Experimental qudit state estimation via point tomography

D. Martínez1,2,3, L. Pereira4, K. Sawada1,2, P. González1,2, J. Cariñe5, M. Muñoz6, A. Delgado1,2, E. S. Gómez1, S. P. Walborn1,2 et al.

G. Lima1,2,*

  • *Contact author: glima@udec.cl
PDF

Phys. Rev. Research 7, 033119 – Published 4 August, 2025

DOI: https://doi.org/10.1103/gpfl-wdgg

Abstract

Point tomography is an approach to the problem of state estimation, which is arguably the most efficient and simple method for modern high-precision quantum information experiments. In this scenario, the experimenter knows the target state that their device should prepare, except that intrinsic systematic errors will create small discrepancies in the state actually produced. By introducing a kind of informationally complete measurement, dubbed Fisher-symmetric measurements, point tomography determines deviations from the expected state with optimal efficiency. Moreover, the number of outcomes of a measurement saturating the Gill-Massar limit for reconstructing d-dimensional quantum states can be greatly reduced from ∼4d−3 to only 2d−1 outcomes. Thus, improving the measurement overhead as the dimension increases. Here we demonstrate the experimental viability of point tomography. Using a modern photonic platform constructed with state-of-the-art multicore optical fiber technology, we generate four-dimensional quantum states and implement seven-outcome Fisher-symmetric measurements. Our experimental results exhibit the main feature of point tomography, namely, a precision close to the Gill-Massar limit with a single few-outcome measurement. Specifically, we achieved a precision of (3.81±0.05)/N, while the Gill-Massar limit for d=4 is 3/N (N being the ensemble size).

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (40)

