Anomalous pressure dependence of the bulk modulus and Yb valence in cubic YbPd

B. Tegomo Chiogo1,*, V. Balédent2,3, J.-P. Rueff4,5, E. Saïman2, V. Poree4,6, T. Schweitzer7, D. Wong1, C. Schulz1, T. Mazet7 et al.

A. Chainani8, D. Malterre7, and K. Habicht1,9

  • *Contact author: bodry.tegomo_chiogo@helmholtz-berlin.de
PDF

Phys. Rev. Research 8, 033055 – Published 13 July, 2026

DOI: https://doi.org/10.1103/ftks-31jr

Abstract

We investigate the Yb valence instabilities in the strongly correlated YbPd compound using resonant x-ray emission spectroscopy as a function of pressure across the charge-order (CO) transition. At a low temperature (T=30K) in the CO phase, the Yb 4f valence remains nearly constant up to a pressure PL=1.5 ±0.2GPa, and then increases gradually at higher pressures. In contrast, at room temperature in the normal phase, an anomalous decrease of the Yb 4f valence is observed, without any accompanying structural phase transition. This behavior is corroborated by a systematic pressure-dependent decrease of the unit-cell volume. Based on a Birch-Murnaghan analysis, the compressibility indicates hardening of the lattice with applied pressure up to a distinct kink seen at PK=1.6 ±0.2GPa. In contrast, for P > PK, the Yb 4f valence saturates, and the compressibility reveals a counterintuitive pressure-induced softening. The results show a minimum in the compressibility of YbPd (with f0–f1 hole-type mixed valence), reminiscent of the maximum in compressibility seen in the γ–α first-order isostructural phase transition in cerium (with f0–f1 electron-type mixed valence).

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (63)

