Gauge flux generations of weakly magnetized Dirac spin liquid in a kagomé lattice

Si-Yu Pan1, Jiahao Yang1, and Gang v. Chen1,2,3,*

  • *Contact author: chenxray@pku.edu.cn
PDF

Phys. Rev. Research 7, 043294 – Published 15 December, 2025

DOI: https://doi.org/10.1103/ggsm-bwwy

Abstract

Inspired by the recent progress on the Dirac spin liquid and the kagomé lattice antiferromagnets, we revisit the U(1) Dirac spin liquid on the kagomé lattice and consider the response of this quantum state to the weak magnetic field by examining the matter-gauge coupling. Even though the system is in the strong Mott insulating regime, the Zeeman coupling could induce the internal U(1) gauge flux with the assistance of the Dzyaloshinskii-Moriya interaction. In addition to the perturbatively induced nonuniform flux from the microscopic interactions, the system spontaneously generates the uniform U(1) gauge flux in a nonperturbative fashion to create the spinon Landau levels and thus gains the kinetic energy for the spinon matters. Renormalized mean-field theory is employed to validate these two flux generation mechanisms. The resulting state is argued to be an ordered antiferromagnet with the in-plane magnetic order, and the gapless Goldstone mode behaves like the gapless gauge boson and the spinons appear at higher energies. The dynamic properties of this antiferromagnet and the implication for other matter-gauge-coupled systems are discussed.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (39)

