oxford OX1 3PU, United Kingdom

  • *Contact author: ruima@xmu.edu.cn
  • †Contact author: alexander.mietke@physics.ox.ac.uk
PDF

Phys. Rev. Research 8, 023046 – Published 15 April, 2026

DOI: https://doi.org/10.1103/jlps-h2qg

Abstract

Theories of self-organized active fluid surfaces have emerged as an important class of minimal models for the shape dynamics of biological membranes, cells, and tissues. However, due to their inherent geometric nonlinearities and the absence of general minimization principles in active systems, it remains a major challenge to systematically study the emergent shape spaces that such theories give rise to. Here, we introduce a variational approach that allows for a direct computation of stationary surface geometries and flows, which enables the classification of nonequilibrium phase transitions in shape spaces described by active surface theories. To achieve this, we construct a dissipation functional systematically from the entropy production in active surfaces and show how generic symmetries imposed by Onsager relations can be exploited to also account for reactive nondissipative terms in constitutive laws. This functional is supplemented by Lagrange multipliers that relax nonlinear geometric constraints, which leads to a tractable variational problem suitable for implicit dynamic simulations and explicit calculations of nontrivial steady state geometries and flows. We apply this framework to study the dynamics of open fluid membranes and closed active fluid surfaces, and characterize the space of stationary solutions that corresponding surfaces and flows occupy. These analyses rationalize the interplay of first-order shape transitions of internally and externally forced fluid membranes, reveal degenerate regions in stationary shape spaces of mechanochemically active surfaces, and identify a mechanism by which hydrodynamic screening controls the geometry of active surfaces undergoing cell divisionlike shape transformations.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (71)