  1. H. v. Löhneysen, A. Rosch, M. Vojta, and P. Wölfle, Fermi-liquid instabilities at magnetic quantum phase transitions, Rev. Mod. Phys. 79, 1015 (2007).
  2. P. Gegenwart, Q. Si, and F. Steglich, Quantum criticality in heavy-fermion metals, Nat. Phys. 4, 186 (2008).
  3. S. Doniach, The Kondo lattice and weak antiferromagnetism, Physica B+C 91, 231 (1977).
  4. R. Pott, W. Boksch, G. Leson, B. Politt, H. Schmidt, A. Freimuth, K. Keulerz, J. Langen, G. Neumann, F. Oster, J. Röhler, U. Walter, P. Weidner, and D. Wohlleben, Magnetic order and other phase transitions in mixed-valent YbPd, Phys. Rev. Lett. 54, 481 (1985).
  5. P. Bonville, J. Hammann, J. A. Hodges, P. Imbert, and G. J. Jéhanno, Magnetic and nonmagnetic charge states in YbPd, Phys. Rev. Lett. 57, 2733 (1986).
  6. T. Hasegawa, N. Ogita, M. Sugishima, A. Mitsuda, H. Wada, and M. Udagawa, Low temperature phase of YbPd investigated by Raman scattering, J. Phys.: Conf. Ser. 273, 012030 (2011).
  7. M. Sugishima, K. Yamada, A. Mitsuda, H. Wada, K. Matsubayashi, Y. Uwatoko, K. Suga, and K. Kindo, Effects of magnetic field and pressure on the intermediate valence state of YbPd, J. Phys.: Condens. Matter 22, 375601 (2010).
  8. Y. Tokiwa, S. Grüheit, H. S. Jeevan, C. Stingl, and P. Gegenwart, Low-temperature antiferromagnetic ordering in the heavy-fermion metal YbPd, J. Phys.: Conf. Ser. 273, 012062 (2011).
  9. R. Takahashi, T. Honda, A. Miyake, T. Kagayama, K. Shimizu, T. Ebihara, T. Kimura, and Y. Wakabayashi, Valence ordering in the intermediate-valence magnet YbPd, Phys. Rev. B 88, 054109 (2013).
  10. M. Shiga, K. Okimura, H. Takata, A. Mitsuda, I. Maruyama, H. Wada, Y. Inagaki, and T. Kawae, Observation of Kondo resonance in valence-ordered YbPd, Phys. Rev. B 100, 245117 (2019).
  11. A. Mitsuda, M. Sugishima, T. Hasegawa, S. Tsutsui, M. Isobe, Y. Ueda, M. Udagawa, and H. Wada, Origins of phase transitions in valence fluctuating YbPd, J. Phys. Soc. Jpn. 82, 084712 (2013).
  12. A. Miyake, T. Kagayama, K. Shimizu, and T. Ebihara, The novel phase diagram of YbPd, J. Phys.: Conf. Ser. 391, 012045 (2012).
  13. A. Miyake, K. Kasano, T. Kagayama, K. Shimizu, R. Takahashi, Y. Wakabayashi, T. Kimura, and T. Ebihara, Interplay between charge and magnetic orderings in YbPd, J. Phys. Soc. Jpn. 82, 084706 (2013).
  14. S. Tsutsui, T. Hasegawa, A. Mitsuda, M. Sugishima, K. Oyama, M. Mizumaki, N. Ogita, H. Wada, and M. Udagawa, Lattice instability coupled with valence degrees of freedom in valence fluctuation compound YbPd, Phys. Rev. B 102, 245150 (2020).
  15. T. Jeong and Y. Kwon, Electronic and magnetic properties of a heavy fermion compound YbPd, Phys. Lett. A 362, 500 (2007).
  16. Y.-F. Liao, B. Tegomo Chiogo, T. Clausse, T. Mazet, K.-D. Tsuei, D. Malterre, and A. Chainani, Dual Kondo effect charge ordering and zero thermal expansion in a correlated intermetallic, Commun. Mater. 3, 23 (2022).
  17. M. Domke, C. Laubschat, E. V. Sampathkumaran, M. Prietsch, T. Mandel, G. Kaindl, and H. U. Middelmann, Bulk and surface valence in YbPdx compounds, Phys. Rev. B 32, 8002 (1985).
  18. C. Dallera, M. Grioni, A. Shukla, G. Vankó, J. L. Sarrao, J. P. Rueff, and D. L. Cox, New spectroscopy solves an old puzzle: The kondo scale in heavy fermions, Phys. Rev. Lett. 88, 196403 (2002).
  19. K. Kummer, Y. Kucherenko, S. Danzenbächer, C. Krellner, C. Geibel, M. G. Holder, L. V. Bekenov, T. Muro, Y. Kato, T. Kinoshita, S. Huotari, L. Simonelli, S. L. Molodtsov, C. Laubschat, and D. V. Vyalikh, Intermediate valence in Yb compounds probed by 4f photoemission and resonant inelastic x-ray scattering, Phys. Rev. B 84, 245114 (2011).
  20. K. Kummer, C. Geibel, C. Krellner, G. Zwicknagl, C. Laubschat, N. Brookes, and D. V. Vyalikh, Similar temperature scale for valence changes in Kondo lattices with different Kondo temperatures, Nat. Commun. 9, 2011 (2018).
  21. P. W. Bridgman, The compressibility and pressure coefficient of resistance of ten elements, Proc. Am. Acad. Arts Sci. 62, 207 (1927).
  22. M. J. Lipp, D. Jackson, H. Cynn, C. Aracne, W. J. Evans, and A. K. McMahan, Thermal signatures of the Kondo volume collapse in cerium, Phys. Rev. Lett. 101, 165703 (2008).