  1. D. C. Tsui, H. L. Stormer, and A. C. Gossard, Two-dimensional magnetotransport in the extreme quantum limit, Phys. Rev. Lett. 48, 1559 (1982).
  2. H. L. Stormer, D. C. Tsui, and A. C. Gossard, The fractional quantum Hall effect, Rev. Mod. Phys. 71, S298 (1999).
  3. Y. Ran, M. Hermele, P. A. Lee, and X.-G. Wen, Projected-Wave-Function study of the spin- 1/2 Heisenberg model on the kagomé lattice, Phys. Rev. Lett. 98, 117205 (2007).
  4. Y.-M. Lu, Y. Ran, and P. A. Lee, Z2 Spin liquid in S=12 Heisenberg model on kagome lattice: A projective symmetry-group study of Schwinger fermion mean-field states, Phys. Rev. B 83, 224413 (2011).
  5. S. Yan, D. A. Huse, and S. R. White, Spin-liquid ground state of the S=1/2 kagome Heisenberg antiferromagnet, Science 332, 1173 (2011).
  6. Z. Hao and O. Tchernyshyov, Fermionic spin excitations in two- and three-dimensional antiferromagnets, Phys. Rev. Lett. 103, 187203 (2009).
  7. M. Hermele, Y. Ran, P.A. Lee, and X.-G. Wen, Properties of an algebraic spin liquid on the kagome lattice, Phys. Rev. B 77, 224413 (2008).
  8. I. Dzyaloshinsky, A thermodynamic theory of “weak” ferromagnetism of antiferromagnetics, J. Phys. Chem. Solids 4, 241 (1958).
  9. T. Moriya, Anisotropic superexchange interaction and weak ferromagnetism, Phys. Rev. 120, 91 (1960).
  10. P. A. Lee and N. Nagaosa, Proposal to use neutron scattering to access scalar spin chirality fluctuations in kagome lattices, Phys. Rev. B 87, 064423 (2013).
  11. S. Gazit, M. Randeria, and A. Vishwanath, Emergent Dirac fermions and broken symmetries in confined and deconfined phases of Z2 gauge theories, Nat. Phys. 13, 484 (2017).
  12. O. Cépas, C. M. Fong, P. W. Leung, and C. Lhuillier, Quantum phase transition induced by Dzyaloshinskii-Moriya interactions in the kagome antiferromagnet, Phys. Rev. B 78, 140405(R) (2008).
  13. M. Elhajal, B. Canals, and C. Lacroix, Symmetry breaking due to Dzyaloshinsky-Moriya interactions in the kagomé lattice, Phys. Rev. B 66, 014422 (2002).
  14. Y. H. Gao and G. Chen, Topological thermal Hall effect for topological excitations in spin liquid: Emergent Lorentz force on the spinons, SciPost Phys. Core 2, 004 (2020).
  15. X. G. Wen, F. Wilczek, and A. Zee, Chiral spin states and superconductivity, Phys. Rev. B 39, 11413 (1989).
  16. Y. Ran, W.-H. Ko, P. A. Lee, and X.-G. Wen, Spontaneous spin ordering of Dirac spin liquid in a magnetic field, Phys. Rev. Lett. 102, 047205 (2009).
  17. O. I. Motrunich, Orbital magnetic field effects in spin liquid with spinon fermi sea: Possible application to κ−(ET)2Cu2(CN)3, Phys. Rev. B 73, 155115 (2006).
  18. O. I. Motrunich, Variational study of triangular lattice spin-1/2 model with ring exchanges and spin liquid state in κ−(ET)2Cu2(CN)3, Phys. Rev. B 72, 045105 (2005).
  19. Y. Shen, Y.-D. Li, H. Wo, Y. Li, S. Shen, B. Pan, Q. Wang, H. C. Walker, P. Steffens, M. Boehm, Y. Hao, D. L. Quintero-Castro, L. W. Harriger, M. D. Frontzek, L. Hao, S. Meng, Q. Zhang, G. Chen, and J. Zhao, Evidence for a spinon fermi surface in a triangular-lattice quantum-spin-liquid candidate, Nature (London) 540, 559 (2016).
  20. Y.-D. Li and G. Chen, Detecting spin fractionalization in a spinon fermi surface spin liquid, Phys. Rev. B 96, 075105 (2017).
  21. L. Balents and O. A. Starykh, Collective spinon spin wave in a magnetized U(1) spin liquid, Phys. Rev. B 101, 020401(R) (2020).
  22. T. Qin, Q. Niu, and J. Shi, Energy magnetization and the thermal Hall effect, Phys. Rev. Lett. 107, 236601 (2011).
  23. X.-T. Zhang, Y. H. Gao, and G. Chen, Thermal Hall effects in quantum magnets, Phys. Rep. 1070, 1 (2024).
  24. A. Maity, H. Guo, S. Sachdev, and V. Tripathi, Thermal Hall response of an abelian chiral spin liquid at finite temperatures, Phys. Rev. B 111, 205119 (2025).
  25. Y. Teng, Y. Zhang, R. Samajdar, M. S. Scheurer, and S. Sachdev, Unquantized thermal Hall effect in quantum spin liquids with spinon fermi surfaces, Phys. Rev. Res. 2, 033283 (2020).
  26. C. Gros, Physics of projected wavefunctions, Ann. Phys. 189, 53 (1989).
  27. L.-W. He and J.-X. Li, Spinon quantum spin Hall state in the kagome antiferromagnet with a Dzyaloshinskii-Moriya interaction, Phys. Rev. B 110, 035131 (2024).
  28. Y. Iqbal, W.-J. Hu, R. Thomale, D. Poilblanc, and F. Becca, Spin liquid nature in the Heisenberg J1−J2 triangular antiferromagnet, Phys. Rev. B 93, 144411 (2016).
  29. Y. Iqbal, F. Ferrari, A. Chauhan, A. Parola, D. Poilblanc, and F. Becca, Gutzwiller projected states for the J1−J2 Heisenberg model on the kagome lattice: Achievements and pitfalls, Phys. Rev. B 104, 144406 (2021).
  30. S. Sorella, Wave function optimization in the variational Monte Carlo method, Phys. Rev. B 71, 241103(R) (2005).
  31. M. Ogata and A. Himeda, Superconductivity and antiferromagnetism in an extended Gutzwiller approximation for t−J model: Effect of double-occupancy exclusion, J. Phys. Soc. Jpn. 72, 374 (2003).
  32. F. C. Zhang, C. Gros, T. M. Rice, and H. Shiba, A renormalised Hamiltonian approach to a resonant valence bond wavefunction, Supercond. Sci. Technol. 1, 36 (1988).
  33. L. Du, Q. Chen, A. D. Barr, A. R. Barr, and G. A. Fiete, Floquet Hofstadter butterfly on the kagome and triangular lattices, Phys. Rev. B 98, 245145 (2018).
  34. H. Jia, B. Ma, Z. D. Wang, and G. Chen, Quantum spin supersolid as a precursory Dirac spin liquid in a triangular lattice antiferromagnet, Phys. Rev. Res. 6, 033031 (2024).
  35. A. Bose and A. Paramekanti, Spin dynamics of an easy-plane Dirac spin liquid in a frustrated XY model: Application to honeycomb cobaltates, Phys. Rev. B 111, 104435 (2025).
  36. M. Zhu, V. Romerio, N. Steiger, S.D. Nabi, N. Murai, S. Ohira-Kawamura, K. Y. Povarov, Y. Skourski, R. Sibille, L. Keller, Z. Yan, S. Gvasaliya, and A. Zheludev, Continuum excitations in a spin supersolid on a triangular lattice, Phys. Rev. Lett. 133, 186704 (2024).
  37. M. Bintz, V. S. Liu, J. Hauschild, A. Khalifa, S. Chatterjee, M. P. Zaletel, and N. Y. Yao, Dirac spin liquid in quantum dipole arrays, arXiv:2406.00098.
  38. R. Samajdar, M.S. Scheurer, S. Chatterjee, H. Guo, C. Xu, and S. Sachdev, Enhanced thermal Hall effect in the square-lattice Néel state, Nat. Phys. 15, 1290 (2019).
  39. G. Grissonnanche, A. Legros, S. Badoux, E. Lefrançois, V. Zatko, M. Lizaire, F. Laliberté, A. Gourgout, J.-S. Zhou, S. Pyon, T. Takayama, H. Takagi, S. Ono, N. Doiron-Leyraud, and L. Taillefer, Giant thermal Hall conductivity in the pseudogap phase of cuprate superconductors, Nature (London) 571, 376 (2019).