  1. M. Kaksonen and A. Roux, Mechanisms of clathrin-mediated endocytosis, Nat. Rev. Mol. Cell Biol. 19, 313 (2018).
  2. R. Jahn and T. C. Südhof, Membrane fusion and exocytosis, Annu. Rev. Biochem. 68, 863 (1999).
  3. L.-G. Wu, E. Hamid, W. Shin, and H.-C. Chiang, Exocytosis and endocytosis: Modes, functions, and coupling mechanisms, Annu. Rev. Physiol. 76, 301 (2014).
  4. B. Alberts, D. Bray, J. Lewis, M. Raff, K. Roberts, and J. Watson, Molecular Biology of the Cell, 4th ed. (Garland, New York, 2002).
  5. R. Phillips, J. Kondev, J. Theriot, and H. Garcia, Physical Biology of the Cell (Garland Science, New York, 2012).
  6. R. Dimova, S. Aranda, N. Bezlyepkina, V. Nikolov, K. A. Riske, and R. Lipowsky, A practical guide to giant vesicles. Probing the membrane nanoregime via optical microscopy, J. Phys.: Condens. Matter 18, S1151 (2006).
  7. G. Salbreux, G. Charras, and E. Paluch, Actin cortex mechanics and cellular morphogenesis, Trends Cell Biol. 22, 536 (2012).
  8. D. Bray and J. White, Cortical flow in animal cells, Science 239, 883 (1988).
  9. M. Mayer, M. Depken, J. S. Bois, F. Jülicher, and S. W. Grill, Anisotropies in cortical tension reveal the physical basis of polarizing cortical flows, Nature (London) 467, 617 (2010).
  10. T. Lecuit and P.-F. Lenne, Cell surface mechanics and the control of cell shape, tissue patterns and morphogenesis, Nat. Rev. Mol. Cell Biol. 8, 633 (2007).
  11. P. Chugh, A. G. Clark, M. B. Smith, D. A. D. Cassani, K. Dierkes, A. Ragab, P. P. Roux, G. Charras, G. Salbreux, and E. K. Paluch, Actin cortex architecture regulates cell surface tension, Nat. Cell Biol. 19, 689 (2017).
  12. H. Turlier, B. Audoly, J. Prost, and J.-F. Joanny, Furrow constriction in animal cell cytokinesis, Biophys. J. 106, 114 (2014).
  13. A. C. Martin, M. Gelbart, R. Fernandez-Gonzalez, M. Kaschube, and E. F. Wieschaus, Integration of contractile forces during tissue invagination, J. Cell Biol. 188, 735 (2010).
  14. C.-P. Heisenberg and Y. Bellaïche, Forces in tissue morphogenesis and patterning, Cell 153, 948 (2013).
  15. J. Ranft, M. Basan, J. Elgeti, J.-F. Joanny, J. Prost, and F. Jülicher, Fluidization of tissues by cell division and apoptosis, Proc. Natl. Acad. Sci. USA 107, 20863 (2010).
  16. A. Daeden, A. Mietke, E. Derivery, C. Seum, F. Jülicher, and M. Gonzalez-Gaitan, Polarized branched actin modulates cortical mechanics to produce unequal-size daughters during asymmetric division, Nat. Cell Biol. 25, 235 (2023).
  17. M. Denk-Lobnig, J. F. Totz, N. C. Heer, J. Dunkel, and A. C. Martin, Combinatorial patterns of graded RhoA activation and uniform F-actin depletion promote tissue curvature, Development 148, dev199232 (2021).
  18. G. Salbreux and F. Jülicher, Mechanics of active surfaces, Phys. Rev. E 96, 032404 (2017).
  19. A. Mietke, F. Jülicher, and I. F. Sbalzarini, Self-organized shape dynamics of active surfaces, Proc. Natl. Acad. Sci. USA 116, 29 (2019).
  20. A. Mietke, V. Jemseena, K. V. Kumar, I. F. Sbalzarini, and F. Jülicher, Minimal model of cellular symmetry breaking, Phys. Rev. Lett. 123, 188101 (2019).
  21. A. Torres-Sánchez, M. K. Winter, and G. Salbreux, Interacting active surfaces: A model for three-dimensional cell aggregates, PLoS Comput. Biol. 18, e1010762 (2022).
  22. D. Khoromskaia and G. Salbreux, Active morphogenesis of patterned epithelial shells, eLife 12, e75878 (2023).
  23. R. Bailleul, N. Cuny, D. Khoromoskaia, S. Basu, G. Bergamini, P. Cucurachi, S. Rupp, A. Guse, C. Curantz, N. Swinhoe, P. Cleves, J. Craggs, S. Fujita, Y.-I. Nakajima, P. J. Steenbergen, A. Diz-Muñoz, G. Salbreux, and A. Ikmi, Cross-species biomechanical determinants of shape diversity, bioRxiv.
  24. P. B. Canham, The minimum energy of bending as a possible explanation of the biconcave shape of the human red blood cell, J. Theor. Biol. 26, 61 (1970).
  25. W. Helfrich, Elastic properties of lipid bilayers: Theory and possible experiments, Z. Naturforsch., C 28, 693 (1973).
  26. E. A. Evans, Bending resistance and chemically induced moments in membrane bilayers, Biophys. J. 14, 923 (1974).
  27. O.-Y. Zhong-can and W. Helfrich, Instability and deformation of a spherical vesicle by pressure, Phys. Rev. Lett. 59, 2486 (1987).
  28. O.-Y. Zhong-can and W. Helfrich, Bending energy of vesicle membranes: General expressions for the first, second, and third variation of the shape energy and applications to spheres and cylinders, Phys. Rev. A 39, 5280 (1989).
  29. R. Lipowsky, The conformation of membranes, Nature (London) 349, 475 (1991).
  30. U. Seifert, K. Berndl, and R. Lipowsky, Shape transformations of vesicles: Phase diagram for spontaneous-curvature and bilayer-coupling models, Phys. Rev. A 44, 1182 (1991).
  31. H. Jian-Guo and O.-Y. Zhong-Can, Shape equations of the axisymmetric vesicles, Phys. Rev. E 47, 461 (1993).
  32. F. Jülicher and U. Seifert, Shape equations for axisymmetric vesicles: A clarification, Phys. Rev. E 49, 4728 (1994).
  33. R. Lipowsky, Domain-induced budding of fluid membranes, Biophys. J. 64, 1133 (1993).
  34. F. Jülicher and R. Lipowsky, Shape transformations of vesicles with intramembrane domains, Phys. Rev. E 53, 2670 (1996).
  35. I. Derényi, F. Jülicher, and J. Prost, Formation and interaction of membrane tubes, Phys. Rev. Lett. 88, 238101 (2002).