  23. M. J. Lipp, Z. Jenei, H. Cynn, Y. Kono, C. Park, C. Kenney-Benson, and W. Evans, Anomalous elastic properties across the γ to α volume collapse in cerium, Nat. Commun. 8, 1198 (2017).
  24. K. Oyama, K. Tanabe, A. Mitsuda, H. Wada, N. Hirao, S. I. Kawaguchi, Y. Ohishi, J. Gouchi, and Y. Uwatoko, Pressure-induced cubic valence fluctuating ground state in YbPd, JPS Conf. Proc. 30, 011141 (2019).
  25. J. M. Ablett, A. Berlioux, D. Prieur, J. Harrison, L. Heller, S. Gliga, and J.-P. Rueff, MULTIXS: A new scanning multi-analyzer x-ray emission spectrometer at the GALAXIES beamline at synchrotron SOLEIL, Rev. Sci. Instrum. 96, 053104 (2025).
  26. C. Prescher and V. B. Prakapenka, DIOPTAS: A program for reduction of two-dimensional X-ray diffraction data and data exploration, High Press. Res. 35, 223 (2015).
  27. D. L. Heinz and R. Jeanloz, The equation of state of the gold calibration standard, J. Appl. Phys. 55, 885 (1984).
  28. N. Tateiwa and Y. Haga, Evaluations of pressure-transmitting media for cryogenic experiments with diamond anvil cell, Rev. Sci. Instrum. 80, 123901 (2009).
  29. A. Celeste, F. Borondics, and F. Capitani, Hydrostaticity of pressure-transmitting media for high pressure infrared spectroscopy, High Press. Res. 39, 608 (2019).
  30. K. Hämäläinen, D. P. Siddons, J. B. Hastings, and L. E. Berman, Elimination of the inner-shell lifetime broadening in x-ray-absorption spectroscopy, Phys. Rev. Lett. 67, 2850 (1991).
  31. H. Yamaoka, N. Tsujii, K. Yamamoto, A. M. Vlaicu, H. Oohashi, H. Yoshikawa, T. Tochio, Y. Ito, A. Chainani, and S. Shin, Bulk sensitive spectroscopy for the valence transition in YbInCu4-based compounds, Phys. Rev. B 78, 045127 (2008).
  32. A. Kotani, Theoretical analysis of X-ray magnetic circular dichroism at the Yb L2,3 absorption edges of YbInCu4 in high magnetic fields around the field-induced valence transition, Eur. Phys. J. B 85, 31 (2012).
  33. T. Mazet, D. Malterre, M. François, C. Dallera, M. Grioni, and G. Monaco, Nonpareil Yb behavior in YbMn6Ge6−xSnx, Phys. Rev. Lett. 111, 096402 (2013).
  34. W. J. Gannon, K. Chen, M. Sundermann, F. Strigari, Y. Utsumi, K.-D. Tsuei, J.-P. Rueff, P. Bencok, A. Tanaka, A. Severing, and M. C. Aronson, Intermediate valence in single crystalline Yb2Si2Al, Phys. Rev. B 98, 075101 (2018).
  35. C. Dallera, E. Annese, J.-P. Rueff, A. Palenzona, G. Vankó, L. Braicovich, A. Shukla, and M. Grioni, Determination of pressure-induced valence changes in YbAl2 by resonant inelastic x-ray emission, Phys. Rev. B 68, 245114 (2003).
  36. A. Fernandez-Pañella, V. Balédent, D. Braithwaite, L. Paolasini, R. Verbeni, G. Lapertot, and J.-P. Rueff, Valence instability of YbCu2Si2 through its magnetic quantum critical point, Phys. Rev. B 86, 125104 (2012).
  37. H. Sato, H. Yamaoka, Y. Utsumi, H. Nagata, M. A. Avila, R. A. Ribeiro, K. Umeo, T. Takabatake, Y. Zekko, J. Mizuki, J.-F. Lin, N. Hiraoka, H. Ishii, K.-D. Tsuei, H. Namatame, and M. Taniguchi, Pressure-induced valence change of YbNiGe3 investigated by resonant x-ray emission spectroscopy at the Yb L3 edge, Phys. Rev. B 89, 045112 (2014).
  38. K. Matsubayashi, T. Hirayama, T. Yamashita, S. Ohara, N. Kawamura, M. Mizumaki, N. Ishimatsu, S. Watanabe, K. Kitagawa, and Y. Uwatoko, Pressure-induced valence crossover and novel metamagnetic behavior near the antiferromagnetic quantum phase transition of YbNi3Ga9, Phys. Rev. Lett. 114, 086401 (2015).
  39. T. Mazet, D. Malterre, M. François, L. Eichenberger, M. Grioni, C. Dallera, and G. Monaco, Composition and temperature dependence of the Yb valence in YbMn6Ge6−xSnx studied by RIXS, Phys. Rev. B 92, 075105 (2015).
  40. L. Eichenberger, A. Magnette, D. Malterre, R. Sibille, F. Baudelet, L. Nataf, and T. Mazet, Possible room-temperature signatures of unconventional 4f-electron quantum criticality in YbMn6Ge6−xSnx, Phys. Rev. B 101, 020408(R) (2020).
  41. L. Eichenberger, M. François, D. Malterre, R. Sibille, N. P. M. Casati, L. Nataf, F. Baudelet, and T. Mazet, Pressure-induced Yb valence transition and magnetism in YbMn6Ge6−xSnx, Phys. Rev. B 107, 205146 (2023).
  42. B. Tegomo Chiogo, N. P. Martin, L. V. B. Diop, B. Malaman, D. Malterre, F. Baudelet, L. Nataf, and T. Mazet, Temperature and pressure dependence of the Yb valence state in YbMn0.17Si1.89, J. Appl. Phys. 132, 205902 (2022).
