Separation of light ion species in the transition from shock-dominated to compressive inertial confinement fusion implosions

N. V. Kabadi*,†, P. J. Adrian‡, T. Evans, M. Gatu Johnson, C. K. Li, F. H. Séguin, G. D. Sutcliffe§, R. D. Petrasso, and J. A. Frenje

C. Forrest, V. Yu Glebov, R. Janezic, and C. Stoeckl∥

  • *Contact author: neelkabadi@lle.rochester.edu
  • †Present address: University of Rochester Laboratory for Laser Energetics, Rochester, NY, USA.
  • ‡Present address: Pacific Fusion, San Leandro, CA, USA.
  • §Present address: Livermore National Laboratory, Livermore, CA, USA.
  • ∥Present address: Marvel Fusion, Hamburg, Germany.
PDF

Phys. Rev. Research 8, 033356 – Published 23 September, 2026

DOI: https://doi.org/10.1103/hzvv-p4d6

Abstract

A series of glass-shell DHe3 gas-filled implosions was carried out on the OMEGA Laser Facility. In these experiments, the thicknesses of the glass shells were varied from 4.2 to 9.4 µm, producing implosions that spanned from shock-to-compression-dominated emission. Data from several diagnostics were used to infer the conditions and nuclear yields for the DHe3-p and DD-n reactions during shock and compression burns. From the inferred yields and ion temperatures, the deuterium fractions in the hot spot during both emission phases were estimated. It is found that there is a substantial surplus (∼5%) of deuterium in the hot spot compared to the initial fill fraction during both shock and compression phases for all implosion types. This is the first measurement indicating persistent species separation throughout both phases of inertial confinement fusion (ICF) implosions. In ICF implosions, deviations from a 50:50 species ratio will decrease the fusion rate, directly impacting performance. Future ICF implosion design work would benefit from including models that capture multi-ion dynamics.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (34)