  1. S. Lloyd, Enhanced sensitivity of photodetection via quantum illumination, Science 321, 1463 (2008).
  2. M. Szczykulska, T. Baumgratz, and A. Datta, Multi-parameter quantum metrology, Adv. Phys.: X 1, 621 (2016).
  3. F. Albarelli, M. Barbieri, M. G. Genoni, and I. Gianani, A perspective on multiparameter quantum metrology: From theoretical tools to applications in quantum imaging, Phys. Lett. A 384, 126311 (2020).
  4. B. Lanyon, M. Barbieri, M. Almeida, T. Jennewein, T. C. Ralph, K. J. Resch, G. J. Pryde, J. L. O’Brien, A. Gilchrist, and A. G. White, Simplifying quantum logic using higher-dimensional Hilbert spaces, Nat. Phys. 5, 134 (2009).
  5. A. Bocharov, M. Roetteler, and K. M. Svore, Factoring with qutrits: Shor’s algorithm on ternary and metaplectic quantum architectures, Phys. Rev. A 96, 012306 (2017).
  6. A. Babazadeh, M. Erhard, F. Wang, M. Malik, R. Nouroozi, M. Krenn, and A. Zeilinger, High-dimensional single-photon quantum gates: Concepts and experiments, Phys. Rev. Lett. 119, 180510 (2017).
  7. S. Muralidharan, C.-L. Zou, L. Li, J. Wen, and L. Jiang, Overcoming erasure errors with multilevel systems, New J. Phys. 19, 013026 (2017).
  8. M. Taddei et al., Computational advantage from the quantum superposition of multiple temporal orders of photonic gates, PRX Quantum 2, 010320 (2021).
  9. R. D. Gill and S. Massar, State estimation for large ensembles, Phys. Rev. A 61, 042312 (2000).
  10. C. Ferrie, Self-guided quantum tomography, Phys. Rev. Lett. 113, 190404 (2014).
  11. D. H. Mahler, L. A. Rozema, A. Darabi, C. Ferrie, R. Blume-Kohout, and A. M. Steinberg, Adaptive quantum state tomography improves accuracy quadratically, Phys. Rev. Lett. 111, 183601 (2013).
  12. S. S. Straupe, Adaptive quantum tomography, JETP Lett. 104, 510 (2016).
  13. G. I. Struchalin, E. V. Kovlakov, S. S. Straupe, and S. P. Kulik, Adaptive quantum tomography of high-dimensional bipartite systems, Phys. Rev. A 98, 032330 (2018).
  14. F. Huszár and N. M. T. Houlsby, Adaptive Bayesian quantum tomography, Phys. Rev. A 85, 052120 (2012).
  15. L. Pereira, L. Zambrano, J. Cortés-Vega, S. Niklitschek, and A. Delgado, Adaptive quantum tomography in high dimensions, Phys. Rev. A 98, 012339 (2018).
  16. J. M. Renes, R. Blume-Kohout, A. J. Scott, and C. M. Caves, Symmetric informationally complete quantum measurements, J. Math. Phys. 45, 2171 (2004).
  17. D. M. Appleby, H. B. Dang, and C. A. Fuchs, Symmetric informationally-complete quantum states as analogues to orthonormal bases and minimum-uncertainty states, Entropy 16, 1484 (2014).
  18. J. Rehacek, B.-G. Englert, and D. Kaszlikowski, Minimal qubit tomography, Phys. Rev. A 70, 052321 (2004).
  19. W. M. Pimenta et al., Minimal state tomography of spatial qubits using a spatial light modulator, Opt. Express 18, 24423 (2010).
  20. N. Bent, H. Qassim, A. A. Tahir, D. Sych, G. Leuchs, L. L. Sánchez-Soto, E. Karimi, and R. W. Boyd, Experimental realization of quantum tomography of photonic qudits via symmetric informationally complete positive operator-valued measures, Phys. Rev. X 5, 041006 (2015).
  21. R. Stricker, M. Meth, L. Postler, C. Edmunds, C. Ferrie, R. Blatt, P. Schindler, Th. Monz, R. Kueng, and M. Ringbauer, Experimental single-setting quantum state tomography, PRX Quantum 3, 040310 (2022).
  22. N. Li, C. Ferrie, J. A. Gross, A. Kalev, and C. M. Caves, Fisher-symmetric informationally complete measurements for pure states, Phys. Rev. Lett. 116, 180402 (2016).
  23. H. Zhu and M. Hayashi, Universally Fisher-symmetric informationally complete measurements, Phys. Rev. Lett. 120, 030404 (2018).
  24. J. Cariñe, G. Cañas, P. Skrzypczyk, I. Šupić, N. Guerrero, T. Garcia, L. Pereira, M. A. S. Prosser, G. B. Xavier, A. Delgado, S. P. Walborn, D. Cavalcanti, and G. Lima, Multi-core fiber integrated multi-port beam splitters for quantum information processing, Optica 7, 542 (2020).
  25. D. Martínez, E. S. Gómez, J. Cariñe, L. Pereira, A. Delgado, S. P. Walborn, A. Tavakoli, and G. Lima, Certification of a non-projective qudit measurement using multiport beamsplitters, Nat. Phys. 19, 190 (2023).
  26. S. Pirandola et al., Advances in quantum cryptography, Adv. Opt. Photonics 12, 1012 (2020).
  27. A. K. Fedorov, N. Gisin, S. M. Beloussov, A. I. Lvovsky, Quantum computing at the quantum advantage threshold: A down-to-business review, arXiv:2203.17181.
  28. See Supplemental Material at http://link.aps.org/supplemental/10.1103/gpfl-wdgg for futher details about the theory and components employed in the experiment.
  29. D. Richardson, J. Fini, and L. Nelson, Space-division multiplexing in optical fibres, Nat. Photon. 7, 354 (2013).
  30. G. B. Xavier and G. Lima, Quantum information processing with space-division multiplexing optical fibres, Commun. Phys. 3, 9 (2020).
  31. Y. Ding, D. Bacco, K. Dalgaard, X. Cai, X. Zhou, K. Rottwitt, L. K. Oxenløwe, High-dimensional quantum key distribution based on multicore fiber using silicon photonic integrated circuits, npj Quantum Inf. 3, 25 (2017).
  32. G. Cañas, N. Vera, J. Cariñe, P. Gonález, J. Cardenas, P. W. R. Connolly, A. Przysiezna, E. S. Gómez, M. Figueroa, G. Vallone, P. Villoresi, T. Ferreira da Silva, G. B. Xavier, and G. Lima, High-dimensional decoy-state quantum key distribution over multicore telecommunication fibers, Phys. Rev. A 96, 022317 (2017).
  33. S. Sarmiento, S. Etcheverry, J. Aldama, I. H. López, L. T. Vidarte, G. B. Xavier, D. A. Nolan, J. S. Stone, M. J. Li, D. Loeber, and V. Pruneri, Continuous-variable quantum key distribution over a 15 km multi-core fiber, New J. Phys. 24, 063011 (2022).
  34. M. Zahidy, D. Ribezzo, C. De Lazzari et al., Practical high-dimensional quantum key distribution protocol over deployed multicore fiber, Nat. Commun. 15, 1651 (2024).
  35. H. J. Lee, S.-K. Choi, and H. S. Park, Experimental demonstration of four-dimensional photonic spatial entanglement between multi-core optical fibres, Sci. Rep. 7, 4302 (2017).
  36. H. J. Lee and H. S. Park, Generation and measurement of arbitrary four-dimensional spatial entanglement between photons in multicore fibers, Photonics Res. 7, 19 (2019).
  37. E. A. Ortega et al., Experimental space-division multiplexed polarization-entanglement distribution through 12 paths of a multicore fiber, PRX Quantum 2, 040356 (2021).
  38. E. S. Gómez, S. Gómez, I. Machuca, A. Cabello, S. Pádua, S. P. Walborn, and G. Lima, Multidimensional entanglement generation with multicore optical fibers, Phys. Rev. Appl. 15, 034024 (2021).
  39. H. Abarzúa et al., Adaptive-step perturb-and-observe algorithm for multidimensional phase noise stabilization in fiber-based multi-arm Mach-Zehnder interferometers, Algorithms 17, 534 (2024).
  40. J. Shang, Z. Zhang, and H. K. Ng, Superfast maximum-likelihood reconstruction for quantum tomography, Phys. Rev. A 95, 062336 (2017).