  36. U. Seifert, Configurations of fluid membranes and vesicles, Adv. Phys. 46, 13 (1997).
  37. J. Hassinger, G. Oster, D. Drubin, and P. Rangamani, Design principles for robust vesiculation in clathrin-mediated endocytosis, Biophys. J. 112, 310a (2017).
  38. N. Walani, J. Torres, and A. Agrawal, Endocytic proteins drive vesicle growth via instability in high membrane tension environment, Proc. Natl. Acad. Sci. USA 112, E1423 (2015).
  39. L. V. Chernomordik and M. M. Kozlov, Mechanics of membrane fusion, Nat. Struct. Mol. Biol. 15, 675 (2008).
  40. M. Arroyo and A. DeSimone, Relaxation dynamics of fluid membranes, Phys. Rev. E 79, 031915 (2009).
  41. M. Doi, Onsager's variational principle in soft matter, J. Phys.: Condens. Matter 23, 284118 (2011).
  42. M. Arroyo, N. Walani, A. Torres-Sánchez, and D. Kaurin, Onsager's variational principle in soft matter: Introduction and application to the dynamics of adsorption of proteins onto fluid membranes, in The Role of Mechanics in the Study of Lipid Bilayers, edited by D. Steigmann (Springer International Publishing, Cham, 2018), pp. 287–332.
  43. G. Salbreux, F. Jülicher, J. Prost, and A. Callan-Jones, Theory of nematic and polar active fluid surfaces, Phys. Rev. Res. 4, 033158 (2022).
  44. A. Katchalsky and P. F. Curran, Nonequilibrium Thermodynamics in Biophysics (Harvard University Press, Cambridge, MA, 1965).
  45. L. Onsager, Reciprocal relations in irreversible processes. I., Phys. Rev. 37, 405 (1931).
  46. L. Onsager, Reciprocal relations in irreversible processes. II., Phys. Rev. 38, 2265 (1931).
  47. F. Jülicher, S. W. Grill, and G. Salbreux, Hydrodynamic theory of active matter, Rep. Prog. Phys. 81, 076601 (2018).
  48. A. Torres-Sánchez, D. Millán, and M. Arroyo, Modelling fluid deformable surfaces with an emphasis on biological interfaces, J. Fluid Mech. 872, 218 (2019).
  49. A. Sahu, Y. A. Omar, R. A. Sauer, and K. K. Mandadapu, Arbitrary Lagrangian-Eulerian finite element method for curved and deforming surfaces: I. General theory and application to fluid interfaces, J. Comput. Phys. 407, 109253 (2020).
  50. GitHub, www.github.com/amietke/ActiveShapeSpaces.
  51. C. Hirt, A. Amsden, and J. Cook, An arbitrary Lagrangian-Eulerian computing method for all flow speeds, J. Comput. Phys. 14, 227 (1974).
  52. See Supplemental Material at http://link.aps.org/supplemental/10.1103/jlps-h2qg for detailed derivations of variational equations and of conservation laws in terms of ALE parametrizations, which includes Refs. [70, 71].
  53. F. Jülicher, A. Ajdari, and J. Prost, Modeling molecular motors, Rev. Mod. Phys. 69, 1269 (1997).
  54. J. Prost, F. Jülicher, and J. F. Joanny, Active gel physics, Nat. Phys. 11, 111 (2015).
  55. J. Meixner, Zur Thermodynamik der irreversiblen Prozesse in Gasen mit chemisch reagierenden, dissoxiierenden und anregbaren komponenten, Ann. Phys. 435, 244 (1943).
  56. J. Kierzenka and L. F. Shampine, A BVP solver based on residual control and the Maltab PSE, ACM Trans. Math. Software 27, 299 (2001).
  57. R. Ma and J. Berro, Endocytosis against high turgor pressure is made easier by partial protein coating and a freely rotating base, Biophys. J. 120, 52a (2021).
  58. A. Agrawal and D. J. Steigmann, Modeling protein-mediated morphology in biomembranes, Biomech. Model. Mechanobiol. 8, 371 (2009).
  59. J. S. Bois, F. Jülicher, and S. W. Grill, Pattern formation in active fluids, Phys. Rev. Lett. 106, 028103 (2011).
  60. M. Bonati, L. D. Wittwer, S. Aland, and E. Fischer-Friedrich, On the role of mechanosensitive binding dynamics in the pattern formation of active surfaces, New J. Phys. 24, 073044 (2022).
  61. M. Théry, A. Jiménez-Dalmaroni, V. Racine, M. Bornens, and F. Jülicher, Experimental and theoretical study of mitotic spindle orientation, Nature (London) 447, 493 (2007).
  62. N. T. L. Rodrigues, S. Lekomtsev, S. Jananji, J. Kriston-Vizi, G. R. X. Hickson, and B. Baum, Kinetochore-localized PP1–Sds22 couples chromosome segregation to polar relaxation, Nature (London) 524, 489 (2015).
  63. J. Sedzinski, M. Biro, A. Oswald, J.-Y. Tinevez, G. Salbreux, and E. Paluch, Polar actomyosin contractility destabilizes the position of the cytokinetic furrow, Nature (London) 476, 462 (2011).
  64. M. J. Lighthill, On the squirming motion of nearly spherical deformable bodies through liquids at very small Reynolds numbers, Commun. Pure Appl. Math. 5, 109 (1952).
  65. E. Lauga and T. R. Powers, The hydrodynamics of swimming microorganisms, Rep. Prog. Phys. 72, 096601 (2009).
  66. M. Schmitt and H. Stark, Marangoni flow at droplet interfaces: Three-dimensional solution and applications, Phys. Fluids 28, 012106 (2016).
  67. A. Zöttl and H. Stark, Emergent behavior in active colloids, J. Phys.: Condens. Matter 28, 253001 (2016).
  68. C. A. Whitfield and R. J. Hawkins, Instabilities, motion and deformation of active fluid droplets, New J. Phys. 18, 123016 (2016).
  69. L. D. Wittwer and S. Aland, A computational model of self-organized shape dynamics of active surfaces in fluids, J. Comp. Phys. X: X 17, 100126 (2023).
  70. E. Kreyszig, Introduction to Differential Geometry and Riemannian Geometry (University of Toronto Press, Toronto, 1968).
  71. A. Sahu, R. A. Sauer, and K. K. Mandadapu, Irreversible thermodynamics of curved lipid membranes, Phys. Rev. E 96, 042409 (2017).