  1. J. D. Lindl, P. Amendt, R. L. Berger, S. G. Glendinning, S. H. Glenzer, S. W. Haan, R. L. Kauffman, O. L. Landen, and L. J. Suter, The physics basis for ignition using indirect-drive targets on the National Ignition Facility, Phys. Plasmas 11, 339 (2004).
  2. M. Rosenberg, H. Rinderknecht, N. Hoffman, P. Amendt, S. Atzeni, A. Zylstra, C. Li, F. Séguin, H. Sio, M. G. Johnson, et al., Exploration of the transition from the hydrodynamiclike to the strongly kinetic regime in shock-driven implosions, Phys. Rev. Lett. 112, 185001 (2014).
  3. S. Park, S. A. Zhekov, D. N. Burrows, G. P. Garmire, and R. McCray, A Chandra view of the morphological and spectral evolution of supernova remnant 1987A, Astrophys. J. 610, 275 (2004).
  4. M. Miceli, S. Orlando, D. N. Burrows, K. A. Frank, C. Argiroffi, F. Reale, G. Peres, O. Petruk, and F. Bocchino, Collisionless shock heating of heavy ions in SN 1987A, Nat. Astron. 3, 236 (2019).
  5. H. G. Rinderknecht, M. Rosenberg, C. Li, N. Hoffman, G. Kagan, A. Zylstra, H. Sio, J. Frenje, M. Gatu Johnson, F. Seguin, R. Petrasso, P. Amendt, C. Bellei, S. Wilks, J. Delettrez, V. Glebov, C. Stoeckl, T. Sangster, D. Meyerhofer, and A. Nikroo, Ion thermal decoupling and species separation in shock-driven implosions, Phys. Rev. Lett. 114, 025001 (2015).
  6. H. Sio, O. Larroche, S. Atzeni, N. V. Kabadi, J. A. Frenje, M. Gatu Johnson, C. Stoeckl, C. K. Li, C. J. Forrest, V. Glebov, P. J. Adrian, A. Bose, A. Birkel, S. P. Regan, F. H. Seguin, and R. D. Petrasso, Probing ion species separation and ion thermal decoupling in shock-driven implosions using multiple nuclear reaction histories, Phys. Plasmas 26, 072703 (2019).
  7. H. Sio, J. Frenje, A. Le, S. Atzeni, T. Kwan, M. Gatu Johnson, G. Kagan, C. Stoeckl, C. Li, C. Parker, et al., Observations of multiple nuclear reaction histories and fuel-ion species dynamics in shock-driven inertial confinement fusion implosions, Phys. Rev. Lett. 122, 035001 (2019).
  8. H. Rinderknecht, P. Amendt, M. Rosenberg, C. Li, J. Frenje, M. Gatu Johnson, H. Sio, F. Séguin, R. Petrasso, A. Zylstra, G. Kagan, N. Hoffman, D. Svyatsky, S. Wilks, V. Y. Glebov, C. Stoeckl, and T. Sangster, Ion kinetic dynamics in strongly-shocked plasmas relevant to ICF, Nucl. Fusion 57, 066014 (2017).
  9. D. T. Casey, J. A. Frenje, M. Gatu Johnson, M. J.-E. Manuel, H. G. Rinderknecht, N. Sinenian, F. H. Séguin, C. K. Li, R. D. Petrasso, P. B. Radha, et al., Evidence for stratification of deuterium-tritium fuel in inertial confinement fusion implosions, Phys. Rev. Lett. 108, 075002 (2012).
  10. J. R. Rygg, J. A. Frenje, C. K. Li, F. H. Séguin, R. D. Petrasso, J. A. Delettrez, V. Y. Glebov, V. N. Goncharov, D. D. Meyerhofer, S. P. Regan, T. C. Sangster, and C. Stoeckl, Tests of the hydrodynamic equivalence of direct-drive implosions with different D2 and He3 mixtures, Phys. Plasmas 13, 052702 (2006).
  11. H. W. Herrmann, J. R. Langenbrunner, J. M. Mack, J. H. Cooley, D. C. Wilson, S. C. Evans, T. J. Sedillo, G. A. Kyrala, S. E. Caldwell, C. S. Young, et al., Anomalous yield reduction in direct-drive deuterium/tritium implosions due to He3 addition, Phys. Plasmas 16, 056312 (2009).
  12. S. C. Hsu, T. R. Joshi, P. Hakel, E. L. Vold, M. J. Schmitt, N. M. Hoffman, R. M. Rauenzahn, G. Kagan, X.-Z. Tang, R. C. Mancini, Y. Kim, and H. W. Herrmann, Observation of interspecies ion separation in inertial-confinement-fusion implosions, Europhys. Lett. 115, 65001 (2016).
  13. T. R. Joshi, S. C. Hsu, P. Hakel, N. M. Hoffman, H. Sio, and R. C. Mancini, Progress on observations of interspecies ion separation in inertial-confinement-fusion implosions via imaging x-ray spectroscopy, Phys. Plasmas 26, 062702 (2019).
  14. H. G. Rinderknecht, P. A. Amendt, S. C. Wilks, and G. Collins, Kinetic physics in ICF: Present understanding and future directions, Plasma Phys. Control. Fusion 60, 064001 (2018).
  15. O. Larroche, H. G. Rinderknecht, M. J. Rosenberg, N. M. Hoffman, S. Atzeni, R. D. Petrasso, P. A. Amendt, and F. H. Séguin, Ion-kinetic simulations of D- He3 gas-filled inertial confinement fusion target implosions with moderate to large Knudsen number, Phys. Plasmas 23, 012701 (2016).
  16. W. T. Taitano, A. N. Simakov, L. Chacón, and B. Keenan, Yield degradation in inertial-confinement-fusion implosions due to shock-driven kinetic fuel-species stratification and viscous heating, Phys. Plasmas 25, 056310 (2018).
