Randomized benchmarking with leakage errors

Yi-Hsiang Chen* and Charles H. Baldwin†

  • Quantinuum, 303 South Technology Court, Broomfield, Colorado 80021, USA

  • *Contact author: yihsiang.chen@quantinuum.com
  • †Contact author: charles.baldwin@quantinuum.com
PDF

Phys. Rev. Research 7, 043065 – Published 17 October, 2025

DOI: https://doi.org/10.1103/j8sz-6ws9

Abstract

Leakage errors are unwanted transfer of population outside of a defined computational subspace and they occur in almost every platform for quantum computing. While prevalent, leakage is often overlooked when measuring and reporting the fidelity of quantum gates with standard methods. In fact, when leakage is substantial it can cause a large overestimation of fidelity from the typical method used to measure fidelity, randomized benchmarking. We provide several methods for properly estimating fidelity in the presence of leakage errors that are applicable in different error regimes with carefully chosen sequence lengths. Then, we numerically demonstrate the methods for two-qubit randomized benchmarking, which often have the largest errors. Finally, we reanalyze previously shared data from Quantinuum systems with some of the methods provided.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (34)

  1. R. Ozeri, W. M. Itano, R. B. Blakestad, J. Britton, J. Chiaverini, J. D. Jost, C. Langer, D. Leibfried, R. Reichle, S. Seidelin, J. H. Wesenberg, and D. J. Wineland, Errors in trapped-ion quantum gates due to spontaneous photon scattering, Phys. Rev. A 75, 042329 (2007).
  2. I. D. Moore, W. C. Campbell, E. R. Hudson, M. J. Boguslawski, D. J. Wineland, and D. T. C. Allcock, Photon scattering errors during stimulated Raman transitions in trapped-ion qubits, Phys. Rev. A 107, 032413 (2023).
  3. S. J. Evered, D. Bluvstein, M. Kalinowski, S. Ebadi, T. Manovitz, H. Zhou, S. H. Li, A. A. Geim, T. T. Wang, N. Maskara, H. Levine, G. Semeghini, M. Greiner, V. Vuletić, and M. D. Lukin, High-fidelity parallel entangling gates on a neutral-atom quantum computer, Nature (London) 622, 268 (2023).
  4. C. J. Wood and J. M. Gambetta, Quantification and characterization of leakage errors, Phys. Rev. A 97, 032306 (2018).
  5. R. Acharya, L. Aghababaie-Beni, I. Aleiner, T. I. Andersen, M. Ansmann, F. Arute et al., Quantum error correction below the surface code threshold, Nature (London) 638, 920 (2025).
  6. R. W. Andrews, C. Jones, M. D. Reed, A. M. Jones, S. D. Ha, M. P. Jura, J. Kerckhoff, M. Levendorf, S. Meenehan, S. T. Merkel, A. Smith, B. Sun, A. J. Weinstein, M. T. Rakher, T. D. Ladd, and M. G. Borselli, Quantifying error and leakage in an encoded Si/SiGe triple-dot qubit, Nat. Nanotechnol. 14, 747 (2019).
  7. E. Chertkov, Y.-H. Chen, M. Lubasch, D. Hayes, and M. Foss-Feig, Robustness of near-thermal dynamics on digital quantum computers, arXiv:2410.10794.
  8. N. C. Brown, A. W. Cross, and K. R. Brown, Critical faults of leakage errors on the surface code, arXiv:2003.05843.
  9. E. Magesan, J. M. Gambetta, and J. Emerson, Characterizing quantum gates via randomized benchmarking, Phys. Rev. A 85, 042311 (2012).
  10. S. A. Moses, C. H. Baldwin, M. S. Allman, R. Ancona, L. Ascarrunz, C. Barnes et al., A race-track trapped-ion quantum processor, Phys. Rev. X 13, 041052 (2023).
  11. D. C. McKay, I. Hincks, E. J. Pritchett, M. Carroll, L. C. G. Govia, and S. T. Merkel, Benchmarking quantum processor performance at scale, arXiv:2311.05933.
  12. A. M. Polloreno, A. Carignan-Dugas, J. Hines, R. Blume-Kohout, K. Young, and T. Proctor, A theory of direct randomized benchmarking, Quantum 9, 1848 (2025).
  13. J. M. Epstein, A. W. Cross, E. Magesan, and J. M. Gambetta, Investigating the limits of randomized benchmarking protocols, Phys. Rev. A 89, 062321 (2014).
  14. T. Chasseur and F. K. Wilhelm, Complete randomized benchmarking protocol accounting for leakage errors, Phys. Rev. A 92, 042333 (2015).