  43. F. Frontini, B. W. Lebert, K. K. Cho, M. S. Song, B. K. Cho, C. J. Pollock, and Y.-J. Kim, Intermediate valence state in YbB4 revealed by resonant x-ray emission spectroscopy, J. Phys.: Condens. Matter 34, 345601 (2022).
  44. K. Imura, Y. Yoneyama, H. Ando, N. Kabeya, H. Yamaoka, N. Hiraoka, H. Ishii, T. Ishimasa, and N. K. Sato, Variation of pressure-induced valence transition with approximation degree in Yb-based quasicrystalline approximants, J. Phys. Soc. Jpn. 92, 093701 (2023).
  45. H. Yamaoka, N. Tsujii, M.-T. Suzuki, Y. Yamamoto, I. Jarrige, H. Sato, J.-F. Lin, T. Mito, J. Mizuki, H. Sakurai, et al., Pressure-induced anomalous valence crossover in cubic YbCu5-based compounds, Sci. Rep. 7, 5846 (2017).
  46. H. Yamaoka, N. Tsujii, Y. Yamamoto, Y. Michiue, J.-F. Lin, N. Hiraoka, H. Ishii, K.-D. Tsuei, and J. Mizuki, Reentrant valence transition in YbCu4.5 under pressure, Phys. Rev. B 97, 085106 (2018).
  47. H. Yamaoka, A. Ohmura, N. Tsujii, H. Ishii, N. Hiraoka, H. Sato, and M. Sawada, Pressure-induced large valence transitions in Yb-Cu binary intermetallic systems, Phys. Rev. B 109, 155147 (2024).
  48. A. V. Goltsev and M. M. Abd-Elmeguid, Origin of the pressure dependence of the Kondo temperature in Ce- and Yb-based heavy-fermion compounds, J. Phys.: Condens. Matter 17, S813 (2005).
  49. H. M. Ledbetter and R. P. Reed, Elastic properties of metals and alloys, I. iron, nickel, and iron‐nickel alloys, J. Phys. Chem. Ref. Data 2, 531 (1973).
  50. F. Birch, Finite Elastic Strain of Cubic Crystals, Phys. Rev. 71, 809 (1947).
  51. O. B. Tsiok, V. V. Brazhkin, A. G. Lyapin, and L. G. Khvostantsev, Logarithmic kinetics of the amorphous-amorphous transformations in SiO2 and GeO2 glasses under high pressure, Phys. Rev. Lett. 80, 999 (1998).
  52. F. R. Drymiotis, H. Ledbetter, J. B. Betts, T. Kimura, J. C. Lashley, A. Migliori, A. P. Ramirez, G. R. Kowach, and J. Van Duijn, Monocrystal elastic constants of the negative-thermal-expansion compound zirconium tungstate (ZrW2O8), Phys. Rev. Lett. 93, 025502 (2004).
  53. C. Pantea, A. Migliori, P. B. Littlewood, Y. Zhao, H. Ledbetter, J. C. Lashley, T. Kimura, J. Van Duijn, and G. R. Kowach, Pressure-induced elastic softening of monocrystalline zirconium tungstate at 300K, Phys. Rev. B 73, 214118 (2006).
  54. H. Fang and M. T. Dove, Pressure-induced softening as a common feature of framework structures with negative thermal expansion, Phys. Rev. B 87, 214109 (2013).
  55. H. Fang, A. E. Phillips, M. T. Dove, M. G. Tucker, and A. L. Goodwin, Temperature-dependent pressure-induced softening in Zn(CN)2, Phys. Rev. B 88, 144103 (2013).
  56. H. Fang, M. T. Dove, and A. E. Phillips, Common origin of negative thermal expansion and other exotic properties in ceramic and hybrid materials, Phys. Rev. B 89, 214103 (2014).
  57. A. B. Cairns and A. L. Goodwin, Negative linear compressibility, Phys. Chem. Chem. Phys. 17, 20449 (2015).
  58. Z. Wei, L. Tan, G. Cai, A. E. Phillips, I. da Silva, M. G. Kibble, and M. T. Dove, Colossal pressure-induced softening in scandium fluoride, Phys. Rev. Lett. 124, 255502 (2020).
  59. I.-K. Jeong, T. W. Darling, M. J. Graf, T. Proffen, R. H. Heffner, Y. Lee, T. Vogt, and J. D. Jorgensen, Role of the lattice in the γ→α phase transition of Ce: A high-pressure neutron and x-ray diffraction study, Phys. Rev. Lett. 92, 105702 (2004).
  60. F. Decremps, L. Belhadi, D. L. Farber, K. T. Moore, F. Occelli, M. Gauthier, A. Polian, D. Antonangeli, C. M. Aracne-Ruddle, and B. Amadon, Diffusionless γ⇄α phase transition in polycrystalline and single-crystal cerium, Phys. Rev. Lett. 106, 065701 (2011).
  61. J. W. Allen and R. M. Martin, Kondo volume collapse and the γ→α transition in cerium, Phys. Rev. Lett. 49, 1106 (1982).
  62. M. Lavagna, C. Lacroix, and M. Cyrot, Volume collapse in the Kondo lattice, Phys. Lett. A 90, 210 (1982).
  63. J. W. Allen and L. Z. Liu, α−γ transition in Ce. II. A detailed analysis of the Kondo volume-collapse model, Phys. Rev. B 46, 5047 (1992).

Outline

Information

Phys. Rev. Research 8, 033055– Published 13 July, 2026
  • Received 1 February 2026
  • Accepted 4 June 2026
