Distinct behaviors of the two stages of heterogeneous crystallization under different supercooling degrees

Junfeng Zhou1, Zhen Chen1,*, and Lei Xu1,2,†

  • *Contact author: chenzhen_physics@163.com
  • †Contact author: xuleixu@cuhk.edu.hk
PDF

Phys. Rev. Research 8, 033256 – Published 1 September, 2026

DOI: https://doi.org/10.1103/gfzw-xq28

Abstract

Crystallites form in supercooled liquids as particles rearrange into ordered structures, driven by thermal fluctuations or external stimuli. While the thermodynamics of heterogeneous crystallization under boundary constraints is well described by classical nucleation theory, the kinetics of symmetry formation—particularly in systems far from the transition point—remains poorly understood. In this study, we investigate the heterogeneous crystallization of a colloidal system across a wide range of effective supercooling degrees by varying the volume fraction. Using confocal microscopy, we capture the motion and local structures of particles in situ with high spatial and temporal resolution. Our results reveal a consistent crystallization pathway across different supercooling levels: Rotational symmetry forms prior to translational symmetry, with normal modes of local structures playing distinct roles in each stage of crystallization. Notably, the liquid-to-precursor transformation is robust even under deep supercooling, suggesting minimal influence of supercooling on rotational order development. In contrast, the precursor-to-solid transformation is significantly accelerated in denser systems, indicating that translational order is strongly governed by the degree of supercooling. These findings provide insights into the interplay between thermodynamics and kinetics in heterogeneous crystallization and offer guidance for controlling phase transitions across a broad range of disciplines.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (49)