  15. J. J. Wallman, M. Barnhill, and J. Emerson, Robust characterization of loss rates, Phys. Rev. Lett. 115, 060501 (2015).
  16. J. J. Wallman, M. Barnhill, and J. Emerson, Robust characterization of leakage errors, New J. Phys. 18, 043021 (2016).
  17. B. Wu, X. Wang, X. Yuan, C. Huang, and J. Chen, Leakage benchmarking for universal gate sets, Entropy 26, 71 (2024).
  18. J. Claes, E. Rieffel, and Z. Wang, Character randomized benchmarking for non-multiplicity-free groups with applications to subspace, leakage, and matchgate randomized benchmarking, PRX Quantum 2, 010351 (2021).
  19. Z. Chen et al., Measuring and suppressing quantum state leakage in a superconducting qubit, Phys. Rev. Lett. 116, 020501 (2016).
  20. A. G. Radnaev, W. C. Chung, D. C. Cole, D. Mason, T. G. Ballance, M. J. Bedalov et al., A universal neutral-atom quantum computer with individual optical addressing and non-destructive readout, arXiv:2408.08288.
  21. J. A. Muniz, M. Stone, D. T. Stack, M. Jaffe, J. M. Kindem, L. Wadleigh et al., High-fidelity universal gates in the Yb171 ground state nuclear spin qubit, arXiv:2411.11708.
  22. More explicitly, let us consider an error process with a leakage error probability of pL and a seepage probability pS. For a circuit with ℓ gates, the probability of one leakage event is p(oneleakage)=ℓpL(1−pL)ℓ−1=O(ℓpL). If the quantum state starts in the computational space, then a seepage event can happen only after a leakage event has happened. Therefore, the probability of a one seepage event is p(oneseepage)=∑k=1ℓ(ℓ−k)pS(1−pS)ℓ−k−1pL(1−pL)ℓ−1=O(ℓ2pLpS), which is a second-order effect when pS≈pL.
  23. To show this, consider the non-negative quantity 〈k|Λ(|i〉〈i|)|k〉≥0, where 〈k|i〉=0 and |i〉〈i|,|k〉〈k|∈χC. This implies t−r≥0 from Eq. (8).
  24. R. Harper, I. Hincks, C. Ferrie, S. T. Flammia, and J. J. Wallman, Statistical analysis of randomized benchmarking, Phys. Rev. A 99, 052350 (2019).
  25. A. J. Weinstein et al., Universal logic with encoded spin qubits in silicon, Nature (London) 615, 817 (2023).
  26. R. Stricker, D. Vodola, A. Erhard, L. Postler, M. Meth, M. Ringbauer, P. Schindler, T. Monz, M. Müller, and R. Blatt, Experimental deterministic correction of qubit loss, Nature (London) 585, 207 (2020).
  27. It might be more useful in some contexts to estimate λ but several methods directly estimate r and then extracting λ has higher uncertainty due to the uncertainty in r and t adding but the estimate coming from the difference λ=t−r. With r or λ, we can still estimate the fidelity by scaling the factors and adding with t.
  28. In general, a system may have multiple leakage subspaces that have different population transfer rates. For example, two qubits have at least five different leakage subspaces due to the leakage subspaces of each individual qubit, e.g., {|0L〉,|1L〉,|L0〉,|L1〉,|LL〉}.
  29. https://github.com/cqcl/quantinuum-hardware-specifications.
  30. J. M. Pino, J. M. Dreiling, C. Figgatt, J. P. Gaebler, S. A. Moses, M. S. Allman, C. H. Baldwin, M. Foss-Feig, D. Hayes, K. Mayer, C. Ryan-Anderson, and B. Neyenhuis, Demonstration of the trapped-ion quantum CCD computer architecture, Nature (London) 592, 209 (2021).
  31. M. A. Fogarty, M. Veldhorst, R. Harper, C. H. Yang, S. D. Bartlett, S. T. Flammia, and A. S. Dzurak, Nonexponential fidelity decay in randomized benchmarking with low-frequency noise, Phys. Rev. A 92, 022326 (2015).
  32. B. H. Fong and S. T. Merkel, Randomized benchmarking, correlated noise, and Ising models, arXiv:1703.09747.
  33. D. Hayes, D. Stack, B. Bjork, A. C. Potter, C. H. Baldwin, and R. P. Stutz, Eliminating leakage errors in hyperfine qubits, Phys. Rev. Lett. 124, 170501 (2020).
  34. M. Kang, W. C. Campbell, and K. R. Brown, Quantum error correction with metastable states of trapped ions using erasure conversion, PRX Quantum 4, 020358 (2023).