  17. T. R. Boehly, D. L. Brown, R. S. Craxton, R. L. Keck, J. P. Knauer, J. H. Kelly, T. J. Kessler, S. A. Kumpan, S. J. Loucks, S. A. Letzring, F. J. Marshall, R. L. McCrory, S. F. B. Morse, W. Seka, J. M. Soures, and C. P. Verdon, Initial performance results of the OMEGA laser system, Opt. Commun. 133, 495 (1997).
  18. N. V. Kabadi, R. Simpson, P. J. Adrian, A. Bose, J. A. Frenje, M. Gatu Johnson, B. Lahmann, C. K. Li, C. E. Parker, F. H. Séguin, et al., Thermal decoupling of deuterium and tritium during the inertial confinement fusion shock-convergence phase, Phys. Rev. E 104, L013201 (2021).
  19. V. Y. Glebov, C. Stoeckl, T. C. Sangster, S. Roberts, G. J. Schmid, R. A. Lerche, and M. J. Moran, Prototypes of National Ignition Facility neutron time-of-flight detectors tested on OMEGA, Rev. Sci. Instrum. 75, 3559 (2004).
  20. F. H. Seguin, J. A. Frenje, C. K. Li, D. G. Hicks, S. Kurebayashi, J. R. Rygg, B.-E. Schwartz, R. D. Petrasso, S. Roberts, J. M. Soures, D. D. Meyerhofer, T. C. Sangster, J. P. Knauer, C. Sorce, V. Y. Glebov, C. Stoeckl, T. W. Phillips, R. J. Leeper, K. Fletcher, and S. Padalino, Spectrometry of charged particles from inertial-confinement-fusion plasmas, Rev. Sci. Instrum. 74, 975 (2003).
  21. H. Sio, J. A. Frenje, J. Katz, C. Stoeckl, D. Weiner, M. Bedzyk, V. Glebov, C. Sorce, M. Gatu Johnson, H. G. Rinderknecht, et al., A particle x-ray temporal diagnostic (PXTD) for studies of kinetic, multi-ion effects, and ion-electron equilibration rates in inertial confinement fusion plasmas at OMEGA (invited), Rev. Sci. Instrum. 87, 11D701 (2016).
  22. V. A. Smalyuk, P. B. Radha, J. A. Delettrez, V. Y. Glebov, V. N. Goncharov, D. D. Meyerhofer, S. P. Regan, S. Roberts, T. C. Sangster, J. M. Soures, C. Stoeckl, J. A. Frenje, C. K. Li, R. D. Petrasso, and F. H. Séguin, Time-resolved areal-density measurements with proton spectroscopy in spherical implosions, Phys. Rev. Lett. 90, 135002 (2003).
  23. J. A. Frenje, C. K. Li, F. H. Seguin, J. Deciantis, S. Kurebayashi, J. R. Rygg, R. D. Petrasso, J. Delettrez, V. Y. Glebov, C. Stoeckl, F. J. Marshall, D. D. Meyerhofer, T. C. Sangster, V. A. Smalyuk, and J. M. Soures, Measuring shock-bang timing and ρR evolution of DHe3 implosions at OMEGA, Phys. Plasmas 11, 2798 (2004).
  24. G. Zimmerman, Recent developments in Monte Carlo techniques, LLNL Report No. UCRL-JC-105616, 1990.
  25. N. V. Kabadi, P. J. Adrian, A. Bose, D. T. Casey, J. A. Frenje, M. G. Johnson, B. Lahmann, O. M. Mannion, R. D. Petrasso, H. G. Rinderknecht, F. H. Séguin, H. W. Sio, G. D. Sutcliffe, and A. B. Zylstra, A second order yield-temperature relation for accurate inference of burn-averaged quantities in multi-species plasmas, Phys. Plasmas 28, 022701 (2021).
  26. H.-S. Bosch and G. M. Hale, Improved formulas for fusion cross-sections and thermal reactivities, Nucl. Fusion 32, 611 (1992).
  27. G. Kagan and X.-Z. Tang, Electro-diffusion in a plasma with two ion species, Phys. Plasmas 19, 082709 (2012).
  28. G. Kagan and X.-Z. Tang, Thermo-diffusion in inertially confined plasmas, Phys. Lett. A 378, 1531 (2014).
  29. N. Kabadi, P. Adrian, C. Stoeckl, A. Sorce, H. W. Sio, M. Bedzyk, T. Evans, S. Ivancic, J. Katz, J. Knauer, J. Pearcy, D. Weiner, R. Betti, A. Birkel, D. Cao, M. G. Johnson, S. P. Regan, R. D. Petrasso, and J. Frenje, The phase-2 particle x-ray temporal diagnostic for simultaneous measurement of multiple x-ray and nuclear emission histories from OMEGA implosions (invited), Rev. Sci. Instrum. 93, 103538 (2022).
  30. N. Kabadi, A. Sorce, C. Stoeckl, H. W. Sio, P. Adrian, M. Bedzyk, J. Frenje, J. Katz, J. Knauer, J. Pearcy, D. Weiner, B. A. Aguirre, R. Betti, A. Birkel, D. Cao, M. Gatu Johnson, D. Patel, R. D. Petrasso, and S. P. Regan, A multi-channel x-ray temporal diagnostic for measurement of time-resolved electron temperature in cryogenic deuterium–tritium implosions at OMEGA, Rev. Sci. Instrum. 92, 023507 (2021).
  31. The MathWorks, Inc., Matlab version: 23.2.0 (r2023b), 2023, https://www.mathworks.com.
  32. L. Ballabio, J. Kallne, and G. Gorini, Relativistic calculation of fusion product spectra for thermonuclear plasmas, Nucl. Fusion 38, 1723 (1998).
  33. Eljen Technology, EJ-232 scintillator, 2021, https://eljentechnology.com/products/plastic-scintillators/ej-232-ej-232q.
  34. J. F. Ziegler, M. Ziegler, and J. Biersack, SRIM—The stopping and range of ions in matter (2010), Nucl. Instrum. Methods Phys. Res., Sect. B 268, 1818 (2010).