  1. C. H. Lee, H. Matsuhata, A. Yamamoto, T. Ohta, H. Takazawa, K. Ueno, and T. Hirayama, Structural phase transition accompanied by metal-insulator transition in PrRu4P12, J. Phys.: Condens. Matter 13, L45 (2001).
  2. H. Emmerich, H. Löwen, R. Wittkowski, T. Gruhn, G. I. Tóth, G. Tegze, and L. Gránásy, Phase-field-crystal models for condensed matter dynamics on atomic length and diffusive time scales: An overview, Adv. Phys. 61, 665 (2012).
  3. F. C. Meldrum and C. O’ Shaughnessy, Crystallization in confinement, Adv. Mater. 32, 2001068 (2020).
  4. N. Khatun, A. C. Nkele, and K. Bagchi, Crystallization of orientationally ordered matter, J. Phys.: Condens. Matter 37, 261501 (2025).
  5. W. M. Jacobs and D. Frenkel, Phase transitions in biological systems with many components, Biophys. J. 112, 683 (2017).
  6. S. D. Durbin and G. Feher, Protein crystallization, Annu. Rev. Phys. Chem. 47, 171 (1996).
  7. F. Zhang, Nonclassical nucleation pathways in protein crystallization, J. Phys.: Condens. Matter 29, 443002 (2017).
  8. J. M. Choi, A. S. Holehouse, and R. V. Pappu, Physical principles underlying the complex biology of intracellular phase transitions, Annu. Rev. Biophys. 49, 107 (2020).
  9. P. Athron, C. Balazs, and L. Morris, Supercool subtleties of cosmological phase transitions, J. Cosmol. Astropart. Phys. 03 (2023) 006.
  10. A. Mazumdar and W. Graham, Review of cosmic phase transitions: Their significance and experimental signatures, Rep. Prog. Phys. 82, 076901 (2019).
  11. P. G. Debenedetti and F. H. Stillinger, Supercooled liquids and the glass transition, Nature (London) 410, 259 (2001).
  12. I. Pihlajamaa and L. M. C. Janssen, Dissecting mode-coupling theory for supercooled liquids, Phys. Rev. Res. 6, 043319 (2024).
  13. K. K. Tanaka and Y. Kimura, Theoretical analysis of crystallization by homogeneous nucleation of water droplets, Phys. Chem. Chem. Phys. 21, 2410 (2019).
  14. P. Tan, N. Xu, and L. Xu, Visualizing kinetic pathways of homogeneous nucleation in colloidal crystallization, Nat. Phys. 10, 73 (2014).
  15. M. Rauls, K. Bartosch, M. Kind, S. Kuch, R. Lacmann, and A. Mersmann, The influence of impurities on crystallization kinetics–A case study on ammonium sulfate, J. Cryst. Growth 213, 116 (2000).
  16. S. O. Lumsdon, E. W. Kaler, and O. D. Velev, Two-dimensional crystallization of microspheres by a coplanar AC electric field, Langmuir 20, 2108 (2004).
  17. G. Jung and C. F. Petersen, Confinement-induced demixing and crystallization, Phys. Rev. Res. 2, 033207 (2020).
  18. L. T. Shereda, R. G. Larson, and M. J. Solomon, Boundary-driven colloidal crystallization in simple shear flow, Phys. Rev. Lett. 105, 228302 (2010).
  19. D. Moroni, P. Rein ten Wolde, and P. G. Bolhuis, Interplay between structure and size in a critical crystal nucleus, Phys. Rev. Lett. 94, 235703 (2005).
  20. G. Bai, D. Gao, Z. Liu, X. Zhou, and J. Wang, Probing the critical nucleus size for ice formation with graphene oxide nanosheets, Nature (London) 576, 437 (2019).
  21. E. Sanz, C. Vega, J. R. Espinosa, R. Caballero-Bernal, J. L. F. Abascal, and C. Valeriani, Homogeneous ice nucleation at moderate supercooling from molecular simulation, J. Am. Chem. Soc. 135, 15008 (2013).
  22. S. H. Oh, Y. Kauffmann, C. Scheu, W. D. Kaplan, and M. Ruhle, Ordered liquid aluminum at the interface with sapphire, Science 310, 661 (2005).
  23. J. P. Palafox-Hernandez and B. B. Laird, Orientation dependence of heterogeneous nucleation at the Cu-Pb solid-liquid interface, J. Chem. Phys. 145, 211914 (2016).
  24. Y. Chen, Z. Yao, S. Tang, H. Tong, T. Yanagishima, H. Tanaka, and P. Tan, Morphology selection kinetics of crystallization in a sphere, Nat. Phys. 17, 121 (2021).
  25. T. Wu, Y. Sun, N. Li, M. M. de Villiers, and L. Yu, Inhibiting surface crystallization of amorphous indomethacin by nanocoating, Langmuir 23, 5148 (2007).
  26. F. Zabihi and M. Eslamian, Effect of the ultrasonic substrate vibration on nucleation and crystallization of PbI2 crystals and thin films, Crystals 8, 60 (2018).
  27. M. Sun, Z. Cheng, W. Chen, and M. Jones, Understanding symmetry breaking at the single-particle level via the growth of tetrahedron-shaped nanocrystals from higher-symmetry precursors, ACS Nano 15, 15953 (2021).
  28. C. F. Mbah, J. Wang, S. Englisch, P. Bommineni, N. R. Varela-Rosales, E. Spiecker, and M. Engel, Early-stage bifurcation of crystallization in a sphere, Nat. Commun. 14, 5299 (2023).
  29. S. Y. Chung, Y. M. Kim, J. G. Kim, and Y. J. Kim, Multiphase transformation and Ostwald’s rule of stages during crystallization of a metal phosphate, Nat. Phys. 5, 68 (2009).
  30. P. Rein ten Wolde and D. Frenkel, Homogeneous nucleation and the Ostwald step rule, Phys. Chem. Chem. Phys. 1, 2191 (1999).
  31. V. J. Hall and G. J. Simpson, Direct observation of transient Ostwald crystallization ordering from racemic serine solutions, J. Am. Chem. Soc. 132, 13598 (2010).
  32. B. Peters, Reaction Rate Theory and Rare Events (Elsevier, Amsterdam, 2017).
  33. D. M. Sadler and G. H. Gilmer, Rate-theory model of polymer crystallization, Phys. Rev. Lett. 56, 2708 (1986).
  34. A. Okamoto, T. Kuwatani, T. Omori, and K. Hukushima, Free-energy landscape and nucleation pathway of polymorphic minerals from solution in a Potts lattice-gas model, Phys. Rev. E 92, 042130 (2015).
  35. J. S. van Duijneveldt and D. Frenkel, Computer simulation study of free energy barriers in crystal nucleation, J. Chem. Phys. 96, 4655 (1992).
  36. S. Arai and H. Tanaka, Surface-assisted single-crystal formation of charged colloids, Nat. Phys. 13, 503 (2017).
  37. E. Zaccarelli, C. Valeriani, E. Sanz, W. C. K. Poon, M. E. Cates, and P. N. Pusey, Crystallization of hard-sphere glasses, Phys. Rev. Lett. 103, 135704 (2009).
  38. H. J. Schöpe, G. Bryant, and W. Van Megen, Two-step crystallization kinetics in colloidal hard-sphere systems, Phys. Rev. Lett. 96, 175701 (2006).
  39. Y. L. Wu, D. Derks, A. van Blaaderen, and A. Imhof, Melting and crystallization of colloidal hard-sphere suspensions under shear, Proc. Natl. Acad. Sci. USA 106, 10564 (2009).
  40. S. Zang, A. W. Hauser, S. Paul, G. M. Hocky, and S. Sacanna, Enabling three-dimensional real-space analysis of ionic colloidal crystallization, Nat. Mater. 23, 1131 (2024).
  41. A. P. Hynninen and M. Dijkstra, Phase diagrams of hard-core repulsive Yukawa particles, Phys. Rev. E 68, 021407 (2003).
  42. P. M. Reis, R. A. Ingale, and M. D. Shattuck, Crystallization of a quasi-two-dimensional granular fluid, Phys. Rev. Lett. 96, 258001 (2006).
  43. K. Zahn and G. Maret, Dynamic criteria for melting in two dimensions, Phys. Rev. Lett. 85, 3656 (2000).
  44. W. Lechner and C. Dellago, Accurate determination of crystal structures based on averaged local bond order parameters, J. Chem. Phys. 129, 114707 (2008).
  45. M. Cho, G. R. Fleming, S. Saito, I. Ohmine, and R. M. Stratt, Instantaneous normal mode analysis of liquid water, J. Chem. Phys. 100, 6672 (1994).
  46. I. Ohmine and H. Tanaka, Potential energy surfaces for water dynamics. II. Vibrational mode excitations, mixing, and relaxations, J. Chem. Phys. 93, 8138 (1990).
  47. P. J. Yunker, K. Chen, Z. Zhang, W. G. Ellenbroek, A. J. Liu, and A. G. Yodh, Rotational and translational phonon modes in glasses composed of ellipsoidal particles, Phys. Rev. E 83, 011403 (2011).
  48. P. Tan, N. Xu, A. B. Schofield, and L. Xu, Understanding the low-frequency quasilocalized modes in disordered colloidal systems, Phys. Rev. Lett. 108, 095501 (2012).
  49. https://www2.ph.ed.ac.uk/∼abs/.
